398 Controls in detail
Automatic transmission
Gear ranges
With the automatic transmission in drive
positionD and driving in program mode C
or S (
page 399), you can select a gear
range for the automatic transmission to
operate within.
You can limit the gear range by pressing
the left gearshift button on the steering
wheel gearshift control, and reverse the
gear range limit by pressing the right gear-
shift button on the steering wheel gearshift
control (
page 400).The selected gear range appears in the in-
strument cluster.
1Current gear range
Effect
ïThe transmission shifts through
sixth gear only (applies to
vehicles with 7-speed automatic
transmission only).
îThe transmission shifts through
fifth gear only (applies to
vehicles with 7-speed automatic
transmission only).
éThe transmission shifts through
fourth gear only.
Effect
èThe transmission shifts through
third gear only.
With this selection you can use
the braking effect of the engine.
çThe transmission shifts through
second gear only.
Allows the use of engine’s
braking power when driving:

on steep downgrades

in mountainous regions

under extreme operating
conditions
æThe transmission operates in
first gear only.
For maximum use of engine’s
braking effect on very steep or
lengthy downgrades.
ProCarManuals.com

503 Operation
Driving instructions
Specified tire inflation pressures must be
maintained. This applies particularly if the
tires are subject to extreme operating con-
ditions (e.g. high speeds, heavy loads, high
ambient temperatures).
For more information, see “Tires and
wheels” (
page 520).
Hydroplaning
Depending on the depth of the water layer
on the road, hydroplaning may occur, even
at low speeds and with new tires. Reduce
vehicle speed, avoid track grooves in the
road and apply brakes cautiously in the
rain.
Tire traction
The safe speed on a wet, snow covered or
icy road is always lower than on a dry road.
You should pay particular attention to the
condition of the road whenever the outside
temperatures are close to the freezing
point.Mercedes-Benz recommends winter tires
(
page 549) with a minimum tread depth
of approximately 1/6in (4 mm) on all four
wheels for the winter season to ensure
normal balanced handling characteristics.
On packed snow, they can reduce your
stopping distance compared to summer
tires.
Stopping distance, however, is still consid-
erably greater than when the road is not
covered with snow or ice. Exercise appro-
priate caution.
Warning!G
Do not drive with a flat tire. A flat tire affects
the ability to steer or brake the vehicle. You
may lose control of the vehicle. Continued
driving with a flat tire or driving at high
speed with a flat tire will cause excessive
heat build-up and possibly a fire.
Warning!G
If ice has formed on the road, tire traction
will be substantially reduced. Under such
weather conditions, drive, steer and brake
with extreme caution.
!Avoid spinning of a drive wheel. This may
cause serious damage to the drivetrain which is
not covered by the Mercedes-Benz Limited War-
ranty.
ProCarManuals.com

531 Operation
Tires and wheels
Checking tire pressure electronically
with the Advanced Tire Pressure
Monitoring System (Advanced TPMS)The Advanced TPMS only functions on
wheels that are equipped with the proper
electronic sensors. It monitors the tire in-
flation pressure, as selected by the driver,
in all four tires. A warning is issued to alert
you to a decrease in pressure in one or
more of the tires.
Tire inflation pressure inquiries are made
using the multifunction display. The
present inflation pressures are displayed
only after a few minutes of travel time.
iThe Advanced Tire Pressure Monitoring
System (Advanced TPMS) is equipped with a
combination low tire pressure/TPMS malfunc-
tion telltale in the instrument cluster
(
page 576). Depending on how the telltale illu-
minates, it indicates a low tire inflation pressure
condition or a malfunction in the Advanced
TPMS system itself:

If the telltale illuminates continuously, one
or more of your tires is significantly underin-
flated. There is no malfunction in the
Advanced TPMS.

If the telltale flashes for 60 seconds and
then stays illuminated, the Advanced TPMS
system itself is not operating properly.
iUSA only:
This device complies with Part 15 of the FCC
Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful
interference, and
(2) this device must accept any interference
received, including interference that may
cause undesired operation.
Any unauthorized modification to this device
could void the user’s authority to operate the
equipment.
iCanada only:
This device complies with RSS-210 of Industry
Canada. Operation is subject to the following
two conditions:
(1) This device may not cause interference, and
(2) this device must accept any interference
received, including interference that may
cause undesired operation of the device.
Any unauthorized modification to this device
could void the user’s authority to operate the
equipment.iPossible differences between the readings
of a tire inflation pressure gauge of an air hose,
e.g. gas station equipment, and the vehicle’s
control system can occur. Usually the readings
issued by the control system are more precise.
iThe menu overview can be found on
(
page 258).
ProCarManuals.com

534 Operation
Tires and wheels
Reactivating Advanced TPMS
The Advanced TPMS must be reactivated
when you have adjusted the tire inflation
pressure to a new level (e.g. because of dif-
ferent load or driving conditions). The Ad-
vanced TPMS is then recalibrated to the
current tire inflation pressures.
Using the Tire and Loading Information
placard on the driver’s door B-pillar
(
page 523) or, if available, the sup-
plemental tire inflation pressure
information on the inside of the fuel fill-
er flap (
page 509), make sure the tire
inflation pressure of all four tires is
correct.
Switch on the ignition (page 336).
Press( or& to select the menu
“Service”.
Press$ or% to select
“Tire pressure”.
Press#.
You will see

the current inflation pressures for
each tire
or

the message
“Tire pressures
displayed after driving
a few minutes”
appear in the multifunction display.
Press%.
The message
“Use current pressure
values as new
reference values
To confirm press "OK"”
appears in the multifunction display.
Warning!G
It is the driver’s responsibility to calibrate
the Advanced TPMS on the recommended
cold inflation pressure. Underinflated tires
affect the ability to steer or brake the vehi-
cle. You might lose control over the vehicle.
iReactivate the Advanced TPMS after adjust-
ing the tire inflation pressure to the inflation
pressure recommended for the vehicle operating
condition. Tire inflation pressure should only be
adjusted on cold tires. Observe the recommend-
ed tire inflation pressure on the Tire and Loading
Information placard on the driver’s door B-pillar
(
page 523). Some vehicles may have supple-
mental tire inflation pressure information for
driving at high speeds (
page 529) or for vehi-
cle loads less than the maximum loaded vehicle
condition. If such information is provided, it can
be found on the inside of the fuel filler flap
(
page 509).
iAfter wheel rotation or sensor replacement,
the vehicle must be parked for 20 minutes be-
fore attempting to reactivate the Advanced
TPMS.
iThe menu overview can be found on
(
page 258).
ProCarManuals.com

541 Operation
Tires and wheels
Manufacturer’s identification mark
The manufacturer’s identification mark2
(
page 540) denotes the tire
manufacturer.
New tires have a mark with two symbols.
Retreaded tires have a mark with four sym-
bols. For more information on retreaded
tires (
page 520).
Tire size
The code3 (
page 540) indicates the
tire size.
Tire type code
The code4 (
page 540) may, at the
option of the manufacturer, be used as a
descriptive code for identifying significant
characteristics of the tire.
Date of manufacture
The date of manufacture5 (
page 540)
identifies the week and year of manufac-
ture. The first two figures identify the week,
starting with “01” to represent the first full
week of the calendar year. The second two
figures represent the year.
For example, “3202” represents the 32nd
week of 2002.
Maximum tire load
1Maximum tire load rating
The maximum tire load is the maximum
weight the tires are designed to support.For more information on tire load rating
(
page 537).
For information on calculating total and
cargo load capacities (
page 525).
iFor illustration purposes only. Actual data
on tires are specific to each vehicle and may vary
from data shown in above illustration.
Warning!G
Do not overload the tires by exceeding the
specified load limit as indicated on the Tire
and Loading Information placard located on
the driver’s door B-pillar. Overloading the
tires can overheat them, possibly causing a
blowout. Overloading the tires can also
result in handling or steering problems, or
brake failure.
ProCarManuals.com

678 Technical data
Rims and tires
!Only use tires which have been tested and
approved for your vehicle by Mercedes-Benz.
Tires approved by Mercedes-Benz are developed
to provide best possible performance in conjunc-
tion with the driving safety systems on your vehi-
cle such as ABS or ESP
®. Tires specially
developed for your vehicle and tested and ap-
proved by Mercedes-Benz can be identified by
finding the following on the tire’s sidewall:

MO = Mercedes-Benz Original equipment
tires
Using tires other than those approved by
Mercedes-Benz may result in damage that is not
covered by the Mercedes-Benz Limited
Warranty.
!Using tires other than those approved by
Mercedes-Benz can have detrimental effects,
such as

poor handling characteristics

increased noise

increased fuel consumption
Moreover, tires and rims not approved by
Mercedes-Benz may, under load, exhibit dimen-
sional variations and different tire deformation
characteristics that could cause them to come
into contact with the vehicle body or axle parts.
Damage to the tires or the vehicle may be the
result.
iFurther information on tires and rims is
available at any authorized Mercedes-Benz
Center. A Tire and Loading Information placard
with the recommended tire inflation pressures is
located on the driver’s door B-pillar
(
page 523). Some vehicles may have supple-
mental tire inflation pressure information for
driving at high speeds (
page 529) or for vehi-
cle loads less than the maximum loaded vehicle
condition (
page 536). If such information is
provided, it can be found on the tire inflation
pressure label located on the inside of the fuel
filler flap. The tire inflation pressure should be checked
regularly and should only be adjusted on cold
tires. Follow tire manufacturer’s maintenance
recommendation included with vehicle.
iThe following pages also list the approved
wheel rim and tire sizes for equipping your vehi-
cles with winter tires. Winter tires are not avail-
able as standard or optional factory equipment,
but can be purchased from an authorized
Mercedes-Benz Center.
Depending on vehicle model and the standard or
optional factory-equipped wheel rim/tire config-
uration on your vehicle (Appearance Package,
Sport Package etc.), equipping your vehicle with
winter tires approved for your vehicle model may
also require the purchase of two or four wheel
rims of the recommended size for use with these
winter tires. See an authorized Mercedes-Benz
Center for more information.
ProCarManuals.com
