Page 2 of 406
Publication details
Internet
Further information about Mercedes-Benz
vehicles and about Daimler AG can be found
on the following websites:
http://www.mbusa.com (USA only)
http://www.mercedes-benz.ca (Canada
only) Editorial office
© Daimler AG: Not to be reprinted, translated
or otherwise reproduced, in whole or in part,
without written permission from Daimler AG. Vehicle manufacturer
Daimler AG
Mercedesstraße 137
70327 Stuttgart
Germany
Symbols
Registered trademarks:
R Bluetooth ®
is a registered trademark of
Bluetooth SIG Inc.
R DTS is a registered trademark of DTS, Inc.
R Dolby and MLP are registered trademarks
of DOLBY Laboratories.
R BabySmart™, ESP ®
and PRE-SAFE ®
are
registered trademarks of Daimler AG.
R HomeLink ®
is a registered trademark of
Johnson Controls.
R iPod ®
and iTunes ®
are registered trade-
marks of Apple Inc.
R Burmester is a registered trademark of
Burmester Audiosysteme GmbH.
R Microsoft ®
and Windows media ®
are reg-
istered trademarks of Microsoft Corpora-
tion.
R SIRIUS is a registered trademark of Sirius
XM Radio Inc.
R HD Radio is a registered trademark of iBiq-
uity Digital Corporation.
R Gracenote ®
is a registered trademark of
Gracenote, Inc.
R ZAGATSurvey ®
and related brands are reg-
istered trademarks of ZagatSurvey, LLC.
In this Operator's Manual you will find the fol- lowing symbols: G
WARNING
Warning notes make you aware of dangers
which could pose a threat to your health or
life, or to the health and life of others. H
Environmental note
Environmental notes provide you with infor-
mation on environmentally aware actions or
disposal.
! Notes on material damage alert you to
dangers that could lead to damage to your
vehicle.
i Practical tips or further information that
could be helpful to you. X
This symbol indicates an instruction
that must be followed.
X Several of these symbols in succes-
sion indicate an instruction with sev-
eral steps.
(Y
page) This symbol tells you where you can
find more information about a topic.
YY This symbol indicates a warning or an
instruction that is continued on the
next page.
Dis‐
Dis‐
play play This font indicates a display in the
multifunction display/COMAND dis-
play.
Parts of the software in the vehicle are pro-
tected by copyright ©
2005
The FreeType Project
http://www.freetype.org. All rights
reserved.
As at 29.10.2013
Page 16 of 406
Operation ......................................... 52
System self-test ...............................54
Occupant safety
Automatic measures after an acci-
dent .................................................59
Children in the vehicle .................... .59
Important safety notes .................... 43
Pets in the vehicle ........................... 65
PRE-SAFE ®
(anticipatory occu-
pant protection) ............................... 58
Seat belt .......................................... 44
OCS
Conditions ....................................... 51
Faults ............................................... 55
Operation .........................................52
System self-test ............................... 54
Odometer ........................................... 236
Oil see Engine oil
On-board computer
Assistance graphic menu ............... 243
Assistance menu ........................... 244
Displaying a service message ........ 329
Display messages .......................... 250
DISTRONIC PLUS ........................... 191
Factory settings ............................. 249
Head-up display ............................. 233
Important safety notes .................. 230
Instrument cluster menu ............... 248
Lights menu ................................... 247
Media menu ................................... 240
Menu overview .............................. 235
Message memory .......................... 250
Navigation menu ............................ 238
Operation ....................................... 231
Radio menu ................................... 240
Service menu ................................. 244
Settings menu ............................... 244
Standard display ............................ 236
Telephone menu ............................ 242
Trip menu ...................................... 236
Video DVD operation ..................... 241
Opening and closing the side trim
panels ................................................. 132
Operating safety Declaration of conformity ................ 26
Important safety notes .................... 25 Operating system
see On-board computer
Operator's Manual
Overview .......................................... 23
Vehicle equipment ........................... 23
Outside temperature display ........... 231
Overhead control panel ...................... 38
Override feature Rear side window s........................... 65 P
Paint code number ............................ 396
Paintwork (cleaning instructions) ... 332
Panic alarm .......................................... 42
Panorama roof with power tilt/
sliding panel
Important safety notes .................. 101
Opening/closing ............................ 103
Problem (malfunction) ................... 106
Resetting ....................................... 105
Parking
Important safety notes .................. 174
Parking brake ................................ 176
Position of exterior mirror, front-
passenger side ............................... 119
Rear view camera .......................... 207
see PARKTRONIC
Parking aid
Active Parking Assist ..................... 202
see Exterior mirrors
see PARKTRONIC
Parking assistance
see PARKTRONIC
Parking brake
Display message ............................ 254
Electric parking brake .................... 176
Warning lamp ................................. 290
Parking lamps
Switching on/of f........................... 126
PARKTRONIC
Deactivating/activating ................. 201
Driving system ............................... 199
Function/note s............................. 199
Important safety notes .................. 199
Problem (malfunction) ................... 202 14
Index
Page 17 of 406
Range of the sensors ....................
.199
Warning displa y............................. 200
PASSENGER AIR BAG
Indicator lamps ................................ 43
PASSENGER AIR BAG indicator
lamp
Problem (malfunction) ................... 263
Perfume atomizer
Operating ....................................... 150
Perfume vial ................................... 150
Problem (malfunction) ................... 152
Pets in the vehicle ............................... 65
Plastic trim (cleaning instruc-
tions) .................................................. 336
Power washers .................................. 331
Power windows see Side windows
PRE-SAFE ®
(anticipatory occupant
protection) Display message ............................ 259
Operation ......................................... 58
PRE-SAFE ®
Brake
Activating/deactivating ................. 245
Display message ............................ 259
Function/note s................................ 74
Important safety notes .................... 74
Warning lamp ................................. 293
PRE-SAFE ®
PLUS (anticipatory
occupant protection PLUS) Operation ......................................... 58
Protection against theft
ATA (Anti-Theft Alarm system) ......... 76
Immobilizer ...................................... 76
Protection of the environment
General notes .................................. 22
Pulling away
Automatic transmission ................. 160
Hill start assist ............................... 160 Q
Qualified specialist workshop ........... 26R
Radiator cover ................................... 325
Radio Selecting a station ......................... 240 Radio-wave reception/transmis-
sion in the vehicle
Declaration of conformity ................ 26
Reading lamp ..................................... 129
Rear compartment Setting the airflow ......................... 146
Setting the air vents ...................... 153
Setting the temperature ................ 145
Rear fog lamp
Switching on/of f........................... 125
Rear lamps
see Lights
Rear seat (folding the backrest for-
wards/back) ...................................... 302
Rear seats Display message ............................ 281
Rear view camera
Cleaning instructions ..................... 334
Function/note s............................. 207
Switching on/of f........................... 208
Rear-view mirror
Anti-glare (manual) ........................ 117
Dipping (automatic) ....................... 119
Rear window blind ............................ 308
Rear window defroster Problem (malfunction) ................... 149
Switching on/of f........................... 148
Recuperation display ........................ 236
Refrigerant (air-conditioning sys-
tem) Important safety notes .................. 402
Refueling
Fuel gauge ....................................... 33
Important safety notes .................. 171
Refueling process .......................... 172
see Fuel
Remote control
Garage door opener ....................... 318
Programming (garage door
opener) .......................................... 319
Replacing bulbs
General notes ................................ 130
Important safety notes .................. 130
Overview of bulb types .................. 130
Removing/replacing the cover
(front wheel arch) .......................... 131
Reporting safety defects .................... 27 Index
15
Page 20 of 406
Stowage well beneath the trunk
floor
....................................................3 05
Summer tires In winter ........................................ 360
Sun visor ............................................ 307
Suspension tuning AIRMATIC ...................................... 198
Switching air-recirculation mode
on/off ................................................. 149 T
Tachometer ........................................ 231
Tail lamps Display message ............................ 265
see Lights
Tank content
Fuel gauge ....................................... 33
Technical data
Capacities ...................................... 397
Information ................................... .396
Tires/wheels ................................. 386
Vehicle data ................................... 403
Telephone
Accepting a call (multifunction
steering wheel) .............................. 242
Display message ............................ 282
Introduction ................................... 242
Menu (on-board computer) ............ 242
Number from the phone book ....... .243
Redialing ........................................ 243
Rejecting/ending a call ................. 242
Temperature
Coolant (display in the instrumentcluster) .......................................... 231
Coolant (display in the on-board
computer) ...................................... 244
Outside temperature ..................... .231
Setting (climate control) ................ 145
Through-loading feature ................... 301
TIREFIT kit .......................................... 342
Tire pressure Calling up (on-board computer) ..... 365
Checking manually ........................ 365
Display message ............................ 277
Important safety notes .................. 365
Maximum ....................................... 364 Notes ............................................. 363
Not reached (TIREFIT) .................... 344
Reached (TIREFIT) .......................... 344
Recommended ............................... 361
Tire pressure loss warning sys-
tem
General notes ................................ 368
Important safety notes .................. 368
Restarting ...................................... 369
Tire pressure monitor
Checking the tire pressure elec-
tronically ........................................ 367
Function/notes ............................ .365
General notes ................................ 365
Important safety notes .................. 365
Radio type approval for the tire
pressure monitor ........................... 368
Restarting ...................................... 367
Warning lamp ................................. 294
Warning message .......................... 367
Tires
Aspect ratio (definition) ................. 380
Average weight of the vehicle
occupants (definition) .................... 379
Bar (definition) ............................... 378
Changing a wheel .......................... 381
Characteristics .............................. 378
Checking ........................................ 359
Curb weight (definition) ................. 380
Definition of terms ......................... 378
Direction of rotatio n...................... 381
Display message ............................ 277
Distribution of the vehicle occu-
pants (definition) ............................ 381
DOT, Tire Identification Number
(TIN) ............................................... 378
DOT (Department of Transporta-
tion) (definition) ............................. 379
GAWR (Gross Axle Weight Rating)
(definition) ..................................... 379
GVW (Gross Vehicle Weight) (def-
inition) ........................................... 379
GVWR (Gross Vehicle Weight Rat-
ing) (definition) .............................. 379
Important safety notes .................. 358
Increased vehicle weight due to
optional equipment (definition) ...... 379
Kilopascal (kPa) (definition) ........... 379 18
Index
Page 28 of 406
In situations like this, the body, the under-
carriage, chassis parts, wheels or tires
could be damaged without the damage
being visible. Components damaged in this way can unexpectedly fail or, in the case of
an accident, no longer withstand the strain
they are designed to.
If the underbody paneling is damaged,
combustible materials such as leaves,
grass or twigs can gather between the
underbody and the underbody paneling. If
these materials come in contact with hot
parts of the exhaust system, they can catch fire.
In such situations, have the vehicle
checked and repaired immediately at a
qualified specialist workshop. If on con-
tinuing your journey you notice that driving
safety is impaired, pull over and stop the
vehicle immediately, paying attention to
road and traffic conditions. In such cases,
visit a qualified specialist workshop. Declarations of conformity
Vehicle components which receive
and/or transmit radio waves USA:
"The wireless devices of this vehicle
comply with Part 15 of the FCC Rules. Oper-
ation is subject to the following two condi-
tions: 1) These devices may not cause harm-
ful interference, and 2) These devices must
accept any interference received, including
interference that may cause undesired oper-
ation. Changes or modifications not expressly approved by the party responsible for com-
pliance could void the user’s authority to
operate the equipment."
Canada: "The wireless devices of this vehicle
comply with Industry Canada license-exempt RSS standard(s). Operation is subject to the
following two conditions: (1) These devices
may not cause interference, and (2) These
devices must accept any interference, includ-
ing interference that may cause undesired
operation of the device." Diagnostics connection
The diagnostics connection is only intended
for the connection of diagnostic equipment at
a qualified specialist workshop. G
WARNING
If you connect equipment to the diagnostics
connection in the vehicle, it may affect the
operation of the vehicle systems. As a result, the operating safety of the vehicle could be
affected. There is a risk of an accident.
Do not connect any equipment to a diagnos-
tics connection in the vehicle. G
WARNING
Objects in the driver's footwell can restrict the pedal travel or obstruct a depressed pedal.
The operating and road safety of the vehicle is
jeopardized. There is a risk of an accident.
Make sure that all objects in the vehicle are
stowed correctly, and that they cannot enter
the driver's footwell. Install the floormats
securely and as specified in order to ensure
sufficient clearance for the pedals. Do not use loose floormats and do not place floormats on
top of one another.
! If the engine is switched off and equip-
ment on the diagnostics connection is
used, the starter battery may discharge.
Connecting equipment to the diagnostics
connection can lead to emissions monitoring information being reset, for example. This
may lead to the vehicle failing to meet the
requirements of the next emissions test dur-
ing the main inspection. Qualified specialist workshop
An authorized Mercedes-Benz Center is a
qualified specialist workshop. It has the nec-
essary specialist knowledge, tools and quali-
fications to correctly carry out the work
required on your vehicle. This is especially the case for work relevant to safety. 26
Introduction
Page 38 of 406
Center console
Center console, upper section
Function Page
0043
Climate control systems 138
0044
002F
Hazard warning
lamps 127
0087
Vehicle functions/system
settings button (see the
separate Operator's Man-
ual)
0085
Telephone button (see the
separate Operator's Man-
ual)
0083
PASSENGER AIR BAG indi-
cator lamp
43
ATA indicator lamp 76 Function Page
0084
Analog clock
006B
Media button (see the sep-
arate Operator's Manual)
006C
Radio button (see the sep-
arate Operator's Manual)
006D
Navigation button (see the
separate Operator's Man-
ual)
006E
00F8
Inserts/removes a
CD/DVD; see the separate
Operator's Manual) 36
Center consoleAt a glance
Page 82 of 406
Useful information
i This Operator's Manual describes all
models and all standard and optional equip- ment of your vehicle available at the time of
publication of the Operator's Manual.
Country-specific differences are possible.
Please note that your vehicle may not be
equipped with all features described. This
also applies to safety-related systems and
functions.
i Read the information on qualified special-
ist workshops (Y page 26). SmartKey
Important safety notes
G
WARNING
If children are left unsupervised in the vehicle, they could:
R open the doors, thus endangering other
people or road users.
R get out and disrupt traffic.
R operate the vehicle's equipment.
Additionally, children could set the vehicle in
motion if, for example, they:
R release the parking brake.
R shifting the automatic transmission out of
park position P
R Start the engine.
There is a risk of an accident and injury.
When leaving the vehicle, always take the
SmartKey with you and lock the vehicle. Never
leave children or animals unattended in the
vehicle. Always keep the SmartKey out of
reach of children. G
WARNING
If you attach heavy or large objects to the
SmartKey, the SmartKey could be uninten-
tionally turned in the ignition lock. This could
cause the engine to be switched off. There is a risk of an accident. Do not attach any heavy or large objects to the
SmartKey. Remove any bulky key rings before
inserting the SmartKey into the ignition lock.
! Keep the SmartKey away from strong
magnetic fields. Otherwise, the remote
control function could be affected.
Strong magnetic fields can occur in the
vicinity of powerful electrical installations.
Do not keep the SmartKey: R with electronic devices, e.g. a mobile
phone or another SmartKey
R with metallic objects, e.g. coins or metal
foil
R inside metallic objects, e.g. a metal case
This can affect the functionality of the
SmartKey.
Vehicles with KEYLESS-GO start function: do not keep the SmartKey on the parcel shelf or in the trunk. Otherwise, the SmartKey maynot be detected, e.g. when starting the engine
using the Start/Stop button.
A check which periodically establishes a radio
connection between the vehicle and the
SmartKey determines whether a valid Smart- Key is in the vehicle. This occurs, for example:
R when starting the engine
R whilst driving
R when the external door handles are
touched
R during convenience closing 80
SmartKeyOpening and closing
Page 83 of 406
SmartKey functions
0043
0037 Locks the vehicle
0044 0054 Opens/closes the trunk lid
0087 0036 Unlocks the vehicle
X To unlock centrally: press button0087.
If you do not open the vehicle within
approximately 40 seconds of unlocking:
R the vehicle is locked again.
R protection against theft is reactivated.
X To lock centrally: press button0043.
The SmartKey centrally locks/unlocks: R the doors
R the trunk lid
R the fuel filler flap
The turn signals flash once when unlocking
and three times when locking.
You can also set an audible signal to confirm that the vehicle has been locked. The audiblesignal can be activated and deactivated via
COMAND or Audio 20 (see the separate oper-
ating instructions).
When the locator lighting is activated via
COMAND or Audio 20, it lights up when it is
dark after the vehicle is unlocked with the
remote control (see the separate operating
instructions).
X To open the trunk lid automatically
from outside the vehicle: press and hold
button 0044until the trunk lid opens.
X To open the trunk lid automatically
from outside the vehicle: if the SmartKeyis in close proximity to the vehicle: press
the
0054 button on the SmartKey.
You can release the button as soon as the
trunk lid starts to close. KEYLESS-GO
General notes Bear in mind that the engine can be started by
any of the vehicle occupants if there is a
SmartKey in the vehicle.
Locking/unlocking centrally You can start, lock or unlock the vehicle using
KEYLESS-GO. To do this, you only need carry
the SmartKey with you. You can combine the
functions of KEYLESS-GO with those of a con- ventional SmartKey. Unlock the vehicle by
using KEYLESS-GO, for instance, and lock it
using the 0037button on the SmartKey.
The driver's door and the door at which the
handle is used, must both be closed. The
SmartKey must be outside the vehicle. When
locking or unlocking with KEYLESS-GO, the
distance between the SmartKey and the cor-
responding door handle must not be greater
than 3 ft (1 m).
A check which periodically establishes a radio
connection between the vehicle and the
SmartKey determines whether a valid Smart- Key is in the vehicle. This occurs, for example:
R when starting the engine
R whilst driving
R when the external door handles are
touched
R during convenience closing SmartKey
81Opening and closing Z
Page 87 of 406
Problems with the SmartKey
Problem
Possible causes/consequences and
0050
0050Solutions You can no longer lock
or unlock the vehicle
using the SmartKey. The SmartKey battery is discharged or nearly discharged.
X Check the SmartKey battery (Y page 84) and replace it if nec-
essary (Y page 84).
If this does not work:
X Unlock (Y page 88) or lock (Y page 89) the vehicle using the
mechanical key. There is interference from a powerful source of radio waves.
X Unlock (Y page 88) or lock (Y page 89) the vehicle using the
mechanical key. The SmartKey is faulty.
X Unlock (Y page 88) or lock (Y page 89) the vehicle using the
mechanical key.
X Have the SmartKey checked at a qualified specialist workshop. You can no longer lock
or unlock the vehicle
using KEYLESS-GO. KEYLESS-GO was deactivated.
X Reactivate KEYLESS-GO (Y page 81). The SmartKey battery is discharged or nearly discharged.
X Check the SmartKey battery (Y page 84) and replace it if nec-
essary (Y page 84).
If this does not work:
X Unlock (Y page 88) or lock (Y page 89) the vehicle using the
mechanical key. There is interference from a powerful source of radio waves.
X Unlock (Y page 88) or lock (Y page 89) the vehicle using the
mechanical key. KEYLESS-GO is malfunctioning.
X Lock/unlock the vehicle using the remote control function of
the SmartKey.
X Have the vehicle and SmartKey checked at a qualified specialist
workshop.
If the vehicle can also not be locked/unlocked using the remote
control function:
X Unlock (Y page 88) or lock (Y page 89) the vehicle using the
mechanical key.
X Have the vehicle and SmartKey checked at a qualified specialist
workshop. SmartKey
85Opening and closing Z
Page 88 of 406
Problem
Possible causes/consequences and
0050
0050Solutions The engine cannot be
started using the
SmartKey. The on-board voltage is too low.
X Switch off non-essential consumers, e.g. seat heating or interior
lighting, and try to start the engine again.
If this does not work:
X Check the starter battery and charge it if necessary
(Y page 347).
or
X Jump-start the vehicle (Y page 349).
or
X Consult a qualified specialist workshop. The engine cannot be
started using the Start/
Stop button. The
SmartKey is in the vehi-
cle. The vehicle is locked.
X Unlock the vehicle and try to start the vehicle again. The SmartKey battery is discharged or nearly discharged.
X Check the SmartKey battery (Y page 84) and replace it if nec-
essary (Y page 84).
If this does not work:
X Start your vehicle with the SmartKey in the ignition lock. There is interference from a powerful source of radio waves.
X Start your vehicle with the SmartKey in the ignition lock. You have lost a Smart-
Key. X
Have the SmartKey deactivated at a qualified specialist work-
shop.
X Report the loss immediately to the vehicle insurers.
X If necessary, have the locks changed as well. You have lost the
mechanical key. X
Report the loss immediately to the vehicle insurers.
X If necessary, have the locks changed as well. 86
SmartKeyOpening and closing
