MERCEDES-BENZ C240 4MATIC WAGON 2004 S203 Owner's Manual

351 Technical data
Fuels, coolants, lubricants, etc.
When switching fuels, make sure:

Fuel level is below half full.


Fuel level is above reserve (fuel reserve
warning lamp is not lit).


Amount of added fuel is more than
5 gallons (20 liters).


Ignition is off during refill.


Immediately after refueling engine is
started and operated for at least five
minutes.
These precautions and recommendations
are supposed to prevent any difficulties
when starting and operating the engine
which otherwise may be experienced
before the engine has fully adapted to the
different fuel.
If in spite of these recommendations the
engine does not perform properly, adding
more gasoline [at least 3 gallons
(12 liters)] to the fuel may improve the
engine behavior.Cold weather performance
It is possible that starting times will signif-
icantly increase at temperatures
below 32°F (0°C). At low temperatures
the use of a block heater (Canada only) is
recommended (see your authorized
Mercedes-Benz Center for further
information). Rough idling may also be
experienced at such temperatures before
the engine is fully warmed up.
Hot weather performance
At ambient temperatures above 95°F
(35°C) start times may increase and be
accompanied by a rough idle following the
start.Cruising range
E85 fuel contains less energy per gallon
than gasoline. To ensure that engine per-
formance with ethanol fuel is similar to
that when using gasoline, the engine must
burn more ethanol fuel. As a result, it is to
be expected that the fuel consumption will
increase when using E85 compared to
gasoline operation.
Maintenance
Please inform your Mercedes-Benz Center
if you use or have used E85 fuel when your
vehicle is delivered for maintenance or
repairs.
!E85 fuel is unsuitable for use when
ambient temperatures fall below 14°F
(-10°C).
iUse of E85 may reduce your driving
range.

352 Technical dataFuels, coolants, lubricants, etc.Coolants
The engine coolant is a mixture of water
and anticorrosion/antifreeze, which
provides:

Corrosion protection


Freeze protection


Boiling protection (by increasing the
boiling point)
The cooling system was filled at the factory
with a coolant providing freeze protection
to approximately -22°F (-30°C) and
corrosion protection.
If the antifreeze mixture is effective
to -22°F (-30°C), the boiling point of the
coolant in the pressurized cooling system
is reached at approx. 266°F (130°C).The coolant solution must be used
year-round to provide the necessary corro-
sion protection and increase boil-over
protection. Refer to Service Booklet for
replacement interval.
Coolant system design and coolant used
stipulate the replacement interval. The
replacement interval published in the Ser-
vice Booklet is only applicable if MB 325.0
anticorrosion/antifreeze solution or other
Mercedes-Benz approved products of
equal specification (see Factory Approved
Service Products pamphlet) are used to re-
new the coolant concentration or bring it
back up to the proper level.
To provide important corrosion protection,
the solution must be at least 45%
anticorrosion/antifreeze [equivalent to
freeze protection to approx. - 22°F
(-30°C)]. If you use a solution that is more than 55%
anticorrosion/antifreeze [freeze
protection to approx. - 49°F (-45°C)], the
engine temperature will increase due to
the lower heat transfer capability of the
solution. Therefore, do not use more than
this amount of anticorrosion/antifreeze.
If the coolant level is low, water and
MB 325.0 anticorrosion/antifreeze should
be used to bring it up to the proper level
(have cooling system checked for signs of
leakage). Please make sure the mixture is
in accordance with label instructions.
The water in the cooling system must meet
minimum requirements, which are usually
satisfied by normal drinking water. If you
are not sure about the water quality,
consult your authorized Mercedes-Benz
Center.

353 Technical data
Fuels, coolants, lubricants, etc.
Anticorrosion/antifreeze
Your vehicle contains a number of
aluminum parts. The use of aluminum
components in motor vehicle engines
necessitates that anticorrosion/antifreeze
coolant used in such engines be specifi-
cally formulated to protect the aluminum
parts.Failure to use such anticorrosion/anti-
freeze coolant will result in a significantly
shortened service life.
Therefore, the following product is strongly
recommended for use in your vehicle:
Mercedes-Benz 325.0
Anticorrosion/Antifreeze Agent.Before the start of the winter season (or
once a year in hot southern regions), you
should have the anticorrosion/antifreeze
concentration checked. The coolant is also
regularly checked each time you bring your
vehicle to your authorized Mercedes-Benz
Center for service.
Anticorrosion/antifreeze quantityModel
Approx. freeze protection–35°F (–37°C)
–49°F (–45°C)
C 240/C 320 (all models)
3.4 US qt (3.2 l)
3.8 US qt (3.6 l)

354 Technical dataFuels, coolants, lubricants, etc.Windshield washer and headlamp cleaning* system
Both the windshield and headlamp washer
systems are supplied from the windshield
washer fluid reservoir.
The washer fluid reservoir has a capacity of
approx.:

3.2 US qt (3.0 l) in vehicles without
headlamp cleaning system*


6.4 US qt (6.0 l) in vehicles with
headlamp cleaning system*

Refill the reservoir with MB Windshield
Washer Concentrate and water
(or concentrate and commercially
available premixed windshield washer
solvent/antifreeze, depending on
ambient temperatures).Washer fluid mixing ratio
For temperatures above freezing, use
MB Windshield Washer Concentrate “S”
and water:


1 part “S” to 100 parts water
[40 ml “S” to 1 gallon (4.0 liters) water].
For temperatures below freezing, use
MB Windshield Washer Concentrate “S”
and commercially available premixed
windshield washer solvent/antifreeze:


1 part “S” to 100 parts solvent
[40 ml “S” to 1 gallon (4.0 liters) solvent].
Warning!
G
Washer solvent/antifreeze is highly flamma-
ble. Do not spill washer solvent/antifreeze
on hot engine parts, because it may ignite
and burn. You could be seriously burned.

355 Technical data
Consumer information
Consumer information
The following text is published as required
of all manufacturers of passenger cars
under Title 49, Code of U.S. Federal
Regulations, Part 575 pursuant to the
“National Traffic and Motor Vehicle Safety
Act of 1966”.Uniform tire quality grading
Quality grades can be found, where
applicable, on the tire sidewall between
tread shoulder and maximum section
width. For example:
All passenger car tires must conform to
federal safety requirements in addition to
these grades.Tread wear
The tread wear grade is a comparative
rating based on the wear rate of the tire
when tested under controlled conditions
on a specified government test course. For
example, a tire graded 150 would wear
one and one-half (1
1/2) times as well on
the government course as a tire
graded 100. The relative performance of
tires depends upon the actual conditions
of their use, however, and may depart
significantly from the norm due to varia-
tions in driving habits, service practices
and differences in road characteristics and
climate.Traction
The traction grades, from highest to lowest
are AA, A, B, and C. Those grades
represent the tire’s ability to stop on wet
pavement as measured under controlled
conditions on specified government test
surfaces of asphalt and concrete. A tire
marked C may have poor traction
performance.
Tread wear
Traction
Temperature
200
AA
A
Warning!
G
The traction grade assigned to this tire is
based on straight ahead braking traction
tests, and does not include acceleration,
cornering, hydroplaning, or peak traction
characteristics.

356 Technical dataConsumer informationTemperature
The temperature grades are A (the
highest), B, and C, representing the tire’s
resistance to the generation of heat and its
ability to dissipate heat when tested under
controlled conditions on a specified indoor
laboratory test wheel. Sustained high
temperature can cause the material of the
tire to degenerate and reduce tire life, and
excessive temperature can lead to sudden
tire failure. Grade C corresponds to a level
of performance which all passenger car
tires must meet under the Federal Motor
Vehicle Safety Standard No. 109.
Grades B and A represent higher levels of
performance on the laboratory test wheel
than the minimum required by law.
Warning!
G
The temperature grade for this tire is
established for a tire that is properly inflated
and not overloaded. Excessive speed,
underinflation, or excessive loading, either
separately or in combination, can cause
excessive heat build-up and possible tire
failure.

357 Technical terms
ABS
(A
ntilock B
rake S
ystem)
Prevents the wheels from locking up
during braking so that the vehicle can
continue to be steered.
Alignment bolt
Metal pin with thread. The centering
pin is an aid used when changing a tire
to align the wheel with the wheel hub.
BabySmart
TM1
airbag deactivation
system
This system detects if a special system
compatible child restraint seat is
installed on the front passenger seat.
The system will automatically deacti-
vate the passenger front airbag when
such a seat is properly installed
(PASS. AIRBAG OFF indicator lamp
located in the center console comes
on). See your authorized
Mercedes-Benz Center for availability.BabySmart
TM compatible child seats
Special restraint system for children.
The sensor system for the passenger
seat prevents deployment of the
passenger front airbag if a
BabySmartTM compatible child seat is
installed.
BAS
(B
rake A
ssist S
ystem)
System for potentially reducing braking
distances in emergency braking
situations. The system is activated
when it senses an emergency based on
how fast the brake is applied.
Bi-Xenon headlamps*
Headlamps which use an electric arc as
the light source and produce a more
intense light than filament headlamps.
Bi-Xenon headlamps produce low
beam and high beam.CAC
(C
ustomer A
ssistance C
enter)
Mercedes-Benz customer service
center, which can help you with any
questions about your vehicle and
provide assistance in the event of a
breakdown.
CAN system
(C
ontroller A
rea N
etwork)
Data bus network serving to control
vehicle functions such as door locking
or windshield wiping depending on
vehicle settings and/or ambient
conditions.
Cockpit
All instruments, switches, buttons and
indicator/warning lamps in the
passenger compartment needed for
vehicle operation and monitoring.
1BabySmart
TM is a trademark of Siemens
Automotive Corp.

358 Technical termsCOMAND*
(C
ockpit M
anagement and D
ata
System)
Information and operating center for
vehicle sound and communications
systems, including the radio and the
navigation system, as well as other
optional equipment (CD changer*,
telephone*, etc.).
Control system
The control system is used to call up
vehicle information and to change
component settings. Information and
messages appear in the multifunction
display. The driver uses the buttons on
the multifunction steering wheel to
navigate through the system and to
adjust settings.
Cruise control
Driving convenience system for
automatically maintaining the vehicle
speed set by the driver.Engine number
The number set by the manufacturer
and placed on the cylinder block to
uniquely identify each engine
produced.
Engine oil viscosity
Measurement for the inner friction
(viscosity) of the oil at different temper-
atures. The higher the temperature an
oil can tolerate without becoming thin,
or the lower the temperature it can
tolerate without becoming viscous, the
better the viscosity.
ESP
(E
lectronic S
tability P
rogram)
Improves vehicle handling and
directional stability.
ETD
(E
mergency T
ensioning D
evice)
Device which deploys in certain frontal
and rear collisions exceeding the
system's threshold to tighten the
seat belts.
->SRSFSS
(F
lexible S
ervice S
ystem)
Service indicator in the multifunction
display that informs the driver when
the next vehicle maintenance service
is due.
Gear range
Number of gears which are available to
the automatic transmission for shifting.
The automatic gear shifting process
can be adapted to specific operating
conditions using the gear selector
lever.
GPS
(G
lobal P
ositioning S
ystem)
Satellite-based system for relaying
geographic location information to and
from vehicles equipped with special
receivers. Employs CD digital maps for
navigation.

359 Technical terms
Instrument cluster
The displays and indicator/warning
lamps in the driver’s field of vision,
including the tachometer, speedo-
meter, engine temperature display and
fuel gauge.
Kickdown
Depressing the accelerator past the
point of resistance shifts the transmis-
sion down to the lowest possible gear.
This very quickly accelerates the
vehicle and should not be used for
normal acceleration needs.
Lock button
Button on the door which indicates
whether the door is locked or
unlocked. Pushing the lock button
down on an individual door from inside
will lock that door.
Memory function*
Used to store three individual seat,
steering wheel and mirror positions for
each SmartKey.Menu
The control system displays are
arranged in menus. Each menu
contains a number of commands for
particular systems. In the Audio menu,
for example, you will find the
commands
SELECT RADIO STATION
or
OPERATE CD PLAYER
. Using commands,
you can directly change the settings for
your vehicle.
MON
(M
otor O
ctane N
umber)
The Motor Octane Number for gasoline
as determined by a standardized
method. It is an indication of a
gasoline's ability to resist undesired
detonation (knocking). The average of
both the MON (Motor Octane Number)
and ->RON (Research Octane Number)
is posted at the pump, also known as
ANTI-KNOCK INDEX.Multifunction display
Display field in the instrument cluster
used to present information provided
by the control system.
Multifunction steering wheel
Steering wheel with buttons for
operating the control system.
Overspeed range
Engine speeds within the red marking
of the tachometer dial. Avoid this
engine speed range, as it may result in
serious engine damage that is not
covered by the Mercedes-Benz Limited
Warranty.
Poly-V-belt drive
Drives engine-components (alternator,
AC compressor, etc.) from the engine.

360 Technical termsPower train
Collective term designating all
components used to generate and
transmit motive power to the drive
axles, including


engine


clutch/torque converter


transmission


transfer case


drive shaft


differential


axle shafts/axles
Program mode selector switch
Used to switch the automatic trans-
mission between standard operationS
and comfort operationC.Remote Vehicle Diagnostics
Transmission of vehicle data and
current location to the Mercedes-Benz
Customer Assistance Center for
subscribers to Tele Aid service.
REST
(Residual engine heat utilization)
Feature that uses the engine heat
stored in the coolant to heat the
vehicle interior for a short time after
the engine has been turned off.
Restraint systems
Seat belts, belt tensioners, airbags and
child restraint systems. As inde-
pendent systems, their protective
functions complement one another.RON
(R
esearch O
ctane N
umber)
The Research Octane Number for gaso-
line as determined by a standardized
method. It is an indication of a gaso-
line's ability to resist undesired deto-
nation (knocking). The average of both
the ->MON (Motor Octane Number)
and RON (Research Octane Number) is
posted at the pump, also known as
ANTI-KNOCK INDEX.
Shift lock
When the vehicle is parked, this lock
prevents the transmission gear
selector lever from being moved out of
positionP without SmartKey turned
and brake pedal depressed.
SRS
(S
upplemental R
estraint S
ystem)
Seat belts, emergency tensioning
device and airbags. Though indepen-
dent systems, they are closely inter-
faced to provide effective occupant
protection.
