235
Operation
Tires and wheels
Tire pressure changes by approximately
1.5 psi (0.1 bar) per 18°F (10°C) of air
temperature change. Keep this in mind
when checking tire pressure where the
temperature is different from the outside
temperature.
Tire temperature and tire pressure are also
increased while driving, depending on the
driving speed and the tire load.
Check the spare tire periodically for condi-
tion and inflation. Spare tires will age and
become worn over time even if never used,
and thus should be inspected and replaced
when necessary.
Rotating wheels
On vehicles with the same wheel size all
around, wheels can be rotated every 3000
to 6000 miles (5 000 to 10 000 km), or sooner if necessary, according to the de-
gree of tire wear. The same direction of tire
rotation must be retained.
Rotate the wheels before the characteris-
tic tire wear pattern becomes visible
(shoulder wear on front wheels and tread
center wear on rear wheels).
Thoroughly clean the inner side of the
wheels after each rotation. Check and en-
sure proper tire inflation pressure.
Warning!
G
Follow recommended inflation pressures.
Do not overinflate tires. Overinflating tires
can result in sudden de
flation (blowout) be-
cause they are more likely to become punc-
tured or damaged by road debris, potholes
etc.
Do not underinflate tires. Underinflated tires
wear unevenly, adversely affect handling
and fuel economy, and are more likely to fail
from being overheated.
Do not overload the tires by exceeding the
specified vehicle capacity weight (as indicat-
ed by the label on the pillar in the driver’s
door opening). Overloading the tires can
overheat them, possibly causing a blowout.Warning!
G
Rotate front and rear wheels only if they are
of the same size.
Warning!
G
Have the tightening torque checked after
changing a wheel. Wheels could become
loose if not tightened with a torque of
80 ft.lb. (110 Nm).
Use only genuine Mercedes-Benz wheel
bolts specified for your vehicle's rims.

352 IndexTelephoneEmergency call 179
Telephone* 24, 200 Answering a call 128
Dialing a number from the phone book 128
Ending a call 128
Hands-free microphone 26
Loading phone book* 128
Messages in display 269
Operating 126
Operation 176
Redialing 129
Temperature Display mode 117
Grades of tires 326
Setting interior temperature 145
Setting units in display 117
Tires 235
Tightening torque 331
Tightening torque (Wheel bolts) 291
Tilt Backrest 33
Head restraint 34
Seat cushion 33 Time
Setting hours 116
Setting minutes 116
Time display Setting 117
Tire inflation pressure Checking 225, 234
Tire speed rating 219, 331
Tire traction 219
Tires 233, 311 Collapsible 328
Consumer information 325
Direction of rotation 234
Driving instructions 218
Retreads 233
Rims and tires 311
Service life 234
Temperature 235
Temperature grades 326
Tread depth 236
Wear pattern 235
Winter 236
Tools 272
Tow-away alarm 25, 79 Arming 79
Disarming 79 Disarming for transport 79
Towing eye bolt (vehicle tool kit) Installing 302
Towing the vehicle 299
Tracking services For stolen vehicle 209
Traction 136, 325, 331
Transmission see Automatic transmission 229
Transmission selector lever 277 Unlocking manually 277
Tread depth (tires) 236
Treadwear 325
Trim panel Opening 304
Trip computer 125
Trip odometer Resetting 103
Trunk Auxiliary fuse box 304
Lighting 101
Trunk lid 85
Trunk lid Closing 86
Emergency release 86
Opening 85

354 IndexVehicle tool kit 272Alignment bolt 272
Spare fuses 272
Special fuse puller 272
Towing eye bolt 272
Vehicle jack 272
Wheel bolts 272
Wheel wrench 272
Vehicle washing 242
Ventilated storage compartment 148
Ventilation Storage compartment 148
VIN (Vehicle Identification Number) 308, 331
Voice control system* 331
Voice recognition system* Hands-free microphone 26
W
Warning sounds Drivers seat belts 62
Parking brake 46
Warranty coverage 307
Washer fluid see Windshield washer fluid
Washing the vehicle 240
Wear pattern (tires) 235
Weights 316 Wheel change
Tightening torque 291
Wheels Rotating 235
Tires and wheels 233
Window curtain airbags 61
Windows see Side windows
Windshield Defogging 145, 153
Refilling washer fluid 232
Replacing wiper blades 287
Washer fluid 232, 324
Washer system 324
Windshield washer fluid 324 Message in display 270
Mixing ratio 324
Refilling 232
Wiping with 49
Windshield washer system 324
Windshield wipers 48 Fast wiper speed 48
Replacing wiper blades 287
Single wipe 49
Switching on 48
Wiping with windshield washer fluid 49 Winter driving 236
Block heater 237
Snow chains 237
Tires 236
Transmission program mode 136
Winter driving instructions 220
Winter tires 236
Wiper blades Cleaning 243
Installing 287
Removing 287
Removing insert 287
Replacing 287
Wiping And washing simultaneously 49
Interval 48
With windshield washer fluid 49
X
Xenon headlamps Bi-Xenon 327
