MERCEDES-BENZ C240 4MATIC WAGON 2004 S203 Owner's Manual

201 Controls in detail
Sliding/pop-up roof*
Opening (Summer opening feature)
Press and hold buttonΠafter
unlocking the vehicle.
The windows and the sliding/pop-up
roof begin to open after approximately
one second.

Release theΠbutton to stop
procedure.Closing (Convenience feature)

Press and hold button‹ after
locking the vehicle.
The windows and the sliding/pop-up
roof begin to close after approximately
one second.

Release the‹ button to stop
procedure.
Make sure all side windows and the
sliding/pop-up roof are properly closed
before leaving the vehicle.
Synchronizing the sliding/pop-up roof
The power sliding/pop-up roof must be
resynchronized each time

after the battery has been
disconnected.


after the sliding/pop-up roof has been
closed manually.


if the sliding/pop-up roof does not
open smoothly.


after a malfunction.
Synchronizing

Switch on ignition.

Press and hold the switch in
direction1 until the sliding/pop-up
roof is fully raised at the rear.
Hold the switch for approximately one
second.
The sliding/pop-up roof is adjusted.

202 Controls in detailDriving systems
Driving systemsThe driving system of your vehicle is
described on the following pages:

Cruise control, with which the vehicle
can maintain a preset speed
For information on the BAS, ABS and ESP
driving systems, see “Driving safety sys-
tems” (
page 74).
Cruise control
Cruise control automatically maintains the
speed you set for your vehicle.
Use of cruise control is recommended for
driving at a constant speed for extended
periods of time. You can set or resume
cruise control at any speed over 20 mph
(30 km/h).
The cruise control function is operated by
means of the cruise control lever.
The cruise control lever is the uppermost
lever found on the left-hand side of the
steering column (
page 20).
Warning!
G
Cruise control is a convenience system de-
signed to assist the driver during vehicle op-
eration. The driver is and must remain at all
times responsible for the vehicle speed and
for safe brake operation.
Only use cruise control if the road, traffic
and weather conditions make it advisable to
travel at a steady speed.

The use of cruise control can be danger-
ous on winding roads or in heavy traffic
because conditions do not allow safe
driving at a steady speed.


The use of cruise control can be danger-
ous on slippery roads. Rapid changes in
tire traction can result in wheel spin and
loss of control.


Deactivate cruise control when driving
in fog.
The “Resume” function should only be oper-
ated if the driver is fully aware of the previ-
ously set speed and wishes to resume this
particular preset speed.

203 Controls in detail
Driving systems
1Set current or higher speed
2Set current or lower speed
3Cancel cruise control
4Resume at last set speed
Setting current speed
Accelerate or decelerate to the desired
speed.

Briefly lift1 or depress2 cruise
control lever.
The current speed is set.

Remove your foot from the accelerator
pedal.
Cruise control is activated.Canceling cruise control
There are several ways to cancel cruise
control:

Step on the brake pedal.
or

Briefly push cruise control lever to
position3.
Cruise control will be canceled. The
last speed set will be stored for later
use.iOn uphill or downhill grades, cruise
control may not be able to maintain the
set speed. Once the grade eases, the
set speed will be resumed.
!Moving gear selector lever to
positionN while driving also cancels
cruise control. However, the gear
selector lever should not be moved to
positionN while driving except to coast
when the vehicle is in danger of
skidding (e.g. on icy roads).iThe last stored speed is canceled when
you turn off the engine.

204 Controls in detailDriving systemsSetting a higher speed
Lift cruise control lever to position1
and hold it up until the desired speed is
reached.

Release cruise control lever.
The new speed is set.
Setting a lower speed

Depress cruise control lever to
position2 and hold it down until the
desired speed is reached.

Release cruise control lever.
The new speed is set.Fine adjustment in 1 mph
(Canada: 1 km/h) increments
Faster

Briefly tip cruise control lever in the
direction of arrow1.
Slower

Briefly tip cruise control lever in the
direction of arrow2.Setting to last stored speed (“Resume”
function)

Briefly push cruise control lever to
position4.
The cruise control will resume the last
set speed.

Remove your foot from the accelerator
pedal.
iDepressing the accelerator pedal does
not deactivate cruise control. After
brief acceleration (e.g. for passing),
cruise control will resume the last
speed set.
iWhen you use the cruise control lever
to decelerate, the transmission will
automatically downshift if the engine’s
braking power does not brake the
vehicle sufficiently.
Warning!
G
The speed stored in memory should only be
set again if prevailing road conditions per-
mit. Possible acceleration or deceleration
differences arising from returning to preset
speed could cause an accident and/or seri-
ous injury to you and others.

205 Controls in detail
Loading
Loading
Roof rack*
Attach the roof rack only to the roof
rails.

Secure the roof rack according to
manufacturer’s instructions for
installation.
Ski sack*
1Handle
2Cover
3Armrest
Unfolding and loading
Fold armrest3 down (arrow).

Pull handle1 and swing cover2
down.4Velcro strap

Unfasten velcro strap4.

Pull ski sack into passenger compart-
ment and unfold.
Warning!
G
Only use roof racks approved by
Mercedes-Benz for your vehicle model to
avoid damage to the vehicle. Follow manu-
facturer’s installation instructions.!Load the roof rack in such a way that
the vehicle cannot be damaged while
driving.
Make sure

you can fully raise the
sliding/pop-up roof*.


you can fully open the tailgate.


206 Controls in detailLoading5Button
Open tailgate.

Press button5.
The flap opens downward.

From cargo compartment, slide skis
into ski sack.6Strap

Tighten strap6 by pulling at the loose
end (arrow) until the skis in the ski sack
are tightly secured.
Warning!
G
The ski sack is designed for up to four pairs
of skis. Do not load the ski sack with other
objects.
Always fasten the ski sack securely. In an
accident, an unfastened ski sack can cause
injury to vehicle occupants.


207 Controls in detail
Loading
7Hook
8Eye
Connect hook7 to eye8.
Tighten strap by pulling at the loose
end (arrow).Unloading and folding

Loosen the straps.

Disconnect hook7 from eye8.

Unload skis.

Close flap in cargo compartment.

Fold and flatten ski sack lengthwise.

Place folded ski sack inside recess of
backrest.

Fasten velcro strap.

Close ski sack compartment cover.Removing the ski sack
You can remove the ski sack for cleaning
or drying.
1Button
2Ski sack frame
3Flap

Open tailgate.

Press button1.
The flap3 opens downward.

Press button1 firmly until ski sack
frame2 is released.

Pull ski sack frame2 with ski sack
out.

208 Controls in detailLoadingInstalling the ski sack
Install the ski sack in the reverse order.
Push ski sack frame2 with ski sack
inward until the ski sack frame snaps
into place.

Close flap3.

Close tailgate.
Parcel net in cargo compartment
There is a parcel net located on left side of
the cargo compartment. Dependent on the
equipment of your vehicle, there is another
parcel net located on right side of the car-
go compartment.
Removal of parcel net

Slide rails1 upward and remove.
Installation of parcel net

Place mounting lugs2 in opening.

Slide rails1 down as far as they can
go.
Warning!
G
Never drive vehicle with tailgate open while
the ski sack is removed. Deadly carbon
monoxide (CO) gases may enter vehicle in-
terior, resulting in unconsciousness and
death.
Warning!
G
T he p ar c el n e t i s de s ign e d on l y t o ca r ry li gh t
loads.
Do not place heavy or fragile objects, or ob-
jects having sharp edges, in the parcel net.
In an accident, during hard braking or sud-
den maneuvers, they could be thrown
around inside the vehicle, and cause injury
to vehicle occupants.

209 Controls in detail
Loading
Storage compartment under cargo compartment floor
To open cargo compartment floor
Press handle1 on the recess.

Lift compartment cover.To close cargo compartment floor

Lower the cover and lock by applying
light pressure to handle1.
Retractable luggage cover and
partition net
The twin-reel roller blind comprises a lug-
gage cover and a partition net. It is mount-
ed on the backrest of the rear seat and can
also be used with backrest folded down.Partition net
Partition net with rear seats folded up
1Tab
2Eyelets on roof

Pull out upper blind (safety net) by
tabs1.

Engage it into eyelets on the roof2.
iThe compartment can be used to store
small, light or flat objects.
Warning!
G
If items are stored in the compartment,
make sure compartment is securely closed.
In an accident, during hard braking or sud-
den maneuvers, they could be thrown
around inside the vehicle, and cause injury
to vehicle occupants.
Warning!
G
To help avoid personal injury during a colli-
sion or sudden maneuver, always use parti-
tion net when transporting cargo.

210 Controls in detailLoadingPartition net with rear seats folded
down
1Tab
2Eyelets on roof
Pull out upper blind (safety net) by
tabs1 until it engages.

Fold seat forward (
page 211).

Pull out upper blind fully.

Engage it into eyelets on the roof2.Luggage cover
Closing

Pull luggage cover back by handle1
until it locks into position.
Opening

Press handle1 down and release.
The luggage cover retracts automati-
cally.Twin-reel roller blind

Retract the safety net and luggage
cover.
Removing

Fold split rear bench seat forward
(page 211).

Slide twin-reel roller blind1 to left
and remove.
iWith the luggage cover rolled up, fold
the lip down.
