249 Controls in detail
Power windows
Stopping windows
Press or pull respective switch again.
Opening and closing the windows with
the SmartKey
The power tilt/sliding sunroof*
(
p a g e 2 5 1 ) w i l l a l s o b e o p e n e d o r c l o s e d
when the power windows are operated
with the SmartKey.

Aim transmitter eye at the driver’s door
handle.
!If the upward movement of a door win-
dow is blocked during the closing pro-
cedure, the door window will stop and
open slightly.
Remove the obstruction, pull the
switch again past the resistance point
and release.
If the door window still does not close
when there is no obstruction, then pull
the switch and hold it. The door window
will then close without the obstruction
sensor function.Warning!
G
Driver’s door only:
If within five seconds you again pull the
switch past the resistance point and re-
lease, the automatic reversal will not
function.
Warning!
G
Never operate the windows or tilt/sliding
sunroof* if there is the possibility of anyone
being harmed by the opening or closing pro-
cedure.
In the event that the procedure causes
potential danger, the procedure can be
immediately halted by releasing the button
on the SmartKey. To reverse direction of
movement, press Œ for opening or ‹
for closing.

250 Controls in detailPower windowsOpening (Summer opening feature)
Press and hold button Πafter
unlocking the vehicle.
The windows and tilt/sliding sunroof*
begin to open after approximately one
second.

Release the Πbutton to stop
procedure.
Closing (Convenience feature)

Press and hold button ‹ after
locking the vehicle.
The windows and tilt/sliding sunroof*
begin to close after approximately one
second.

Release the ‹ button to stop
procedure.
Make sure all side windows and the
tilt/sliding sunroof* are properly closed
before leaving the vehicle.Closing the side windows and power
tilt/sliding sunroof* with KEYLESS-GO

Press and hold lock button at door
(page 58) until the side windows and
the tilt/sliding sunroof* are closed.
Synchronizing power windows
The power windows must be resynchro-
nized each time

after the battery has been
disconnected.


if the power windows cannot be fully
opened (Express-open) or closed
(Express-close).

Switch ignition on (
page 36).

Pull the power window switches until
the side windows are closed.
Hold the switches for approximately
one second.
The power windows are synchronized.
Warning!
G
When closing the windows and the tilt/slid-
ing sunroof*, make sure there is no danger
of anyone being harmed by the closing pro-
cedure.
The windows will not automatically re-open
if blocked during convenience closing.
If potential danger exists, proceed as fol-
lows:

Release the lock button.


Pull on the door handle and hold firmly.
The side windows and the tilt/sliding
sunroof* will open for about two sec-
onds if the door handle is held but the
door not opened.

251 Controls in detail
Power tilt/sliding sunroof*
Power tilt/sliding sunroof*
Opening and closing the power tilt/sliding sunroof
The tilt/sliding sunroof can be opened and
closed electrically. The switch for the
tilt/sliding sunroof is on the overhead
control panel.Sunroof switch1Push up to raise roof at rear
2Pull down to lower roof at rear
3Push forward to slide roof closed
4Push back to slide roof openWith the roof closed or tilted open, a
screen can be slid into the roof opening to
guard against sun rays. When sliding the
roof open, the screen will also retract.
Screen
Warning!
G
When closing the tilt/sliding sunroof, make
sure there is no danger of anyone being
harmed by the closing procedure.
The opening/closing procedure of the
tilt/sliding sunroof can be immediately
halted by releasing the switch or, if the
switch was moved past the resistance point
and released, by moving the switch in any
direction.
The tilt/sliding sunroof is made out of glass.
In the event of an accident, the glass may
shatter. This may result in an opening in the
roof.
In a vehicle rollover, occupants not wearing
their seat belts or not wearing them properly
may be thrown out of the opening. Such an
opening also presents a potential for injury
for occupants wearing their seat belts
properly as entire body parts or portions of
them may protrude from the passenger
compartment.


252 Controls in detailPower tilt/sliding sunroof*

Switch on ignition (
page 36).
Opening and closing the power
tilt/sliding sunroof

To open, close, raise, or lower the
tilt/sliding sunroof, move the sunroof
switch to resistance point in the
required direction of arrows1 to4.
Release the sunroof switch when the
tilt/sliding sunroof has reached the
desired position.Fully opening (Express-open) and
closing (Express-close) the power
tilt/sliding sunroof

To open or close the tilt/sliding
sunroof, move the sunroof switch past
the resistance point in the required
direction of arrow3 or4 and
release.
The tilt/sliding sunroof opens or closes
completely.
Stopping the power tilt/sliding sunroof
during Express-operation

Move the sunroof switch in any
direction.
When leaving the vehicle, always remove the
SmartKey or SmartKey with KEYLESS-GO*
from the starter switch, take it with you, and
lock the vehicle. Do not leave children
unattended in the vehicle, or with access to
an unlocked vehicle. Unsupervised use of
vehicle equipment can cause an accident
and/or serious personal injury.!To avoid damaging the seals, do not
transport any objects with sharp edges
which can stick out of the tilt/sliding
sunroof.
Do not open the tilt/sliding sunroof if
there is snow or ice on the roof, as this
could result in malfunctions.
The tilt/sliding sunroof can be opened
or closed manually should an electrical
malfunction occur (
page 401).
iYou can also open or close the tilt/slid-
ing sunroof using the:

SmartKey (summer opening/con-
venience feature) (
page 249)


button, in the control panel of
the climate control (
page 185) or
automatic climate control
(
page 195)


buttone in the control panel of
the automatic climate control
(page 195)
iIf the movement of the tilt/sliding
sunroof is blocked during the closing
procedure, the tilt/sliding sunroof will
stop and re-open slightly.


253 Controls in detail
Power tilt/sliding sunroof*
Opening and closing the power
tilt/sliding sunroof with the SmartKey
The power windows (
page 249) will also
be opened or closed when you operate the
tilt/sliding sunroof with the SmartKey.

Aim transmitter eye at the driver’s door
handle.
Opening (Summer opening feature)

Press and hold button Πafter
unlocking the vehicle.
The windows and the tilt/sliding
sunroof begin to open after
approximately one second.

Release the Πbutton to stop
procedure.Closing (Convenience feature)

Press and hold button ‹ after
locking the vehicle.
The windows and the tilt/sliding
sunroof begin to close after
approximately one second.

Release ‹ button to stop
procedure.
Make sure all side windows and the
tilt/sliding sunroof are properly closed
before leaving the vehicle.
Closing the power tilt/sliding sunroof
with KEYLESS-GO* (Convenience
feature)
The power windows (
page 249) will also
be closed when the power tilt/sliding
sunroof is operated with the KEYLESS-GO
function.

Press and hold lock button at door
(page 58) until the side windows and
the tilt/sliding sunroof are closed.
Warning!
G
Never operate the windows or tilt/sliding
sunroof if there is the possibility of anyone
being harmed by the opening or closing pro-
cedure.
In the event that the procedure causes
potential danger, the procedure can be
immediately halted by releasing the
transmit button on the SmartKey. To reverse
direction of movement, press button Œ
for opening or ‹ for closing.

254 Controls in detailPower tilt/sliding sunroof*
Synchronizing the power tilt/sliding sunroof
The tilt/sliding sunroof must be
synchronized each time after:

the battery has been disconnected or
discharged


the tilt/sliding sunroof has been closed
manually (
page 401)


the tilt/sliding sunroof does not open
smoothly


a malfunction

Switch on the ignition (
page 36).

Move and hold the sunroof switch in
the direction of arrow 1 (
page 251)
until the tilt/sliding sunroof is fully
raised at the rear.
Hold the sunroof switch for
approximately one second.

Check the Express-open feature
(page 252).
If the tilt/sliding sunroof opens
completely, the tilt/sliding sunroof is
synchronized. Otherwise repeat the
above steps.
Warning!
G
When closing the windows and the
tilt/sliding sunroof, make sure there is no
danger of anyone being harmed by the clos-
ing procedure.
The tilt/sliding sunroof will not automatical-
ly reopen if blocked during convenience
closing.
If potential danger exists, proceed as fol-
lows:

Release the lock button.


Pull on the door handle and hold firmly.
The side windows and the tilt/sliding
sunroof will open for as long as the door
handle is held but the door not opened.

255 Controls in detail
Driving systems
Driving systems
The driving systems of your vehicle are de-
scribed on the following pages:

Cruise control, with which the vehicle
can maintain a preset speed


Parktronic*, which serves as a parking
assistant.
For information on the BAS, ABS, and ESP
driving systems, see “Driving safety sys-
tems” (
page 84).
Cruise control
Cruise control automatically maintains the
speed you set for your vehicle.
Use of cruise control is recommended for
driving at a constant speed for extended
periods of time.
CLK 320/CLK 55 AMG:
You can set or resume cruise control at any
speed over 20 mph (30 km/h).
CLK 500:
You can set or resume cruise control at any
speed over 25 mph (40 km/h).
The cruise control function is operated by
means of the cruise control lever.
The cruise control lever is the uppermost
lever on the left-hand side of the steering
column (
page 22).
Warning!
G
Cruise control is a convenience system de-
signed to assist the driver during vehicle op-
eration. The driver is and must remain at all
times responsible for the vehicle speed and
for safe brake operation.
Only use cruise control if the road, traffic
and weather conditions make it advisable to
travel at a steady speed.

The use of cruise control can be danger-
ous on winding roads or in heavy traffic
because conditions do not allow safe
driving at a steady speed.


The use of cruise control can be danger-
ous on slippery roads. Rapid changes in
tire traction can result in wheel spin and
loss of control.


Deactivate cruise control when driving
in fog.
The “Resume” function should only be oper-
ated if the driver is fully aware of the previ-
ously set speed and wishes to resume this
particular preset speed.

256 Controls in detailDriving systems1Set current or higher speed
2Set current or lower speed
3Cancel cruise control
4Resume at last set speedSetting current speed

Accelerate or decelerate to the desired
speed.

Briefly lift1 or depress2 the cruise
control lever.
The current speed is set.

Remove your foot from the accelerator
pedal.
Cruise control is activated.
The selected speed appears in the multi-
function display for approximately five sec-
onds, and the corresponding speedometer
segments from the selected speed to the
vehicle maximum speed are illuminated.
Warning!
G
CLK 500:
Cruise control brakes automatically so that
the set speed is not exceeded. The brake
pedal is depressed automatically to do this.
Keep in mind that cruise control is a conve-
nience system designed to assist the driver
during vehicle operation. The driver is and
must always remain responsible for the ve-
hicle’s speed and for safe brake operation.
Keep driver’s foot area clear at all times, in-
cluding the area under the brake pedal. Ob-
jects stored in this area may impair pedal
movement which could interfere with the
braking ability of the cruise control system.
Do not place your foot under the brake pedal
- your foot could become caught.

257 Controls in detail
Driving systems
Canceling cruise control
There are several ways to cancel cruise
control:
Step on the brake pedal.
Cruise control is canceled. The last
speed set is stored for later use.
or

Briefly push the cruise control lever to
position3.
Cruise control is canceled. The last
speed set is stored for later use.
iOn uphill or downhill grades, cruise
control may not be able to maintain the
set speed. Once the grade eases, the
set speed will be resumed.
CLK 320/CLK 55 AMG:
If the engine’s braking power does not
brake the vehicle sufficiently on down-
hill grades, the automatic transmission
will automatically downshift.
CLK 500:
On downhill grades, the cruise control
will hold the set speed with active brak-
ing action.
In addition, on longer downhill grades
the automatic transmission will auto-
matically downshift.
iThe last stored speed is canceled when
you turn off the engine.
iCruise control automatically switched
off, if
CLK 320/CLK 55 AMG:

you step on the brake pedal.


you move the gear selector lever in
positionN while driving.


the vehicle speed is under 20 mph
(30 km/h).


ESP is in operation.
The segments in the multifunction dis-
play are flashing.
CLK 500:


you step on the brake pedal.


you press the parking brake pedal.
In this case the segments in the
multifunction display (
page 256)
go out and no warning sounds.

258 Controls in detailDriving systems
Setting a higher speed
Lift cruise control lever to position1
and hold it up until the desired speed is
reached.

Release cruise control lever.
The new speed is set.Setting a lower speed

Depress cruise control lever to
position2 and hold it down until the
desired speed is reached.

Release cruise control lever.
The new speed is set.


the vehicle speed is under 25 mph
(40 km/h).


ESP is in operation or switched off
with the ESP switch (
page 87)


you move the gear selector lever in
positionN while driving
The segments in the multifunction dis-
play (page 256) go out, and an
acoustic warning sounds.
!Moving gear selector lever to
positionN while driving also cancels
cruise control. However, the gear se-
lector lever should not be moved to
positionN while driving except to coast
when the vehicle is in danger of skid-
ding (e.g. on icy roads).
iDepressing the accelerator pedal does
not deactivate cruise control. After
brief acceleration (e.g. for passing),
cruise control will resume the last
speed set.
iCLK 320/CLK 55 AMG
When you use the cruise control lever
to decelerate, the transmission will au-
tomatically downshift if the engine’s
braking power does not brake the vehi-
cle sufficiently.
CLK 500:
When you use the cruise control lever
to decelerate, the brake system will au-
tomatically brake the vehicle if the en-
gine’s braking power does not brake
the vehicle sufficiently.
