221 Controls in detail
Soft top
Unlocked status noticed when stopped
Switch on the ignition.

To lock the soft top in its fully closed
position, press soft top switch.
The message
Top closed
will be shown
in the multifunction display.
or:

To lock the soft top in its fully opened
position, pull up on the soft top switch.
The message
Top open
will be shown in
the multifunction display.Unlocked status noticed while driving

Stop the vehicle.

Leave the ignition switched on.

To lock the soft top in its fully closed
position, press soft top switch.
The message
Top closed
will be shown
in the multifunction display.
or:

To lock the soft top in its fully opened
position, pull up on the soft top switch.
The message
Top open
will be shown in
the multifunction display.
Warning!
G
Stop the vehicle and lock the soft top before
continuing to drive. You could otherwise en-
danger yourself and others.
Warning!
G
If the soft top does not completely open or
close, the roof hydraulics will lose pressure
and the soft top is lowered

after approximately seven minutes
when the ignition is switched on


after approximately 15 seconds when
the ignition is switched off
Shortly before the soft top is lowered, a
warning will sound and the soft top switch
lamp will flash. In the multifunction display
you will see K, and the message
Top
being lowered!
appears


Properly lock the soft top (
page 220)
before continuing to drive
ProCarManuals.com

222 Controls in detailSoft topOpening and closing the soft top with
the SmartKey
The windows will also be opened or closed
when you operate the power windows with
the SmartKey.

Aim the transmitter eye at the door
handle.Opening (Summer opening feature)

Press and hold button Πuntil the
soft top is completely open.
The windows and soft top begin to
open after approximately one second.
During the opening procedure the mul-
tifunction display shows the message Top in operation
.
If the opening procedure is finished,
the multifunction display will briefly
show the message Top open
.

Release transmit button Πto inter-
rupt procedure.
Warning!
G
Before operating the soft top, make sure no
persons can be injured by the moving parts
(roll bar, soft top frame, and soft top com-
partment cover) due to negligence.
Hands must never be placed near the roll
bar, soft top frame, upper windshield area,
shelf behind roll bar, or soft top storage
compartment while the soft top is being
raised or lowered. Serious personal injury
may occur.
If potential danger exists, release the re-
spective button on the SmartKey. This im-
mediately interrupts the raising or lowering
procedure. You then can operate Πto
lower or ‹ to raise the soft top away
from the danger zone.
ProCarManuals.com

223 Controls in detail
Soft top
Closing (Convenience feature)
Aim the transmitter eye at the door
handle.

Press and hold button ‹ until the
soft top is completely closed.
The windows and soft top begin to
close after approximately one second.
During the closing procedure the multi-
function display shows the message Top in operation
.
If the soft top is closed and locked, the
multifunction display will briefly show
the message
Top closed
.

Release transmit button ‹ to inter-
rupt procedure.
Ensure that all side windows and the
soft top are properly closed before leaving
the vehicle.Wind screen
The wind screen deflects drafts away from
the driver and passenger when the soft top
is lowered. It is stored in a separate stor-
age bag in the trunk.
Warning!
G
If the soft top does not completely open or
close a warning sounds and the soft top
switch flashes. In the multifunction display
you will see K, and the message
Top
being lowered!
appears. After about
15 seconds the roof hydraulics lose pres-
sure.
Properly lock the soft top (
page 220) be-
fore continuing to drive.
Warning!
G
The wind screen can restrict the driver’s vi-
sion to the rear of the vehicle. To prevent a
possible accident when visibility is limited
(e.g. in darkness), the upper part of the wind
screen should be folded back.
ProCarManuals.com

224 Controls in detailSoft topInstalling
Remove the wind screen from its stor-
age bag.
1Upper section
2Lower section

Fold sections1 and2 together.3Catch
4Retainer claw
5Snap fastener

Press retainer claw4 on upper sec-
tion into snap fastener5 of lower sec-
tion.6Retaining lugs
7Mounting fixture on right side
8Catch

Fold retaining lugs6 out.

Slide pre-assembled wind screen into
mounting fixture on right side7 using
retaining pin on right side. Simulta-
neously, retaining lugs6 should slide
into seat belt passage in rear bench
seat.
ProCarManuals.com

225 Controls in detail
Soft top

Pull catch8 back and guide left re-
taining pin into mounting fixture on left
side.

Fold upper section of wind screen up
toward head restraints until it stops.Removing

Fold upper section of wind screen back
down.

Pull catch8 back and pull wind
screen out toward front of vehicle. Be
careful not to damage interior trim with
guide tabs.

Fold retaining lugs6 back.
9Catch

Press catch 9 and fold upper and low-
er sections back.

Place the wind screen back into the
bag.
Warning!
G
Check for secure locking by pulling up on
the wind screen.
To prevent personal injury, remove wind
screen if rear seats are to be occupied by
passengers.
ProCarManuals.com

226 Controls in detailDriving systems
Driving systemsThe driving systems of your vehicle are de-
scribed on the following pages:

Cruise control and Distronic*, with
which the vehicle can maintain a preset
speed


Parktronic*, which serves as a parking
assistant.
For information on the BAS, ABS, and ESP
driving systems, see “Driving safety sys-
tems” (
page 76).
Cruise control
Cruise control automatically maintains the
speed you set for your vehicle.
Use of cruise control is recommended for
driving at a constant speed for extended
periods of time. You can set or resume
cruise control at any speed over 20 mph
(30 km/h).
The cruise control function is operated by
means of the cruise control lever.
The cruise control lever is the uppermost
lever found on the left-hand side of the
steering column (
page 20).
Warning!
G
Cruise control is a convenience system de-
signed to assist the driver during vehicle op-
eration. The driver is and must remain at all
times responsible for the vehicle speed and
for safe brake operation.
Only use cruise control if the road, traffic
and weather conditions make it advisable to
travel at a steady speed.

The use of cruise control can be danger-
ous on winding roads or in heavy traffic
because conditions do not allow safe
driving at a steady speed.


The use of cruise control can be danger-
ous on slippery roads. Rapid changes in
tire traction can result in wheel spin and
loss of control.


Deactivate cruise control when driving
in fog.
The “Resume” function should only be oper-
ated if the driver is fully aware of the previ-
ously set speed and wishes to resume this
particular preset speed.
ProCarManuals.com

227 Controls in detail
Driving systems
1Set current or higher speed
2Set current or lower speed
3Cancel cruise control
4Resume at last set speed
Setting current speed
Accelerate or decelerate to the desired
speed.

Briefly lift1 or depress2 the cruise
control lever.
The current speed is set.

Remove your foot from the accelerator
pedal.
Cruise control is activated.Canceling cruise control
There are several ways to cancel cruise
control:

Step on the brake pedal.
or

Briefly push the cruise control lever to
position3.
Cruise control will be canceled. The
last speed set will be stored for later
use.iOn uphill or downhill grades, cruise
control may not be able to maintain the
set speed. Once the grade eases, the
set speed will be resumed.
!Moving gear selector lever to
positionN while driving also cancels
cruise control. However, the gear se-
lector lever should not be moved to
positionN while driving except to coast
when the vehicle is in danger of skid-
ding (e.g. on icy roads).iThe last stored speed is canceled when
you turn off the engine.
ProCarManuals.com

228 Controls in detailDriving systemsSetting a higher speed
Lift cruise control lever to position1
and hold it up until the desired speed is
reached.

Release cruise control lever.
The new speed is set.
Setting a lower speed

Depress cruise control lever to
position2 and hold it down until the
desired speed is reached.

Release cruise control lever.
The new speed is set.Fine adjustment in 1 mph
(Canada: 1 km/h) increments
Faster

Briefly tip cruise control lever in the di-
rection of arrow1.
Slower

Briefly tip cruise control lever in the di-
rection of arrow2.Setting to last stored speed
(“Resume” function)

Briefly push cruise control lever to
position4.
The cruise control will resume the last
set speed.

Remove your foot from the accelerator
pedal.
iDepressing the accelerator pedal does
not deactivate cruise control. After
brief acceleration (e.g. for passing),
cruise control will resume the last
speed set.
iWhen you use the cruise control lever
to decelerate, the transmission will au-
tomatically downshift if the engine’s
braking power does not brake the vehi-
cle sufficiently.
Warning!
G
The speed stored in memory should only be
set again if prevailing road conditions per-
mit. Possible acceleration or deceleration
differences arising from returning to preset
speed could cause an accident and/or seri-
ous injury to you and others.
ProCarManuals.com

229 Controls in detail
Driving systems
Distronic*
When activated, the Distronic adaptive
cruise control system increases the driving
convenience afforded by the cruise control
during travel on expressways and other
major roads.

If the Distronic distance sensor detects
a slower moving vehicle directly ahead,
your vehicle speed will be reduced so
that you follow that vehicle at a preset
distance.


If there is no vehicle directly ahead of
you, Distronic will function in the same
way as cruise control (
page 226).
Warning!
G
Distronic adaptive cruise control is no sub-
stitute for active driving involvement. It does
not react to stationary objects, nor recog-
nize or predict the curvature and lane layout
or the movement of vehicles ahead. Distron-
ic can only apply a maximum of 20% of the
vehicle’s braking power.
It is the driver’s responsibility at all times to
be attentive to traffic and road conditions
and to provide the steering, braking and oth-
er driving inputs necessary to retain control
of the vehicle.Warning!
G
Distronic is a convenience system. Its speed
adjustment reduction capability is intended
to make cruise control more effective and
usable when traffic speeds vary. However, it
is not intended to, nor does it, replace the
need for extreme care. The responsibility for
the vehicle speed and the distance to the ve-
hicle ahead, including most importantly
brake operation to assure safe stopping dis-
tance, always rests with the driver.
Distronic cannot take street and traffic con-
ditions into account.
Warning!
G
Distronic requires familiarity with its opera-
tional characteristics. We strongly recom-
mend that you review the following
information carefully before operating the
system.iFor operation in the USA only: This de-
vice complies with Part 15 of the
FCC Rules. Operation is subject to the
following two conditions:

This device may not cause harmful
interference, and


this device must accept any inter-
ference received, including interfer-
ence that may cause undesired
operation.
Any unauthorized modification to this
device could void the user’s authority
to operate the equipment.
ProCarManuals.com

230 Controls in detailDriving systemsWarning!
G
Distronic cannot take street and traffic con-
ditions into account. Only use Distronic if
the road, traffic and weather conditions
make it advisable to travel at a steady
speed.Warning!
G
Use of Distronic can be dangerous on slip-
pery roads. Rapid changes in tire traction
can result in wheel spin and loss of control.
Distronic does not act upon adverse sight
distance conditions. Do not use Distronic
during conditions of fog and heavy rain,
snow or sleet.
Warning!
G
Close attention to road and traffic condi-
tions is imperative at all times, regardless of
whether or not Distronic is activated.
Use of Distronic can be dangerous on wind-
ing roads or in heavy traffic because condi-
tions do not allow safe driving at a steady
speed.
Distronic will not react to stationary objects
in the roadway (e.g. a stopped vehicle in a
traffic jam or a disabled vehicle). Distronic
will also not respond to oncoming vehicles.
Switch off Distronic:

when changing from the left to the right
lane if vehicles are moving more slowly
in the left lane


when entering a turn lane or highway off
ramp


in complex driving situations, such as in
highway construction zones
In these situations, Distronic will continue to
maintain the set speed unless deactivated.
Distronic is designed and intended only to
maintain a set speed and keep a set dis-
tance from moving objects in front of it.Warning!
G
The “Resume” function should only be oper-
ated if the driver is fully aware of the previ-
ously set speed and wishes to resume this
particular preset speed.
ProCarManuals.com
