MERCEDES-BENZ CL500 2007 C216 Owners Manual

90 Control systems
COMAND introduction
Selecting “FM/AM Radio”:
Slideqmor rotate ymz.
Confirming selection: Press n.
The FM/AM Radio menu appears.
Selecting “Radio”: Slide mror
rotateymz.
Confirming selection: Press n.
The Radio submenu appears.
Select “Save Station” from selection
list by rotating ymz or sliding rmq.
Select desired position.
Confirming selection: Press n.
The selected station is saved at the
designated position. The display
switches back to the Radio display.


91 Control systems
COMAND introduction
Main menus of COMAND
Sound
Muting: Press the F shortcut but-
ton in the center console (
page 82).
The sound of the current audio source
is switched on or is muted.Switching off navigation announce-
ments entirely
Canceling navigation message:
Briefly press F shortcut button dur-
ing an announcement.
Switching off navigation messages:
Press and hold F during an an-
nouncement until the announcement is
switched off.
You will see the message “The driving
instructions have been muted.” for a
short while.Adjusting volume
1Thumbwheel
Adjusting: Turn, thumbwheel.
The volume of the currently selected
audio source changes.
iThe components and operating principles of
COMAND can be found on (
page 81).
iWhen the sound is muted, you will see the
symbol
F in the status line. When you
change the audio source, the sound is automati-
cally switched on. You will be able to hear an-
nouncements from the navigation system even
when the sound is muted.
iThe announcements remain switched off
even if you start a new route guidance or if
COMAND is switched off/on with theo but-
ton.
If you switch COMAND off by removing the
SmartKey from the starter switch and then
switch the ignition back on after more than
3 minutes, the announcements are automatical-
ly switched back on.

92 Control systems
COMAND introduction
Volume of navigation announcements
You can adjust the volume of the naviga-
tion announcements independently from
the volume of the respective audio source.
During a navigation announcement:
turn thumbwheel,
or
pressæ or ç on the multifunc-
tion steering wheel.
Adjusting volume for telephone calls
In hands-free mode, you can adjust the vol-
ume of a telephone call while the call is
currently active.
During a telephone call:
turn thumbwheel,
or
pressæ or ç on the multifunc-
tion steering wheel.Selecting sound settings
You can select different sound settings for
each individual audio source. The respec-
tive sound menu can be found via the sub-
menu for which you wish to make settings.
Example:
“Audio”
“Audio”
“FM/AM Radio”

“Sound” Adjusting treble or bass
Select “Sound”
“Treble” or “Bass”.
The setting last selected is indicated by
an outlined bar.
Adjusting treble and bass
1Setting last selected
2Current setting
Changing setting: Slide rmq or
rotateymz until desired treble or bass
setting is reached.
Exiting menu: Press n, L or
slideomp.
The setting is saved.

93 Control systems
COMAND introduction
Adjusting balance or fader
Balance is used to determine whether the
sound focus should be shifted toward the
driver’s side or the passenger’s side.
Fader is used to determine whether the
sound focus should be shifted toward the
front or rear of the vehicle
Select “Sound”
“Balance/Fader”.
The setting last selected is indicated by
an outlined bar.
Adjusting balance and fader
1Current setting indicated by orange
cross-hair symbol
Changing setting: Slide rmq or omp
until desired balance/fader setting is
reached.
Exiting menu: Press n or L.
The setting is saved.
Surround sound
With surround sound, you can choose be-
tween “LOGIC7
® ON” and “LOGIC7® OFF”.
Harman/kardon LOGIC7
® surround sound
is available for the following operating
modes:

Audio DVD (MLP, DTS, PCM, and Dolby
Digital audio formats)

Audio CD

MP3

Radio (FM, AM, WB,
Satellite (USA only))

PCMCIA
iSince some DVDs contain both stereo as
well as multi-channel audio formats, it may be
necessary to adapt the audio format
(
page 119).
iThe “LOGIC7® ON” function of the har-
man/kardon LOGIC7® surround sound system
makes it possible to play discrete 5.1 and stereo
recordings with optimal surround sound for ev-
ery passenger. Music on CDs or audio DVDs with
high-resolution surround formats such as MLP,
DTS or Dolby Digital is played back optimally.
For an ideal sound experience on all seats,
LOGIC7
® distributes 5.1 surround information
via the 13-channel system architecture. The re-
sult is a sound as intended by the sound engi-
neers during the original recording.
harman/kardon LOGIC7
® converts all two-chan-
nel stereo sound material into multi-channel sur-
round sound. With the help of LOGIC7
®,
surround information stored during the original
recording are read out and distributed through
the 13 channels. No effects are created during
this process; only that which was already there
becomes audible.
In addition, harman/kardon LOGIC7
® moves the
perceived sound source away from the individual
loudspeakers, thus generating a natural 360°
sound experience for every passenger.

94 Control systems
COMAND introduction
Adjusting surround sound
With surround sound, you can choose be-
tween “LOGIC7
® ON” and “LOGIC7® OFF”.
Select “Sound”
“3D Sound”.
Adjusting surround sound
1Current setting
Selecting a setting: Slidermq or
rotateymz.
Saving setting: Press n.
The setting is saved and the menu is
closed.
Exiting menu without saving chang-
es: Press L or slide omp.Switching off/on the audio source
Switching off: Select “Audio”
“Au-
dio”
“Audio OFF”.
The audio source is switched off; “Au-
dio OFF” appears in the display.
Switching on: Select “Audio”, then the
desired audio source.
or
Load CD/DVD (page 111) or a
PCMCIA card (
page 112).
iBy selecting “LOGIC7® OFF”, all compatible
formats as they are present on the medium are
played back. Due to the vehicle’s spatial charac-
teristics, an optimal sound experience is not en-
sured on all seats.
iPlease note the following:

For an ideal sound experience at all seats,
the balance and fader should be adjusted to
the center of the passenger compartment
with LOGIC7
® switched on.

The best sound results are achieved by play-
ing high-quality audio CDs and audio DVDs.

For MP3 tracks, the bit rate should be at
least 128 kbit/s.

Surround sound does not function for
mono-signal sources.

In the event of poor radio reception quality,
e.g. inside a tunnel, you should switch off
LOGIC7
®, as a dynamic switch from Stereo
to Mono could occur, resulting in temporary
sound distortion.

With some stereo recordings, the resulting
sound may deviate from conventional stereo
playback.
iWhen you insert an audio CD or audio DVD,
it automatically becomes the active audio
source.

95 Control systems
COMAND FM/AM radio
COMAND FM/AM radio
Submenu overview
Warning!G
Please devote your attention first and fore-
most to the traffic situation you are in.
Before your journey, please familiarize your-
self with the radio functions.
Only use the COMAND when road and traffic
conditions permit you to do so. Otherwise
you could be involved in an accident in
which you or others could be injured.
iThe components and operating principles of
COMAND can be found on (
page 81).
Radio
(except Weather Band)Presets
(except Weather Band)Channel
(only Weather Band)FM or AM or WBSound
Station List
(in FM waveband only)AutostoreChannel listSwitch to FM wavebandTreble
Save StationPreset station listSwitch to AM wavebandBass
Frequency EntrySwitch to Weather BandBalance/Fader
Show Station Info
(in FM waveband only)3D Sound

96 Control systems
COMAND FM/AM radio
Switching to radio mode
Select “Audio”
“Audio”
“FM/AM
Radio”.
or
Press the M shortcut button once or
twice.
The radio display appears once you
have switched to radio mode. You will
hear the station/channel last tuned in
in the previously selected waveband,
provided that the station/channel can
be received.
Illustration: radio mode in FM waveband
1Main area with frequency display
2Preset position of selected station
3Frequency of selected station
4Name of selected station
5Sound settings
6To switch to Weather Band
7To switch to AM waveband
8Selected waveband
9Preset options
aRadio options
Switching wavebands
You can switch between the FM, AM and
WB (Weather Band) wavebands.
Select “Audio”
“Audio”
“FM/AM
Radio”
“FM” or “AM” or “WB”.
You will hear the station last tuned in
on the selected waveband.
Selecting stations/channels
You have the following selection options:

The station list

The search function

The station presets

The manual frequency entry

The channel list
Selecting stations using the station list
iThe number of times you have to press the
M shortcut button depends on the operating
mode currently selected.
iStation name display 4 is available for the
FM waveband and can only be seen when it is
switched on (
page 99) and if the station trans-
mits a name.
iThe station list is only available for the FM
waveband. It contains all the stations that can be
currently received and is sorted by station fre-
quencies.

97 Control systems
COMAND FM/AM radio
Select “Audio”
“Audio”
“FM/AM
Radio”
“FM”.
Select “Radio”
“Station List”.
The station list appears. The dot R in
front of a list entry indicates the cur-
rently selected station. A number in
front of the list entry indicates the pre-
set position in the station preset mem-
ory.
Select a station by rotating ymz or
sliding qmr and press n.
Selecting stations/channels using the
search function
Slide omp or rotate ymz when the
main area is selected.
Depending on the direction in which
the controller is being slid or rotated,
the system searches upward or down-
ward and stops at the next receivable
station/channel.Selecting stations using station pre-
sets
Select “Audio”
“Audio”
“FM/AM
Radio”
“FM” or “AM”.
Select “Presets”.
or
Press n when the main area is select-
ed.
The preset menu appears. The dot R
in front of a preset position indicates
that the currently selected station is
saved there.
Select station preset by rotating ymz
or sliding qmr and press n.Selecting stations by entering the fre-
quency manually
Select “Audio”
“Audio”
“FM/AM
Radio”
“FM” or “AM”.
Select “Radio”
“Frequency Entry”.
The menu for manual frequency entry
appears.
Exiting menu without making an en-
try: Press L back button in the cen-
ter console (
page 82).
Increasing or decreasing number:
Slide qmr or rotate ymz.
Selecting the next number:
Slidemp.
Confirming frequency entry:
Pressn.
COMAND tunes in to the frequency en-
tered.
iThis function is not available for Weather
Band.iThis function is not available for Weather
Band.
iYou can only select currently permitted
numbers.


98 Control systems
COMAND FM/AM radio
Selecting channels using the channel
list
Select “Audio”
“Audio”
“FM/AM
Radio”
“WB”
“Channel”.
or
Press n when the main area is select-
ed.
The channel list appears. The dotR in
front of a list entry indicates the cur-
rently selected channel.
Select channel by rotating ymz or
slidingqmr and press n.
Saving stationsYou have the following options:

Saving stations manually

Saving stations using Autostore
Saving stations manually
Option 1
Select “Audio”
“Audio”
“FM/AM
Radio”
“FM” or “AM”.
Select “Radio ”
“Save Station”.
Option 2
Press n when the main area is select-
ed.
Option 3
Select “Audio”
“Audio”
“FM/AM
Radio”
“FM” or “AM”.
Select “Presets”.
All three of these will call up a station pre-
set screen. The dot R in front of a preset
position indicates that the currently select-
ed station is saved there.
Selecting a preset position:
Slideqmr or rotate ymz.
Saving a station to a selected preset po-
sition
If you have called up the station preset
screen using option 1:
Press n briefly.
In options 2 and 3:
Press and hold n until you hear a sig-
nal.
The station is saved.
iIf you enter a frequency in the AM waveband
which is outside the frequency range, COMAND
tunes in to the next lowest frequency.
iThis function is only available for Weather
Band.
iTwenty stations can be saved in each wave-
band except for Weather Band.


99 Control systems
COMAND FM/AM radio
Saving using autostore
Option 1
Press n when the main area is select-
ed.
Select “Autostore”.
Option 2
Select “Audio”
“Audio”
“FM/AM
Radio”
“FM” or “AM”.
Select “Presets”
“Autostore”.
Option 3
Select “Audio”
“Audio”
“FM/AM
Radio”
“Radio”
“Save Station”

“Autostore”.
Station name display
1Station name display
Switching the station name display
on/off: Select “Audio”
“Audio”

“FM/AM Radio”
“FM”
“Radio”

“Show Station Info”.The display is switched on or off, de-
pending on the previous setting. When
the display is switched on, a check-
mark appears in front of the
“Show Station Info” menu item.
iThis function is not available for Weather
Band. The Autostore function saves receivable
stations as presets in order of their reception
quality. All stations saved manually in the preset
memory will be lost if COMAND finds 20 sta-
tions. If COMAND finds less than 20 stations, for
example 9, then the stations saved in preset po-
sitions 1 – 9 will be over written.iIn the FM waveband, COMAND can show
the name of the station currently tuned in. Sta-
tion name display 1 can only be seen when it is
switched on and if the station transmits a name.
