Beltsee Sea tbelts
Blind SpotA ssist
Activating/deactivating (on-
board computer) ............................ 213
Displa ymessage ............................ 237
Notes/functio n.............................. 191
see Active Blind Spot Assist
Bluetooth
®
Connecting another mobile
phone ............................................ 266
Searching for amobilephone ........ 265
see also Digital Operator's Man-
ua l.................................................. 258
Telephony ...................................... 265
Brake Assist
see BAS (Brake Assist System)
Brake fluid
Displa ymessage ............................ 225
Note s............................................. 347
Brake forc edistribution
see EBD (electroni cbrake force
distribution)
Brakes
ABS .................................................. 62
Adaptive Brake Assist ...................... 66
BAS .................................................. 62
BAS PLU SwithC ross-Traffic
Assist ............................................... 62
Brake fluid (notes) ......................... 347
Displa ymessage ............................ 220
EBD .................................................. 70
High-performance brake system .... 159
Hil lstart assis t............................... 135
HOLD function ............................... 169
Important safety notes .................. 157
Maintenance .................................. 158
Parking brake ................................ 153
Riding tip s...................................... 157
Warning lamp ................................. 248
Breakdown
Where will Ifind...? ........................ 299
see Fla ttire
see Towing away
Brightness control( instrument
cluste rlighting) ................................... 33
Button sonthe steering wheel ......... 201
C
California
Important notice for retail cus-
tomers and lessees .......................... 26
Calling up amalfunction
see Displa ymessages
Calling up the climate controlb ar
Multimedia system ........................ 262
Calling up the climate control
menu
Multimedia system ........................ 262
Car
see Vehicle
Care
360° camera ................................. 296
Carw ash. ....................................... 292
Carpets .......................................... 298
Displa y........................................... 297
Exhaus tpipe. ................................. 296
Exterior lights ................................ 295
Gear or selector lever .................... 297
Genera lnotes ................................ 292
Interior ........................................... 297
Matte finish ................................... 294
Paint .............................................. 294
Plastic trim .................................... 297
Power washer. ............................... 293
Rear vie wcamera .......................... 296
Roof lining ...................................... 298
Seatb elt. ....................................... 298
Seatc over..................................... 297
Sensors ......................................... 296
Steering wheel. .............................. 297
Tri mp ieces. ................................... 297
Washing by hand ........................... 293
Wheels. .......................................... 295
Window s........................................ 295
Wipe rblade s.................................. 295
Woode ntrim .................................. 297
Carg otie dow nrings ......................... 272
CD
see also Digital Operator's Man-
ual.................................................. 258
CD player (on-board computer) ........ 209
Centerc onsole
Lower section ............................ 37, 38
Upper section .................................. 36
Index5
Page 14 of 354

LATCH-type(ISOFIX) child seat
anchors ................................................ 59
License plate lamp( display mes-
sage) .................................................. .231
Light function ,active
Display message ............................ 231
Light sensor (display message) ....... 231
Lights
Adaptive Highbeam Assist ............. 112
Automatic headlamp mode ............ 110
Cornering light function ................. 112
Foggeduph eadlamps .................... 113
General notes ................................ 110
Hazard warning lamps ................... 112
High beamf lasher .......................... 111
High-beam headlamps ................... 111
Ligh tswitch ................................... 110
Low-beam headlamps .................... 111
Parking lamps ................................ 111
Rea rfog lamp ................................ 111
Setting exterio rlighting ................. 110
Standing lamps .............................. 111
Switching the daytime running
lamps on/off (on-board com-
puter) ............................................. 214
Turn signals ................................... 111
see Interior lighting
Loading guidelines ............................ 268
Locking
see Centrall ocking
Locking (doors)
Automatic ........................................ 81
Emergency locking ........................... 82
From insid e(central locking but-
ton) ..................................................8 1
Locking centrally
see Central locking
Low-beamh eadlamps
Changing bulbs .............................. 115
Display message ............................ 231
Switchin gon/off .......................... .111
Lumbar support
Adjusting the 4-way lumbars up-
port ................................................ 101
M
M+S tires ............................................ 318 Malfunction message
see Display messages
Matte finish (cleaning instruc-
tions) ..................................................2 94
mbrace
Call priority ....................................2 79
Display message ............................ 225
Downloading destinations
(COMAND) ..................................... 280
Downloading route s....................... 282
Emergency call .............................. 277
General notes ................................ 276
Geo fencing ................................... 283
Locating astole nvehicle ...............2 81
MB info call button ........................ 279
Remote fault diagnosis. ................. 282
Remote vehicl eloc king .................. 281
Roadsid eAssistance button .......... 278
Search &Send ............................... 280
Self-test ......................................... 277
Speed alert .................................... 282
System .......................................... 277
Triggering the vehicl ealarm ........... 283
Vehicl eremote unlocking .............. 281
Mechanical key
Function/note s................................ 76
Genera lnotes .................................. 76
Inserting .......................................... 76
Locking vehicl e................................ 82
Removing ......................................... 76
Unlocking the driver' sdoor.............. 82
Memory card (audio) ......................... 209
Memory function
Seats, steering wheel, exterior
mirrors ........................................... 109
Mercedes-Benz Intelligent Drive
360°camera .................................. 185
Active Blind Spot Assist ................. 194
Active Lane Keeping Assist ............ 197
Active Parking Assist ..................... 177
ATTENTIO NASSIST ........................ 189
Blind Spot Assist ............................ 191
DISTRONIC PLU S........................... 162
DISTRONIC PLU SwithS teering
Assist and Stop&G oPilot ............... 168
Genera lnotes ................................ 160
Lane Keeping Assist ...................... 193
PARKTRONIC ................................. 174
12Index
Page 16 of 354

On-boardcomputer
AMG menu .................................... .216
Assistance graphic menu ...............2 11
Assistance menu ........................... 212
Display messages .......................... 219
Displaying aservice message ........2 91
DISTRONI CPLUS ........................... 166
Factory settings .............................2 15
G-Mete r......................................... 216
Head-up displa y............................. 203
Important safety notes .................. 200
Instrument cluster menu ............... 215
Lights menu ................................... 214
Media menu ................................... 208
Menu overview .............................. 204
Message memory .......................... 219
Navigation menu ............................ 206
Operation ....................................... 201
RACETIMER ................................... 217
Radi omenu ................................... 208
Service menu ................................. 211
Setting smenu ............................... 211
Standard display ............................ 204
Telephone menu ............................ 210
Tri pm enu ...................................... 204
Video DVD operation ..................... 209
Operatin gsafety
Declaration of conformity ................ 28
Important safety notes .................... 28
Operatin gsystem
see On-board computer
Operation
Digital Operator's Manua l................ 23
Operator's Manual
Overview .......................................... 26
Vehicl eequipment ........................... 26
Outside temperature display ........... 201
Overhead controlp anel...................... 39
P
Paddles hifters
see Steering wheelp addleshifters
Paint code number ............................ 343
Paintwork (cleaning instructions) ... 294
Panic alarm .......................................... 41 Panorama roo
fwithp ower tilt/
sliding panel
Important safety notes .................... 90
Operating ......................................... 92
Operating the rolle rsunblind sfor
the sliding sunroof. .......................... 93
Problem (malfunction) ..................... 95
Rain closing feature ......................... 93
Reversing feature ............................. 91
Parking
Important safety notes .................. 152
Parking brake ................................ 153
Position of exterio rmirror, front-
passenger sid e............................... 108
Rear vie wcamera .......................... 181
Switching off the engine ................ 153
see PARKTRONIC
Parking aid
see 360° camera
see Active Parking Assist
see Exterior mirrors
see PARKTRONIC
see Rear vie wcamera
Parking assistance
see PARKTRONIC
Parking brake
Applying automaticall y................... 154
Applying or releasing manually ...... 154
Displa ymessage ............................ 222
Electric parking brake .................... 153
Emergency braking ........................ 155
Genera lnotes ................................ 153
Releasing automaticall y................. 154
Warning lamp ................................. 252
Parking lamps
Switching on/of f........................... 111
PARKTRONIC
Deactivating/activating ................. 176
Driving system ............................... 174
Function/note s............................. 174
Important safety notes .................. 174
Problem (malfunction) ................... 177
Range of the sensors ..................... 175
Warning display ............................. 176
PASSENGER AI RBAG
Displa ymessage ............................ 229
Indicato rlam ps ................................ 42
Problems (malfunction) .................. 229
14Index
Page 19 of 354

Sensors (cleaning instructions).......296
Service menu (on-board com-
puter) ..................................................2 11
Service message
see ASSYST PLUS
Service products
Brake fluid ..................................... 347
Coolant (engine) ............................ 347
Engine oil ....................................... 346
Fuel ................................................ 344
Important safety notes .................. 344
Refrigerant (air-conditioning sys-
tem) ............................................... 348
Washer fluid ................................... 348
Settin gthe date/time format
see also Digita lOperator's Man-
ua l..................................................2 58
Settin gthe language
see also Digita lOperator's Man-
ua l..................................................2 58
Settin gthe time
see also Digita lOperator's Man-
ua l..................................................2 58
Settings
Factory (on-board computer) ......... 215
On-board computer ....................... 211
SETUP (on-board computer) ............. 216
Side impact air bag .............................4 8
Side marker lamp (display mes-
sage) ................................................... 231
Side windows
Cleaning ......................................... 295
Conveniencec losing feature ............ 88
Convenienceo pening feature ..........8 8
Important safety information ........... 87
Opening/closing .............................. 87
Problem( malfunction) .....................9 0
Resettin g......................................... 89
Reversin gfeature ............................ .87
SIRIUS services
see also Digital Operator's Man-
ual .................................................. 258
Sliding sunroof
Opening/closing .............................. 91
Resetting ... ...................................... 92
see Panorama roof with power
tilt/sliding panel SmartKey
Changing the bat
tery ....................... 77
Changing the programming .............7 6
Checkin gthe battery ...................... .77
Convenience closingf eature ............ 89
Convenience opening feature .......... 88
Display message ............................ 245
Door central locking/unlocking ...... .74
Important safety notes .................... 74
KEYLESS-GO start function .............. 76
Loss .................................................7 9
Mechanical key ................................ 76
Overview .......................................... 74
Positions (ignition lock) ................. 131
Problem (malfunction) ..................... 79
Starting the engine ........................ 133
Smartphone
Starting the engine ........................ 134
SMS
see also Digital Operator's Man-
ual .................................................. 258
Snow chains ...................................... 319
Socket (12 V)
Center console .............................. 276
General notes ................................ 276
Rear compartment. ........................276
Sound
Switching on/off ........................... 259
Special seat bel tretractor .................. 57
Specialist workshop ............................ 29
Speed, controlling
see Cruise control
Speedometer
Activating/deactivating the addi-
tional speedometer ........................ 215
Digita l............................................ 205
In the Instrument cluster ................. 34
Segments ...................................... 200
Sel
ecting the displa yunit ...............2 15
SPORT handling mode
Deactivating/activating
(Mercedes-AMG vehicles) ................ 68
Warning lamp ................................. 251
Sports exhaus tsystem
see AMG sports exhaust system
Standin glamps
Display message ............................ 231
Switching on/off ........................... 111
Index17
Page 27 of 354

Protection of the environment
General notes
HEnvironmental note
Daimler's declared policy is one of compre-
hensive environmental protection.
The objectives are for the natural resources
that form the basis of our existence on this
planet to be used sparingly and in amanner
that takes the requirements of both nature
and humanity into account.
You too can help to protect the environment
by operating your vehicle in an environmen-
tally responsible manner.
Fuel consumption and the rate of engine,
transmission, brake and tire wear are affected by these factors:
Roperating conditionsofy our vehicle
Ryour personal driving style
You can influence both factors. You should
bear the following in mind:
Operating conditions:
Ravoid short trips as these increase fuel con-
sumption.
Ralways make sure that the tire pressures
are correct.
Rdo not carry any unnecessary weight.
Rremove roof racks once you no longer need
them.
Rar egularly serviced vehicle will contribute
to environmental protection. You should
therefore adhere to the service intervals.
Ralways have service work carried out at a
qualified specialist workshop.
Personal driving style:
Rdo not depress the accelerator pedal when
startin gthe engine.
Rdo not warm up the engine when the vehicle
is stationary.
Rdrive carefully and maintain asafe distance
from the vehicle in front.
Ravoid frequent, sudden acceleration and
braking.
Rchange gear in good time and use each gear
only up to Ôof its maximum engine speed.
Rswitch off the engine in stationary traffic.
Rkeep an eye on the vehicle's fuel consump-
tion.
HEnvironmental note
Have adefective high-voltage battery dis-
posed of in an environmentally-responsible
manner. Contact aqualified specialist work-
shop which has the necessary specialist
knowledge and tools to carry out the work
required. Mercedes-Benz recommends that
you use an authorized Mercedes-Benz Center
for this purpose.
Environmental concerns and recom-
mendations
Wherever the operating instructions require you
to dispose of materials, first try to regenerate or
re-use them. Observe the relevant environmen-
tal rules and regulations when disposing of
materials. In this way you will help to protect the
environment.
Genuine Mercedes-Benz parts
HEnvironmental note
Daimler AG also suppliesr econditioned major
assemblies and parts which are of the same
quality as new parts. They are covered by the
same Limited Warranty entitlements as new
parts.
!Air bags and Emergency Tensioning Devi-
ces, as well as control units and sensors for
these restraint systems, may be installed in
the following areas of your vehicle:
Rdoors
Rdoor pillars
Rdoor sills
Rseats
Rcockpit
Rinstrumentc luster
Rcenter console
Genuine Mercedes-Benz parts25
Introduction
Z
Page 49 of 354

To avoid hazardous situations, alwaysmake
sure that all of the vehicle's occupants:
Rhave fastened their seat belts correctly,
including pregnant women
Rare sittin gcorrectly and maintain the great-
est possible distance to the air bags
Rfollow the following instructions
Always make sure that there are no objects
between the air bag and the vehicle's occu-
pants.
RAdjust the seats properly before beginning
your journey. Always make sure that the seat
is in an almost upright position. The center of
the head restraint must support the head at
about eye level.
RMove the driver's and front-passenger seats
as far back as possible. The driver's seat posi-
tion must allow the vehicle to be driven safely.
ROnly hold the steerin gwheel on the outside.
This allows the air bag to be fully deployed.
RAlways lean against the backrest while driv-
ing. Do not lean forwards or lean against the
door or side window. You may otherwise be in
the deployment area of the air bags.
RAlways keep your feet in the footwell in front
of the seat. Do not put your feet on the dash-
board, for example. Your feet may otherwise
be in the deployment area of the air bag.
RFor this reason, alwayss ecure persons less
than 5ft(1.50 m) tall in suitable restraint sys-
tems. Up to this height, the seat belt cannot
be worn correctly.
If ac hild is traveling in your vehicle, also
observe the followingn otes:
RAlways secure children under twelve years of
age and less than5ft(1.50 m)tallins uitable
child restraint systems.
RChil drestraint systems shoul dbeinstalle don
the rea rseats.
ROnlys ecureac hild in arearward-facing child
restraint systemont he front-passengerseat
when the front-passenge rfront ai rbag is
deactivated .Ifthe PASSENGER AIR BAG OFF
indicator lamp is permanentl ylit,t he front-
pa sseng
e
rfront ai rbag is deactivated
(Ypage 42).
RAlway sobser ve the instructions and safety
note sont he "Occupant Classification System
(OCS) "(
Ypage 49) and on "Children in the vehicle" (
Ypage 57
)inadditiontot he child
restraint system manufacturer' sinstallation
and operating instructions.
Objects in the vehicle interior may prevent
an air bag from functioning correctly. Before
starting your journey and to avoid risks resulting from the speed of the ai rbag as it deploys, make
sure that:
Rther eare no people ,animals or objects
between the vehicl eoccupants and an air
bag.
Rther eare no objects between the seat, door
and B-pillar.
Rno hard objects, e.g .coa th angers, hang on
the gra bhandles or coa thooks.
Rno accessories, such as cup holders, are
attachedtot he vehiclewithint he deployment
are aofana irbag, e.g .todoors,s idew indows,
rea rsidet rim or side walls.
Rno heavy,s harp-edged or fragile objects are in
the pockets of your clothing. Store such
objects in asuitabl eplace.
GWARNING
If yo umodify the ai rbag cove rora ffix objects
such as stickers to it, the ai rbag can no longer
functio ncorrectly. There is an increased risk
of injury.
Never modify an ai rbag cove rora ffix objects
to it.
GWARNING
Sensors to contro lthe ai rbagsa re locate din
the doors .Modifications or work not per-
formed correctl ytothe doors or door panel-
ing ,asw ellasd amag ed doors ,can lead to the
functio nofthe sensors being impaired .The air
bags might therefore not functio nproperly
anymore .Consequently ,the ai rbagsc annot
protect vehicl eoccupants as they are
designed to do .There is an increased ris kof
injury.
Never modify the doors or parts of the doors.
Alway shavew orkont he doors or door pan-
eling carrie doutataq uali fied specialist work-
shop.
Occupant safety47
Safety
Z
Page 50 of 354

Frontair bags
Driver's air bag :deploys in fron tofthesteer -
ing wheel. Front-passenger fron tair bag ;
deploys in fron tofand abov ethe glov ebox.
When deployed, th efront air bags offer addi-
tional head and thorax protection for th eoccu-
pants in th efront seats.
The PASSENGER AI RBAG OFFa nd PASSENGER
AI RB AG ON indicator lamp sinform you about
th es tatus of th efront-pa ssenger air bag
(
Ypage 42).
The front-passenger fron tair bag will only
deplo yif:
Rthes ystem, based on th eOCS weigh tsensor
readings, detect sthatthe front-passenger
seat is occupied (
Ypage 49).The
PASSENGER AI RBAG ON indicator lamp is lit
(
Ypage 49)
Rth er estrain tsystem control unit predicts a
high acciden tseverit y
Knee bags
Driver's knee bag :deploys underneat hthe
steering column and front-passenger knee
bag ;underneat hthe glov ebox.T he driver' s
and front-passenger knee bags are triggered
together wit hthe fron tair bags . The driver'
sand front-passenger knee bags
offer additional thigh, knee and lower leg pro -
tection for th eoccupant sinthefron tseats.
Sidei mpact air bags
GWARNIN G
Unsuitable seat cover scould restrict or eve n
preven tthe deploymen toftheair bags inte-
grated int othe seats. Consequently, th eair
bags canno tprotect vehicl eoccupant sas
they are designed to do. In addition ,the func-
tion of th eOccupant Classification Syste m
(OCS )cou ld be restricted. This poses an
increased ris kofinjury or eve nfatal injury.
You should only use seat cover sthath ave
been approve dfor th erespective seat by
Mercedes-Benz.
Fron tside impac tair bags :and rear side
impact air bags ;deplo ynexttot heouter bol-
ster of th eseat backrest .
When deployed, th eside impac tair bag offers
additional thorax protection .How ever, it does
no tp rotect the:
Rhead
Rneck
Rarm s
In th eevent of aside impact, th eside impac tair
bag is deployed on th eside on whic hthe impac t
occurs.
The side impac tair bag on th efront-pa ssenger
side (front) deploys under th efollowin gcondi -
tions:
Rth eO CS system detect sthatthe front-
passenger seat is occupied or
Rth eb elt tongue is engage dinthebelt buckle
of th efront-pa ssenger seat
48Occupant safety
Safety
Page 58 of 354

Function
PRE-SAFE®intervenes:
Rin emergenc ybraking situations, e.g. when
BA Sisa ctivated
Rin critical driving situations, e.g. when physi-
cal limits are exceeded and th evehicl eunder-
steer soro versteer sseverely
Rvehicles wit hthe Drivin gAssistanc epackage:
when adriver assistanc esystem intervenes
powerfully or th eradar sensor system detect s
an imminent danger of collision in certai nsit-
uation s
PRE-SAF E
®takes thefollowin gmeasures
depending on th ehazardous situation detected:
Rthef ront seat belt sare pre-tensioned.
Rif th evehicl eskids, th eside windows and th e
panoram aroofw ithp ower tilt/slidin gpanel
are closed.
Rvehicles wit hthe memory function for th e
front-passenger seat :the front-passenger
seat is adjusted if it is in an unfavorable posi -
tion .
If th ehazardous situation passes without result -
ing in an accident, PRE-SAF E
®slackens thebelt
pre-tensioning .All setting smade by PRE-SAF E®
can then be reversed.
If theseat belt pre-tensioning is no treduced:
XMov ethe seat backrest or seat bac kslightly
when th evehicl eiss tationary.
The seat belt pre-tensioning is reduce dand
th el ockin gmechanism is released.
The seat-belt adjustmen tisanintegral part of
th eP R
E-SAF E®convenience function .You will
fin dinformation on th econveni ence function
under "Belt adjustment" (
Ypage 46).
PRE-SAFE®PLUS (anticipatory occu-
pant protection system PLUS)
Introduction
PRE-SAF E®PLUSiso nlya vailable in vehicles
wit hthe Drivin gAssistanc epackage.
Usin gthe radar sensor system, PRE-SAF E
®
PLUSisa ble to detect that ahead-on or rear-end
collision is imminent .Incertainhazardous sit -
uations, PRE-SAF E
®PLUStakes pre-emptive
measures to protect th evehicl eoccupants.
Important safety notes
The intervention of PRE-SAF E®PLUScanno t
preven tanimminent collision .
The driver is no twarned about th eintervention
of PRE-SAF E
®PLUS.
PRE-SAF E®PLUSdoes no tinterven eifthevehi-
cle is backin gup.
When driving ,orwhen parking or exiting apark -
ing spac ewitha ssistanc efromA ctiveParking
Assist ,PRE-SAF E
®PLUSwill no tapply th e
brakes.
Function
PRE-SAF E®PLUSintervenes in certai nsitua-
tion sift heradar sensor system detect san
imminent head-on or rear-end collision .
PRE-SAF E
®PLUStakes th efollowin gmeasures
depending on th ehazardous situation detected:
Rif th eradar sensor system detect sthata
head-on collision is imminent ,the seat belt s
are pre-tensioned.
Rif th eradar sensor system detect stha tar ear-
en dc ollision is imminent :
-theb rak epressur eisincreased if th edriver
applie sthe brakes when th evehicl eiss ta-
tionary.
-th es eat belt sare pre-tensioned.
The PRE-SAF E®PLUSbraking application is can -
celed:
Rif th eaccelerato rpedal is depressed when a
gear is engage d
Rif theriskofac ollision passes or is no longer
detected
Rif DISTRONI CPLUSindicates an intention to
pull away
If th ehazardous situation passes without result -
ing in an accident, th eoriginal setting sare
restored .
Automati cmeasures after an acci-
dent
Immediately after an accident, th efollowin g
measures are implemented, depending on th e
typ eand severit yoftheimpact :
Rtheh azard warning lamps are activated
Rthee mergenc ylighting is activated
Rthev ehicl edoor sare unlocked
56Occupant safety
Safety
Page 64 of 354

ABS (Anti-lock Braking System)
Gene ralinform ation
ABSregulates brak epressur einsuchaw ay that
th ew heels do no tloc kw hen you brake. This
allows you to continu esteering th evehicl ewhen
braking .
The ! ABSw arning lamp in th einstrumen t
cluste rlights up when th eignition is switched
on .Itg oeso ut when th eengineisr unning.
AB Sw orks from aspee dofa bout5mph
(8 km/h), regardless of road-surface conditions.
AB Sw orks on slipper ysurfaces, eve nwhen you
only brak egently.
Import ant safety notes
iObservethe "Importan tsafet ynotes "sec-
tion (Ypage 61).
GWARNIN G
If AB Sisf aulty, th ewheels could loc kwhen
braking .The steerabilit yand braking charac -
teristics may be severely impaired. Addition -
ally, further drivin gsafet ysystems are deac -
tivated. There is an increased danger of skid-
din gand accidents .
Drive on carefully. Hav eABS checke dimme-
diately at aqualified specialis tworkshop .
When AB Sismalfunctioning ,other systems ,
includin gdrivin gsafet ysystems ,will also
become inoperative. Observ ethe information
on th eABS warning lamp (
Ypage 249) and dis-
play message swhichm ay be shown in th e
instrumen tcluste r(
Ypage 220).
Braking
XIf ABS intervenes: continuetodepress th e
brak epedal vigorously until th ebraking sit -
uation is over.
XTo make afullb rake application: depress
th eb rak epedal wit hfull force .
If AB Sintervenes when braking ,you will fee la
pulsing in th ebrak epedal .
The pulsating brak epedal can be an indication
of hazardous road conditions, and function sasa
reminder to tak eextra carew hile driving.
BAS (Brak eAssistS ystem)
Gene ralinform ation
BASo perate sinemergenc ybraking situations.
If you depress th ebrak epedal quickly, BA S
automatically boosts th ebraking force ,thu s
shortening th estopping distance.
Imp ortant safety notes
iObserv ethe "Importan tsafet ynotes "sec-
tion (Ypage 61) .
GWARNIN G
If BA Sism alfunctioning ,the braking distanc e
in an emergenc ybraking situation is
increased. There is ariskofana ccident.
In an emergenc ybraking situation ,depress
th eb rak epedal wit hfull force .ABS prevents
th ew heels from locking .
Braking
XKeepthe brak epedal firmly depressed until
th ee mergenc ybraking situation is over.
AB Sp revents th ewheels from locking .
The brakes will function as usual once you
release th ebrak epedal .BAS is deactivated.
BAS PLUS (Brak eAssistS ystem
PLUS)w ith Cross-Traffic Assist
Gene ralinform ation
BASP LUSc an help you to minimiz ethe riskofa
collision wit havehicleorap edestrian and
reduce th eeffects of suc hacollision .IfBAS
PLU Sdetects adanger of collision ,you are
assisted when braking .
iPay attention to theimportant safet ynotes
in th e"Drivin gsafet ysystems "section
(
Ypage 61) .
BA SP LUSiso nlya vailable on vehicles wit hthe
Drivin gAssistance package.
Fo rB AS PLU Stoa ssist you when driving, th e
radar sensor system and th ecamera system
mus tbeo perational.
62Driving safety systems
Safety
Page 65 of 354

With the help ofasensor system and acamera
system, BAS PLUS can detect obstacles:
Rthat are in the path of your vehicle for an
extended period of time
Rthat cross the path of your vehicle
In addition, pedestrians in the path of your vehi-
cle can be detected.
BAS PLUS detect spedestrians by using typical
characteristic ssuch as the body contours and
posture of aperson standin gupright.
If the radar sensor system or the camera system is malfunctioning, BAS PLUS functions are
restricted or no longer available. The brake sys-
tem is still available with completeb rake boost-
ing effect and BAS.
iObserve the restriction sdescribed in the
"Important safety notes" sec-
tion“ (
Ypage 63).
Important safety notes
GWARNING
BAS PLUS cannot alwaysc learly identify
object sand complex traffic situations.
In such cases, BAS PLUS may:
Rintervene unnecessarily
Rnot intervene
There is arisk of an accident.
Always pay careful attention to the traffic sit- uation and be ready to brake. Terminat ethe
intervention in anon-critical driving situation.
GWARNING
BAS PLUS cannot alwaysc learly identifypeo-
ple, this is especially the case if they are mov-
ing. BAS PLUS cannot intervene in these
cases. There is arisk of an accident.
Always pay careful attention to the traffic sit-
uation and be ready to brake.
GWARNING
BAS PLUS does not react:
Rto small people, e.g. children
Rto animals
Rto oncoming vehicles
Rwhen cornering
As aresult, BAS PLUS may not intervene in all
critical situations. There is arisk of an acci-
dent.
Always pay careful attention to the traffic sit-
uation and be ready to brake.
In the event of snowfall or heavy rain, the rec-
ognition can be impaired.
Recognition by the radar sensor system is also
impaired if:
Rthere is dirt on the sensor soranything else
coveringt he sensors
Rthere is interference by other radar sources
Rthere are stron gradar reflections, for exam-
ple in parking garages
Ran arrow vehicle is travelin ginfront, e.g. a
motorbike
Rav ehicle is travelin ginfrontonad ifferentline
Rvehicles quickly move into the radar sensor
system detection range
Recognition by the camera system is also
impaired in the event of:
Rdirt on the camera or if the camera is covered
Rglare on the camera system, e.g. from the sun being low in the sky
Rdarkness
Ror if:
-pedestrians move quickly, e.g. into the path
of the vehicle
-the camera system no longer recognizes a
pedestrian as aperson due to special cloth-
ing or other objects
-ap edestrian is concealed by other objects
-the typical outline of aperson is not distin-
guishable from the background
Following damage to the fronte nd of the vehicle,
have the configuration and operation of the
radar sensor schecked at aqualified specialist
workshop. This also applies to collisions at slow
speeds where there is no visible damage to the
frontoft he vehicle.
Following damage to the windshield, have the
configuration and operation of the camera sys-
tem checked at aqualified specialist workshop.
Driving safety systems63
Safety
Z
