80 Video
DVD video
i The DVD menu is the menu stored on the
DVD itself. Its structure differs from one DVD to
another and enables specific actions or settings
to be performed.
Opening the DVD menu
In DVD video mode, if necessary dis-
play the menu system (
page 77).
Select “DVD-Video” K “DVD Func-
tions”
K “Menu”.
The DVD menu appears.
Selecting menu items from the DVD
menu
Slide qmr or omp.
To select: Press n.
The selection menu appears.
i Menu items that cannot be selected are
grayed out.
To confirm selection: Select “Select”.
COMAND will perform the action or dis-
plays a submenu represented by the
menu item selected in the DVD menu.
If necessary select from further options
in the same way.
COMAND then switches back to the
DVD menu.
i Depending on the DVD, it is possible the
menu item “Play” either has no function or no
function in certain parts of the DVD menu. This
is indicated by the 7 symbol on the display.
or
In DVD video mode, if necessary dis-
play the control menu (
page 77).
Select “Menu” K“DVD-Video” K “DVD
Functions”
Select a directional arrow to navigate
the DVD menu.
DVD menu
DVD menu

81 Video
DVD video
Stopping film or skipping to the
beginning/end of a scene
Select any menu item from the DVD
menu.
The selection menu appears.
To stop a film: Select the menu item
“Stop”.
To skip to the end of the scene: Se-
lect the menu item r.
To skip to the beginning of the
scene: Select the menu item p.
i Depending on the DVD, it is possible the
menu items p and r either have no func-
tion or no function in certain parts of the DVD
menu. This is indicated by the 7 symbol on the
display.
Switching to the next DVD menu up
Press the í button.
or
Select the corresponding menu item
from the DVD menu.
or
Select any menu item from the DVD
menu.
In the selection menu select the menu
item “Go Up”.
i Depending on the DVD, it is possible the
menu item “Go Up” either has no function or no
function in certain parts of the DVD menu. This is
indicated by the 7 symbol on the display.
Back to movie
Press the í button repeatedly until
the film is shown.
or
Select the corresponding menu item
from the DVD menu.
or
Select any menu item from the DVD
menu.
In the selection menu select the menu
item “Back (to movie)”.
i Depending on the DVD, it is possible the
menu item “Back (to movie)” either has no func-
tion or no function in certain parts of the DVD
menu.
i The function is not available for all DVDs. If
it is available, you can set the DVD menu lan-
guage, the audio language or the audio format.
The number of settings is determined by the DVD
content. The settings may also be possible in the
DVD menu (
page 80).
In DVD video mode, if necessary dis-
play the menu system (
page 77).
Select “DVD-Video” K “DVD Func-
tions”.
Select “Audio Language”.
A selection menu will appear after a
short time. The dotRin front of an en-
try indicates the currently selected lan-
guage.
To change setting: Rotate ymz or
slide qmr until the desired setting is
reached.
To save setting: Press n.
To exit menu without changes: Slide
omp.
Setting language

82 Video
DVD video
i The functions are not available for all DVDs.
The number of subtitles or camera angles is de-
termined by the DVD content. The settings may
also be possible in the DVD menu (
page 80).
In DVD video mode, if necessary dis-
play the menu system (
page 77).
Select “DVD-Video” K “DVD Func-
tions”.
Select “Subtitles” or “Camera Angle”.
In both cases, a selection menu will ap-
pear. The dotRin front of an entry in-
dicates the current setting.
To change setting: Rotate ymz or
slide qmr until the desired setting is
reached.
To save setting: Press n.
To exit menu without changes: Slide
omp.DVDs may have interactive content (e. g. a
video game).
In a video game, for example, you can con-
trol the play by selecting or triggering ac-
tions. The type and number of actions is
dependent on the DVD.
To select an action: Slide qmr or
omp.
To trigger an action: Press n.
A menu appears, the first entry
“Select” is highlighted.
Press n.
or
In DVD video mode, if necessary dis-
play the control menu (
page 77).
Select “Menu” K“DVD-Video” K “DVD
Functions”.
Select a directional arrow to select or
trigger an action.The way you can control the actions de-
pends on the DVD.
Subtitles and camera angleInteractive content

83 Telephone
General information ......................85
Activating the mobile phone ........86
Submenu overview .......................91
COMAND phone book ...................93
Call lists ..........................................97
Making calls ................................ 101
Address book .............................. 104

84 Telephone
Safety Precautions
Safety Precautions
G Warning
Some jurisdictions prohibit the driver from
using a cellular telephone while driving.
Whether or not prohibited by law, for safety
reasons, the driver should not use the cellu-
lar telephone while the vehicle is in motion.
Stop the vehicle in a safe location before
placing or answering a call.
If you nonetheless choose to use the mobile
phone while driving, please use the hands-
free feature and be sure to pay attention to
the traffic situation at all times. Use the mo-
bile phone only when road, weather and traf-
fic conditions permit. Otherwise, you may
not be able to observe traffic conditions and
could endanger yourself and others.
Bear in mind that at a speed of just 30 mph
(approximately 50 km/h), your vehicle is
covering a distance of 44 feet (approximate-
ly 14 m) every second.
G Warning
You and others may damag e y o u r h e a l t h d u e
to excessive electromagnetic radiation. By
using an external antenna, the possible
health risks of electromagnetic fields, which
are under discussion among the scientific
community, should be largely prevented.
G Warning
Never operate radio transmitters equipped
with a built-in or attached antenna (i.e. with-
out being connected to an external antenna)
from inside the vehicle while the engine is
running. Doing so could lead to a malfunc-
tion of the vehicle’s electronic system, pos-
sibly resulting in an accident and/or
personal injury.

85 Telephone
General information
The telephone function via the Bluetooth®
interface is available in conjunction with a
Bluetooth-enabled mobile phone.
With a suitable mobile phone, you can use
COMAND’s hands-free feature and receive
electronic business cards (vCards) via the
Bluetooth
® interface.
Further information on suitable mobile
phones and connecting Bluetooth-enabled
mobile phones to COMAND is available via
the Internet at www.mbusa.com.Interruptions to the connection may occur
if

there is inadequate GSM network cov-
erage in certain regions

you are switching from one GSM trans-
mitting/receiving station (GSM cell) to
another and there is no voice channel
available in this cell

you are using a SIM card that is not
compatible with the available network.

when using a mobile phone with “Twin-
card”, the mobile phone is simulta-
neously logged into the network with
the second SIM card.
If the mobile phone is connected with
COMAND via the Bluetooth
® interface, you
can operate the phone using the following
devices:

COMAND controller and keypad on the
COMAND control unit

Multifunction steering wheel

Voice ControlThe explanations in this section assume
that the mobile phone is connected to CO-
MAND via the Bluetooth
® interface. Excep-
tions are explicitly described.
Under the following circumstances, the
phone may not yet be useable:

If it is not yet logged into a network.
The phone will try independently to log
into a network. If no network is
available, you will not be able to make
“911” emergency calls.
If you try to make an outgoing call, the
message “No Service” appears briefly.
General information
Making calls via Bluetooth®
interface
Interruptions to the connection
while driving
Operating options
Functional restrictions

86 Telephone
Activating the mobile phone
Prerequisites for the mobile phone
For making calls using COMAND via the
Bluetooth
® interface, you will need a Blue-
tooth-enabled mobile phone.
i Not all mobile phones available on the mar-
ket are comparably suitable. Further information
on suitable mobile phones and connecting Blue-
tooth-enabled mobile phones to COMAND is
available via the Internet at www.mbusa.com.
Activating Bluetooth®
Before you begin activation of your mobile
phone connection via the Bluetooth® inter-
face please ensure it is compatible with
Bluetooth
® handsfree profile 1.0
(
mobile phone operating guide)
Switch on the mobile phone and enter
the PIN, if applicable (
mobile phone
operating guide).
Activate Bluetooth® connection on the
mobile phone (
mobile phone operat-
ing guide).
i On certain mobile phones, not only do you
have to activate the Bluetooth® function but the
device must also be made “visible” for other de-
vices.
Each Bluetooth
® device has a Bluetooth® device
name. It is recommended to give the device a
personal name, by which you can clearly recog-
nize your mobile phone.
i If the Bluetooth function on the
COMAND is switched off, the message “Blue-
tooth not activated in system settings.” appears.
Activate Bluetooth® connection on
COMAND (
page 169).
Registering a mobile phone
(authorizing)
When you use your mobile phone in con-
junction with COMAND for the first time,
you must register (authorize) it.
It is possible to register several mobile
phones. The connection is always estab-
lished to the mobile phone that was acti-
vated last. When you authorize a new
mobile phone, it is activated automatically.
You can switch between the authorized
mobile phones (
page 88).Searching for a mobile phone
In the phone submenu select “Phone”
K “Phone List” K “Update”.
COMAND searches for suitable Blue-
tooth
® phones within range and enters
them in the phone list.
i The duration of the search procedure de-
pends on the number and type of Bluetooth®
phones. The search may take a few minutes.
When first entering the device list and be-
fore running an update, the black
dotRindicates the active phone (found
and authorized).
After running an update:
Phone icons 3 indicate if a phone is found
(black) or not (grey).
Activating the mobile phone
Mobile phone with Bluetooth® inter-
face

87 Telephone
Activating the mobile phone
The check marks 1 indicate if a phone
has been authorized (black) or not (grey).
If a phone is not in the vehicle but has been
authorized previously, the phone symbol
and the check mark are grey 2.
i If the device list already contains ten autho-
rized devices, you must de-authorize one of the
authorized devices (
page 88). You will then
have to switch this device off and start the
search again. Otherwise the new device you are
looking for will not appear in the list.
To start search again:
Select “Update”.
Entering passcode
Select the as yet unauthorized device
(no check mark yet) from the list.
Select “Options” K “Authorize” or
Press n.
The input menu for the passcode ap-
pears.
i The passcode is any number chosen by you
between one and sixteen digits in length. We rec-
ommend to use at least four digits because this
improves the quality of the encryption during
connection. The passcode can differ during each
authorization for each device. You must enter
the same number on COMAND and on the device
to be authorized. Please also refer to the instruc-
tions in the mobile phone operating guide.
To enter from COMAND: Select the
digits in the menu bar one after the oth-
er.
To correct entry: Select õ.
To cancel entry: Select “Back”.
To confirm entry: Select B.If a Bluetooth
® connection is established
successfully, you will be prompted to enter
a code on the mobile phone (
mobile
phone operating guide).
Enter the same passcode on the mobile
phone as you did on COMAND.
The device is authorized. You can now
make calls via COMAND’s hands-free
device using the authorized
mobile phone.
External authorization
If COMAND cannot find your mobile phone,
this may be due to special security settings
on your mobile phone. In this case, you can
check whether, conversely, your mobile
phone can find COMAND.


88 Telephone
Activating the mobile phone
COMAND’s Bluetooth® device name is
“MB Bluetooth”.
In the phone submenu select “Phone”
K “Phone List” K “Update” K
“Options”
K “External Authorization”.
Start Bluetooth® search procedure on
the mobile phone (
mobile phone op-
erating guide).
Select COMAND (“MB Bluetooth”) from
the device list on your mobile phone.
When prompted to do so, enter the
passcode on the mobile phone and on
COMAND.
Displaying details on a mobile phone
In the phone submenu select “Phone”
K “Phone List”.
Select the mobile phone from the list.
Select “Options” K “Details”.
The details screen for the device is dis-
played.
To close details screen: Rotate ymz,
slide qmr or omp or press n.Deregistering (de-authorizing) a mobile
phone
In the phone submenu select “Phone”
K “Phone List”.
Select the authorized mobile phone.
Select “Options” K “De-Authorize”.
You will be asked whether the device
should really be de-authorized.
Select “Yes” or “No”.
If you select “Yes”, the authorization of
the device is withdrawn.
i If the authorization of a device, which had
been authorized in the past, has been withdrawn
and it is no longer found in the search, the device
list no longer includes this device.
Activating another mobile phone
If you have authorized several mobile
phones, you can switch between the indi-
vidual mobile phones.
When you authorize a new mobile phone, it
is activated automatically. Only one mobile
phone is active at a time.
Select “Phone” K “Phone List”.
Select the mobile phone from the list.
Press n.
The selected mobile phone is activated
if the selected mobile is within recep-
tion range and its Bluetooth
® function
is switched on. Any previously activat-
ed phone is deactivated.
Receiving business cards
You can import business cards (vCards)
into the address book from external Blue-
tooth
® devices. Please note the following:

Bluetooth® must be activated
(
page 169)
i If the “Bluetooth” function on the
COMAND is switched off, the message “Blue-
tooth not activated in system settings.” appears.

89 Telephone
Activating the mobile phone

The external device can send vCards
via Bluetooth®.

The external device in the vehicle is
switched on and authorized
(
page 86).
If the phone main menu is displayed se-
lect “Phone”
K “Receive Business
Cards”.
or
If the address book is displayed, select
“Address Book”
K “Receive Business
Cards”.
To import: Start the data transfer on
the external device (
operating guide
for the relevant device).
The COMAND imports the data for the
business cards and displays the num-
ber of business cards received.
To end reception: Press n.
or
Press the í button.
i You can also receive business cards via the
PCMCIA memory card. To do this, the business
cards must be stored in the main directory of the
PCMCIA memory card. Load PCMCIA memory
card (
page 110).
i These settings should normally not be
changed as the factory settings are matched to
most mobile phones.
i Changes may result in significant impair-
ments to the transmission quality. These set-
tings may not be changed during an active phone
call.
In the phone submenu select “Phone”
K “Phone List”.
Select an authorized mobile phone
from the list.
Select “Options” K “Reception Volu-
me” or “Transmission Volume”.
i Reception volume and Transmission only ap-
pear for authorized devices.
1Volume bar
To set the volume: Rotate ymz or
slide qmr.
The volume bar moves up or down.
To confirm selection: Press n or
slide om.
Setting transmit and receive volume
