MERCEDES-BENZ CL-Class 2004 C215 Comand Manual

82 Satellite radio*Satellite radio operationAutomatic station scan
The stations in the selected category can
be scanned in numerical order for 8 se-
conds each.
In the Satellite radio main menu, press
the
Scan
soft key.
The scan function will begin.
Scan
will
appear in black lettering.Ending scan function and playing a
station

Press the
Scan
soft key again.
The station selected will appear with
the station name.
Scan
will appear in
white lettering again.
Station selection via direct channel
entry

Press *.
Input line will appear.

Enter the number of the channel you
wish to select, e.g. 55.
The channel you have selected will be-
gin to play. The corresponding station
name will appear, if station is available.iError messages will be displayed in the
multifunction display.

83 Satellite radio*
Satellite radio operation
You can use the following functions:
Saving stations manually

Selecting a station from the Satellite
preset memory (
page 84)

Selecting a station by entering the
channel number (
page 82)Saving station manually
In the Satellite radio main menu

Press one of the number keys, e.g. 2,
longer than 2 seconds.
You will hear a confirmation beep if the
beep tones option was activated in the
system settings (
page 199).
The satellite radio saves the current
station at the memory preset selected.
The memory preset selected will ap-
pear in the status line, e.g.
SAT2
.On the memory list

In the Satellite radio main menu, press
the
Presets
soft key.
The SAT preset memory will appear.

Use G or g to select a memory pre-
set.

Press E
longer than 2 seconds.
You will hear a confirmation beep if the
beep tones option was activated in the
system settings (
page 199).
The satellite radio saves the current
station at the memory preset selected.
You will see the Satellite radio main menu

automatically after 8 seconds

if you press s.
Memory functionsiThere are 10 presets available.
iAn existing entry is overwritten in the
memory list when a new input is given.

84 Satellite radio*Satellite radio operationSelecting a station on the memory list
In the Satellite radio main menu, press
the
Presets
soft key.
The SAT preset memory will appear.

Use g or G to highlight a memory
preset.

Press E.
The Satellite radio main menu will then
appear automatically after 8 seconds,
indicating the memory preset number
in the status line.

In the Satellite radio main menu, press
the
Info
soft key.
The information display will appear.
You will see (if available)

the full station name

additional program information

Press the
Back
soft key to switch back
to the Satellite radio main menu.
Displaying information

85 Satellite radio*
Satellite radio operation
You can call the provider service center for
questions or releases, whenever you need.
Press the
SIRIUS
soft key.
The Service information display will ap-
pear.
1Phone number of the provider,
(SIRIUS) or “Call Service Provider”
2The Electronical Serial Number (ESN)
of your SAT tuner

Press the
Back
soft key to switch back
to the Satellite radio main menu.
Refer to chapter “At a glance” on how to
adjust sound settings.
You can set

the sound Bass/Treble individually

the sound-center (Fader and Balance)

select predefined sound optimization
Displaying service information
Sound settings

86 Satellite radio*Satellite radio operation

87
Important notes
Telephone operation
Telephone*

88 Telephone*Important notesIn chapter “Telephone”, you will find de-
tailed information regarding the telepho-
ne*, including emergency call.
1 Observe all legal requirementsWarning
G
Some jurisdictions prohibit the driver from
using a cellular telephone while driving a ve-
hicle. Whether or not prohibited by law, for
safety reasons, the driver should not use the
cellular telephone while the vehicle is in mo-
tion. Stop the vehicle in a safe location be-
fore answering or placing a call.
If you nonetheless choose to use the cellular
phone while driving, please use the hands-
free device and be sure to pay attention to
the traffic situation at all times. Use the cel-
lular phone
1 only when road, weather and
traffic conditions permit.
Never operate radio transmitters equipped
with a built-in or attached antenna (i.e.
without being connected to an external an-
tenna) from inside the vehicle while the en-
gine is running. Doing so could lead to
malfunction of the vehicle’s electronic sys-
tems, possibly resulting in an accident and
personal injury.
!Radio transmitters, such as a portable
telephone or a citizens band unit
should only be used inside the vehicle
if they are connected to a separate ex-
terior antenna that has been approved
by Mercedes-Benz.

Important notes

89 Telephone*
Important notes
iIf you have a Mercedes-Benz specified
integrated mobile telephone (TDMA/
CDMA or GSM) and the telephone is
inserted in the cradle, the telephone
functions can be used as follows:
at the COMAND

at the multifunction steering wheel

with the Voice control system*
This instruction manual describes the
operation at the COMAND. Unless
otherwise indicated, the descriptions
and illustrations refer to the COMAND.
Operation at the mobile phone and
operation with the Voice control
system* are described in separate
operating guides. Refer to the vehicle
Operator's Manual for operation of the
telephone using the multifunction
steering wheel.
iIn certain menus, the COMAND can
display date and time of the calls.
The COMAND can display phone
number and name of the other party
(e.g. if the COMAND detects an
incoming call, but also in other menus).
For the number to be displayed, the
number information must be
transmitted with the incoming call. The
same goes for the name display which
additionally requires that the caller’s
number and name are saved in the
phone book.

90 Telephone*Important notes
Please read the chapter “Telephone”
first before attempting to operate your
telephone.

Please also read the important notes in
the telephone and Voice control sys-
tem* operating manuals.

Always drive with extreme caution
when you operate the telephone
hands-free.

For safety reasons, you should not use
the mobile telephone handset to make
a call while driving the vehicle.
If the signal strength is very weak (dis-
play in the symbol bar of all menus):
Wait until reception improves before
making a call.

Close the windows and reduce all out-
side noise as much as possible when
you use hands-free operation.

Also make sure that the air vents are
not pointed in the direction of the
microphones located in the overhead
control panel near the rear view mirror.
Adjust air vents and/or reduce blower
speed if necessary.

A brief disconnection from the cellular
network is not a malfunction, as this
can occur when the network switches
areas. The phone will automatically try
to sign on to a network again.

If the message
Enter Lock Code
for Cell
appears, enter the unlock
code to enable all telephone functions
(
page 92). If you do not do so, only
the emergency call (911) is available.
GSM mobile phone

If the message
Enter PIN:
on the
mobile phone appears, enter the PIN-
code to enable the telephone functions
(
page 92). If you do not do so, only
the emergency (911) call is available on
the mobile phone.In the following situations, it is not possible
or not yet possible to use the telephone:

The telephone is already unlocked but
is not or not yet registered in the net-
work.
The message
no Serv.
appears in the
status bar. The telephone will try to re-
gister into an existing network. If the
network is available, the telephone will
be ready for use.
The above message also appears

if the network is no longer available
due to weak signals

if you try to make a call (message Service Unavailable
appears
for 8 seconds)

91 Telephone*
Important notes

The message
Activating Telepho-
ne. Please Wait.
appears.
COMAND prepares the telephone for
use. Select other system functions, e.g.
radio, by pressing the corresponding
button or wait until the telephone is ac-
tive.

One of the two messages
Telephone

Unavailable
or
Telephone
Not
Inserted
appears.
Please connect the mobile phone.

One of the two messages
Telephone

Error
or
Telephone
Not In-
stalled
appears.
Please contact an authorized
Mercedes-Benz Center.GSM mobile phone

If the message
Check SIM Card
(Emergency Call “911” Only
Possible With Tel.)
:

Insert the SIM card into the mobile
phone (Telephone Operating
Manual).
