MERCEDES-BENZ C55AMG 2006 W203 Owner's Manual

140 Controls in detail
Control system
Time/Date submenu
Access the
Time/Date submenu via the
Settings menu. Use the Time/Date
submenu to change the instrument cluster
display settings.
The following functions are available:Time synchronization with head unit*
This function can only be seen on vehicles
with COMAND* and navigation module*.
Move the selection marker with
buttonæ orç to the
Time/Date
submenu.
Press buttonj ork repeatedly
until the message
Time synchro.
w/Head Unit
appears in the multifunc-
tion display.
The selection marker is on the current
setting.
Press buttonæ orç to select
the desired setting.Set the time (hours)
This function can be seen in vehicles with
audio system, or in vehicles with
COMAND* if the time synchronization with
head unit* feature was set to
Off.
Move the selection marker with
buttonæ orç to the
Time/Date
submenu.
Press buttonj ork repeatedly
until the message
Time Hours appears
in the multifunction display.
FunctionPage
Time synchronization with
head unit*140
Set time (hours)140
Set time (minutes)141
Select automatic time change
(Daylight Saving Time (DST)
summer/Standard time winter)142
Set date (month)142
Set date (day)143
Set date (year)143
i
Vehicles with COMAND*:
For information on setting the time,
refer to the separate COMAND
operating instructions.

141 Controls in detail
Control system
The selection marker is on the hour
setting.
Press buttonæ orç to set the
hour.Set the time (minutes)
This function can be seen in vehicles with
audio system, or in vehicles with
COMAND* if the time synchronization with
head unit* feature was set to
Off.
Move the selection marker with
buttonæ orç to the
Time/Date
submenu.
Press buttonj ork repeatedly
until the message
Time Minutes
appears in the multifunction display.The selection marker is on the minute
setting.
Press buttonæ orç to set the
minutes.
i
Vehicles with COMAND*:
For information on setting the time,
refer to the separate COMAND
operating instructions.

142 Controls in detail
Control system
Select automatic time change (Daylight
Saving Time (DST) summer/Standard
time winter)
This function can be seen in vehicles with
audio system, or in vehicles with
COMAND* if the time synchronization with
head unit* feature was set to
Off.
Move the selection marker with
buttonæ orç to the
Time/Date
submenu.
Press buttonj ork repeatedly
until the message
Change-over
Summer / Winter time
appears in the
multifunction display.
The selection marker is on the current
setting.
Press buttonæ orç to select if
the changeover between summer and
winter time should be automatic or
manual.
Set the date (month)
This function can be seen in vehicles with
audio system, or in vehicles with
COMAND* if the time synchronization with
head unit* feature was set to
Off.
Move the selection marker with
buttonæ orç to the
Time/Date
submenu.
Press buttonj ork repeatedly
until the message
Date Set MM appears
in the multifunction display.
The selection marker is on the month
setting.
Press buttonæ orç to set the
month.
i
Vehicles with COMAND*:
For information on setting the date,
refer to the separate COMAND
operating instructions.

143 Controls in detail
Control system
Set the date (day)
This function can be seen in vehicles with
audio system, or in vehicles with
COMAND* if the time synchronization with
head unit* feature was set to
Off.
Move the selection marker with
buttonæ orç to the
Time/Date
submenu.
Press buttonj ork repeatedly
until the message
Date Set day
appears in the multifunction display.The selection marker is on the day
setting.
Press buttonæ orç to set the
day.Set the date (year)
This function can be seen in vehicles with
audio system, or in vehicles with
COMAND* if the time synchronization with
head unit* feature was set to
Off.
Move the selection marker with
buttonæ orç to the
Time/Date
submenu.
Press buttonj ork repeatedly
until the message
Date Set YY appears
in the multifunction display.
i
Vehicles with COMAND*:
For information on setting the date,
refer to the separate COMAND
operating instructions.
i
Vehicles with COMAND*:
For information on setting the date,
refer to the separate COMAND
operating instructions.


144 Controls in detail
Control system
The selection marker is on the year
setting.
Press buttonæ orç to set the
year.Lighting submenu
Access the
Lighting submenu via the
Settings menu. Use the Lighting
submenu to change the lamp and lighting
settings on your vehicle.
The following functions are available:Set daytime running lamp mode
(USA only)
Move the selection marker with
buttonæ orç to the
Lighting
submenu.
Press buttonj ork repeatedly
until the message
Hdlamp mode appears
in the multifunction display.
FunctionPage
Set daytime running lamp mode
(USA only)144
Set locator lighting145
Set night security illumination146
Set interior lighting delayed
shut-off147
i
This function is not available in
countries where the daytime running
lamp mode is mandatory and therefore
in a constant mode.


145 Controls in detail
Control system
The selection marker is on the current
setting.
Press buttonæ orç to select
manual operation (
Manual) or daytime
running lamp mode (
Constant)
activated.
With daytime running lamp mode activated
and the exterior lamp switch in
positionM orU, the low beam
headlamps are switched on when the
engine is running.In low ambient light conditions the
following lamps will switch on additionally:

Parking lamps

Tail lamps

License plate lamps

Side marker lamps
For more information on the daytime
running lamp mode, see “Lighting”
(
page 114).Set locator lighting
With the locator lighting feature activated
and the exterior lamp switch in
positionU, the following lamps will
switch on during darkness when the vehi-
cle is unlocked with the SmartKey:

Parking lamps

Tail lamps

License plate lamps

Side marker lamps

Front fog lamps
The locator lighting switches off when the
driver’s door is opened.
If you do not open a door after unlocking
the vehicle with the SmartKey, the lamps
will switch off automatically after approxi-
mately 40 seconds.
Move the selection marker with
buttonæ orç to the
Lighting
submenu.
i
For safety reasons, resetting the set-
tings to factory settings (
page 135)
while driving will not deactivate the
daytime running lamp mode.
The following message appears in the
multifunction display:
Lighting - Cannot be completely
reset to factory sets. while
driving.


146 Controls in detail
Control system
Press buttonj ork repeatedly
until the message
Surround lighting
appears in the multifunction display.
The selection marker is on the current
setting.
Press buttonæ orç to switch
the locator lighting function
On.
Turn the exterior lamp switch to
positionU when exiting the vehicle
(
page 114).
The locator lighting feature is
activated.Set night security illumination
(Headlamps delayed shut-off)
Use this function to set whether or not the
exterior lamps illuminate during darkness
after exiting the vehicle and all doors
closed.
With the delayed shut-off feature activated
and the exterior lamp switch in
positionU before the engine is turned
off, the following lamps will switch on
when the engine is turned off and remain
lit for approximately 15 seconds:

Parking lamps

Tail lamps

License plate lamps

Side marker lamps

Front fog lamps
If after turning off the engine you do not
open a door or do not close an opened
door, the lamps will automatically switch
off after 60 seconds.
Move the selection marker with
buttonæ orç to the
Lighting
submenu.
Press buttonj ork repeatedly
until the message
Hdlamp delay off
appears in the multifunction display.
The selection marker is on the current
setting.
i
You can reactivate this function within
10 minutes by opening a door.


147 Controls in detail
Control system
Press buttonæ orç to switch
the delayed shut-off feature
Off or On.
Turn the exterior lamp switch to
positionU before turning off the
engine (
page 114).
The headlamps delayed shut-off
feature is activated.
You can temporarily deactivate the
delayed shut-off feature:
Before exiting the vehicle, turn the
SmartKey in the starter switch to
position0.
Then turn it to position2 and back to
position0.
The delayed shut-off feature is
deactivated. It will reactivate as soon
as you reinsert the SmartKey in the
starter switch.Set interior lighting delayed shut-off
Use this function to set whether or not the
interior lighting to remains lit during dark-
ness for approximately 10 seconds after
you have removed the SmartKey from the
starter switch.
Move the selection marker with
buttonæ orç to the
Lighting
submenu.
Press buttonj ork repeatedly
until the message
Int. light delay
off
appears in the multifunction
display.
The selection marker is on the current
setting.
Press buttonæ orç to switch
the delayed shut-off feature
Off or On.
Vehicle submenu
Access the
Vehicle submenu via the
Settings menu. Use the Vehicle submenu
to make general vehicle settings.
The following function is available:
Set automatic locking
Use this function to activate or deactivate
the automatic central locking. With the
automatic central locking system
activated, the vehicle is centrally locked at
vehicle speeds of approximately 9 mph
(15 km/h).
Move the selection marker with
buttonæ orç to the
Vehicle
submenu.
FunctionPage
Set automatic locking147


148 Controls in detail
Control system
Press buttonj ork repeatedly
until the message
Automatic door lk.
appears in the multifunction display.
The selection marker is on the current
setting.
Press buttonæ orç to switch
the automatic central locking
On or Off.Convenience submenu
Access the
Convenience submenu via the
Settings menu. Use the Convenience
submenu to change the settings for a
number of convenience features.
The following functions are available:Activate easy-entry/exit feature
Use this function to activate and
deactivate the easy-entry/exit feature
(
page 39).
FunctionPage
Activate easy-entry/exit feature148
Set parking position for exterior
rear view mirror149
Warning!G
You must make sure no one can become
trapped or injured by the moving steering
wheel when the easy-entry/exit feature is
activated.
To cancel steering wheel movement, do one
of the following:

Move steering column stalk
(
page 38).

Press memory position switch
(
page 112).
Do not leave children unattended in the ve-
hicle, or with access to an unlocked vehicle.
Children could open the driver’s door and
unintentionally activate the easy-entry/exit
feature, which could result in an accident
and/or serious personal injury.


149 Controls in detail
Control system
Move the selection marker with
buttonæ orç to the
Convenience submenu.
Press buttonj ork repeatedly
until the message
Easy-entry feature
appears in the multifunction display.
The selection marker is on the current
setting.
Press buttonæ orç to switch
the easy-entry feature
On or Off.Set parking position for exterior rear
view mirror
Use the
Mirror set. parking aid function
to select whether the passenger-side
exterior rear view mirror should be turned
downward during parking maneuvers when
reverse gearR is engaged. For additional
information, see “Activating exterior rear
view mirror parking position”
(
page 170).
Move the selection marker with
buttonæ orç to the
Convenience submenu.
Press buttonj ork repeatedly
until the message
Mirror set.
parking aid
appears in the
multifunction display.
The selection marker is on the current
setting.
Press buttonæ orç to switch
function
On or Off.
