MERCEDES-BENZ CLK350 2008 C209 Owner's Manual

140 Controls in detail
Instrument cluster
Tachometer
The red marking on the tachometer
(
page 28) denotes excessive engine
speed.
To help protect the engine, the fuel supply
is interrupted if the engine is operated
within the red marking.
Clock
In vehicles with Audio 20, the clock can be
set via the control system (
page 160).
Outside temperature indicator
The outside temperature is indicated in the
multifunction display (
page 141).The outside temperature sensor is located
in the front bumper area. Due to its loca-
tion, the sensor can be affected by road or
engine heat during idling or slow driving.
This means that the accuracy of the dis-
played temperature can only be verified by
comparison to a thermometer placed next
to the sensor, not by comparison to exter-
nal displays (e.g. bank signs etc.).
When moving the vehicle into colder ambi-
ent temperatures (e.g. when leaving your
garage), you will notice a delay before the
lower temperature is displayed.
A delay also occurs when ambient temper-
atures rise. This prevents inaccurate tem-
perature indications caused by heat
radiated from the engine during idling or
slow driving.
!Avoid driving at excessive engine speeds, as
it may result in serious engine damage that is not
covered by the Mercedes-Benz Limited
Warranty.
iVehicles with COMAND*:
For information on setting the time in COMAND,
refer to the separate COMAND operating
instructions.
Warning!G
The outside temperature indicator is not de-
signed to serve as an ice-warning device and
is therefore unsuitable for that purpose.
Indicated temperatures just above the freez-
ing point do not guarantee that the road sur-
face is free of ice. The road may still be icy,
especially in wooded areas or on bridges.

141 Controls in detail
Control system
Control system
The control system is activated as soon as
the SmartKey in the starter switch is
turned to position1 or as soon as the
KEYLESS-GO* start/stop button is in
position1. The control system enables you
to

call up information about your vehicle

change vehicle settings
For example, you can use the control sys-
tem to find out when your vehicle is next
due for service, to set the language for
messages in the instrument cluster dis-
play, and much more.
The control system relays information to
the multifunction display.
Multifunction display
1Outside temperature
2Trip odometer
3Current shift program mode
4Main odometer
5Current gear selector lever posi-
tion/gear range
For more information on menus displayed
in the multifunction display, see “Menus”
(
page 144).
iThe displays for the audio systems (radio,
CD player etc.) will appear in English, regardless
of the language selected.
Warning!G
A driver’s attention to the road and traffic
conditions must always be his /her primary
focus when driving.
For your safety and the safety of others,
selecting features through the multifunction
steering wheel should only be done by the
driver when traffic and road conditions
permit it to be done safely.
Bear in mind that at a speed of just 30 mph
(approximately 50 km/h), your vehicle is
covering a distance of 44 feet (approxi-
mately 14 m) every second.

142 Controls in detail
Control system
Multifunction steering wheel
The displays in the multifunction display
and the settings in the control system are
controlled by the buttons on the multifunc-
tion steering wheel (
page 30).
1Multifunction display
Operating the control system
2Selecting the submenu or setting the
volume:
Press button
æup / to increase
çdown / to decrease
3Telephone*:
Press button
sto take a call
to dial
to redial
tto end a call
to reject an incoming call
4Menu systems:
Press button
èfor next menu
ÿfor previous menu
5Moving within a menu:
Press button
jfor next display
kfor previous display

143 Controls in detail
Control system
Depending on the selected menu
(
page 144), pressing the buttons on the
multifunction steering wheel will alter what
is shown in the multifunction display.
The information available in the multifunc-
tion display is arranged in menus, and ac-
companying functions or submenus.
The individual functions are then found
within the relevant menu (radio or CD op-
erations under
Audio, for example). These
functions serve to call up relevant informa-
tion or to customize the settings for your
vehicle.It is helpful to think of the menus, and the
functions within each menu, as being
arranged in a circular pattern.

If you press buttonè orÿ
repeatedly, you will pass through each
menu one after the other.

If you press buttonk orj
repeatedly, you will pass through each
function display, one after the other, in
the current menu.In the
Settings... menu, instead of func-
tions you will find a number of submenus
for calling up and changing settings. For
instructions on using these submenus, see
“Submenus in the Settings menu”
(
page 156).
The number of menus available in the sys-
tem depends on which optional equipment
is installed in your vehicle.
The menus are described on the following
pages.

144 Controls in detail
Control system
MenusThis is what you will see when you scroll
through the menus.The table on the next page provides an
overview of the individual menus.

145 Controls in detail
Control system
Menus, submenus and functions
Table continued on next page.
Menu1Menu2Menu3Menu4
Commands/submenus
Standard displayAMG1
1AMG vehicles only
AUDIONAV*
(page 147)(page 148)(page 151)(page 153)
Run Flat Indicator
(Canada only)Engine oil temperatureSelecting radio stationShow route guidance instruc-
tions, current direction traveled
Tire Pressure Monitoring
(USA only)Vehicle supply voltageSelecting satellite radio sta-
tion*
Digital speedometerRACETIMEROperating CD player
Call up maintenance service
displayOverall analysis
Lap analysis

146 Controls in detail
Control system
Menu5Menu6Menu7Menu8
Commands/submenus
Vehicle status message
memory1
1The vehicle status message memory menu is only displayed if there is a message stored.
SettingsTrip computerTEL*
(page 154)(page 155)(page 167)(page 169)
Calling up vehicle malfunction,
warning and system status
messages stored in memoryReset to factory settingsFuel consumption statistics
since startLoad phone book
Instrument cluster submenuFuel consumption statistics
since the last resetSearch for name in phone book
Time/Date submenuCall up range
Lighting submenu
Vehicle submenu
Convenience submenu
iThe headings used in the menus table are
designed to facilitate navigation within the sys-
tem and are not necessarily identical to those
shown in the control system displays.
The first function displayed in each menu will au-
tomatically show you which part of the system
you are in.

147 Controls in detail
Control system
Standard display menu
In the standard display, the outside tem-
perature and the trip odometer are shown
in the multifunction display.
1Outside temperature
2Trip odometer
If you see another display, press
buttonè orÿ repeatedly until the
standard display appears.
Press buttonk orjto select
the functions in the standard display
menu.The following functions are available:
Display digital speedometer
Press buttonj ork until the
digital speedometer appears in the
multifunction display.
The current vehicle speed is shown in
the multifunction display and the sta-
tus line appears.1Digital Speedometer
2Status line with outside temperature
3Trip odometer
iYou can have the digital speedometer dis-
played instead of the outside temperature in the
standard display. You can select the setting in
the submenu
Instr. Cluster via the function
Basic Display (page 159).
FunctionPage
Run Flat Indicator
(Canada only)342
Tire Pressure Monitoring
(USA only)344
Call up digital speedometer 147
Call up maintenance service
display366
iYou can have the digital speedometer dis-
played instead of the outside temperature in the
status line. You can select the setting in the sub-
menu
Instr. Cluster via the function Status
Line Display
(page 159).

148 Controls in detail
Control system
AMG menu
The main screen of the AMG menu shows
you the gear currently engaged as well as
the engine oil temperature.
Press buttonè orÿ repeatedly
until the AMG menu appears in the
multifunction display.
1Gear indicator
2Engine oil temperature
Press buttonk orj to select
the following functions in the AMG
menu:Vehicle supply voltage
Press buttonè orÿ repeatedly
until the AMG menu appears in the
multifunction display.
Press buttonj repeatedly until the
vehicle supply voltage appears in the
multifunction display.
1Gear indicator
2Vehicle supply voltage
iThis function is only available in AMG
vehicles.
iThe engine oil temperature value and unit
flash if the engine oil temperature has not yet
reached 176°F (80°C). During this time, avoid
driving at full engine speed.
FunctionPage
Vehicle supply voltage148
RACETIMER149
Overall analysis150
Lap analysis151
iIf the engine reaches the overspeed range in
the manual shift program, the menu will be
shown in red. In addition, you will see
UP next to
gear indicator1 as a reminder to upshift.

149 Controls in detail
Control system
RACETIMER
The RACETIMER allows you to time and
save driving stretches in hours, minutes
and seconds.
Press buttonè orÿ repeatedly
until the AMG menu appears in the
multifunction display.
Press buttonj repeatedly until the
RACETIMER appears in the
multifunction display.1Gear indicator
2RACETIMER
3Lap
Starting the RACETIMERPress buttonæ.
The timer starts.Displaying intermediate time
Press buttonç while the timer is
running.
The intermediate time is shown for
5 seconds.
Stopping the RACETIMER
Press buttonæ.
The timer stops.
Saving lap time and starting a new lap
Press buttonç while the timer is
running.
Warning!G
The RACETIMER feature is only for use on
roads and in conditions where high speed
driving is permitted. Racing on public roads
is prohibited under all circumstances and
the driver is and must always remain re-
sponsible for following posted speed limits.
iYou can start the RACETIMER when the
engine is running or the starter switch is in
position2 (
page 38).
iWhile the RACETIMER is being displayed,
you can not adjust the volume using buttonæ
orç.
iWhen you stop the vehicle and turn the
SmartKey to position1 (
page 38) or, in vehi-
cles with KEYLESS-GO*, turn off the engine and
do not open the driver’s door, the RACETIMER
stops timing. Timing is resumed when you switch
the ignition back on (
page 38) or restart the
engine (
page 52) and then press
theæbutton.
iYou can save up to 9 laps.
