Fuels, coolants, lubricants etc. - capacities
Te ch n i c a l
data
Instruments
and controls Operation Driving
Instrument
cluster display Practical hints Car care Index
Air conditioner system R-134a refrigerant and special PAG lubricant (Never R-12)
Windshield washer and
headlamp cleaning system Vehicles without headlamp
cleaning system:
Capacity approx. 3.2 US qt
(3.0 l)
Vehicles with headlamp
cleaning system:
Capacity approx. 6.4 US qt
(6.0 l)MB Windshield washer concentrate1
1 Use MB Windshield Washer Concentrate “S” and water for temperatures above freezing or MB Windshield Washer Concentrate “S” and

commercially available premixed windshield washer solvent / antifreeze for temperatures below freezing. Follow suggested mixing r atios, see
page 320.
Capacity Fuels, coolants, lubricants etc.

379
Fuels, coolants, lubricants etc. - capacities
Te ch n i c a l
data
Instruments
and controls Operation Driving
Instrument
cluster display Practical hints Car care Index
Engine oils
Engine oils are specifically tested for their suitability in
our engines. Therefore, use only engine oils
recommended by Mercedes-Benz. Information on
recommended brands is available in the Factory
Approved Service Products pamphlet, or at your
authorized Mercedes-Benz Center.
Please follow Service Booklet recommendations for
scheduled oil changes. Failure to do so could result in
engine damage not covered by the Mercedes-Benz
Limited Warranty.
Engine oil additives
Do not blend oil additives with engine oil. They may be
harmful to the engine operation.
Damage or malfunctions resulting from blending oil
additives are not covered by the Mercedes-Benz Limited
Warranty.
Air conditioner refrigerant
R-134a (HFC) refrigerant and special PAG lubricating oil
is used in the air conditioner system.
Never use R-12 (CFC) or mineral-based lubricating oil,
otherwise damage to the system will occur.
Brake fluid
During vehicle operation, the boiling point of the brake
fluid is continuously reduced through the absorption of
moisture from the atmosphere. Under extremely hard
operating conditions, this moisture content can lead to
the formation of bubbles in the system thus reducing
the system’s efficiency.
The brake fluid must therefore be replaced every two
years, preferably in the spring.
It is recommended to use only brake fluid approved by
Mercedes-Benz. Your authorized Mercedes-Benz
Center will provide you with additional information.

380
Fuels, coolants, lubricants etc. - capacities
Te ch n i c a l
data
Instruments
and controls Operation Driving
Instrument
cluster display Practical hints Car care Index
Premium unleaded gasoline
Caution!
To maintain the engine’s durability and performance,
premium unleaded gasoline must be used. If premium
unleaded is not available and low octane fuel is used,
follow these precautions: • have the fuel tank filled only partially with unleaded
regular and fill up with premium unleaded as soon
as possible,
• avoid full throttle driving and abrupt acceleration,
• do not exceed an engine speed of 3000 rpm, if the
vehicle is loaded with a light load such as two
persons and no luggage,
• do not exceed
2/3 of maximum accelerator pedal
position, if the vehicle is fully loaded or operating in
mountainous terrain. Fuel requirements
Use only Premium unleaded meeting ASTM
standard D 439:
The octane number (posted at the pump) must be
91 min. It is an average of both the Research (R) octane
number and the Motor (M) octane number: (R+M) / 2).
This is also known as ANTI-KNOCK INDEX.
Unleaded gasoline containing oxygenates such as
Ethanol, IPA, IBA and TBA can be used provided the
ratio of any one of these oxygenates to gasoline does not
exceed 10%, MTBE not to exceed 15%.
The ratio of Methanol to gasoline must not exceed 3%
plus additional cosolvents.
Using mixtures of Ethanol and Methanol is not allowed.
Gasohol, which contains 10% Ethanol and 90% unleaded
gasoline, can be used.
These blends must also meet all other fuel requirements
such as resistance to spark knock, boiling range, vapor
pressure etc.

381
Fuels, coolants, lubricants etc. - capacities
Te ch n i c a l
data
Instruments
and controls Operation Driving
Instrument
cluster display Practical hints Car care Index
Gasoline additives
A major concern among engine manufacturers is carbon
build up caused by gasoline. Mercedes-Benz
recommends the use of only quality gasoline containing
additives that prevent the build up of carbon deposits.
After an extended period of using fuels without such
additives, carbon deposits can build up especially on the
intake valves and in the combustion area, leading to
engine performance problems such as:
• warm-up hesitation,
• unstable idle,
• knocking / pinging,
• misfire,
• power loss.
Do not blend other specific fuel additives with fuel.
They only result in unnecessary cost, and may be
harmful to the engine operation.
Damage or malfunctions resulting from poor fuel
quality or from blending specific fuel additives are not
covered by the Mercedes-Benz Limited Warranty. Coolants
The engine coolant is a mixture of water and
anticorrosion / antifreeze, which provides:
• corrosion protection,
• freeze protection,
• boiling protection (by increasing the boiling point).
The cooling system was filled at the factory with a
coolant providing freeze protection to approximately
- 22
°F (- 30
°C) and corrosion protection.
If the antifreeze mixture is effective to - 22
°F (- 30
°C),
the boiling point of the coolant in the pressurized
cooling system is reached at approximately 266
°F
(130
°C).
The coolant solution must be used year round to provide
the necessary corrosion protection and increase in the
boil-over protection. You should have it replaced every
3years.
To provide the important corrosion protection, the
solution must be at least 45% anticorrosion / antifreeze
(equals a freeze protection to approximately - 22
°F
(- 30
°C). If you use a solution that is more than 55%
anticorrosion /antifreeze (freeze protection to
approximately - 49
°F (- 45
°C), the engine temperature

382
Fuels, coolants, lubricants etc. - capacities
Te ch n i c a l
data
Instruments
and controls Operation Driving
Instrument
cluster display Practical hints Car care Index
will increase due to the lower heat transfer capability of
the solution. Therefore, do not use more than this
amount of anticorrosion / antifreeze.
If the coolant level is low, water and MB anticorrosion /
antifreeze should be used to bring it up to the proper
level (have cooling system checked for signs of leakage).
The water in the cooling system must meet minimum
requirements, which are usually satisfied by normal
drinking water. If your are not sure about the water
quality, consult your authorized Mercedes-Benz Center.
Anticorrosion / antifreeze
Your vehicle contains a number of aluminium parts. The
use of aluminium components in motor vehicle engines
necessitates that anticorrosion / antifreeze coolant used
in such engines be specifically formulated to protect the
aluminium parts. (Failure to use such anticorrosion /
antifreeze coolant will result in a significantly
shortened service life.)
Therefore the following product is strongly
recommended for use in your vehicle: Mercedes-Benz
anticorrosion / antifreeze agent. Before the start of the winter season (or once a year in
the hot southern regions), you should have the
anticorrosion / antifreeze concentration checked. The
coolant is also regularly checked each time you bring
your vehicle to your authorized Mercedes-Benz Center
for service.
Anticorrosion / antifreeze quantity
Approximately freeze protection
– 35
°F
(– 37°C) – 49
°F
(– 45°C)
4.8 US qt
(4.5 l) 5.3 US qt
(5.0 l)

383
Consumer information
Te ch n i c a l
data
Instruments
and controls Operation Driving
Instrument
cluster display Practical hints Car care Index
Consumer information
This has been prepared as required of all manufactures
of passenger cars under Title 49, Code of U.S. Federal
Regulations, Part 575 pursuant to the “National Traffic
and Motor Vehicle Safety Act of 1966”.
Uniform tire quality grading
Quality grades can be found where applicable on the
tire sidewall between tread shoulder and maximum
section width. For example:
All passenger car tires must conform to federal safety
requirements in addition to these grades.
Treadwear
The treadwear grade is a comparative rating based on
the wear rate of the tire when tested under controlled
conditions on a specified government test course. For
example, a tire graded 150 would wear one and one-half
(1
1/2) times as well on the government course as a tire
graded 100. The relative performance of tires depends
upon the actual conditions of their use, however, and may depart significantly from the norm due to
variations in driving habits, service practices and
differences in road characteristics and climate.
Traction
The traction grades, from highest to lowest are AA, A, B,
and C. Those grades represent the tire’s ability to stop
on wet pavement as measured under controlled
conditions on specified government test surfaces of
asphalt and concrete. A tire marked C may have poor
traction performance.
Tread wear 200 Traction AA Temperature A
Wa r n i n g !
The traction grade assigned to this tire is based on
straightahead braking traction tests, and does not
include acceleration, cornering, hydroplaning, or
peak traction characteristics.

384
Consumer information
Te ch n i c a l
data
Instruments
and controls Operation Driving
Instrument
cluster display Practical hints Car care Index
Tempera t u re
The temperature grades are A (the highest), B, and C,
representing the tire‘s resistance to the generation of
heat and its ability to dissipate heat when tested under
controlled conditions on a specified indoor laboratory
test wheel. Sustained high temperature can cause the
material of the tire to degenerate and reduce tire life,
and excessive temperature can lead to sudden tire
failure. The grade corresponds to a level of performance
which all passenger car tires must meet under the
Federal Motor Vehicle Safety Standard No. 109. Grades
B and A represent higher levels of performance on the
laboratory test wheel than the minimum required by
law.
Wa r n i n g !
The temperature grade for this tire is established
for a tire that is properly inflated and not
overloaded. Excessive speed, underinflation, or
excessive loading, either separately or in
combination, can cause excessive heat build up
and possible tire failure.

385
Index
Te ch n i c a l
data
Instruments
and controls Operation Driving
Instrument
cluster display Practical hints Car care
Index
Index
AAdding engine oil........................................................... 318
Air pump ......................................................................... 322
Airbags .............................................................................. 72
ANTILOCK BRAKE SYSTEM
Malfunction and warning message........................ 293
Antilock brake system (ABS) ....................................... 272
Antitheft alarm system ................................................... 44
Ashtrays........................................................................... 211
Audio system Button and soft key operation................................. 176
Cassette mode ........................................................... 182
CD changer ................................................................ 187
CD mode ..................................................................... 186
Operating and display elements............................. 174
Operating safety ........................................................ 173
Operation.................................................................... 176
Operation Audio and telephone .............................. 173
Radio mode ................................................................ 179
Telephone operation ................................................. 190 Audio systems................................................................. 108
Cassette player .......................................................... 110
CD Player .................................................................... 109
Radio ........................................................................... 108
Automatic central locking .............................................. 40
Automatic climate control ............................................ 160 Activated charcoal filter ........................................... 168
Adjustable air outlets, rear passenger compartment ......................................................... 172
Air recirculation ........................................................ 167
Air volume, manual .................................................. 165
Basic setting............................................................... 164
Defrosting ................................................................... 166
Display and controls ................................................. 162
Dust filter.................................................................... 164
Economy mode .......................................................... 169
Front center console storage compartment ventilation..................................... 171
Residual engine heat utilization ............................. 169
Special settings ......................................................... 165
Windows fogged up on the outside ........................ 166
Automatic transmission ............................................... 246 Fluid level ................................................................... 317
Transmission selector lever, manually unlocking ............................................ 344

386
Index
Te ch n i c a l
data
Instruments
and controls Operation Driving
Instrument
cluster display Practical hints Car care
Index
BBabySmart
TM airbag deactivation system..................... 69
Battery ............................................................................. 336
Block heater .................................................................... 266
Brake assist system (BAS) ............................................ 271
Bulbs See Replacing bulbs ................................................. 345
CCD changer installed ..................................................... 187
Cellular telephone ......................................................... 219
Center console .................................................................. 24
Central locking switch .................................................... 38
Central locking system ................................................... 31Automatic central locking ......................................... 40
Central locking switch ............................................... 38
Choosing global or selective mode........................... 33
Doors ............................................................................. 36
General notes............................................................... 30
Locking and unlocking with remote control .......... 33
Mechanical keys .......................................................... 35
Obtaining replacement keys ..................................... 29
Summer opening/convenience feature ................... 34 Vehicle keys ................................................................. 28
Changing wheels........................................................... 327 Inflating the collapsible spare tire ........................ 333
Storing spare wheel in wheel well ........................ 334
Check regularly and before a long trip...................... 280
Child seat See Infant and child restraint systems .................... 82
Climate control ............................................................... 152 Adjustable air outlets, rear passenger compartment ......................................................... 172
Air recirculation ........................................................ 158
Basic setting............................................................... 156
Defrosting ................................................................... 157
Display and controls ................................................. 154
Dust filter.................................................................... 155
Economy mode .......................................................... 159
Front center console storage compartment ventilation ............................................................. 171
Residual engine heat utilization ............................. 159
Special settings ......................................................... 156
Windows fogged up on the inside .......................... 157
Windows fogged up on the outside ................ 157, 166
COMAND, radio and telephone................................... 226
Combination switch ....................................................... 148
Control and operation of radio transmitters ............. 226
Coolant level ................................................................... 319

387
Index
Te ch n i c a l
data
Instruments
and controls Operation Driving
Instrument
cluster display Practical hints Car care
Index
Coolant temperature gauge .......................................... 137
Cruise control ................................................................. 268
Cup holder ...................................................................... 210
DDashboard ......................................................................... 22
Door control panel ........................................................... 20
Drive sensibly - Save Fuel ............................................ 257EEasy-entry/exit feature ................................................... 47
Electronic key ................................................................... 29
Electronic main key
Changing batteries ................................................... 351
Synchronizing remote control ................................ 353
Electronic stability program (ESP).............................. 274
Emergency call See Tele Aid ............................................................... 228
Emergency engine shut-down ..................................... 353
Emergency operation of sliding/pop-up roof ............ 354
Emergency tensioning retractor (ETR)......................... 71
Emergency unlocking in case of accident ................... 40
Engine oil consumption ................................................ 142 Engine oil level indicator .............................................. 141
Express opening and closing (power windows) ........ 197
Exterior lamp switch ..................................................... 143
Daytime running lamp mode .................................. 145
Exterior lamps ............................................................... 345 Additional turn signals on the exterior mirror ... 350
Bulbs for high and low beam ................................. 347
Headlamp assembly ................................................. 346
High mounted stop lamp ......................................... 350
License plate lamps ................................................. 349
Parking and standing lamp .................................... 347
Replacing bulbs ........................................................ 345
Side marker lamp, front .......................................... 350
Taillamp assemblies ................................................ 348
Turn signal lamp ...................................................... 347
Exterior mirror adjustment ............................................ 90
Exterior mirror, front passenger side, parking position .......................................................... 91
FFirst aid kit ...................................................................... 310
Flat tire
See Changing wheels .............................................. 327
Flexible service system (FSS) ...................................... 138
