MERCEDES-BENZ CL500 2007 C216 Owner's Manual

460 Controls in detail
Automatic climate control
Convenience opening: Press
button
, for approximately
2 seconds.
The side windows and/or tilt/sliding
sunroof will return to their previous po-
sition. You can release button
,
once the opening procedure has be-
gun. The windows and tilt/sliding sun-
roof continue opening until they have
reached their previous positions. The
indicator lamp on the button goes out.
The air recirculation mode is deactivat-
ed.
Residual engine heat and ventilation
With the engine switched off, it is possible
to continue to heat or ventilate the interior.
This feature makes use of the residual heat
produced by the engine.Activating
Switch off the ignition (page 336).
Press buttonT (page 453) up or
down.
The indicator lamp on the button
comes on.
Deactivating
Press buttonT (page 453) up or
down.
The indicator lamp on the button goes
out.
iIf you switch on the residual heat function
when outside temperatures are high, only the
ventilation will be switched on.
iRegardless of the selected air volume, the
blower operates at low speed when heating. In
case of ventilation the blower operates at higher
speed.
iHow long the system will provide heating de-
pends on

the coolant temperature

the temperature set by the operator
iThe residual heat is automatically turned off:

when the ignition is switched on

after approximately 30 minutes

if the battery voltage drops

if the coolant temperature is too low


461 Controls in detail
Trunk
Trunk
Opening trunk
You can open the trunk if the vehicle is sta-
tionary.
A minimum height clearance of 5.78 ft
(1.76 m) is required to open the trunk lid.Opening trunk from outside
1Trunk lid handle
Press and hold button Š on the
SmartKey or SmartKey with
KEYLESS-GO* until trunk unlocks and
begins to open.
or
Pull on handle1.
In vehicles without KEYLESS-GO*: The
vehicle must be unlocked.Opening trunk from inside
1Remote trunk opening/closing switch
Press and hold switch1 until the
trunk is opened.
The indicator lamp in switch1 comes
on and remains lit until the trunk is
closed.
To interrupt the opening procedure:
Release switch1.
Warning!G
Make sure the trunk is closed when the en-
gine is running and while driving. Among
other dangers such as blocked visibility,
deadly carbon monoxide (CO) gases may
enter the vehicle interior resulting in
unconsciousness and death.
!The trunk lid swings open upwards automat-
ically. Always make sure that there is sufficient
overhead clearance.
To stop the opening procedure, press
buttonŠ on the SmartKey or SmartKey with
KEYLESS-GO*.

462 Controls in detail
Trunk
Trunk opening-height restriction
The trunk lid opening height can be limited
when transporting goods on a roof rack
(e.g. presence of an optional MB sport lug-
gage container). When activated, the trunk
opens to approximately the height of the
roof edge.
Activate the limiting opening height of
trunk lid using the COMAND system
(
page 242).
Closing trunkClosing trunk from inside automatically
1Remote trunk opening/closing switch
Press and hold switch1 until the
trunk is closed.
The indicator lamp in the switch goes
out when the trunk is closed.
To interrupt the closing procedure:
Release switch1.
iDo not place the SmartKey in the open
trunk. You may lock yourself out.
iIf the vehicle was previously centrally
locked, the trunk will lock automatically after
closing it. All turn signal lamps flash three times
to confirm locking.
Vehicles with KEYLESS-GO*: To prevent a possi-
ble inadvertent lockout, the trunk will open auto-
matically if a SmartKey with KEYLESS-GO* is
recognized inside the vehicle or in the trunk.
The vehicle is only locked when the turn signals
flash three times. If you are carrying a second SmartKey with KEYLESS-GO* with you, you can
still lock the vehicle.
Warning!G
Maintain sight of trunk area while operating
door mounted switch. Monitor the closing
procedure carefully to make sure no one is
in danger of being injured.
To interrupt the closing procedure, release
the door mounted remote trunk open-
ing/closing switch.
Even with the SmartKey or SmartKey with
KEYLESS-GO* removed from the starter
switch or the SmartKey with KEYLESS-GO*
removed from the vehicle, the remote trunk
opening/closing switch can be operated.
Therefore, do not leave children unattended
in the vehicle, or with access to an unlocked
vehicle. A child’s unsupervised access to a
vehicle could result in an accident and/or
serious personal injury.
iIf the trunk lid comes into contact with an
object while closing (e.g. luggage that has been
piled too high) in the upper motion sequence, the
closing procedure is stopped and the trunk re-
opens slightly.
iYou can also close the trunk by hand.

463 Controls in detail
Trunk
Closing trunk from outside
automatically
Vehicles without KEYLESS-GO*
1Trunk closing switch
Vehicles with KEYLESS-GO*
1Trunk closing switch
Press trunk closing switch1 briefly.
The trunk closes.
Warning!G
Monitor the closing procedure carefully to
make sure no one is in danger of being in-
jured. To prevent possible personal injury,
always keep hands and fingers away from
the trunk lid opening when closing the trunk.
Be especially careful when small children
are around. To stop the closing procedure,
do one of the following:

press button Š on the SmartKey or
SmartKey with KEYLESS-GO

press the trunk opening/closing switch
(on the driver’s door)

press the trunk closing switch

press the KEYLESS-GO locking/closing
switch*

pull the trunk lid handle
Even with the SmartKey or SmartKey with
KEYLESS-GO* removed from the starter
switch or the SmartKey with KEYLESS-GO*
removed from the vehicle, the remote trunk
opening/closing switch can be operated.
Therefore, do not leave children unattended
in the vehicle, or with access to an unlocked
vehicle. A child’s unsupervised access to a
vehicle could result in an accident and/or
serious personal injury.
iIf the trunk lid comes into contact with an
object while closing (e.g. luggage that has been
piled too high) in the upper motion sequence, the
closing procedure is stopped and the trunk re-
opens slightly.
iYou can also close the trunk by hand.

464 Controls in detail
Trunk
Closing trunk and locking vehicle from
outside (vehicles with KEYLESS-GO*)
You can close the trunk and lock the vehi-
cle simultaneously from the outside using
the KEYLESS-GO locking/closing switch.
1KEYLESS-GO locking/closing switch
Make sure you have the SmartKey with
KEYLESS-GO with you.
Press switch1 briefly.With both doors closed:

The locking knobs in the doors
move down.

The trunk starts to close automati-
cally.

All turn signal lamps flash three
times to confirm locking once the
trunk has closed completely.

An acoustic signal sounds three
times.

The anti-theft alarm system is
armed.
Trunk emergency release
With the emergency release button, the
trunk can be opened from inside the trunk.
1Emergency release button
Briefly press emergency release
button1.
The trunk opens.iIf the trunk lid comes into contact with an
object while closing (e.g. luggage that has been
piled too high) in the upper motion sequence, the
closing procedure is stopped and the trunk re-
opens slightly.
iYou can also close the trunk by hand.iThe emergency release button unlocks and
opens the trunk while the vehicle is standing still
or in motion.

465 Controls in detail
Trunk
Illumination of the emergency release but-
ton:

The button will flash for 30 minutes af-
ter opening the trunk.

The button will flash for 60 minutes af-
ter closing the trunk.
Valet locking
1Neutral position
2Locked
Close the trunk (page 462).
Remove the mechanical key from the
SmartKey (
page 635).
Insert the mechanical key in the trunk
lid lock.
Turn the mechanical key clockwise to
position 2 to lock the trunk.
The trunk remains locked even when the
vehicle is centrally unlocked.
Insert the mechanical key in the trunk
lid lock.
Turn the mechanical key counterclock-
wise to neutral position 1 to unlock the
trunk.
You can now open the trunk
(
page 461).
iThe emergency release button does not
open the trunk if the vehicle battery is dis-
charged or disconnected.
iTo deny any unauthorized person access to
the trunk, e.g. when you valet park the vehicle,
lock it separately with the mechanical key. Leave
only the SmartKey or SmartKey with
KEYLESS-GO* less its mechanical key with the
vehicle.
iYou can only cancel the separate trunk lock-
ing mode by means of the mechanical key.

466 Controls in detail
Power tilt/sliding sunroof
Opening and closing power tilt/sliding
sunroof
Warning!G
When closing the tilt/sliding sunroof, make
sure that there is no danger of anyone being
harmed by the closing procedure.
If the tilt/sliding sunroof encounters an ob-
struction that blocks its path in a circum-
stance where you are closing the tilt/sliding
sunroof by moving the tilt/sliding sunroof
switch past the resistance point, or by
pressing and holding button‹on the
SmartKey, by pressing and holding the sen-
sor surface (vehicles with KEYLESS-GO*) on
the outside door handle, the automatic re-
versal function will not operate.
The opening/closing procedure of the
tilt/sliding sunroof can be immediately halt-
ed by releasing the switch or, if the switch
was moved past the resistance point and re-
leased, by moving the switch in any direc-
tion.
The tilt/sliding sunroof is made out of glass.
In the event of an accident, the glass may
shatter. This may result in an opening in the
roof.
In a vehicle rollover, occupants not wearing
their seat belts or not wearing them properly
may be thrown out of the opening. Such an
opening also presents a potential for injury
for occupants wearing their seat belts
properly as entire body parts or portions of
them may protrude from the passenger
compartment.
When leaving the vehicle, always remove the
SmartKey or SmartKey with KEYLESS-GO*
from the starter switch, take it with you, and
lock the vehicle. Do not leave children unat-
tended in the vehicle, or with access to an
unlocked vehicle. A child’s unsupervised ac-
cess to a vehicle could result in an accident
and/or serious personal injury.
!To avoid damaging the seals, do not trans-
port any objects with sharp edges which can
stick out of the tilt/sliding sunroof.Do not open the tilt/sliding sunroof if there is
snow or ice on the roof, as this could result in
malfunctions.
The tilt/sliding sunroof can be opened or closed
manually should an electrical malfunction occur
(
page 638).
!Please keep in mind that weather conditions
can sometimes change rapidly. Make sure to
close the tilt/sliding sunroof when leaving the
vehicle. If water enters the vehicle interior, vehi-
cle electronics could be damaged which is not
covered by the Mercedes-Benz Limited
Warranty.
iWhen the tilt/sliding sunroof is open, reso-
nance noises may result in addition to the usual
wind noises. They are caused by minimal pres-
sure changes in the passenger compartment. To
reduce or eliminate these noises, change the po-
sition of the tilt/sliding sunroof or open a side
window slightly.

467 Controls in detail
Power tilt/sliding sunroof
1Push back to slide sunroof open
2Push forward to slide sunroof closed
3Push up to raise sunroof at rear
4Pull down to lower sunroof at rear
With the sunroof closed or tilted open, a
screen can be slid into the roof opening to
help provide shade. When sliding the sun-
roof open, the screen will also retract.
Switch on the ignition (page 336).
To open, close, raise or lower, move the
switch to resistance point in the re-
quired direction1to4 until the
tilt/sliding sunroof has reached the de-
sired position.
Express-operation: To open, close,
raise or lower, move the switch past
the resistance point in the required
direction1to4 and release.
The tilt/sliding sunroof opens or closes
completely.
Stopping during Express-opening/
closing: Move the switch in any direc-
tion.
iYou can also open or close the tilt/sliding
sunroof using the SmartKey, see “Summer open-
ing feature” (
page 376) and “Convenience
closing feature” (
page 376). Depending on
current position, the tilt/sliding sunroof may
also open or close when the air recirculation
button, (
page 453) is pressed and held
for 2 seconds.
iIf PRE-SAFE® has been activated, the
tilt/sliding sunroof closes automatically until
only a small gap remains.
iWith the SmartKey in starter switch
position0 or removed from the starter switch,
the tilt/sliding sunroof can be operated

until you open the driver’s or passenger door

for up to approximately 5 minutes
iIf the movement of the tilt/sliding sunroof is
blocked during the closing procedure, the sun-
roof will stop and reopen slightly.

468 Controls in detail
Power tilt/sliding sunroof
Synchronizing
The tilt/sliding sunroof must be synchro-
nized

after the tilt/sliding sunroof has been
closed manually (
page 638)

if the tilt/sliding sunroof can only be
opened with a jerking motion

after a malfunction
Switch on the ignition (page 336).
Press and hold the sunroof switch in
the direction of arrow3 until the
tilt/sliding sunroof is fully raised at the
rear.
Keep holding the sunroof switch in the
direction of arrow3 for approximately
1 second.
Check the Express-operation feature
(
page 467).
If the tilt/sliding sunroof opens com-
pletely, the sunroof is synchronized.
Otherwise repeat the above steps.!Do not open the tilt/sliding sunroof com-
pletely if it is not aligned. Otherwise you could
damage the tilt/sliding sunroof.

469 Controls in detail
Loading and storing
Loading and storing
Loading instructions
The total load weight including vehicle oc-
cupants and luggage/cargo should not ex-
ceed the load limit or vehicle capacity
weight as indicated on the corresponding
placard located on the driver’s door B-pillar
(
page 523).
Storage compartments
Warning!G
Always fasten items being carried as secure-
ly as possible using cargo tie-down hooks
and fastening materials appropriate for the
weight and size of the load.
In an accident, during hard braking or sud-
den maneuvers, loose items will be thrown
around inside the vehicle and can cause in-
jury to vehicle occupants unless the items
are securely fastened in the vehicle.
To help avoid personal injury during a colli-
sion or sudden maneuver, exercise care
when transporting cargo. Put luggage or car-
go in the trunk if possible.
Do not pile luggage or cargo higher than the
seat backs. Do not place anything on the
rear-window shelf.
Never drive vehicle with trunk open. Deadly
carbon monoxide (CO) gases may enter ve-
hicle interior resulting in unconsciousness
and death.
Warning!G
To help avoid personal injury during a colli-
sion or sudden maneuver, exercise care
when storing objects in the vehicle. Put lug-
g a g e o r c a r g o i n t h e t r u n k i f p o s s i b l e . D o n o t
pile luggage or cargo higher than the seat
backs.
Parcel nets cannot secure hard or heavy ob-
jects.
Keep compartment lids closed. This will help
to prevent stored objects from being thrown
about and injuring vehicle occupants during

braking

vehicle maneuvers or

an accident.
iAn overview of the storage compartments
can be found on (
page 32).
