open hood MERCEDES-BENZ C CLASS 2019 Owners Manual

1Steering wheel paddle shifters→15 6
2Combination switch→124
3DIRECT SELECT lever→154
4Multimedia system display→254
5Glovebox→105
6Start/stop button→14 5
7Climate control systems→13 9
8Control elementsforthe multimedia system→254
9Hazardwarning lights→12 5
APASSENGER AIRBAGindicator lamps→44
BStowage compartment→105
CControl panelforthe multimedia system→255
DControl knobforvolume and switchesthesound on/off
→254
ESwitchesthe multimedia system on/off→254
FRear window roller sunblind→79
GECOstart/stop function→15 2
HActiveParking Assist→211
ISetsthevehicle level→19 8
JDYNAMIC SELECT switch→15 3
KControl panelforthe multimedia system(steering wheel)
→227
LAdjuststhesteering wheel→101
MControl panelforthe on-board computer→227
Operates cruise control→182
OperatesActive Distance AssistDISTRONIC→185
NDiagnostics connection→25
OOpensthe hood→352
PElectric parking brake→16 8
QLight switch→12 2
RControl panelfor:
ActiveSteering Assist→191
Active LaneKeeping Assist→224
Ataglance – Cockpit7

ProblemPossible causes/consequences andPPSolutions
Vehicles without a panoramic slid‐ing sunroof:The sliding sunroof doesnot operate smoothly.
PushtheWbutton uptothe point ofresistance untilthe sliding sunroof is fully open.
PresstheWbuttonfor another second.
Closethe sliding sunroof.
Vehicles with a panoramic slidingsunroof:The sliding sunroof ortheroller sunblind does not operatesmoothly.
Pulland holdtheWbutton littlebylittle untilthe sliding sunroof is fully closed.
Pull and holdtheWbutton littlebylittle untiltheroller sunblind is fully closed.
Use automatic operationtofully open andthen closethe sliding sunroof.
Anti-theft protection
Function ofthe immobilizer
The immobilizer preventsyourvehicle from beingstarted withoutthe correct SmartKey.
The immobilizer is automatically activated whenthe ignition is switched off and deactivated whenthe ignition is switched on.
When leavingthevehicle, alwaystakethe Smart‐Key withyou and lockthevehicle. Anyone canstartthe engine if avalid SmartKeyhas been leftinsidethevehicle.
Intheeventthe engine cannotbestarted(yetthevehicle’sstarter battery ischarged),the system is not operational. Contact anauthorized Mercedes-Benz Center or call1-800-FOR-MERCedes (inthe USA) or1-800-387-0100(in Canada).
ATA(anti-theft alarmsystem)
Function oftheATAsystem
IftheATAsystem is armed, a visual and audiblealarm is triggered inthefollowing situations:
Rwhen a door is opened
Rwhenthe trunk lid is opened
Rwhenthe hood is opened
TheATAsystem is armed automatically afterapproximatelyten seconds inthefollowing situa‐tions:
Rafter lockingthevehicle withthe SmartKey
Rafter lockingthevehicle using KEYLESS-GO
88Opening and closing

Toremove:using a suitable object, turn twomounts1of cover2in an counter-clock‐wise direction asfar astheywill go.
Removethe unlocked cover2fromthewheel archlinerbypulling it upwards.
Toinstall:insert cover2at bottom ofthewheel archliner.
Using a suitable object, turnthe two mounts1ofthe cover2in clockwise direction asfar astheywill go.
Replacing bulbs in the halogen headlamp
RequirementsThe lighting system is switched off.
Low beam/high beam:
RA H7 55 W light bulb isavailable.
RThe hood is open.
Turnsignal lights:
RA PWY24W light bulb isavailable.
RThe cover inthe front wheel archhas beenremoved.
1Low-beam headlamps
2High beam
3Turnsignals
Turntherelevant housing cover1–3coun‐ter-clockwise andremoveit.
Low beam / high beam:turnthe socketcounter-clockwise andremoveit.
Indicator:turnthe socket counter-clockwise,release it andremoveit.
Pullthe bulb out ofthe socket.
Insertthe new bulb intothe socket suchthatthe entire base ofthe bulb isresting onthebottom ofthe socket.
Insertthe socket and turn it clockwise.
Press onthe housing cover and turn it clock‐wise.
Turnsignal lights:installthe cover inthefront wheel arch.
Changingtherear bulbs (vehicles withhalo‐gen headlamps)
Opening and closingthe side trim panels inthe trunk
Toopen:releaseright-hand or left-hand sidetrim panels1atthetop andremove.
Toclose:re-insert side trim panel1.
13 0Light and visibility

Ensurethefollowing beforestartingthe engine:
RThe legalstipulations inthe area whereyourvehicle is parked allow enginestarting viasmartphone.
RIt is safetostart andrunthe engine whereyourvehicle is parked.
RThe fueltank is sufficientlyfilled.
Startingthevehicle
\nWARNINGRisk of crushing or entrap‐ment duetounintentionalstarting oftheengine
Limbs could be crushed or trapped iftheengine isstarted unintentionally duringservice or maintenancework.
Always securethe engine against unin‐tentionalstarting before carrying outmaintenance orrepairwork.
Requirements:RParkposition]is selected.
RThe anti-theft alarm system is not activated.
RThe panic alarm is not activated.
RThe hazardwarning lights are switched off.
RThe hood is closed.
RThe doors are closed and locked.
RThe windowsand sliding sunroof are closed.
Startthevehicle usingthe smartphone:RAftereveryvehiclestart,the enginerunsforten minutes.
RYou can carryout a maximum of two consec‐utivestarting attempts. Thevehicle must bestarted once withthe SmartKeybefore tryingtostartthevehicle again withthe smart‐phone.
RYou canstopthevehicle again at any time.
RFurther information can befound inthesmartphone app.
Securingthe engine againststarting beforecarrying out maintenance orrepairwork:Switch onthe hazardwarning lights.
or
Unlockthe doors.
or
Open a side window orthe sliding sunroof.
Breaking-in notes
Mercedes-AMGvehicles:observethe notes inthe Supplement. Otherwise,you mayfailtorec‐ognize dangers.
Topreservethe engine duringthefirst1,000 miles (1,500 km):
RDrive atvaryingroad speeds and enginespeeds.
RDrivethevehicle in drive programAor;.
RChangegear beforethetachometer needle is

The segments on speedometer1indicatethesystemstatusforthefollowing:
RCruise control (page181)
RActive Distance AssistDISTRONIC(page183)
NOTEEngine damageduetoexcessivelyhigh engine speeds
The engine will be damaged ifyou drive withthe engine intheoverrevvingrange.
Do not drive with the engine intheover‐revvingrange.
The fuel supply is interruptedtoprotecttheengine whenthered mark ontachometer3(overrevvingrange) isreached.
During normal operating conditions, coolanttemperature display4mayrisetotheredmark.
\nWARNINGDanger of burns when open‐ingthe hood
Ifyou openthe hood whenthe engine hasoverheated or during afireinthe enginecompartment,you could come into contactwith hotgases orother escaping operatingfluids.
Before openingthe hood, allowtheenginetocool down.
Intheevent of afireinthe engine com‐partment,keepthe hood closed andcallthefireservice.
Overview ofthe buttons onthesteeringwheel
1¤Back/Home button (press and hold),on-board computer
2Touch Control, on-board computer
3Control panelfor cruise control orActiveDistance AssistDISTRONIC
4Control panelfor multimedia system:
£Voice Control System
ßDisplaysfavorites
VOL: control knob, adjuststhevolume orswitchesthe sound offc(press)
aMakes/accepts a call
Instrument Display and on-board computer227

Rfrequent operation in mountainousterrain oron poorroad surfaces
Rwhenthe engine is often leftidlingfor longperiods
Roperation in particularly dusty conditionsand/or if air-recirculation mode is frequentlyused
Inthese or similar operating conditions, havetheinterior airfilter, engine air cleaner, engine oiland oilfilteretc.changed more frequently. Thetires must bechecked more frequently ifthevehicle is operated under increased loads.Fur‐ther information can be obtained at aqualifiedspecialistworkshop.
Battery disconnection periods
The ASSYST PLUS service interval displaycan only calculatethe service due datewhenthe batteryis connected.
Notedownthe service due date displayed onthe instrument display before disconnectingthe battery (page 351).
Engine compartment
Opening/closingthe hood
\nWARNINGRisk of accident ifthe enginehood is unlatched while driving
An unlocked engine hood may open up whenthevehicle is in motion and blockyour view.
Never unlatchthe engine hood whiledriving.
Beforeevery trip, ensurethattheengine hood is latched.
\nWARNINGRisk of accident and injurywhen opening and closingthe enginehood
When opening or closingthe engine hood, itmay suddenly drop intothe end position.
There is arisk of injuryfor anyone intheengine hood'srange of movement.
Only open or closethe engine hoodwhenthere are no persons intheengine hood'srange of movement.
\nWARNINGDanger of burns when open‐ingthe hood
Ifyou openthe hood whenthe engine hasoverheated or during afireinthe enginecompartment,you could come into contactwith hotgases orother escaping operatingfluids.
Before openingthe hood, allowtheenginetocool down.
Intheevent of afireinthe engine com‐partment,keepthe hood closed andcallthefireservice.
\nWARNINGRisk of injuryduetomovingparts
Certain components inthe engine compart‐ment may continuetomoveor suddenlymoveagaineven afterthe ignition has beenswitched off, e.g.the coolerfan.
Makesure ofthefollowing before performingtasks inthe engine compartment:
Switchthe ignition off.
352Maintenance and care

Nevertouchthe danger zone surround‐ing moving component parts, e.g.therotation area ofthefan.
Removejewelry andwatches.
Keep items of clothing and hairawayfrom moving parts.
\nWARNINGRisk of injuryfromtouchingcomponent parts undervoltage
The ignition system andthe fuel injectionsystemworkunder highvoltage. Ifyoutouchcomponent parts which are undervoltage,you couldreceivean electric shock.
Nevertouch component parts oftheignition system orthe fuel injection sys‐tem whenthe ignition is switched on.
\nWARNINGRisk of burns from hot com‐ponent parts inthe engine compartment
Certain components inthe engine compart‐ment can beveryhot, e.g.the engine,theradiator and parts oftheexhaust system.
Allowthe enginetocool down and onlytouch component parts described inthefollowing.
\nWARNINGRisk of injuryfrom usingthewindshield wipers whilethe engine hoodis open
Whenthe engine hood is open andthe wind‐shield wipers are set in motion,you can betrappedbythe wiper linkage.
Always switch offthe windshield wipersand ignition before openingthe enginehood.
Toopen:pull lever1toreleasethe hood.
Maintenance and care353

Push handle1ofthe hood catch upwardsand liftthe hoodbyapproximately15in(40 cm).Toclose:lowerthe hood and let itfall from aheight of approximately 8 in (20 cm).
Ifthe hood canstill be lifted slightly,openthe hood again and close it with a little moreforce until it engages correctly.
Engine oil
Checkingthe engine oil level usingthe oildipstick
\nWARNINGRisk of burns from hot com‐ponent parts inthe engine compartment
Certain components inthe engine compart‐ment can beveryhot, e.g.the engine,theradiator and parts oftheexhaust system.
Allowthe enginetocool down and onlytouch component parts described inthefollowing.
Requirements:RThe engine must havean oil dipstick.If not,the engine oil level can bechecked only withthe on-board computer (page 355).
Depending onthe engine,the oil dipstick may beinstalled inthe engine compartment in differentlocations.
Thewaiting time beforecheckingthe oil levelwhenthe engine is at normal operatingtempera‐ture isfiveminutes.
Parkthevehicle on a level surface.
Pull oil dipstick1out and wipe off.
Slowly slide oil dipstick1intothe guidetubetothestop, andtakeit out again afterapproximatelythree seconds.ROil level is correct: oil level is between2and3.
ROil leveltoo low: oil level is at3orbelow.
354Maintenance and care

Checking coolant level
\nWARNINGRisk of burns from hot com‐ponent parts inthe engine compartment
Certain components inthe engine compart‐ment can beveryhot, e.g.the engine,theradiator and parts oftheexhaust system.
Allowthe enginetocool down and onlytouch component parts described inthefollowing.
\nWARNINGDanger of burns when open‐ingthe hood
Ifyou openthe hood whenthe engine hasoverheated or during afireinthe enginecompartment,you could come into contactwith hotgases orother escaping operatingfluids.
Before openingthe hood, allowtheenginetocool down.
Intheevent of afireinthe engine com‐partment,keepthe hood closed andcallthefireservice.
\nWARNINGRisk of scalding from hotcoolant
The engine cooling system is pressurized,particularly whenthe engine iswarm. Ifyouopenthe cap,you could be scaldedbyhotcoolant spraying out.
Letthe engine cool down before open‐ingthe cap.
When openingthe cap,wear protectivegloves and safetyglasses.
Openthe cap slowlytorelease pres‐sure.
Parkthevehicle on a level surface.
Checkthe coolanttemperature display intheinstrument cluster.The coolanttemperature must be below158 °F (70 °C).
Slowly turn cap1counter-clockwisetorelieve overpressure.
Maintenance and care357

Continue turning cap1counter-clockwiseandremoveit.
The coolant level is correct:
RIfthe engine is cold, uptomarker bar2
RIfthe engine iswarm, upto0.6 in (1.5 cm)over marker bar2
If necessary,add coolantthat has beenapprovedbyMercedes-Benz.RFurther information on coolant(page 429).
Addingwasher fluidtothe windshieldwasher system
\nWARNINGRisk of burns from hot com‐ponent parts inthe engine compartment
Certain components inthe engine compart‐ment can beveryhot, e.g.the engine,theradiator and parts oftheexhaust system.
Allowthe enginetocool down and onlytouch component parts described inthefollowing.
\nWARNINGDanger of burns when open‐ingthe hood
Ifyou openthe hood whenthe engine hasoverheated or during afireinthe enginecompartment,you could come into contactwith hotgases orother escaping operatingfluids.
Before openingthe hood, allowtheenginetocool down.
Intheevent of afireinthe engine com‐partment,keepthe hood closed andcallthefireservice.
\nWARNING‑ Risk offireand injury fromwindshieldwasher concentrate
Windshieldwasher concentrate is highlyflammable. It could ignite if it comes intocontact withhot engine component parts ortheexhaust system.
Make surethat no windshieldwasherconcentrate spills out nexttothefilleropening.
Removecap1bythetab.
Addwasherfluid.
Keepingthe air-water duct free
Keepthe area betweenthe hood andthewindshield free of deposits, e.g. ice, snowand leaves.
358Maintenance and care
