display MERCEDES-BENZ C-Class 2001 W203 Comand Manual

System settings
Introduction Audio
Telephone NavigationIndex Info Services and
system settings 215
P82.85-2686-26
P82.85-3076-26
For countries with several time zones (e.g. Canada,
USA):
After you have confirmed the country, the “Timezone”
menu is activated. Highlight the zone you want with the
right-hand rotary/pushbutton
and confirm by
pressing.In the next menu, press the right-hand rotary/pushbutton
to set the menu field “Automatic S/W time”.
“Automatic S/W time” menu field - there is change of
time in this country/timezone and the dates of time
changes are known. Checkmark
indicates that
automatic time change is active.
“Summer time” menu field – the dates of time changes
are unknown, the change to the winter time must be
made manually, page 216.
Press the right-hand rotary/pushbutton
longer than 2
seconds. The settings are adopted, and the main system
menu is displayed.

System settings
Introduction Audio
Telephone NavigationIndex Info Services and
system settings 217 Selecting the time format
In the “Date/Time” menu use the right-hand rotary/
pushbutton
to highlight the “Time Format” menu
field and press to confirm.
The time format menu will appear.
Setting is activeSetting is not active12Date displayed in day, month format
13Date displayed in month, day format
14Time displayed in 24 hour format
15Time displayed in 12 hour format (AM and PM),
in the main menu for system settings and in the
“Date/Time” menu the abbreviations AM or PM are
shown after the time.
To alter the setting:
Use the right-hand rotary/pushbutton
to highlight
an entry and press to confirm (a checkmark will
appear).
You can confirm your selection in one of the following
ways:
• Hold the right-hand rotary/pushbutton
longer
than 2 seconds – this activates the main menu for
system settings
• Press
– this activates the “Date/Time” menu.
P82.85-3078-2615141312

System settings
Introduction Audio
Telephone NavigationIndex Info Services and
system settings 219 Setting changeover between day and night display
In the settings menu (page 209) highlight the menu field
“Display (Day/Night)” with the rotary pushbutton
and
confirm by pressing.
The menu “Display (Day/Night)” will appear.
Setting activeSetting not activeNote:
The setting (2) is active when calling up for the first
time. A change is stored and becomes active when
COMAND is switched on again.
1Changeover of the day/night display by pressing
2Changeover of the day/night display by pressing
and headlights switch
Note:
You can change over between day display, night display
and screen switched off by repeatedly pressing
.
Press
again to switch on the screen.
If the setting (2) is selected the night display is
automatically switched on together with the headlights.
It is possible to change over to the day display by
pressing
.
P82.85-3080-26

220 System settings
Audio Introduction
Telephone Navigation IndexInfo Services and
system settings
Reset all settings to the factory settings
Use the right-hand rotary/pushbutton
to highlight the
“Factory settings” menu field in the settings menu and
press to confirm.
An inquiry menu will appear.To accept the factory settings:
Press the right-hand rotary/pushbutton
confirm the
“Yes” menu field). A screen with the factory settings is
shown for a few seconds. The main menu for system
settings is reactivated.
The factory settigs are:
• Acknowledgement beep - off
• Info beep – off
• Language – English (imp.)
• Time display – AM/PM
• Date display – MM.DD (MM – month, DD – day)
If you do not wish to reset settings:
Use the right-hand rotary/pushbutton to highlight
“No” and press to confirm. This activates the main menu
for system settings.
P82.85-3081-26

Index223
AAccepting a call (using the multifunction
steering wheel) .................................................................. 88
Accepting calls using COMAND ..................................... 89
Activating the location map ........................................... 167
Activating the route map ............................................... 166
Acknowledgement beep .................................................... 15
Adjusting the brightness ............................................... 208
Adjusting the volume ........................................................ 14
Alarm beep ......................................................................... 14
Altering the map scale ........................................... 152, 179
Altering the voice output volume ................................ 173
AM (Ante Meridiem) ....................................................... 217
Audio sources .................................................................... 69
Automatic Station Scan ................................................... 28
Auxiliary audio source, Switching on/off ................... 221BBeep tones, Switching on/off ......................................... 218
CCalibration ....................................................................... 201
Canceling route guidance .............................................. 192
CD changer ........................................................................ 45
CD, Loading into the CD drive ........................................ 44
CDs scan ............................................................................. 62
CD track scan .................................................................... 56
CD playback ....................................................................... 43
Changing to map display during route guidance ...... 177
City list ............................................................................. 143
COMAND (Cockpit Management and Data System) ...... 2
Compass needle .............................................................. 180
Cross hairs ....................................................................... 150
Current map scale .................................................. 152, 166
Current vehicle position ......................................... 167, 170DDate and Time, Setting .................................................... 211
Day/Night display ............................................................ 219
Delete CD name ................................................................. 59
Destination address, Entering ....................................... 141
Destination memory, Sorting ........................................ 208
Destination, Selecting via the map .............................. 149

Index224
Destination, Reaching your ........................................... 189
Destination, Saving in the memory ............................. 205
Deviating from the calculated route ............................ 189
Dialing a number from the phone book ........................ 95
Displaying the route list ................................................ 165
Distance bar ..................................................................... 163
EEmergency call ................................................................. 107
Entering CD names .......................................................... 57
Entering destination address ........................................ 139
Entering the house number .......................................... 148
Entering the station frequency in the presets ............. 37FFactory settings ............................................................... 220
FM, AM ............................................................................... 23
Frequency ranges ....................................................... 23, 27
Fast forward/rewinding ................................................... 55
GGeographical latitude and longitude of your
current position ............................................................... 167
GPS reception, set the time ............................................ 213
GPS-signals ...................................................................... 132HHeading-up ...................................................................... 180
House numbers, Entering ............................................. 148IInformation/status line .................................................... 12
Increase the map scale .......................................... 152, 179
Info beep .................................................................... 14, 218LLast destination, Activating .......................................... 158
List of languages .............................................................. 210
Lists ...................................................................................... 12

Index225
MMap display ..................................................................... 166
Map orientation, Selecting ............................................ 180
Map scale, Current ................................................. 152, 179
Map scale, Reduce .................................................. 152, 179
Map scale, Increasing ............................................ 152, 179
Menus .................................................................................. 12
Message “Activating Navigation.
Please obey all traffic rules!” ................................ 136, 137
Message “Attention, name memory is full;
new entry only possible after cleaning an old one!” .. 58
Message “Being activated” .............................................. 63
Message “CALC. ROUTE” .............................................. 163
Message “Caution. Please turn on ignition.
Otherwise system will shut down in 3 minutes” ......... 15
Message “Caution. Please turn on ignition.
Otherwise system will shut down in 10 seconds” ........ 15
Message “Caution. The system will shut down.” .......... 15
Message “CD changer: No CD” ....................................... 54
Message “CD loading” ................................................ 50, 54
Message “CD-Reading error. Please change CD” ........ 137
Message “Cellular System Busy” ................................. 205
Message “Compiling Route List” .................................. 165Message “Data Connection Cannot
be Established” ............................................................... 205
Message “Data transmission failure” .......................... 205
Message “DEST AREA” .................................................. 163
Message “Error” ................................................................ 64
Message “Error: Phone defective” .................................. 79
Message “Error: Phone not connected” ......................... 79
Message “Forward”, “Rewind” ........................................ 55
Message “Magazine empty” ............................................ 63
Message “Navigation cannot be activated,
an error has occured” ..................................................... 137
Message “NEW ROUTE” ........................................ 163, 189
Message “No CD. Insert navigation CD” ...................... 137
Message “No CD changer” .............................................. 63
Message “No Cellular Connection Available” ............ 205
Message “No information available at this time.
Press SVC button later.” ................................................ 205
Message “No magazine” .................................................. 63
Message “NO ROUTE” .................................................... 163
Message “No Service” ................................................ 79, 86
Message “No Service, redial?” ........................................ 79
Message “OFF MAP” ...................................................... 163
Message “OFF ROAD” .................................................... 163
Message “Reading error” ................................................. 63
Message “Ready” .............................................................. 95

Index226
Message “System busy, redial?” ............................. 79, 123
Message “Tele Aid Call in Progress!” .......................... 205
Message “Tele Aid. Please visit workshop” ................ 205
Message “Telephone is being activated.
Please wait” ....................................................................... 79
Message “Temperature too high” ................................. 764
Message “To subscribe to information services
dial phone number” ....................................................... 205
Message “Voice output is muted” ................................ 173
Mix ............................................................................ 163, 178
Mobile telephone handset ................................................ 91
Moving the cross hairs .................................................. 150
Multifunction steering wheel, multifunction
display (telephone) ........................................................... 80
Multifunction steering wheel, multifunction
display (CD) ....................................................................... 68
Multifunction steering wheel, multifunction
display (radio) ................................................................... 39
NNavigation system ........................................................... 131
Navigation CD, Changing .............................................. 138
North-up ........................................................................... 180Notebook ........................................................................... 110
Number keypad .................................................................... 8
Number of satellites received ........................................ 167
QQuick-dialing ................................................................... 109PPersonal Ser vice Number .............................................. 126
Phone book .................................................................. 95, 97
Phone book, Editing the
PM (Post Meridiem) ........................................................ 217
Points of interest ............................................................. 154
Pop-up window ................................................................... 15
Principle of route guidance ........................................... 162RRadio station frequency, Entering ................................. 37
Radio station, Selecting .................................................... 24
Radio stations, Deleting in the memory ....................... 35
Radio stations, Scanning ................................................. 28

Index227 Radio stations, Saving automatically, AM .................... 32
Radio stations, Saving manually, AM ............................. 31
Radio stations, Saving manually, FM ............................ 29
Reaching your destination ............................................ 189
Reception quality ............................................................. 187
Redial ................................................................................ 102
Reduce the map scale ............................................ 152, 179
Requesting the route mode ........................................... 169
ROAM indicator ......................................................... 85, 118
Route guidance with a mixture of map and
symbol display ................................................................ 178
Route list, Displaying ..................................................... 165
Route map, Activating .................................................... 166
Route mode, Requesting ................................................ 169
Route, Fastest .................................................................. 163
Route, Short ..................................................................... 163
SSaving stations automatically, AM ................................. 32
Saving stations manually, AM ......................................... 31
Saving stations manually, FM ........................................ 29
Saving the current destination ..................................... 195
Saving the current vehicle position .............................. 197Scale bar ................................................................... 152, 179
Selecting a destination via the map ............................ 149
Selecting a detour ........................................................... 184
Selecting an intersection ................................................ 147
Selecting a station ............................................................. 24
Selecting the route calculation mode
and calculating the route .............................................. 159
Selecting CD’s ................................................................... 53
Selecting map orientation ............................................. 180
Selecting the previous destination .............................. 158
Selecting the time format ............................................... 217
Selecting/avoiding specific traffic routes ................... 159
Service numbers ............................................................. 125
Service sources ................................................................. 69
Set the date and time ...................................................... 211
Setting Bass/Treble/Fader/Balance ............................... 72
Setting the date and time manually ............................. 216
Short route ....................................................................... 159
SMS function .................................................................... 118
SMS message, Reading an .............................................. 119
SMS message, Deleting an ............................................. 121
Sorting destination memory ......................................... 198
Sound impressions ........................................................... 69
Speed-dialing (only at COMAND) ................................. 107

Index228
Station selection via direct frequency entry ................ 27
Switching beep tones on and off ................................... 218
Switch the COMAND operating unit on and off ........... 13
Switch off screen ............................................................... 14
Switch the microphone off .............................................. 90
Switching the voice output on/off ............................... 173
Symbol display ................................................................ 166
System ................................................................................. 12TTime zones ........................................................................ 214
Track repeat ........................................................................ 61UUnlock code ....................................................................... 86VVoice output, Switching on/off ..................................... 173
Voice output “Bear left after one quarter mile” .......... 176
Voice output during route guidance ............................ 172Voice output “Please bear left” ...................................... 176
Voice output “Please turn right” .......................... 172, 174
Voice output “Prepare to bear left” ............................... 176
Voice output “Prepare to turn right” ............................ 174
Voice ouput “The route is being calculated” .............. 160
Voice output “The route to your intermediate
destination is being calculated” ................................... 182
Voice output “Turn right after one quarter mile” ...... 174
Voice output “You have reached
your destination” ............................................................ 189
Voice recognition system ........................................... 14, 69
Volume difference .............................................................. 71
WWeather band (WB) .......................................................... 23
Way point ................................................................. 169, 181ZZoom .................................................................................. 112
