MERCEDES-BENZ C-Class 2005 W203 Comand Manual

141 Navigation
POIs (Points of Interest)

Press c.
The full view of the map will appear.
Your current position and the special
destinations are indicated by symbols.

Press any soft key.
The soft key displays will appear.

If required, move the map pushing the
joystick to H, h, g, G,F or
f.

Press the
POIs
soft key.
One of the POI is spotlighted. The name
belonging to it is shown on the status
bar.

Use the
Next
or
Prev.
soft key
to select the desired POI.

Press the
Details
soft key if required.
Details on the POI selected are shown.

Press E.
The Start route guidance menu will
appear (
page 115).
Selecting a POI on the mapiYou can define which symbols will be
shown on the map (
page 129).

142 NavigationPOIs (Points of Interest)If a phone number is associated with a POI,
the number can be used to select a
destination and making a call. The
database uses phone numbers in the USA
and Canada.
Activating the Navigation main menu
(page 96).

Push the joystick to G to select menu
item
Phone number
.

Press E.
The
Enter POI phone number menu will
appear.

Use the number keys 1 through 0
to enter the phone number.
or

Push the joystick to h, H, g or
G to select the numbers. After each
selection, press E.

Push the joystick to F or f to
select numbers diagonally.
When the number is complete, the (
field is highlighted.

Press E.
The Start route guidance menu will
appear (
page 115).
Entering a POI by phone numberiThe menu always appears with the “1”
prefix in first line.
iNumbers not available for entry are
greyed out.
iMultiple matches to a phone number
can occur if several businesses share a
number, or if a central number is used
to cover multiple locations. In these
cases, you will see a list to choose
among them.

143 Navigation
POIs (Points of Interest)
Dialing the POI phone number*
Press the
Call
soft key in the Route
guidance menu.
Dialing will begin. In the status bar, the
off-hook symbol will appear. If the
person called answers the call, the call
is active. You talk over the hands-free
set.

Press K to end the call.iThe
Call
soft key is visible if vehicle is
equipped for phone operation and
Mercedes-Benz specified mobile
telephone* is inserted in phone
cradle*.

144 NavigationToday’s plan

Today’s planThe today’s plan memory can be used to
save destinations for which routes can be
calculated one after the other.
The memory can save a maximum of 18
destinations.
You can add a destination to today’s plan
from the Route guidance menu

from the Last destinations memory and

from the Destination memory.

Press the
Plan
soft key in the
corresponding menu.
The message The

145 Navigation
Today’s plan
Available soft keys
Bestway
soft key:
Sortes entries to obtain the most
efficient route through all the
destinations (
page 145).

Rnd trip
soft key:
Sortes entries to obtain a route that
circles through all the destinations and
eventually ends at the starting position
(
page 145).

Del. all
soft key:
Deletes all entries.

Save
soft key:
Saves an entry to the destination
memory.

Details
soft key:
Shows the entry in full.

Page
V and
Page
v soft keys (if
available):
Use the
Page
V and
Page
v soft keys
to display the next or previous page.

Back
soft key:
Returns you to the previous menu.Best way

Press the
Bestway
soft key in the
today’s plan memory.
The today’s plan memory is sorted to
obtain the most efficient route through
all the destinations.
Round trip

Press the
Rnd trip
soft key in the
today’s plan memory.
The today’s plan memory is sorted to
obtain a route that circles through all
the destinations. The current vehicle location is placed
at the bottom of today’s plan as
Starting position
entry.
iThe Starting position can be represen-
ted by e.g. a parking lot or an off road
location.

146 NavigationToday’s planDisplay details for starting position
Push the joystick to G to select Starting position
.

Press the
Details
soft key.
The address information will appear.
Selecting a destination from the
today’s plan

Activate the today’s plan.

Push the joystick to G or g to
select an entry.

Use the
Page
soft keys to scroll page-
wise through the list (if available).

Press E.
The Start route guidance menu will
appear (
page 115).Saving a today’s plan entry in the
destination memory

Activate the today’s plan.

Press the
Save
soft key.
The Destination memory input menu
will appear (
page 135).
Deleting a today’s plan entry

Activate the today’s plan.

Push the joystick to G or g to
select an entry.

Press the
Delete
soft key.
A prompt message will appear.

Push the joystick to H to select
Yes
.
If you do not want to delete the entry:

Press E to confirm
No
.

Press E.
The system deletes the destination in
the today’s plan. The entries below the
destination deleted move up by one
position.Deleting all the today’s plan entries

Activate the today’s plan.

Press the
Del.
all
soft key.
A prompt message will appear.

Push the joystick to H to select
Yes
.
If you do not want to delete the entries:

Press E to confirm
No
.

Press E.
The system deletes all the destination
entries in the today’s plan.
iWhen you reach the destination, route
guidance ends and the system deletes
the today’s plan entry.

147 Navigation
Software Updates

Software Updates

148 NavigationSoftware Updates1Ejecting DVD
2Opening/closing the display unit
3Warning message
Press EJECT to
close
You can update the system with a new
navigation DVD. The new DVD may include
new maps and/or new device software.Starting an update
DVDs are loaded and ejected at the
navigation module.

Switch the COMAND on (
page 27).Ejecting

Press l.
The display unit moves forward and
then tilts down. The DVD NAVIGATION
slot is visible.

Press the l button left of the
DVD NAVIGATION slot.
The navigation module ejects the DVD.
The message
No DVD in drive.
Please insert Navigation DVD.

will appear.

Remove the DVD from the slot.
Warning
G
The display unit can cause injury if
contacted when open. Please close after
inserting a navigation DVD. !Do not place anything on the lowered
display panel. Placing objects on the
lowered display panel may result in
damage to the display or COMAND
unit which is not covered by the
Mercedes-Benz Limited Warranty.
iUpdating may take several minutes.
During updating, the operation of
COMAND is restricted. You cannot
switch off the system.iThe navigation module is located
behind the display unit of the COMAND
(page 147).
iThere are two l buttons. One is on
the display unit 2. The other is located
left of the DVD NAVIGATION slot 1
behind the display.

149 Navigation
Software Updates
Loading
Insert the new navigation DVD into the
DVD slot with the label side up.
The message
Navigation is
initializing. Please wait.
will
appear.

Press l on the display unit to return
the display unit to its closed position.
The display unit tilts up and then moves
to the rear.After that, the COMAND loads the
software on the DVD.
Shortly after that, the progress bar
appears. After some time, the progress
bar reaches 100%.
The update is completed. You can now
operate the navigation system again.
iInserting a second DVD with another
DVD still loaded will cause damage to
the DVD drive which is not covered by
the Mercedes-Benz Limited Warranty.
iThe message
Press EJECT to
close
will appear. If l on the
display unit is not pressed within 20
seconds, eight successive series of two
beep tones will sound to remind you to
return the display to its closed position
by pressing l on the display unit.

150 NavigationSoftware Updates
