395 Fuels, coolants, lubricants etc. - capacities
Te ch n ica l
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car care Index Engine oils
Engine oils are specifically tested for their suitability in
our engines. Therefore, use only engine oils
recommended by Mercedes-Benz. Information on
recommended brands is available at your authorized
Mercedes-Benz Center.
Please follow Service Booklet recommendations for
scheduled oil changes. Failure to do so could result in
engine damage not covered by the Mercedes-Benz
Limited Warranty.
Engine oil additives
Do not blend oil additives with engine oil. They may be
harmful to the engine operation.
Damage or malfunctions resulting from blending oil
additives are not covered by the Mercedes-Benz Limited
War ra nt y.Air conditioner refrigerant
R-134a (H FC) ref rigerant a nd special PAG l ubricating oil
is used in the air conditioner system.
Never use R-12 (CFC) or mineral-based lubricating oil,
otherwise damage to the system will occur.
Brake fluid
During vehicle operation, the boiling point of the brake
fluid is continuously reduced through the absorption of
moisture from the atmosphere. Under extremely hard
operating conditions, this moisture content can lead to
the formation of bubbles in the system thus reducing
the system’s efficiency.
The brake fluid must therefore be replaced every two
years, preferably in the spring.
It is recommended to use only brake fluid approved by
Mercedes-Benz. Your authorized Mercedes-Benz Center
will provide you with additional information.
Page 402 of 424

396 Fuels, coolants, lubricants etc. - capacities
Te ch n ica l
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car care Index
Premium unleaded gasoline
Caution!
To maintain the engine’s durability and performance,
premium unleaded gasoline must be used. If premium
unleaded is not available and low octane fuel is used,
follow these precautions:
•have the fuel tank filled only partially with unleaded
regular and fill up with premium unleaded as soon
as possible,
•avoid full throttle driving and abrupt acceleration,
•do not exceed an engine speed of 3000 rpm, if the
vehicle is loaded with a light load such as two
persons and no luggage,
•do not exceed
2/3 of maximum accelerator pedal
position, if the vehicle is fully loaded or operating in
mountainous terrain.Fuel requirements
Use only Premium unleaded meeting ASTM
standa rd D 439:
The octane number (posted at the pump) must be
91 min. It is an average of both the Research (R) octane
number and the Motor (M) octane number: (R+M)/2).
This is also known as ANTI-KNOCK INDEX.
Unleaded gasoline containing oxygenates such as
Ethanol, IPA, IBA and TBA can be used provided the
ratio of any one of these oxygenates to gasoline does not
exceed 10%, MTBE not to exceed 15%.
The ratio of Methanol to gasoline must not exceed 3%
plus additional cosolvents.
Using mixtures of Ethanol and Methanol is not allowed.
Gasohol, which contains 10% Ethanol and 90% unleaded
gasoline, can be used.
These blends must also meet all other fuel requirements
such as resistance to spark knock, boiling range, vapor
pressure etc..
Page 403 of 424

397 Fuels, coolants, lubricants etc. - capacities
Te ch n ica l
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car care Index Gasoline additives
A major concern among engine manufacturers is carbon
build up caused by gasoline. Mercedes-Benz
recommends the use of only quality gasoline containing
additives that prevent the build up of carbon deposits.
After an extended period of using fuels without such
a d d i t i ve s , c a r b o n d e po si t s c a n b u il d u p e s pe c ia l ly o n t h e
intake valves and in the combustion area, leading to
engine performance problems such as:
•warm-up hesitation,
•unstable idle,
•knocking/pinging,
•misfire,
•power loss.
Do not blend other specific fuel additives with fuel.
They only result in unnecessary cost, and may be
harmful to the engine operation.
Damage or malfunctions resulting from poor fuel
quality or from blending specific fuel additives are not
covered by the Mercedes-Benz Limited Warranty.Coolants
The engine coolant is a mixture of water and
anticorrosion/antifreeze, which provides:
•corrosion protection,
•freeze protection,
•boiling protection (by increasing the boiling point).
The cooling system was filled at the factory with a
coolant providing freeze protection to approximately
-22°F (-30°C) and corrosion protection.
If the antifreeze mixture is effective to -22°F (-30°C), the
boiling point of the coolant in the pressurized cooling
system is reached at approximately 266°F (130°C).
The cool ant sol ution must be used yea r round to provide
the necessary corrosion protection and increase in the
boil-over protection. You should have it replaced every
3years.
To provide the important corrosion protection, the
solution must be at least 45% anticorrosion/antifreeze
(equals a freeze protection to approx. - 22°F [-30°C]). If
you use a solution that is more than 55% anticorrosion/
antifreeze (freeze protection to approx. - 49°F [-45°C]),
Page 404 of 424

398 Fuels, coolants, lubricants etc. - capacities
Te ch n ica l
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car care Index
the engine temperature will increase due to the lower
h eat transfer ca pa bil ity of th e sol ution. Therefore, d o not
use more than this amount of anticorrosion/antifreeze.
If the coolant level is low, water and MB anticorrosion/
antifreeze should be used to bring it up to the proper
level (have cooling system checked for signs of leakage).
The water in the cooling system must meet minimum
requirements, which are usually satisfied by normal
drinking water. If you are not sure about the water
quality, consult your authorized Mercedes-Benz Center.
Anticorrosion/antifreeze
Your vehicle contains a number of aluminium parts. The
use of aluminium components in motor vehicle engines
necessitates that anticorrosion/antifreeze coolant used
in such e ng ines b e specif ica lly formul ated to protec t th e
aluminium parts. (Failure to use such anticorrosion/
antifreeze coolant will result in a significantly
shortened service life.)
Therefore the following product is strongly
recommended for use in your vehicle: Mercedes-Benz
anticorrosion/antifreeze agent.Before the start of the winter season (or once a year in
the hot southern regions), you should have the
anticorrosion/antifreeze concentration checked. The
coolant is also regularly checked each time you bring
your vehicle to your authorized Mercedes-Benz Center
for service.
Anticorrosion/antifreeze quantity
Model Approx. freeze protection
– 35°F
(– 37°C)– 49°F
(– 45°C)
CL 500,
CL 55 AMG6.1 US qt
(5.75 l)6.7 US qt
(6.3 l)
CL 600 6.3 US qt
(6.0 l)7. 0 U S q t
(6.6 l)
Page 405 of 424

399 Consumer information
Te ch n ica l
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car care Index Consumer information
This has been prepared as required of all manufactures
of passenger cars under Title 49, Code of U.S. Federal
Regulations, Part 575 pursuant to the “National Traffic
and Motor Vehicle Safety Act of 1966”.
Uniform tire quality grading
Quality grades can be found where applicable on the
tire sidewall between tread shoulder and maximum
section width. For example:
All passenger car tires must conform to federal safety
requirements in addition to these grades.
Treadwear
The treadwear grade is a comparative rating based on
the wear rate of the tire when tested under controlled
conditions on a specified government test course. For
example, a tire graded 150 would wear one and one-half
(1
1/2) times as well on the government course as a tire
graded 100. The relative performance of tires depends
upon the actual conditions of their use, however, and may depart significantly from the norm due to
variations in driving habits, service practices and
differences in road characteristics and climate.
Traction
The traction grades, from highest to lowest are AA, A, B,
and C. Those grades represent the tire’s ability to stop
on wet pavement as measured under controlled
conditions on specified government test surfaces of
asphalt and concrete. A tire marked C may have poor
traction performance.
Tread wear 200 Traction AA Temperature A
Wa r n i n g !
The traction grade assigned to this tire is based on
straightahead braking traction tests, and does not
include acceleration, cornering, hydroplaning, or
peak traction characteristics.
Page 406 of 424

400 Consumer information
Te ch n ica l
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car care Index
Temp era tur e
The temperature grades are A (the highest), B, and C,
representing the tire’s resistance to the generation of
heat and its ability to dissipate heat when tested under
controlled conditions on a specified indoor laboratory
test wheel. Sustained high temperature can cause the
material of the tire to degenerate and reduce tire life,
and excessive temperature can lead to sudden tire
failure. The grade C corresponds to a level of
performance which all passenger car tires must meet
under the Federal Motor Vehicle Safety Standard
No. 109. Grades B and A represent higher levels of
performance on the laboratory test wheel than the
minimum required by law.
Wa r n i n g !
The temperature grade for this tire is established
for a tire that is properly inflated and not
overloaded. Excessive speed, underinflation, or
excessive loading, either separately or in
combination, can cause excessive heat build up
and possible tire failure.
Page 407 of 424

401 Index
Te ch n ica l
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car careIndex
Index
AABS (Antilock brake system) .......................................269
Malfunction indicator lamp .....................................294
ACTIV E BODY CONTRO L -
malfunction and warning messages ...................... 310
Active body control (ABC) ............................................275
Active body control (ABC) fluid level .........................332
Air conditioner refrigerant ...........................................395
Air distribution, manual ............................................... 169
Air volume, manual ....................................................... 169
Airbag deactivation system ............................................ 88
Airbag OFF indicator lamp ...........................................296
Airbags .............................................................................. 92
Front airbags ............................................................... 92
Side impact airbags .................................................... 95
Window curtain airbags ............................................. 95
Alarm system ............................................................. 62, 64
Anticorrosion/antifreeze ................... 247, 333, 393, 398
Antiglare night position ............................................... 106
Antilock brake system (ABS) .......................................269
Malfunction indicator lamp .....................................294
Antitheft alarm system ................................................... 62Aquaplaning .................................................................. 244
Armrest, rear bench ....................................................... 195
Ashtrays ........................................................................... 196
Center console, front ................................................ 196
Rear seats ................................................................... 197
Audio systems .................................................................125
Cassette player ..........................................................127
CD player ....................................................................126
Radio ...........................................................................125
Automatic central locking ..............................................52
Automatic climate control ............................................ 164
Activated charcoal filter ...........................................172
Adjustable air outlets,
rear passenger compartment .............................177
Air distribution, manual .......................................... 169
Air recirculation ........................................................ 171
Air volume, manual .................................................. 169
Basic setting ............................................................... 168
Defogging windows ...........................................170, 171
Defrosting ...................................................................170
Display and controls ................................................. 166
Dust filter ................................................................... 167
Economy mode ..........................................................173
Front center console
storage compartment ventilation .......................175
Rear window defroster ............................................. 176
Page 408 of 424

402 Index
Te ch n ica l
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car careIndex
Residual engine heat utilization ............................ 174
Special settings ......................................................... 169
Switching on and off ................................................ 175
Windows fogged on the inside ................................ 170
Windows fogged on the outside .............................. 171
Automatic transmission ...............................................229
Emergency operation ...............................................237
Fluid level ...................................................................332
Program mode selector switch ...............................236
Selector lever position ..............................................232
BBabySmart
TM airbag deactivation system ..................... 88
Self-test ......................................................................... 89
Backrest ............................................................................. 72
BAS (Brake assist system) ............................................268
Battery .............................................................................346
Battery recycling .......................................................348
BATTERY/ALTERNATOR -
malfunction and warning messages ......................299
Block heater ....................................................................249
BRAKE ASSIST - malfunction
and warning messages ............................................300
Brake assist system (BAS) ............................................268Brake fluid ...........................................240, 292, 393, 395
BRAKE FLUID -
malfunction and warning messages ......................301
BRAKE LINING WEAR -
malfunction and warning messages ......................301
Brake pad wear ...............................................................301
Brake warning lamp ..................................................... 292
Brake fluid low ......................................................... 292
Brakes ...................................................238, 240, 268, 272
CCapacities
Fuels, coolants, lubricants etc. .............................. 393
Card, KEYLESS-GO ..........................................................28
Cargo tie-down hooks ................................................... 200
Catalytic converter ........................................................ 220
Center console .................................................................. 24
Center console lighting ................................................. 185
Central locking switch .................................................... 50
Central locking system .................................................... 34
Automatic central locking .........................................52
Central locking switch ............................................... 50
Choosing global or selective mode .....................37, 43
Electronic main key .................................................... 29
Page 409 of 424

403 Index
Te ch n ica l
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car careIndex KEYLESS-GO-card ....................................................... 31
Locking and unlocking .............................................. 36
Locking and unlocking
with KEYLESS-GO-card ......................................... 40
Mechanical keys .......................................................... 47
Remote control ............................................................ 28
Simultaneous use of electronic main key
and KEYLESS-GO-card .......................................... 44
Summer opening/convenience feature ................... 45
Changing batteries in the KEYLESS-GO-card ...........366
Changing wheels ...........................................................340
CHECK ENGINE
malfunction indicator lamp .....................................290
Check regularly and before a long trip ......................287
Checking engine oil level
Via engine oil level indicator .................................. 154
Via oil dipstick ........................................................... 331
Child restraint ............................................ 70, 82, 88, 102
Cleaning and care of the vehicle ................................. 374
Coat hooks ...................................................................... 192
COMAND, radio and telephone ...................................208
Combination switch ...................................................... 160
Consumer information ..................................................399
Control and operation of radio transmitters .............208
COOLANT (coolant level) -
malfunction and warning messages ......................304COOLANT (coolant temperature) -
malfunction and warning messages ..................... 305
Coolant level
Adding ........................................................................ 333
Checking .................................................................... 333
Coolant temperature gauge .......................................... 117
Coolants .......................................................................... 397
Anticorrosion/antifreeze quantity ........................ 398
Courtesy lighting ........................................................... 185
Cruise control ................................................................ 250
CRUISE CONTROL -
malfunction and warning messages ..................... 309
Cup holder
Center console, front ................................................ 193
Rear bench armrest ................................................... 195
DDashboard ......................................................................... 22
Daytime running lamps ................................................ 158
Deep water
Driving instructions ................................................ 248
DISPLAY DEFECTIVE (engine control unit) -
malfunction and warning messages ..................... 298
DISPLAY DEFECTIVE (several systems) -
malfunction and warning messages ..................... 298
Page 410 of 424

404 Index
Te ch n ica l
data Instruments
and controlsOperation DrivingInstrument
cluster displayPractical hints Car careIndex
Display illumination .......................................................116
Distronic (DTR) ...................................................... 133, 253
Activation of Distronic .............................................256
Additional driving hints .......................................... 261
Cleaning sensor ........................................................378
Deactivation of Distronic .........................................258
Displays in the speedometer dial ...........................267
Distance warning function ......................................264
Distronic settings ......................................................265
Driving with Distronic activated ............................259
Invalid attempts to activate .....................................257
Multifunction display ...............................................266
Warning lamp ............................................................295
DISTRONIC (DTR) -
malfunction and warning messages ...................... 321
DOOR -
malfunction and warning messages ...................... 316
Door control panel ........................................................... 20
Door entry lamps ........................................................... 185
Doors .................................................................................. 48
Power closing assist ................................................... 50
Drinking and driving ....................................................239
Drive sensibly - save fuel ..............................................239
Driving instructions ......................................................239
Driving off ....................................................................... 241
EEasy-entry/exit feature ...................................................66
ELEC. STABIL. PROGR. -
malfunction and warning messages ..................... 303
Electronic main key .........................................................29
Changing batteries .................................................. 363
Synchronizing remote control ............................... 365
Electronic stability program (ESP) .............................. 271
Warning lamp ........................................................... 295
Emergency call
See Tele Aid ............................................................... 210
Emergency engine shut-down ..................................... 368
Emergency operation of sliding/pop-up roof ............ 369
Emergency tensioning retractor (ETR) ......................... 91
Emergency trunk lid release button ............................. 61
Emergency unlocking in case of accident ...................52
Emission control ............................................................221
Emission control label .................................................. 386
Engine compartment .................................................... 328
Engine malfunction
CHECK ENGINE
malfunction indicator lamp ............................... 290
Engine oil additives ...................................................... 395
Engine oil consumption ................................................ 155
