MERCEDES-BENZ C CLASS COUPE 2004 Owners Manual

131
Controls in detail
Control system

Move the selection marker with
the
æ orç button to the
CONVE-
NIENCE
submenu.

Press button j ork repeatedly
until you see this message in the
display:
EASY-ENTRY FEATURE ACTI-
VATE
.
The selection marker is on the current
setting.

Press æ orç to change the
easy-entry/exit setting. The following settings are available for
the easy-entry/exit feature:
Setting key-dependency
Use this function to set whether the mem-
ory settings for the seats, the steering
wheel and the mirrors should be stored
separately for each SmartKey (
page 95).

Move the selection marker with
the
æ orç button to the
CONVE-
NIENCE
submenu.

Press button j ork repeatedly
until you see this message in the dis-
play:
SETTINGS KEY-DEPENDENT
.
The selection marker is on the current
setting.

Press æ orç to set
key-dependency to
ON or
OFF
.
OFF
The
easy-entry/exit
feature is
deactivated.
STEERING COLUMN
Only the
steering column
is moved.
STEERING COLUMN +
SEAT
Both the
steering column
and the seat are
moved.

132 Controls in detailControl systemSetting parking position for exterior rear
view mirror
Use the
MIRROR SETTING WHEN PARKING

function to select whether the passen-
ger-side exterior rear view mirror should be
turned downward during parking maneu-
vers when reverse gear is engaged. For ad-
ditional information, see “Activating
exterior rear view mirror parking position”
(
page 147).
You can store a parking position for the
passenger exterior rear view mirror using
the memory switch (
page 97).

Move the selection marker with
the æ orç button to the
CONVE-
NIENCE
submenu.

Press button j ork repeatedly
until you see this message in the dis-
play:
MIRROR SETTING WHEN PARKING
.
The selection marker is on the current
setting.

Press æ orç to switch function ON or
OFF
.
Trip computer menu
Use the trip computer menu to call up sta-
tistical data on your vehicle. The following
information is available:Function
Page
Fuel consumption statistics after
start
133
Fuel consumption statistics
since last reset
133
Call up range (distance to empty)
134

133
Controls in detail
Control system
Fuel consumption statistics after start
Press button
ÿ orè repeatedly
until you see the first function of the
Trip computer menu.

Press button j ork repeatedly
until you see this message in the dis-
play:
AFTER START
.
1 Distance driven since start
2 Time elapsed since start
3 Average speed since start
4 Average fuel consumption since start Fuel consumption since last reset

Press button
ÿ orè repeatedly
until you see the first function of the
Trip computer menu.

Press button j ork repeatedly
until you see this message in the dis-
play:
After RESET
.
1 Distance driven since last reset
2 Time elapsed since last reset
3 Average speed since last reset
4 Average fuel consumption since last re-
set Resetting fuel consumption statistics

Press button
ÿ orè repeatedly
until you see the first function of the
Trip computer menu.

Press button j ork repeatedly
until you see the reading that you want
to reset in the display.

Press and hold the reset button in the
instrument cluster (
page 22) until
the value is reset to 0.
iAll statistics stored since the last en-
gine start will be reset approximately
four hours after the SmartKey in the
starter switch is turned to position 0 or
removed from the starter switch.
Resetting will not occur if you turn the
SmartKey back to position 1 or 2 with-
in this time period.

134 Controls in detailControl systemCall up range (distance to empty)
Press buttonÿ orè repeatedly
until you see the first function of the
Trip computer menu.

Press button j ork repeatedly
until you see this message in the dis-
play:
RANGE
.
In the display you will see the calculat-
ed range based on the current fuel tank
level.
TEL menu*
You can use the functions in the
TEL
menu
to operate your telephone, provided it is
connected to a hands-free system and
switched on.

Switch on the telephone and
COMAND*.

Press button ÿ orè on the
steering wheel repeatedly until you see
the
TEL
menu in the display.
Warning!
G
A driver’s attention to the road must always
be his/her primary focus when driving. For
your safety and the safety of others, we rec-
ommend that you pull over to a safe location
and stop before placing or taking a tele-
phone call. If you choose to use the tele-
phone while driving, please use the
hands-free device and only use the tele-
phone when weather, road and traffic condi-
tions permit.
Some jurisdictions prohibit the driver from
using a cellular telephone while driving a ve-
hicle.
Bear in mind that at a speed of just 30 mph
(approximately 50 km/h), your vehicle is
covering a distance of approximately
44 feet (approximately 13.5 m) every sec-
ond.
Never operate radio transmitters equipped
with a built-in or attached antenna (i.e. with-
out being connected to an external antenna)
from inside the vehicle while the engine is
running. Doing so could lead to a malfunc-
tion of the vehicle’s electronic system, pos-
sibly resulting in an accident and/or
personal injury.

135
Controls in detail
Control system
Which messages will appear in the display
field depends on whether your telephone is
switched on or off:

If the telephone is off, the message in
the multifunction display is:
TEL OFF
.


If the telephone is on:
The telephone will then search for a
network. During this time the display is
empty.
As soon as the telephone has found a
network,
READY
is indicated in the dis-
play.
1 Signal strength This standby message indicates that your
telephone is ready for use and you can op-
erate it using the control system.
Answering a call
When your telephone is ready to receive
calls, you can answer a call at any time. In
the display you will then see the message:

Press button
í.
You have answered the call. In the dis-
play you see the length of the call.
Ending a call

Press button ì.
You have ended the call. In the display
you will again see the standby mes-
sage.
iVehicles with Audio system:
the signal strength is indicated in the
top right corner, for example “S9”. The
higher the number, the stronger the
signal from the cellular network.
Vehicles with COMAND*:
the signal strength is indicated by bars
in the top left corner. The higher the
number of bars, the stronger the signal
from cellular network.

136 Controls in detailControl systemDialing a number from the phone book
If your telephone is ready to receive calls,
you may select and dial a number from the
phone book at any time.
Press buttonÿ orè repeatedly
until you see the
TEL
menu in the
display.

Press button j ork .
The control system reads the phone
book which is stored in the telephone.
This may take up to 30 seconds. In the
display you will see the message PLEASE WAIT
.
When the message
PLEASE WAIT
disap-
pears, the phone book has been load-
ed.

Press button j ork repeatedly
until the desired name appears in the
display.
The stored names are displayed in as-
cending or descending alphabetical or-
der.

Press button í.
The system dials the selected phone
number.

If the connection is successful, the
name of the party you called and
the duration of the call will appear
in the display.


If no connection is made, the con-
trol system stores the dialed num-
ber in the redial memory. Redialing
The control system stores the most recent-
ly dialed phone numbers. This eliminates
the need to search through your entire
phone book.

Press button
ÿ orè repeatedly
until you see the
TEL
menu in the dis-
play.

Press button í.
In the display you see the first number
in the redial memory.

Press button j ork repeatedly
until the desired name appears in the
display.

Press button í.
The control system dials the selected
phone number.
iIf you press and hold j ork for
longer than one second, the system
scrolls rapidly through the list of names
until you release the button again.
Cancel the quick search mode by
pressing ì.

137
Controls in detail
Manual transmission
 Manual transmission
For information on driving with a manual
transmission, see “Manual transmission”
(page 137).
Do not exceed the maximum speed in the
individual gears. Refer to tachometer
(page 22) for engine speeds.Warning!
G
On slippery road surfaces, never downshift
in order to obtain braking action. This could
result in drive wheel slip and reduced vehi-
cle control. Your vehicle’s ABS will not pre-
vent this type of loss of control.
Warning!
G
When leaving the vehicle, always remove the
SmartKey from the starter switch and lock
the vehicle. Do not leave children unattend-
ed in the vehicle, or with access to an un-
locked vehicle. Children could move the
gearshift lever, which could result in an acci-
dent and/or serious injury.
Warning!
G
For vehicles equipped with a manual trans-
mission, getting out of your vehicle with the
gearshift lever not engaged in 1st or reverse
gear and parking brake engaged is danger-
ous. Also, when parked on an incline, an en-
gaged 1st or reverse gear alone may not
prevent your vehicle from moving, possibly
hitting people or objects
Always set the parking brake in addition to
engaging 1st or reverse gear (
page 52).
When parked on an incline, turn the front
wheel towards the road curb.
Do not park this vehicle in areas where com-
bustible materials such as grass, hay, or
leaves can come into contact with the hot
exhaust system, as these materials could be
ignited and cause a vehicle fire.

138 Controls in detailManual transmission
Shifting into reverse
Stop the vehicle completely.

Pull gearshift lever up and shift in
Rreverse.
!Downshifting gears leading to overrev-
ving the engine can result in engine
damage that is not covered by the
Mercedes-Benz Limited Warranty.
Do not exceed the engine speed limits
(page 324).
Never hold the vehicle stopped on a hill
by using the clutch pedal. The clutch
may be damaged which is not covered
by the Mercedes-Benz Limited Warran-
ty.

139
Controls in detail
Automatic transmission*
 Automatic transmission*
For more information on driving with an au-
tomatic transmission, see “Automatic
transmission*” (
page 45).
Your vehicle’s transmission adapts its gear
shifting process to your individual driving
style by continually adjusting the shift
points up or down. These shift point adjust-
ments are performed based on current
operating and driving conditions.
If the operating conditions change, the
automatic transmission reacts by
adjusting its gear shift program. The automatic transmission selects indi-
vidual gears automatically, depending on:


the gear selector lever position
D with
gear ranges 4, 3 , 2 , 1 (
page 141)


the selected shift program ( C/S)
(page 144)


the position of the accelerator pedal
(page 145)


the vehicle speed
The current gear selector lever position
and shift program (
C/S) appear in the
multifunction display (page 109).
An additional indication of the current gear
selector lever position can be found on the
cover of the shifting-gate. The indicators
come on when you activate a switch (e.g.
unlocking the vehicle or opening a door)
and go out after approximately
15 minutes. When the gear selector lever is in
position
D, you can influence transmission
shifting by:


limiting the gear range


changing gears manually
iDuring the brief warm-up, transmission
upshifting is delayed. This allows the
catalytic converter to heat up more
quickly to operating temperature.
Warning!
G
It is dangerous to shift the gear selector
lever out of P or N if the engine speed is
higher than idle speed. If your foot is not
firmly on the brake pedal, the vehicle could
accelerate quickly forward or reverse. You
could lose control of the vehicle and hit
someone or something. Only shift into gear
when the engine is idling normally and when
your right foot is firmly on the brake pedal.

140 Controls in detailAutomatic transmission*One-touch gearshifting
Even with an automatic transmission you
can change the gears manually when the
gear selector lever is in positionD.
Downshifting
Briefly press the gear selector lever to
the left in the D-direction.
The transmission will shift from the current
gear to the next lower gear. This action
simultaneously limits the gear range of the
transmission (
page 141). Upshifting

Briefly press the gear selector lever to
the right in the
D+direction.
The transmission will shift from the current
gear to the next higher gear as permitted
by the shift program. This action simul-
taneously extends the gear range of the
transmission. Canceling gear range limit

Press and hold the gear selector lever
in the
D+direction until
D reappears in
the multifunction display.
The transmission will shift from the current
gear range directly to gear range D.
Shifting into optimal gear range

Press and hold the gear selector lever
in the D-direction.
The transmission will automatically select
the gear range suited for optimal
acceleration and deceleration. This will
involve shifting down one or more gears.
Warning!
G
On slippery road surfaces, never downshift
in order to obtain braking action. This could
result in drive wheel slip and reduced
vehicle control. Your vehicle’s ABS will not
prevent this type of loss of control.
iTo avoid overrevving the engine when
the gear selector lever is moved to
the D-direction, the transmission will
not shift to a lower gear if the engine’s
max. speed would be exceeded.
