MERCEDES-BENZ CLK350 2008 C209 Owner's Manual

120 Controls in detail
Seats
For information on seat adjustment, see
“Adjusting” (
page 41).
Front seat active head restraints
You cannot remove the active head re-
straints on the driver’s and front passen-
ger’s seat.
For removal of the active head restraints
we recommend that you contact an
authorized Mercedes-Benz Center.
For information on head restraint adjust-
ment, see “Seats” (
page 41).For information on active head restraints,
see “Active head restraints” (
page 81).
Rear seat head restraints (CLK coupe)Head restraint height
1Release button
Warning!G
For your protection, drive only with properly
positioned head restraints.
Adjust the head restraint so that it is as
close to the head as possible and the center
of the head restraint supports the back of
the head at eye level. This will reduce the po-
tential for injury to the head and neck in the
event of an accident or similar situation.
Warning!G
For safety reasons, always drive with the
rear head restraints in the upright position
when the rear seats are occupied.
Keep the area around head restraints clear
of articles (e.g. clothing) to not obstruct the
folding operation of the head restraints.
iAdjust the head restraint in such a way that
it is as close to the head as possible.
Warning!G
For your protection, drive only with properly
positioned head restraints.
Adjust the head restraint so that it is as
close to the head as possible and the center
of the head restraint supports the back of
the head at eye level. This will reduce the po-
tential for injury to the head and neck in the
event of an accident or similar situation.

121 Controls in detail
Seats
Raising
Manually adjust the height of the head
restraint by pulling it upward.
If the head restraint is fully retracted,
push release button1 and pull the
head restraint up.
Lowering
To lower the head restraint, push
release button1 and push down on
the head restraint.Folding head restraints back with re-
lease button
1Release button
Push release button1.
The head restraints will fold backward.Folding head restraints back with
switch in the center console
1Rear head restraints folding switchStart the engine (page 51).
Press switch1 to release the head re-
straints.
The head restraints will fold backward.
Do not drive the vehicle without the seat
head restraints. Head restraints are
intended to help reduce injuries during an
accident.
iAdjust the head restraint in such a way that
it is as close to the head as possible.
iYou can also fold the head restraints back
using the switch in the center console.

122 Controls in detail
Seats
Placing rear head restraints upright
Pull the rear head restraint forward un-
til it locks into position.
Head restraint tilt
Two different head restraint angle
positions are available.
Press the release button (page 121)
and tilt the head restraint to the
desired position.
Removing and installing rear seats
head restraints
1Release button
Removing rear seat head restraints
Fold back head restraint (page 121).
Pull head restraint to its highest
position.
Push release button1 and pull out
head restraint.
Installing rear head restraints
Insert head restraint and push it down
until it engages.
Push release button1 and adjust
head restraint to desired position.
Warning!G
Make sure the head restraints engage when
placing them upright. Otherwise their pro-
tective function cannot be assured.
iAdjust the head restraint in such a way that
it is as close to the head as possible.
Warning!G
For your protection, drive only with properly
positioned head restraints.
Adjust the head restraint so that it is as
close to the head as possible and the center
of the head restraint supports the back of
the head at eye level. This will reduce the po-
tential for injury to the head and neck in the
event of an accident or similar situation.
Do not drive the vehicle without the seat
head restraints. Head restraints are intend-
ed to help reduce injuries during an
accident.
Do not interchange head restraints from
front and rear seat.

123 Controls in detail
Seats
Rear seat head restraints
(CLK cabriolet)
Raising rear head restraints
1Rear seat head restraint
Pull head restraint1 to its highest
position.
Lowering rear head restraints with
switch in the center console
1Rear head restraint lowering switch
Switch on the ignition (page 38).
Push the rear head restraints lowering
switch1.
The rear head restraints are lowered.
Warning!G
For safety reasons, always drive with the
rear head restraints in the raised position
when the rear seats are occupied.
Keep the area around head restraints clear
of articles (e.g. clothing) to not obstruct the
lowering/raising operation of the head
restraints.
iThe rear head restraints cannot be lowered
using the switch1 when the roll bars have been
released. The roll bars need to be lowered before
the rear head restraints can be operated again
using switch1.

If the roll bars have released and the soft top
is closed, contact an authorized
Mercedes-Benz Center to have the roll bars
lowered. Do not attempt to lower the roll
bars manually with the soft top closed. Low-
ering the roll bars manually with the soft top
closed may impair the function of the roll
bars.

If the roll bars have released and the soft top
is open, you can lower the roll bars manually
(
page 431) or contact an authorized
Mercedes-Benz Center to have the roll bars
lowered.

124 Controls in detail
Seats
Multicontour seat*
The multicontour seat has a movable seat
cushion and inflatable air cushions built
into the backrest to provide additional
lumbar and side support.
The seat cushion movement, backrest
cushion height and curvature can be
continuously varied with switches on the
side of the seat after the ignition is
switched on (
page 40).1Seat cushion depth
2Backrest bottom
3Backrest center
4Side bolster adjustment
Switch on ignition (page 40).Seat cushion depth
Adjust the seat cushion depth to the
length of your upper leg using
switch1.
Backrest contour
Adjust the contour of the backrest to
the desired position using switches2
and3.
Backrest side bolsters
Adjust the backrest side bolsters so
that they provide good lateral support
using switch4.
iIf, after a period of time, the seat no longer
provides the desired contour, then repeat the ad-
justment procedure.

125 Controls in detail
Seats
Seat heating*
Both switches for the front seats are
located in the center console.
1Seat heating switchThe red indicator lamps on the switch1
show which heating level you have
selected.
Switch on the ignition (page 40).Switching on seat heating
Press seat heating switch1 once.
Three red indicator lamps in the switch
come on.
Continue pressing seat heating
switch1 until desired seat heating
level is reached.
Switching off seat heating
Press seat heating switch1
repeatedly until all red indicator lamps
go out.
Level
3Three indicator lamps on
(highest level).
After approximately five minutes,
seat heating is automatically
switched to level 2.
2Two indicator lamps on.
After approximately ten minutes,
seat heating is automatically
switched to level 1.
1One indicator lamp on
(lowest level).
After approximately 20 minutes,
seat heating is automatically
switched off.
offNo indicator lamp on.
iIf one or more of the indicator lamps on the
seat heater switch1 are flashing, there is insuf-
ficient voltage due to too many electrical con-
sumers being switched on. The seat heating
switches off automatically.
The seat heating will switch back on again auto-
matically as soon as sufficient voltage is
available.

126 Controls in detail
Seats
Seat ventilation*
Both switches for the front seats are
located in the center console.
1Seat ventilation switchThe blue indicator lamps in the switch1
show which ventilation level you have
selected:
Switch on the ignition (page 40).Switching on seat ventilation
Press seat ventilation switch1.
Three blue indicator lamps come on.
Press seat ventilation switch1
repeatedly until the desired seat venti-
lation level is reached.
Switching off seat ventilation
Press seat ventilation switch1
repeatedly until all blue indicator lamps
go out.
Level
3Three indicator lamps on
2Two indicator lamps on
1One indicator lamp on
offNo indicator lamp on
iThe seat ventilation for the driver’s seat is
automatically set to the highest level if activated
via summer opening feature (
page 253).
iIf one or more of the indicator lamps on the
seat ventilation switch1 are flashing, there is
insufficient voltage due to too many electrical
consumers being switched on. The seat ventila-
tion switches off automatically.
The seat ventilation will switch back on again au-
tomatically as soon as sufficient voltage is
available.

127 Controls in detail
Memory function
Memory function
Prior to operating the vehicle, the driver
should check and adjust the seat height,
seat position fore and aft, and seat back-
rest angle if necessary, to ensure adequate
control, reach and comfort. The head
restraint should also be adjusted for
proper height. See also the section on
air bags (
page 65) for proper seat
positioning.
In addition, adjust the steering wheel to
ensure adequate control, reach, operation
and comfort. Both the interior and exterior
rear view mirrors should be adjusted for
adequate rear vision.
Fasten seat belts. Infants and small chil-
dren should be seated in a properly se-
cured restraint system that complies with
U.S. Federal Motor Vehicle Safety
Standards 213 and 225 and
Canadian Motor Vehicle Safety Standards
213 and 210.2.With the memory function you can store up
to three different configuration.
Each stored position on the driver’s side
includes the following settings:

Seat position

Steering wheel position

Exterior rear view mirror position

Multicontour seat*: previously saved
settingEach stored position on the passenger side
includes the following setting:

Seat position
Warning!G
Do not activate the memory function while
driving. Activating the memory function
while driving could cause the driver to lose
control of the vehicle.

128 Controls in detail
Memory function
The memory button and memory position
switch are located on the door.
1Memory button
2Memory position switch
Switch on the ignition (page 40).
or
Open the respective door and insert
the SmartKey in the starter switch.
Storing positions into memory
Adjust the seats, steering wheel and
exterior rear view mirrors to the
desired position (
page 42).
Turn memory position switch2 to the
desired memory position.
Press memory button1.
Release memory button1 and press
memory position switch2 within
3 seconds.
All settings are stored to the selected
position.
Recalling positions from memory
Turn memory position switch2 to the
desired memory position.
Press and hold memory position
switch2 until the seat, steering wheel
and exterior rear view mirrors have
completely moved to the stored
positions.
!Do not operate the seats using the memory
button if the seat backrest is in an excessively re-
clined position. Doing so could cause damage to
front or rear seats.
First move the seat backrest to an upright
position.
iReleasing the memory position switch stops
movement to the stored positions immediately.

129 Controls in detail
Lighting
Lighting
For information on how to switch on the
headlamps and use the turn signals, see
“Switching on headlamps” (
page 55)
and “Turn signals” (
page 56).
Exterior lamp switch
iIf you drive in countries where vehicles drive
on the other side of the road than the country
where the vehicle is registered, you must have
the headlamps modified for symmetrical low
beams. Relevant information can be obtained at
any authorized Mercedes-Benz Center.
iVehicles equipped with active Bi-Xenon*
headlamps:
The active Bi-Xenon headlamps monitor your
steering angle and driving speed, then
automatically shift their beams to either side to
better follow the curvature of the road ahead,
increasing usable illumination over conventional
headlamps.
1‚Standing lamps, left (turn left two
stops)
2ˆStanding lamps, right (turn left
one stop)
3MOff
Daytime running lamp mode
(
page 131)
4UAutomatic headlamp mode
Daytime running lamp mode
(
page 131)
5CParking lamps (also tail lamps,
license plate lamps, side marker
lamps, instrument panel lamps)
6BLow beam headlamps or high
beam headlamps.
7‡Front fog lamps
8†Rear fog lamp
iIf you hear a warning signal you have
forgotten to switch off the low beam headlamps
or the parking lamps before opening the driver’s
door.
In addition the message
Switch Off Lights
appears in the multifunction display.
Switch off the low beam headlamps or the park-
ing lamps.
If the message
Switch Off Lights or Re-
move Key
appears in the multifunction display
remove the SmartKey from the starter switch or
switch off the automatic headlamp mode.
!Failure to switch off the exterior lamps when
leaving the vehicle may result in a discharged
battery.
