MERCEDES-BENZ CL-Class 2003 C215 Comand Manual

133 Navigation
Destination input
Altering the map scale
8Scale selector
Current map scale _
New map scale ?
9Square shows the map section which is
to be increasedZooming in for more detailed map

Press %.
The scale selector will appear and
show the current _ and the next larger
scale ?.
Square 9 shows the map detail which
is to be recalculated.

Press the right-hand rotary/push-
button v.
iAs you move the crosshairs towards the
edge of the screen using the number
keys, an adjacent section of the map is
activated. It may take a few seconds to
point to each new map.
Adjacent map sections overlap some-
what so that destinations at the edge of
the map can be marked as well.
P82.85-9442-31USP82.85-9442-31US
139
RESERVOIR NO 3
1
0.5 mi
0.05mi 5 mi 500 mi
8
9
iYou can continue to increase the scale
within 5 seconds
Press key %.

Turn the right-hand rotary/push-
button v to the left.
A division mark corresponds to an avai-
lable scale. You can select 13 different
scales ranging from 0.05 miles/inch to
500 miles/inch.

134 NavigationDestination input
Press the right-hand rotary/push-but-
ton v or wait 6 seconds to calculate
the map with the new scale.
A clock symbol will appear on the top
right of the display, the square will be
masked.Zooming out for less detailed map

Press /.
The scale selector will appear and
show the current _ and the next smal-
ler scale ?.

Press the right-hand rotary/push-but-
ton v or wait 6 seconds to calculate
the map with the new scale.
A clock symbol will appear on the top
right of the display.Confirming destination and calculating
route
The crosshairs highlight the desired desti-
nation

Press the right-hand rotary/push-
button v longer than 2 seconds.

Then calculate the route (
page 141).
iYou can continue to decrease the scale
within 5 seconds
Press /.

Turn the right-hand rotary/push-
button v to the right.

135 Navigation
Destination input
Destination entry via coordinates
You can enter a destination if the corres-
ponding coordinates are known.“Coordinate Destination” menu
Turn the right-hand rotary/push-button
v to highlight “Coordinate Destinati-
on...” in the Destination via Map menu
(page 131) and press to confirm.
The “Coordinate Destination” input
menu will appear.

Enter coordinates with the number
keys.
Activating the adjustment mode and alte-
ring the setting

Press the right-hand rotary/push-
button v.

Turn the right-hand rotary/push-button
v.
or

Enter coordinates with the number
keys.
Store the new setting and move the mar-
king to the next entry

Press the right-hand rotary/push-
button v and turn the button.

Subsequently repeat operating se-
quence and enter coordinates comple-
tely.Changing between western (W) and eas-
tern (E) longitude

Press / repeatedly.
Changing between northern (N) and
southern (S) latitude

Press % repeatedly.
NAVI Coordinate DestnLongitude
° 58´ 14.9´´ W
Latitude
040° 45´ 28.5´´ N 073
P82.85-9443-31US
iAdjustment range
Longitude (W - West or E - East)
0-179° 0-59 min
0-59 s 0.1-0.9 s

Latitude (N - North or S - South)
0-89° 0-59 min
0-59 s 0.1-0.9 s

136 NavigationDestination inputConfirming coordinate destination and
calculate the route
Press the right-hand rotary/push-
button v longer than 2 seconds.
A selection menu appears showing the
entry “Coordinate Destn”.

Press the right-hand rotary/push-but-
ton v and confirm “OK”.

Then calculate the route (
page 141).In the selection menu you can also

store the coordinate destination in the
destination memory with a name
Turn the right-hand rotary/push-
button v to highlight “Save” and
press to confirm.
The input menu “Save destination”
will appear (
page 174).

Enter the name and then calculate
the route.

activate the map with crosshairs
Turn the right-hand rotary/push-
button v to highlight “Map” and
press to confirm.
This will activate the map
(page 132), the crosshairs high-
light the entered destination.

Press the right-hand rotary/push-
button v to confirm the destinati-
on.
or

Move the crosshairs to the position
you want (
page 132) and press
the right-hand rotary/push-button
v to confirm.

Then calculate the route
(page 141).

137 Navigation
Destination input
This function allows you to select Points of
Interest such as gas stations, parking faci-
lities or shopping centers.“Points of Interest” selection menuSelect a Point of Interest
1Around the current area of vehicle loca-
tion
2Around the previous destination area
3In the surrounding area of another city
4As regional destination, e.g. airport

Turn the right-hand rotary/push-button
v to highlight “Special destinations”
in the main destination input menu and
press to confirm.
The selection menu “Point of Interest”
will appear.

Turn the right-hand rotary/push-button
v to highlight 1 to 4 and press to
confirm.
1, 2, 4 A Category list will appear
3 The input menu “City/Area”
will appear (
page 139)Around the current area of vehicle loca-
tion or previous destination area
Category list5Top of list - or display
previous page =
6Displays next page ? or end of list _
Entering Points of Interest
P82.85-9444-31US
NAVI Points of InterestAround Current Location...
Around Previous Destn...
Select City...
Regional...
12
3
4
P82.85-9445-31US
NAVI Select Category
56
Airports...
Car Rental...
Exhibition Centers...
Freeway...
Railway Stations... Gas Stations...

138 NavigationDestination input
Turn the right-hand rotary/push-button
v to highlight 1 or 2 and press to
confirm.
The list “Select Category” will appear.

Turn the right-hand rotary/push-button
v to highlight the desired category
and press to confirm.
A corresponding list will appear.
7Point of Interest entry with distance to
destination in miles (as the crow flies)
8Symbol for long entry
9Complete entry in a windowDisplay the complete entry in a window 9

Press u.

Press u again to remove 9.
Selecting the desired destination

Turn the right-hand rotary/push-button
v to highlight the entry in the selec-
tion list and press to confirm.

Then calculate the route (
page 141).
iNot all Points of Interest may be listed
on the CD.
P82.85-9446-31US
NAVI Railway Station
1.1 mi GRAND CENTRAL TER
1.0 KM
1.0 KM
1.0 KM
1.1 mi
GRAND CENTRAL
TERMINAL
7
8
9

139 Navigation
Destination input
In the surrounding area of another city“City/Area” input menu
Turn the right-hand rotary/push-button
v to highlight “Select City...” in the
Points of Interest menu and press to
confirm.
The input menu “City/Area” will ap-
pear.

Select the city and activate the city list
(page 125).

Turn the right-hand rotary/push-button
v to highlight the desired destination
in the city list and press to confirm.
The list “Select Category” will appear.

Turn the right-hand rotary/push-button
v to highlight the desired category
and press to confirm.
A corresponding list will appear.

Select the desired destination.

Then calculate the route (
page 141).Regional destinations

Turn the right-hand rotary/push-button
v to highlight “Regional...” in the
Points of Interest menu and press to
confirm.
The list “Select Category” will appear.
P82.85-9447-31US
NAVI City/AreaABCDE GHIJKLM
PQ S UVWXYZ
_1234567890,.
:‘/FNO
R BOSTON
City List
T
iIf several options of a city/suburb are
available, another menu will appear
where you must make and confirm your
desired selection.iNot all Points of Interest may be listed
on the CD.
iNot all Points of Interest may be listed
on the CD.
P82.85-9448-31US
NAVI City/Select Category
Airports...

140 NavigationDestination input
Turn the right-hand rotary/push-button
v to highlight the desired category
and press to confirm.
An input menu, e.g. “Airport” will ap-
pear.

Select an entry (
page 124) and then
activate the list.Activating the list

Press the right-hand rotary/push-
button v longer than 2 seconds.
or

Turn the right-hand rotary/push-button
v to highlight “List” and press to con-
firm.
The list will appear.

Turn the right-hand rotary/push-button
v to highlight the desired entry and
press to confirm.

Then calculate the route (
page 141).
P82.85-9449-31US
NAVI AirportABCDEFGHIJKLMNO
PQRSTUVWXYZ
1234567890,.
:‘/ _ JOHN F KENNEDY INT’LAIRPORT
List
P82.85-9450-31US
NAVI Airport ListJOHN F KENNEDY INT’L AIR
JOHN F KENNEDY INT’L
JFK EX
JOHN F KENNEDY INT’L
VAN
KUPPER AIRPORT (51, SOHO)
LA GUARDIA AIRPORT

141 Navigation
Destination input
This function allows you to display up to 12
destinations you last selected.
1Destination selected last

Turn the right-hand rotary/push-button
v to highlight “Last destinations...” in
the main destination input menu and
press to confirm.
The list “Last destinations...” will ap-
pear.

Turn the right-hand rotary/push-button
v to highlight the desired destination
and press to confirm.

Then calculate the route.First select the calculation mode and then
calculate your route.
Selecting calculation mode
COMAND calculates the route either as
the Fast Route or Short Route 1 whereby
traffic routes 2 can be included or avoi-
ded (with several selections).
1Route types
2Traffic routes
3Calculates route
Selecting the last destinations
P82.85-9451-31US
NAVI Last Destinations
NORTH ADAMS, NORTH
NORTHBROOK, WILWAU
DEERFIELD, CHICORY
MMM, NORTHBROOK
1
Calculating a route
P82.85-9452-31US
NAVI Route Mode
Fast Route
Short Route
Freeway
Ferry
Toll
OK
12
3

142 NavigationDestination inputSelecting a route mode P, one selec-
tion is available
Fast route: Route calculated for opti-
mum driving time

Short route: Route calculated for opti-
mum driving route

Turn the right-hand rotary/push-button
v to highlight the desired route mode
and press to confirm.Including P or avoiding Q traffic rou-
tes, several selections are available

Calculate the route with/without free-
ways

Calculate the route with/without ferry
connections, car trains

Calculate the route with/without toll
roads

Turn the right-hand rotary/push-button
v to highlight the desired type of road
and press the button.Calculating the route

Press the right-hand rotary/push-
button v longer than 2 seconds.
or

Turn the right-hand rotary/push-button
v to highlight “OK” and press to con-
firm.
As soon as calculation begins, you will
see a corresponding message and hear
the voice output “The route is being
calculated”.
iToll roads appear in green on the map.
iIn the event that no reasonable alterna-
te route for that destination exists,
COMAND will calculate the route inclu-
ding the traffic routes 2 even if these
selections are to be avoided.
