250 OperationAt the gas station
Open fuel filler flap by pushing at the
point indicated by the arrow.
The fuel filler flap springs open.

Turn fuel cap to the left and hold on to
it until possible pressure is released.

Take off cap and set it in the recess on
fuel filler flap.
To prevent fuel vapors from escaping
into open air, fully insert filler nozzle
unit.

Only fill your tank until the filler nozzle
unit cuts out – do not top up or overfill.

Replace fuel cap by turning it to the
right.
You will hear when fuel cap is
tightened.

Close fuel filler flap.Warning!
G
Overfilling of the fuel tank may create
pressure in the system which could cause a
gas discharge. This could cause the gas to
spray back out when removing the fuel
pump nozzle, which could cause personal
injury.
iOnly use premium unleaded gasoline
with a minimum Posted Octane Rating
of 91 (average of 96 RON/86 MON).
Information on gasoline quality can
normally be found on the fuel pump.
More information on gasoline can be
found in the Factory Approved Service
Products pamphlet.
Flexible Fuel Vehicles are identified by
a label reading Premium gasoline or
E85 only! on fuel filler flap.
For more information, see “Flexible
Fuel Vehicles” (
page 354).
iLeaving the engine running and the fuel
cap open can cause the? malfunc-
tion indicator lamp to illuminate.
For more information, see “Practical
hints” (
page 276).


363 Technical terms
Instrument cluster
The displays and indicator/warning
lamps in the driver’s field of vision,
including the tachometer, speedo-
meter, engine temperature display and
fuel gauge.
Kickdown
Depressing the accelerator past the
point of resistance shifts the transmis-
sion down to the lowest possible gear.
This very quickly accelerates the
vehicle and should not be used for
normal acceleration needs.
Lock button
Button on the door which indicates
whether the door is locked or
unlocked. Pushing the lock button
down on an individual door from inside
will lock that door.
Memory function*
Used to store three individual seat,
steering wheel and mirror positions for
each SmartKey.Menu
The control system displays are
arranged in menus. Each menu
contains a number of commands for
particular systems. In the Audio menu,
for example, you will find the
commands
SELECT RADIO STATION
or

OPERATE CD PLAYER
. Using commands,
you can directly change the settings for
your vehicle.
MON
(M
otor O
ctane N
umber)
The Motor Octane Number for gasoline
as determined by a standardized
method. It is an indication of a
gasoline's ability to resist undesired
detonation (knocking). The average of
both the MON (Motor Octane Number)
and ->RON (Research Octane Number)
is posted at the pump, also known as
ANTI-KNOCK INDEX.Multifunction display
Display field in the instrument cluster
used to present information provided
by the control system.
Multifunction steering wheel
Steering wheel with buttons for
operating the control system.
Overspeed range
Engine speeds within the red marking
of the tachometer dial. Avoid this
engine speed range, as it may result in
serious engine damage that is not
covered by the Mercedes-Benz Limited
Warranty.
Poly-V-belt drive
Drives engine-components (alternator,
AC compressor, etc.) from the engine.
