navigation system MERCEDES-BENZ C-Class 2001 W203 Comand Manual

System settings
Introduction Audio
Telephone NavigationIndex Info Services and
system settings 221
P82.85-3287-26
1
Auxiliary audio source
Connecting an auxiliary audio source
We recommend that any auxiliary audio unit be
installed and connected by a Mercedes-Benz Center.
The auxiliary audio source (e.g. portable tape deck) will
be installed in the glove compartment of your vehicle
and connected to the socket available for this purpose.
You will require a separate connecting cable for this.
Refer to the separate operating instructions for infor-
mation on how to operate the auxiliary audio source
(e.g. portable tape deck).
Notes:
Traffic radio announcements and voice output during
route guidance can also be heard while the auxiliary
audio source is switched on.
The telephone can be used while the auxiliary audio
source is in operation.Switching on auxiliary audio source on/off
Turn the right-hand rotary/pushbutton
to highlight
the “Aux” menu field in the main System settings menu
and press to confirm.
1Adjusting sound settings, page 83
Note:
The values selected for the auxiliary audio source
sound are independent of those selected for the
COMAND audio sources.

222 System settings
Audio Introduction
Telephone Navigation IndexInfo Services and
system settings
When this menu is activated, the auxiliary audio
source, e.g. a tape deck, will switch on if it has been
connected to the COMAND system.
To mute the external audio source:
Press
. The symbol
will appear in the symbol
bar.
To cancel mute function, press
again.
The symbol
will disappear from the symbol bar.
To switch off the external audio source:
Press e.g. . The COMAND audio source selected
will switch on.Adjusting the volume level of an auxiliary audio source.
• Adjust volume of vehicle radio to a comfortable
listening level.
• Connect adapter cable to portable tape deck and to
vehicle ( socket in glove box).
• Press “SVC” button on COMAND unit.
• Select “AUX:” setting on COMAND unit.
• Press play on portable tape deck.
• Adjust the volume on the portable tape deck so that
the audio system output is at or near the same
comfortable level previously set in radio mode.
• Volume can now be adjusted using either COMAND
or volume controls on multifunction steering wheel.
Note:
Only the volume setting of the tape player can be
controlled using the COMAND system.

Index225
MMap display ..................................................................... 166
Map orientation, Selecting ............................................ 180
Map scale, Current ................................................. 152, 179
Map scale, Reduce .................................................. 152, 179
Map scale, Increasing ............................................ 152, 179
Menus .................................................................................. 12
Message “Activating Navigation.
Please obey all traffic rules!” ................................ 136, 137
Message “Attention, name memory is full;
new entry only possible after cleaning an old one!” .. 58
Message “Being activated” .............................................. 63
Message “CALC. ROUTE” .............................................. 163
Message “Caution. Please turn on ignition.
Otherwise system will shut down in 3 minutes” ......... 15
Message “Caution. Please turn on ignition.
Otherwise system will shut down in 10 seconds” ........ 15
Message “Caution. The system will shut down.” .......... 15
Message “CD changer: No CD” ....................................... 54
Message “CD loading” ................................................ 50, 54
Message “CD-Reading error. Please change CD” ........ 137
Message “Cellular System Busy” ................................. 205
Message “Compiling Route List” .................................. 165Message “Data Connection Cannot
be Established” ............................................................... 205
Message “Data transmission failure” .......................... 205
Message “DEST AREA” .................................................. 163
Message “Error” ................................................................ 64
Message “Error: Phone defective” .................................. 79
Message “Error: Phone not connected” ......................... 79
Message “Forward”, “Rewind” ........................................ 55
Message “Magazine empty” ............................................ 63
Message “Navigation cannot be activated,
an error has occured” ..................................................... 137
Message “NEW ROUTE” ........................................ 163, 189
Message “No CD. Insert navigation CD” ...................... 137
Message “No CD changer” .............................................. 63
Message “No Cellular Connection Available” ............ 205
Message “No information available at this time.
Press SVC button later.” ................................................ 205
Message “No magazine” .................................................. 63
Message “NO ROUTE” .................................................... 163
Message “No Service” ................................................ 79, 86
Message “No Service, redial?” ........................................ 79
Message “OFF MAP” ...................................................... 163
Message “OFF ROAD” .................................................... 163
Message “Reading error” ................................................. 63
Message “Ready” .............................................................. 95

Index226
Message “System busy, redial?” ............................. 79, 123
Message “Tele Aid Call in Progress!” .......................... 205
Message “Tele Aid. Please visit workshop” ................ 205
Message “Telephone is being activated.
Please wait” ....................................................................... 79
Message “Temperature too high” ................................. 764
Message “To subscribe to information services
dial phone number” ....................................................... 205
Message “Voice output is muted” ................................ 173
Mix ............................................................................ 163, 178
Mobile telephone handset ................................................ 91
Moving the cross hairs .................................................. 150
Multifunction steering wheel, multifunction
display (telephone) ........................................................... 80
Multifunction steering wheel, multifunction
display (CD) ....................................................................... 68
Multifunction steering wheel, multifunction
display (radio) ................................................................... 39
NNavigation system ........................................................... 131
Navigation CD, Changing .............................................. 138
North-up ........................................................................... 180Notebook ........................................................................... 110
Number keypad .................................................................... 8
Number of satellites received ........................................ 167
QQuick-dialing ................................................................... 109PPersonal Ser vice Number .............................................. 126
Phone book .................................................................. 95, 97
Phone book, Editing the
PM (Post Meridiem) ........................................................ 217
Points of interest ............................................................. 154
Pop-up window ................................................................... 15
Principle of route guidance ........................................... 162RRadio station frequency, Entering ................................. 37
Radio station, Selecting .................................................... 24
Radio stations, Deleting in the memory ....................... 35
Radio stations, Scanning ................................................. 28
