MERCEDES-BENZ CL500 2007 C216 Owner's Manual

210 Control systems
COMAND navigation system (destination memory)
Destination memory list without in-
put characters: Press n immediately.
or
Destination memory list with input
characters: Slide qm repeatedly until
the input characters disappear.
The list entry “My Address” is automat-
ically highlighted as long as you have
not entered any characters using the
input characters.
If you have entered characters
from the list of input characters:
Rotate ymz or slide qm repeatedly
until the list entry “My Address” is
highlighted.
Press n.
Further operation depends on whether you
want to enter the address manually or use
an address book entry as your own ad-
dress.Entering an address manually
If you want to assign your own ad-
dress for the first time: Select “Save
new entry”.
or
If you want to change your own ad-
dress: Select “Change”
“Save new
entry”.
In both cases, the address input menu ap-
pears.
Enter the address. Proceed as de-
scribed for destination entry in the “En-
tering a destination by address”
section (
page 162).
Select “Save” after entering the ad-
dress.
Your address is saved.Using the address book entry as your
own address
If you want to assign your own ad-
dress for the first time:
Select “Assign Address Book Entry”.
or
If you want to change your own ad-
dress: Select “Change”
“Assign Ad-
dress Book Entry”.
In both cases, the menu appears for
searching for an address book entry.
Select desired address book entry. Pro-
ceed as described in the “Searching for
an address book entry” section
(
page 217).
Once the address data is complete and if it
matches the digital map data, COMAND
saves the entry as your own address in the
destination memory.
If address data is still missing or if it cannot
be found on the digital map, a message ap-
pears indicating that the address is incom-
plete.


211 Control systems
COMAND navigation system (destination memory)
Closing message: Select “OK”.
Depending on which data is missing or
cannot be found on the digital map, you
must now either:

select a state (USA) or province (CDN)

or enter a town/city

or enter a street

or enter a house number
Selecting a state (USA) or province
(CDN): Select desired state (USA) or
province (CDN) from the list.
Entering a town: Proceed as de-
scribed for destination entry in the “En-
tering a town or city” section
(
page 168).
Entering a street: Proceed as de-
scribed for destination entry in the “En-
tering a street” section (
page 171).
Entering a house number: Proceed
as described for destination entry in
the “Entering a house number” section
(
page 175).
If all data is available and matches the
digital map data, you can save the ad-
dress.
Saving: Select “Save”.Displaying your own address
Select “Navi”
“Destination”

“From Memory”.
The destination memory list appears ei-
ther with or without the input charac-
ters. Whether the input characters
appear depends on the number of en-
tries in the destination memory.
Press n.
iIn the address book entry, the town/city
and street must be spelled in the same way as
the destination entry so that the data matches
the digital map data.
In order for the state (USA) or province (CDN) to
match the map data, you may either enter the
entire name or the abbreviation in the address
book.
Examples:

Florida or FL

Colorado or CO

Alberta or AB

Ontario or ON

212 Control systems
COMAND navigation system (destination memory)
Destination memory list without input
characters
In the destination memory list without in-
put characters, the “My Address” entry is
automatically highlighted.
Press n.
If your own address has already been
assigned, you will see the menu for
starting route guidance with your own
address data.
Exiting menu: Select “Back”.Destination memory list with input char-
acters
1Input characters
In the destination memory list with input
characters 1, the input characters are au-
tomatically activated.
Slide qm repeatedly until the input
characters disappear.
The list entry “My Address” is automat-
ically highlighted as long as you have
not entered any characters using the
input characters.
If you have entered characters
from the list of input characters:
Rotate ymz or slide qm repeatedly
until the list entry “My Address” is
highlighted.
Press n.
If your own address has already been
assigned, you will see the menu for
starting route guidance with your own
address data.
Exiting menu: Select “Back”.

213 Control systems
COMAND navigation system (last destinations)
COMAND navigation system (last destinations)
Saving a destination permanently in
the destination memory
Proceed as described in the “Saving a
destination from the list of last destina-
tions” section (
page 206).Saving the vehicle position in the list of
last destinations
Centering map on the vehicle’s posi-
tion: Select “Navi”
“Position”

“Vehicle Position Map”.
Saving: Select “Navi”
“Position”

“Save Position”.
COMAND saves the current vehicle po-
sition as a destination in the list of last
destinations.
Saving the crosshair position in the list
of last destinations
Showing menu system, if neces-
sary: Press n.
Select “Position”
“Save Position”.
COMAND saves the crosshair position
as a destination in the list of last desti-
nations.
Deleting one of the last destinations
Select “Navi”
“Destination”

“From Last Destinations”.
The list of last destinations appears.
Select desired destination.
The address of the destination ap-
pears.
Select “Delete”.
Select “Yes” or “No”.
iCOMAND automatically saves the last desti-
nations for which the route calculation was
launched. It is stored in the “last destinations”
memory. If this memory is full, COMAND deletes
the oldest destination. You can also save one
destination from the list of last destinations in
the destination memory. It will be saved there
permanently.
iIf you have manually moved the map, you
will see a crosshair on the map (
page 157).
You can save the crosshair position as a destina-
tion in the list of last destinations.

214 Control systems
COMAND address book
General notes
The address book contains the entries that
are saved in the COMAND address book
memory. The entries are permanently
available even if the phone is not inserted
in the cradle*. When you insert the mobile
phone into the cradle*, COMAND reads-in
the phone book entries saved in the mobile
phone and stores the entries as a separate
list from the COMAND address book. This
list is a copy of the phone’s phone book.
This can take several minutes, depending
on how many entries the phone book and
the address book contain. After the read-in
process, the COMAND compares the
phone book entries with the address book
entries. If all of the telephone numbers of a
phone book entry in the mobile phone are
present in an address book entry, the ad-
dress book shows only the address book
entry. If not, the address book also shows
the phone book entry in the mobile phone.Address book menu overview
Warning!G
Please devote your attention first and fore-
most to the traffic situation you are in.
Before your journey, please familiarize your-
self with the address book functions.
Only use the COMAND when road and traffic
conditions permit you to do so. Otherwise
you could be involved in an accident in
which you or others could be injured.iThe components and operating principles of
COMAND can be found on (
page 81).
Search New Entry
Search for an ad-
dress book entryCreate new address
book entry

215 Control systems
COMAND address book
Calling up the address book
Select “Telephone”
“Telephone”

“Address Book”.
The main address book display ap-
pears. If the address book already con-
tains entries, you will see the data of an
entry.
Illustration: address book entry
Selecting an entry in the main address
book display
Slide omp or rotate ymz until the
main area is selected.
Creating a new address book entry
Select “Telephone”
“Telephone”

“Address Book”
“New Entry”.
The input menu appears with the data
fields and the input characters.
Illustration: input menu for private data
1To switch between work and home
data ( or symbol)
2Selected data field with input mark
(cursor)
3Display of set data type – in example
display, home data is set ( symbol
and “Home” display)
4Input characters
iFor phone book entries in the mobile phone
that contain a name and a telephone number,
you will see the name and the number. If a phone
book entry in the mobile phone contains several
telephone numbers, you will see the message
“Multiple Numbers” instead of a telephone num-
ber.
iPlease observe the following when creating
a new address book entry:
You can define your own address in the destina-
tion memory in navigation mode. When defining
the address, you can transfer data already en-
tered as an address book entry.
In the address book entry, the town/city and
street must be spelled in the same way as the
destination entry so that the data matches the
digital map data.
In order for the state (province) to match the
map data, its complete name or abbreviation
may be entered.
Examples:

Florida or FL

Colorado or CO

Alberta or AB

Ontario or ON

216 Control systems
COMAND address book
Switching between private and
business data: Select symbol 1.
The display switches to private or busi-
ness data, depending on the previous
status.
Changing data field: Slide rmq re-
peatedly until desired entry is highlight-
ed.
or
Select [ or ] repeatedly until de-
sired entry is highlighted.
Entering data into a field:
Select desired characters one by one
from the input characters.
Toggling upper and lower case for
the input characters: Select& or
(.
Changing language for the input
characters: Select!.
Select desired language.
Changing character set for the input
characters: Select#.
Depending on the previous setting, you
will change to letters with special char-
acters or to numbers with special char-
acters.
Moving cursor in the data field:
SelectY or Z.
Deleting individual characters:
Select) and briefly press n.
The character to the left of the cursor is
deleted.
Deleting an entire entry: Select)
and press and hold n until the entry is
deleted.
Saving an entry: Select?.
Canceling an entry: Select “Back”.
If one of the data fields contains new
data, a prompt will appear asking
whether you want to save the entry.
Select “Yes” or “No”.
The entry will either be saved or
not, depending on your selection.

217 Control systems
COMAND address book
Deleting an entry
Search for desired entry (page 217).
Select “Options”
“Delete”.
A deletion prompt appears.
Select “Yes” or “No”.
The entry will either be deleted or not,
depending on your selection.
Searching for an address book entry
Select “Telephone”
“Telephone”

“Address Book”
“Search”.
The search menu appears with the
smart speller.
1Symbol for complete address data
from the navigation system
2Symbol for summarized entries
from the mobile phone with the same
name but different telephone numbers
3Category symbol
4Smart speller
5Symbol for voice entry
6Back to the main address book displayEntries with category symbol 3 come
from the mobile phone. The following cate-
gory symbols are possible:

= symbol for “Mobile” category

= symbol for “Home” category

= symbol for “Work” category

= symbol for “Fax” category

= symbol for “Pager” category

= symbol for “Main” category or for
unknown category or for phone entries
that are saved on the SIM card of a
GSM mobile phone
Entries without a category symbol or with
the or symbols come from the
COMAND address book. All other entries
come from the mobile phone and are only
visible when the mobile phone is in the cra-
dle*.
It is possible to add voice entries. Entries
with the symbol contain a voice entry
(
page 224).
iYou cannot delete phone book entries from
the mobile phone.

218 Control systems
COMAND address book
Entries with the symbol contain com-
plete, navigable address data from the nav-
igation system that correspond to digital
map data. It is possible to quickly start
route guidance to these types of entry
(
page 223).
Switching from the smart speller to the
list
Slide mq repeatedly or press n until
the smart speller is hidden.
or
Select ?.
Switching from the list to the smart
speller
Select “Back” from the list.Searching
Searching via the smart speller
Switch from the list to the smart speller
if necessary.
Changing smart speller language:
Select!.
Select desired language.
Changing smart speller character
set: Select#.
Depending on the previous setting, you
will change to letters with special char-
acters or to numbers with special char-
acters.
Entering characters: Select the char-
acters one by one of the entry you are
searching for.
Deleting individual characters:
Select) and briefly press n.
Each time you enter or delete a charac-
ter, the closest match will be displayed
at the top of the list.
Deleting an entire entry: Select)
and press and hold n until the entry is
deleted.
Canceling search: Switch from the
smart speller to the list (
page 218).
The entry at the top of the list is auto-
matically highlighted.
Going back to main address book
display: If necessary, switch from the
list to the smart speller (
page 218)
and select “Back” in the smart speller.
Searching via the list
If necessary, switch from the smart
speller to the list (
page 218).
Rotate ymz or slide qmr until desired
entry is highlighted on the list.

219 Control systems
COMAND address book
Displaying a complete address book
entry
Searching for the desired entry
Search for an address book entry
(
page 217).
or
Select an address book entry in the
main address book menu
(
page 215).
Press n.
The detailed view appears.
Illustration: detailed view for private data
1To go back to the previous menu
2To switch between work and home
data ( symbol or )
3Selected data field
4Display of set data type – in example
display, home data is set ( symbol
and “Home” display)
5To call up options
iThe options available under “Options” menu
item 4 depend on which data field 3 is select-
ed. The following options may be available:

Displaying abbreviated content in full
(
page 220)

Changing an address book entry
((
page 221)

Changing the description of a telephone
number data field (
page 221)

Adding a telephone number data field
(
page 222)

Calling a number saved in an entry
(
page 222)

Starting route guidance to an entry
(
page 223)

Options for voice entries (page 224)
