Page 5 of 376
Contents
Opening and closing the roller sun-
blinds for the
panorama sliding/pop-up roof ..... 189
Opening and closing the
panorama sliding/pop-up roof ..... 190
Synchronizing the
panorama sliding / pop-up roof
and the roller sunblinds ............... 193
Driving systems ................................. 194
Cruise control .............................. 194
Loading.............................................. 197
Roof rack*.................................... 197
Luggage cover.............................. 197
Split rear bench seat .................... 197
Loading instructions..................... 199
Useful features .................................. 200
Interior storage spaces ................ 200
Ashtrays ....................................... 203
Cigarette lighter ........................... 204
Telephone* .................................. 205
Tele Aid* ...................................... 206
Garage door opener ..................... 214
Operation......................................... 221
The first 1000 miles (1500km) .......... 222Driving instructions ............................ 223
Drive sensibly – save fuel.............. 223
Drinking and driving ...................... 223
Pedals ........................................... 223
Power assistance .......................... 223
Brakes........................................... 224
Driving off ..................................... 225
Parking.......................................... 225
Tires .............................................. 226
Hydroplaning................................. 227
Tire traction .................................. 227
Tire speed rating ........................... 228
Winter driving instructions ............ 228
Standing water.............................. 229
Passenger compartment ............... 230
Driving abroad .............................. 230
Control and operation of
radio transmitter ........................... 230
Catalytic converter........................ 231
Emission control ........................... 231
Coolant temperature..................... 232
At the gas station ............................... 233
Refueling....................................... 233
Check regularly and
before a long trip .......................... 234
Engine compartment .......................... 236Hood ............................................. 236
Engine oil ...................................... 237
Transmission fluid level ................ 241
Coolant level ................................. 241
Battery .......................................... 242
Windshield washer system and
headlamp cleaning system ........... 243
Tires and wheels ................................ 244
Important guidelines ..................... 244
Life of tire ..................................... 245
Direction of rotation ..................... 245
Checking tire inflation pressure .... 245
Rotating wheels ............................ 246
Winter driving ..................................... 247
Winter tires ................................... 247
Block heater (Canada only) ........... 248
Snow chains ................................. 248
Maintenance ...................................... 249
Clearing the service indicator ....... 249
Service term exceeded ................. 249
Calling up the service indicator .... 250
Resetting the service indicator ..... 250
Vehicle care ....................................... 251
Cleaning and care of the vehicle ... 251
Page 223 of 376
223 Operation
Driving instructions
Driving instructions
Drive sensibly – save fuel
Fuel consumption, to a great extent, de-
pends on driving habits and operating con-
ditions.
To save fuel you should:
Keep tires at the recommended infla-
tion pressures
Remove unnecessary loads
Remove roof rack when not in use
Allow engine to warm up under low
load use
Avoid frequent acceleration and decel-
eration
Have all maintenance work performed
by qualified technicians at the intervals
specified in the Service Booklet and as
required by the FSS. Contact your au-
thorized Mercedes-Benz Center
Fuel consumption is also increased by driv-
ing in cold weather, in stop-and-go traffic,
on short trips and in hilly country.
Drinking and driving
PedalsPower assistance
Warning!
G
Drinking and driving and/or taking drugs
and driving are very dangerous combina-
tions. Even a small amount of alcohol or
drugs can affect your reflexes, perceptions
and judgement.
The possibility of a serious or even fatal ac-
cident are greatly increased when you drink
or take drugs and drive.
Do not drink or take drugs and drive or allow
anyone to drive who has been drinking or
taking drugs.
Warning!
G
Keep driver’s foot area clear at all times. Ob-
jects stored in this area may impair pedal
movement.Warning!
G
With the engine not running, there is no
power assistance for the brake and steering
systems. In this case, it is important to keep
in mind that a considerably higher degree of
effort is necessary to brake and steer the ve-
hicle.
Page 233 of 376
233 Operation
At the gas station
At the gas station
RefuelingThe fuel filler flap is located on the
right-hand side of the vehicle towards the
rear. Locking/unlocking the vehicle with
the remote control automatically
locks/unlocks the fuel filler flap.
Turn off the engine
Remove the SmartKey from the starter
switch.
Open the fuel filler flap by pushing at
the point indicated by the arrow.
The fuel filler flap springs open.
Turn the fuel cap to the left and hold on
to it until possible pressure is released.
Take off the cap and set it in the recess
on the fuel filler flap.
To prevent fuel vapors from escaping
into open air, fully insert filler nozzle
unit.
Only fill your tank until the filler nozzle
unit cuts out – do not top up or overfill.
Replace the fuel cap by turning it to the
right.
You should hear the fuel cap engage.
Close the fuel filler flap.
Warning!
G
Gasoline is highly flammable and poisonous.
It burns violently and can cause serious inju-
ry. Whenever you are around gasoline, avoid
inhaling fumes and skin contact, extinguish
all smoking materials. Never allow sparks,
flame or smoking materials near gasoline! Warning!
G
Flexible Fuel Vehicles (identified by a label
reading Premium gasoline or E85 only! on
fuel filler flap):
Ethanol fuel (E85) and its vapors are highly
flammable, poisonous and burn easily. Etha-
nol fuel can cause serious injuries if ignited
or if you come into contact with it or inhale
fumes of it. Avoid inhalation of Ethanol
fumes and skin contact with Ethanol. Extin-
guish all open flames before refueling. Never
smoke or create sparks close to Ethanol.
Warning!
G
Overfilling of the fuel tank may create pres-
sure in the system which could cause a gas
discharge. This could cause the gas to spray
back out when removing the fuel pump noz-
zle, which could cause personal injury.
Page 245 of 376
245 Operation
Tires and wheels
Life of tire
The service life of a tire is dependent upon
varying factors including but not limited to:
Driving style
Tire pressure
Distance driven
Direction of rotation
Unidirectional tires offer added advantag-
es, such as better aquaplaning perfor-
mance. To benefit, however, you must
ensure that the tires rotate in the direction
specified.
An arrow on the sidewall indicates the in-
tended direction of tire rotation.Checking tire inflation pressure
Correct the tire pressure only when tires
are cold.
Regularly check your tire pressure at inter-
vals of no more than 14 days. If the tires are warm you should only cor-
rect the tire pressure if it is too low for cur-
rent operating conditions.
A table on the fuel filler flap lists the spec-
ified tire inflation pressures for warm and
cold tires as well as for various operating
conditions.
Warning!
G
Tires and spare tire should be replaced after
six years, regardless of the remaining tread.!Keep unmounted tires in a cool, dry
place with as little exposure to light as
possible. Protect tires from contact
with oil, grease and gasoline.
Warning!
G
If the tire pressure drops repeatedly:
Check the tires for punctures from for-
eign objects.
Check to see whether air is leaking from
the valves or from around the rim.
iThe pressures listed for light loads are
minimum values offering high driving
comfort.
Increased inflation pressures listed for
heavier loads may also be used for light
loads. These higher pressures produce
favorable handling characteristics. The
ride of the vehicle, however, will be
somewhat harder. Never exceed the
max. values or inflate tires below the
min. values listed in the fuel filler flap.
Page 246 of 376
246 OperationTires and wheelsTire pressure changes by approximately
1.5 psi (0.1 bar) per 18°F (10°C) of air
temperature change. Keep this in mind
when checking tire pressure where the
temperature is different from the outside
temperature.
Tire temperature and tire pressure are also
increased while driving, depending on the
driving speed and the tire load.Check the spare tire periodically for condi-
tion and inflation. Spare tires will age and
b e c o m e w o r n o v e r t i m e e v e n i f n e v e r u s e d ,
and thus should be inspected and replaced
when necessary.
Rotating wheels
On vehicles with the same wheel size all
around, wheels can be rotated every 3000
to 6000 miles (5 000 to 10 000 km), or sooner if necessary, according to the de-
gree of tire wear. The same direction of tire
rotation must be retained.
Rotate the wheels before the characteris-
tic tire wear pattern becomes visible
(shoulder wear on front wheels and tread
center wear on rear wheels).
Thoroughly clean the inner side of the
wheels after each rotation. Check and en-
sure proper tire inflation pressure.
Warning!
G
Follow recommended inflation pressures.
Do not overinflate tires. Overinflating tires
can result in sudden deflation (blowout) be-
cause they are more likely to become punc-
tured or damaged by road debris, potholes,
etc.
Do not underinflate tires. Underinflated tires
wear unevenly, adversely affect handling
and fuel economy, and are more likely to fail
from being overheated.
Do not overload the tires by exceeding the
specified vehicle capacity weight (as indicat-
ed by the label on the pillar in the driver’s
door opening). Overloading the tires can
overheat them, possibly causing a blowout.Warning!
G
Rotate front and rear wheels only if they are
of the same size.
Warning!
G
Have the tightening torque checked after
changing a wheel. Wheels could become
loose if not tightened with a torque of
80 lb-ft (110 Nm).
Use only genuine Mercedes-Benz wheel
bolts specified for your vehicle's rims.
Page 305 of 376
305 Practical hints
Flat tire
Open flap1 on air pump.
Pull out electrical plug4 and air hose
with the pressure gauge2.
Observe instructions on air pump label.
Remove the valve cap from valve.
Screw the air hose2 on to the tire
valve.
Insert electrical plug4 into vehicle
cigarette lighter socket.
To switch on the air pump turn the
SmartKey in the starter switch to
position1 (
page 31).
Operate air pump until the pressure
gauge displays 36 psi (2.5 bar)
This takes about five minutes for the
space tire. The air hose2 and the
union nut3 can become hot during in-
flation.
To switch off the air pump turn the
SmartKey in the starter switch to
position0 (
page 31).
If the tire pressure is above 36 psi
(2.5 bar), release excess tire pressure
using the vent screw.
Detach the electric air pump.
Store the electrical plug and the air
hose behind the flap and place the air
pump back in the trunk.
!Do not operate the electric air pump
longer than eight minutes without in-
terruption. Otherwise it may overheat.
You may operate the air pump again af-
ter it has cooled off.
Warning!
G
Follow recommended inflation pressures.
Do not overinflate tires. Overinflated tires
can result in sudden deflation (blowout) be-
cause they are more likely to become punc-
tured or damaged by road debris, potholes,
etc.
Do not underinflate tires. Underinfalted tires
wear unevenly, adversely affect handling
and fuel economy, and are more likely to fail
from being overheated.
Do not overload the tires by exceeding the
specified vehicle capacity weight (as indicat-
ed by the label on the driver’s door latch
post). Overloading the tires can overheat
them, possibly causing a blowout.
Page 325 of 376
325 Technical data
Rims and Tires
Rims and Tires
Use only tires and rims which have been
specifically developed for your vehicle and
tested and approved by Mercedes-Benz.
Other tires and rims can have detrimental
effects, such as
poor handling characteristics
increased noise
increased fuel consumption
!Moreover, tires and rims not approved
by Mercedes-Benz may, under load, ex-
hibit dimensional variations and differ-
ent tire deformation characteristics
that could cause them to come into
contact with the vehicle body or axle
parts. This may result in damage to the
tires or the vehicle.
iFurther information on tires and rims is
available at any authorized Mercedes-
Benz Center. A tire inflation pressure
table is located on the fuel filler flap of
the vehicle. The tire pressure should be
checked regularly and should only be
adjusted on cold tires. Follow tire man-
ufacturer’s maintenance recommenda-
tion included with vehicle.
Page 333 of 376
333 Technical data
Fuels, coolants, lubricants, etc.
Premium unleaded gasoline
Fuel requirements
Use only premium unleaded meeting
ASTM standard D 439:
The octane number (posted at the
p um p) m us t be 91 mi n. It i s an a vera ge
of both the Research (R) octane num-
ber and the Motor (M) octane number:
(R+M) / 2). This is also known as the
ANTI-KNOCK INDEX.Unleaded gasoline containing oxygenates
such as ethanol, IPA, IBA and TBA can be
used provided the ratio of any one of these
oxygenates to gasoline does not exceed
10%; MTBE must not exceed 15%.
The ratio of methanol to gasoline must not
exceed 3% plus additional cosolvents.
Using mixtures of ethanol and methanol is
not allowed. Gasohol, which contains 10%
ethanol and 90% unleaded gasoline, can be
used.
These blends must also meet all other fuel
requirements, such as resistance to spark
knock, boiling range, vapor pressure, etc.
!To maintain the engine’s durability and
performance, premium unleaded gaso-
l i n e m u s t b e u s e d . I f p r e m i u m u n l e a d e d
is not available and low octane fuel is
used, follow these precautions:
Have the fuel tank only partially
filled with unleaded regular and fill
up with premium unleaded as soon
as possible.
Avoid full throttle driving and abrupt
acceleration.
Do not exceed an engine speed of
3000 rpm if the vehicle is loaded
with a light load such as two per-
sons and no luggage.
Do not exceed
2/3 of maximum ac-
celerator pedal position if the vehi-
cle is fully loaded or operating in
mountainous terrain.
iFlexible Fuel Vehicles (identified by a
label reading Premium gasoline or
E85 only! on fuel filler flap) are de-
signed to operate on premium unlead-
ed gasoline or Ethanol fuel (E85), or any
mixture of these two.
See notes on Flexible Fuel Vehicles
(page 334).
