MERCEDES-BENZ CL-Class 2001 C215 Comand Manual

Telephone
Introduction
AudioTelephone
Navigation
Index Info Services and
system settings Telephone9911Main telephone menu with other menu fields can
be activated via the “
” symbol
12SMS list, page 133
An SMS message can be read or deleted in the
sequence menus
13“Service No.” menu, page 139
Selecting a service number for an outgoing call or
changing a service number
14Notebook, page 124
Noting a telephone number during a call
Dialing from the notebook
15“Calls” function, page 120
The last incoming calls are stored
16Redial memory, the last 10 (L01-L10) numbers
dialed are stored
L01, last number or name dialed
L01-L10 – numbers or names dialed previously,
page 108
17Telephone menu for entering telephone numbers,
page 106
Switch back to the main telephone menu via the
“ABC/123” menu field 1Main telephone menu
2Telephone system is active
3Accepting calls on COMAND, page 103
Begin dialing, page 107
4Ending a call, page 108
5Microphone mute, page 104
6Reception quality is indicated by up to 5 bars for a
connected and functional telephone
– incoming SMS message, page 132
ROAM indicator:
RM in black – telephone is using a home type system
RM in red – telephone is using a non home type
system
No RM – telephone is using the home system
7Input line
8Alphabet
9Menu fields for activating sub-menus
10“Phone book” selection menu, page 112
Can be activated when the input line is empty
Phone book with names, page 112
Activation according to input of up to 3 letters

100 Telephone
Introduction AudioTelephone
Navigation
Index Info Services and
system settings
Switching telephone operation on
1Status line, telephone not yet logged onto network
2Input line for unlock code
Press
, the menu for entering the unlock code will
appear.
Entering the unlock code
Use the number keys
through
to enter the
unlock code. Asterisks will appear in place of the digits
in the input line.If entered code is correct and the phone is registered in
a network, the phone is ready for use.
Notes:
Your unlock code prevents unauthorized persons from
using your telephone. Be sure to memorize this code, a
three digit number, carefully.
If you enter an incorrect code, the systems returns to
the menu for entering the unlock code.
The unlock code must be entered when the telephone is
switched on for the first time (if phone is in locked
mode), but not if you switch to it from another system
(i.e. navigation).
“No Service” – This message will appear in case the
phone is not registered in a network or the network is
no longer available due to weak signal conditions.
Switching telephone operation off
The phone can be switched by pressing the
button
(when connected to the coiled cord) or the button
(when in portable mode).
P82.85-6059-26
2
1

Telephone
Introduction
AudioTelephone
Navigation
Index Info Services and
system settings Telephone101If the phone memory has been downloaded to
COMAND, the menu fields “Phone Book”, “Last Calls”
and “Calls” will be available. If the memory was not
downloaded, the menu fields will be dimmed out.
Outgoing calls, page 106.
3Telephone is ready for operation,
the “Send” button is highlighted
4Reception quality is indicated by up to 5 bars,
RM will be shown, if you are not in a home system
P82.85-6060-26
3
4

102 Telephone
Introduction AudioTelephone
Navigation
Index Info Services and
system settings
Incoming calls
Accepting a call using the multifunction steering
wheel
1“Call” – the system detects an incoming call, the
phone rings
Accepting a call:
Press
, audio source is automatically muted.
Refusing a call:
Press .
Ending a call:
Press , audio source is restored.
The main telephone display appears.Communication between the multifunction display and
the COMAND screen:
If different systems are displayed, the changes made to
COMAND will have no effect on the driver information
display.
Press the COMAND key marked
to switch to the
telephone functions.
P82.85-6055-21

Telephone
Introduction
AudioTelephone
Navigation
Index Info Services and
system settings Telephone103 Accepting calls using COMAND
2“Call” – the system detects an incoming call, the
phone rings
If no telephone menu is shown on the screen press
if the phone is ringing. The above menu appears.Accepting a call:
Confirm the “Send” button by pressing the rotary/
pushbutton
. An audio source will switch to mute.
Refusing a call, use one of the three ways:
• Press the rotary/pushbutton
to confirm the “End” button
• Press
• Press
.
P82.85-6061-26
2

104 Telephone
Introduction AudioTelephone
Navigation
Index Info Services and
system settings
Ending a call, use one of the three ways:
• Press the rotary/pushbutton
to confirm the
“End” button
• Press
• Press
.
The main telephone menu will reappear.
Important!
If the menu of a different system is displayed on the
COMAND screen and/or the multifunction display, it is
possible to accept an incoming call by pressing
on
the steering wheel, page 86.
Note:
There is an incoming calls memory list. You can
activated the list by using the “Calls” menu field,
page 120. 3“00:01:21 h” – the call time appears
Switching the microphone for the hands-free telephone
off:
Use the rotary/pushbutton
to highlight the “Mute”
button and confirm by pressing.
Volume set for hands-free operation:
Press
– raising the volume
Press – lowering the volume
P82.85-6062-26
3

Telephone
Introduction
AudioTelephone
Navigation
Index Info Services and
system settings Telephone105 Accepting an incoming call using the mobile
telephone handset
The telephone is installed in the storage compartment
under the armrest, see your vehicle’s operating instruc-
tions.
Press the rotary/pushbutton
to confirm the “Send”
button.
Remove the telephone from its cradle and conduct your
call. Hands-free operation will switch off.
Ending a call:
Put the phone back in its mount.
Warning!
Please be sure to pay attention to the traffic
situation at all times. Use the mobile telephone
1
only when the traffic situation allows.
Some jurisdictions prohibit the driver from using
a cellular telephone while driving a vehicle.
Whether or not prohibited by law, for safety
reasons, the driver should not use the cellular
telephone while the vehicle is in motion. Stop the
vehicle in a safe location before answering or
placing a call.1 Observe all legal requirements.

106 Telephone
Introduction AudioTelephone
Navigation
Index Info Services and
system settings
Dialing a telephone number
Entering a telephone number
Press
. The main telephone menu will appear.
Enter the telephone number with the number keys
through
. The menu will change when the
first digit is entered.
Correcting input:
• Press
briefly or use the rotary/pushbutton
to highlight the back arrow and confirm by
pressing – the last digit will be corrected
• Press
longer than 2 seconds – the whole entry
will be corrected. Outgoing calls
You can use the following functions:
• Dialing a telephone number, page 106
• Dialing a number from phone book, page 109
• Redial, page 116
• Dialing from calls list, page 120
• Speed-dialing (only with COMAND), page 121
• Quick-dialing (for the first 10 memory locations),
page 123
• Emergency call, page 136
P82.85-6063-26

Telephone
Introduction
AudioTelephone
Navigation
Index Info Services and
system settings Telephone107 Begin dialing
1If the number together with a name is stored in the
phone book, the name is displayed on the screen
after the “Send” button is pressed.
When the “Send” button is highlighted, press the
rotary/pushbutton
and confirm your entry.
Dialing will begin. The “End” button is marked (high-
lighted).
An active audio source will automatically be muted.Interrupt dialing, use one of the three ways:
• Press the rotary/pushbutton
to confirm the
“End” button
• Press
• Press
.
P82.85-6064-26
1

108 Telephone
Introduction AudioTelephone
Navigation
Index Info Services and
system settings
Conducting a callSubsequent dialing:
During a call you can press the number keys
through
,
and
to transmit other DTMF
tones.
The numbers dialed will appear in the menu for
10 seconds after the last key is pressed (subsequent
dialing display).
When the call is answered, the call time will appear on
the screen.
Ending a call, use one of the three ways:
• Press the rotary/pushbutton
to confirm the
“End” button or call has been finished by the other
party
• Press
• Press
.
P82.85-6065-26
