XPress the button.
The currentselection is displayed.
XTo activate/deactivate:press the
button again.
If theBlind Spot Assist Sensors
DeactivatedorAct. Blind Spot Asst.
Sensors Deactivatedmessage appears,
the radar sensor system is deactivated.
XSwitchonthe radar sensor system
(Ypage 232).
For further information about Blind Spot
Assist,see (Ypage 207).
For further information about Active Blind
Spot Assist,see (Ypage 211).
Activating/deactivating Lane Keeping
Assist
XPress \nor on the steering wheel
to select theDriveAssistmenu.
XPress the or button to select
Lane Keep. Asst.
XPress the button.
The currentselection is displayed.
XPress to confirm.
XPress the or button to setOff,
StandardorAdaptive.
XPress the button to save the setting.
For further information about Lane Keeping
Assist,see (Ypage 209).
For further information about Active Lane
Keeping Assist,see (Ypage 214).
Maintenance menu
In theServ.menu, you have the following
options:
RCalling up display messages in message
memory (Ypage 237)
RRestarting the tire pressure loss warning
system (Ypage 342)
RCheckingthe tire pressure electronically
(Ypage 342)
RCalling up the servicedue date
(Ypage 310)
Settings menu
Introduction
In theSett.menu, you have the following
options:
RChanging the instrument cluster settings
(Ypage 229)
RChanging the light settings (Ypage 230)
RChanging the vehicle settings
(Ypage 232)
RChanging the convenience settings
(Ypage 233)
RRestoringthe factory settings
(Ypage 234)
Instrument cluster
Selecting the unit of measurement for
distance
TheDisplay Unit Speed-/Odometer:
function allows you to choose whether
certain displays appear in kilometers or miles
in the multifunction display.
Menus and submenus229
On-boar dc omputer and displays
Z
Page 232 of 382
You can determinewhether the multifunction
display shows some messages in miles or
kilometers.
XPress the \nor button on the
steeringwheel to selecttheSett.menu.
XPress the or button to select the
Inst. Clustersubmenu.
XPress to confirm.
XPress the or button to select the
Display Unit Speed-/Odometer:
function.
You will see the selected setting:kmor
miles.
XPress the button to save the setting.
The selected unit of measurement for
distance applies to:
Rthe digital speedometer in theTripmenu
Rodometer and the trip odometer
Rtrip computer
Rcurrent consumption and the range
Rthe navigation instructions in theNavi
menu
Rcruise control
RDISTRONIC PLUS
RASSYST PLUS service interval display
Selecting the permanent display function
You can determine whether the multifunction
displaypermanently shows your speed or the
outside temperature.
XPress the \nor button on the
steering wheel to select theSett.menu.
XPress the or button to select the
Inst. Clustersubmenu.
XPress to confirm.
XPress the or button to select the
Permanent Display:function.
You will see the selected settingOutside
TemperatureorSpeedometer [km/h]
(USA)/Speedometer [mph](Canada).
XPress the button to save the setting.
iThe speed is shown in km/h (USA)/mph
(Canada).
Lights
Setting the brightness of the instrument
cluster lighting and switches
The lighting in the instrumentcluster,inthe
displays and the controls in the vehicle
interior can be adjusted using the
Brightness Display/Switches:function.
XPress the \nor button on the
steeringwheel to selecttheSett.menu.
XPress the or button to select the
Lightssubmenu.
XPress to confirm.
XPress the or button to select the
Brightness Display/Switches:
function.
You will see the selected setting.
XPress to confirm.
XPress the or button to adjust the
brightness to any level fromLevel 1to
Level 5(bright).
XPress the or button to save the
setting.
If the light switch is set to \r, or
,the brightness is dependent upon
the brightness of the ambient light.
iThe light sensor in the instrumentcluster
automatically controls the brightnessof
the multifunction display.
In daylight, the displays in the instrument
cluster are not illuminated.
Switching thedaytime running lamps on/
off
iThis function is not available in Canada.
XPress the \nor button on the
steeringwheel to selecttheSett.menu.
XPress the or button to select the
Lightssubmenu.
XPress to confirm.
230Menus and submenus
On-board computer and displays
Page 233 of 382
XPress or to select theDay
Lights:function.
If theDayLights:have been switched on,
the cone of light and the symbol in
the multifunction display are shown in red.
XPress the button to save the setting.
Further information on daytime running
lamps (Ypage 117).
Setting the brightness of the ambient
lighting
XPress the \nor button on the
steeringwheel to select theSett.menu.
XPress the or button to select the
Lightssubmenu.
XPress to confirm.
XPress the or button to select the
Amb. Light +/-.function.
You will see the selected setting.
XPress to confirm.
XPress the or button to adjust the
brightness to any level fromOfftoLevel
5(bright).
XPress the or button to save the
setting.
Setting the ambient lighting color
XPress the \nor button on the
steeringwheel to select theSett.menu.
XPress the or button to select the
Lightssubmenu.
XPress to confirm.
XPress the or button to select the
Ambient Light Colorfunction.
XPress to confirm.
XPress the or button to set the
color toSOLAR,NEUTRALorPOLAR.
XPress the or button to save the
setting.
Activating/deactivating surround
lighting and exterior lighting delayed
switch-off
XPress the \nor button on the
steeringwheel to select theSett.menu.
XPress the or button to select the
Lightssubmenu.
XPress to confirm.
XPress or to select the
Surround Lightingfunction.
When theSurround Lightingfunction is
activated, the light cone and the area
around the vehicle are displayedinred in
the multifunction display.
XPress the button to save the setting.
Deactivating delayed switch-off of the
exterior lighting temporarily:
XBefore leaving the vehicle, turn the
SmartKey to position0in the ignition lock.
XTurn the SmartKey to position2in the
ignition lock.
The exterior lighting delayed switch-off is
deactivated.
Delayed switch-off of the exterior lighting is
reactivated the next time you start the
engine.
If you have activated theSurround
Lightingfunction and the light switch is set
to \r,the following functions are activated
when it is dark:
RSurround lighting:the exterior lighting
remains lit for 40 seconds after unlocking
with the SmartKey. If you start the engine,
the surround lighting is switched off and
the automatic headlamp mode is activated
(Ypage 117).
RExterior lighting delayed switch-off:the
exterior lighting remains lit for 60seconds
after the engine is switched off. If you close
all the doors and the trunklid, the exterior
lighting goes off after5seconds.
iDepending on your vehicle's equipment,
when the surround lighting and delayed
Menus and submenus231
On-boar dc omputer and displays
Z
Page 234 of 382
switch-off exterior lighting are on, the
following light up:
RParking lamps
RLow-beam headlamps
RDaytime running lamps
RSide marker lamps
RSurround lighting in the exterior mirrors
Activating/deactivating the interior
lighting delayed switch-off
If you activate theInterior Lighting
Delayfunction,the interior lighting remains
on for 20seconds after you remove the
SmartKey from the ignition lock.
XPress the \nor button on the
steering wheel to select theSett.menu.
XPress the or button to select the
Lightssubmenu.
XPress to confirm.
XPress or to select theLight.
Delayfunction.
When theInterior Lighting Delay
function is activated, the vehicle interior is
displayed in red in the multifunction
display.
XPress the button to save the setting.
Vehicle
Activating/deactivating the automatic
door locking mechanism
XPress the \nor button on the
steering wheel to select theSett.menu.
XPress or to select theVehicle
submenu.
XPress to confirm.
XPress or to select theAuto.
Door Locksfunction.
When theAutomaticDoorLockfunction
is activated, the vehicle doors are displayed
in red in the multifunction display.
XPress the button to save the setting.
If you activate theAutomatic Door Lock
function,the vehicle is centrally locked above
aspeed of around9mph (15 km/h).
For further information on the automatic
locking feature, see (Ypage 83).
Activating/deactivating the acoustic
locking verification signal
If you switch on theAcousticLockfunction,
an acoustic signal sounds when you lock the
vehicle.
XPress the \nor button on the
steering wheel to select theSett.menu.
XPress or to select theVehicle
submenu.
XPress to confirm.
XPress the or button to select the
Acoustic Lockfunction.
If theAcousticLockfunction is activated,
the symbol in the multifunction
displaylights up red.
XPress the button to save the setting.
Activating/deactivating the radar sensor
system
XPress the \nor button on the
steering wheel to select theSett.menu.
XPress or to select theVehicle
submenu.
XPress to confirm.
XPress the or button to select
Radar Sensor (See Oper. Manual):.
You will see the selected setting:Enabled
orDisabled.
XPress the button to save the setting.
The following systems are switched off when
the radar sensor system is deactivated:
RDISTRONIC PLUS (Ypage 177)
RBAS PLUS (Ypage 67)
RPRE-SAFE®Brake (Ypage 72)
RBlind Spot Assist (Ypage 207)
RActive Blind Spot Assist (Ypage 211)
232Menus and submenus
On-board computer and displays
Page 235 of 382
Convenience
Activating/deactivatingtheEASY-
ENTRY/EXIT feature
GWARNING
When theEASY-ENTRY/EXIT feature adjusts
thesteering wheel,you and other vehicle
occupants–particularly children–could
become trapped. There isarisk of injury.
While the EASY-ENTRY/EXIT feature is
making adjustments, make sure that no one
has any body parts in the sweep of the
steering wheel.
If somebody becomes trapped:
Rpress one of the memory function position
buttons, or
Rmove the switch for steering wheel
adjustmentinthe opposite direction to that
in which the steering wheel is moving.
The adjustment process is stopped.
XPress the \nor button on the
steering wheel to select theSettings
menu.
XPress the or button to select the
Conveniencesubmenu.
XPress to confirm.
XPress the or button to select the
Easy Entry/Exit:function.
If theEasy Entry/Exitfunction is
activated, the vehicle steering wheel is
displayed in red in the multifunction
display.
XPress the button to save the setting.
Further information on the EASY-ENTRY/EXIT
feature (Ypage 108).
Switching the belt adjustment on/off
XPress the \nor button on the
steering wheel to select theSett.menu.
XPress the or button to select the
Conveniencesubmenu.
XPress to confirm.
XPress the or button to select the
Belt Adjustmentfunction.
When theBelt Adjustmentfunction is
activated, the vehicle seat belt is displayed
in red in the multifunction display.
XPress the button to save the setting.
For further information on belt adjustment,
see (Ypage 57).
Switching the fold-in mirrors with the
locking featureon/off
This function is only available on vehicles with
the memory function (Ypage 112).
When you activate theAuto. Mirror
Foldingfunction, the exterior mirrors are
folded in when the vehicle is locked. If you
unlock the vehicle and then openadoor, the
exterior mirrors fold out again.
XPress the \nor button on the
steering wheel to select theSett.menu.
XPress the or button to select the
Conveniencesubmenu.
XPress to confirm.
XPress or to select theAuto.
Mirror Foldingfunction.
If theAuto. Mirror Foldingfunction is
activated, the vehicle's exterior mirror is
displayed in red in the multifunction
display.
XPress the button to save the setting.
To fold the exterior mirrors in or out
If you have switched on theAuto. Mirror
Foldingfunction and you fold in the exterior
mirrors by pressing button ,the exterior
Menus and submenus233
On-board computer and displays
Z
Page 236 of 382
mirrors willnot fold out automatically
(Ypage110).
You can then only fold out the exterior mirrors
using button .
Restoringthe factory settings
XPress the \nor button on the
steering wheeltoselect theSett.menu.
XPress the or button to select the
Factory Settingsubmenu.
XPress to confirm.
TheReset All Settings?message
appears.
XPress the or button to select
NoorYes.
XPress to confirm the selection.
If you have selectedYes,the multifunction
display showsaconfirmation message.
For safety reasons, theDaytime Running
Lightsfunction in theLightssubmenu is
only reset if the vehicleisstationary.
AMG menu in AMG vehicles
AMG displays
Digital speedometer
Gear indicator
$Upshift indicator
!Engine oil temperature
Coolant temperature
%ECO start/stop function status indicator
(Ypage 151)
XPress the \nor button on the
steering wheel to select theAMGmenu.
Upshift indicatorUP $indicates that the
engine has reached the overrevving range
when in the manual gearshift program.
Upshift indicatorUP $fades out other
messages until you have shifted up.
When the engine oil temperature is below
176‡(80 †) the oil temperature is shownin
blue. Avoid drivingatfull engineoutput during
this time.
SETUP
Driveprogram (C/SS+/M)
ESP®mode (ON/OFF)orSPORT handling
mode (SPORT)
$Suspension tuning(COMFORT/SPORT/
SPORT+)
SETUP shows the drive program, the ESP®
(Electronic Stability Program) mode and the
suspension tuning.
XPress the \nor button on the
steering wheel to select theAMGmenu.
XPress the button repeatedly until
SETUP is displayed.
or
XBriefly press the AMG button on the center
console (Ypage 191).
234Menus and submenus
On-boar dc omputer and displays
Page 237 of 382
RACETIMER
Displaying and startingRACETIMER
Lap
RACETIMER
The RACETIMER is only intended for useona
closed race circuit. Do not usethe function
on public roads.
Youcan startthe RACETIMER when the
engine is running or if the SmartKey is in
position2in the ignition lock.
XPress \nor on the steering wheel
to select theAMGmenu.
XPress the button repeatedlyuntilthe
RACETIMER is shown.
XTo start:press the button to startthe
RACETIMER.
Displaying the intermediate time
XPress the \nor button to select
Interm. Time.
XPress to confirm.
The intermediate time is displayed for five
seconds.
Startinganewlap
RACETIMER
Fastest laptime (best lap)
$Lap
XPress to confirmNew Lap.
iIt is possible to storeamaximum of
sixteen laps. The 16th lapcan only be
completed withFinish Lap.
Stoppingthe RACETIMER
XPress the button on the steering
wheel.
XPress to confirmYes.
The RACETIMER interrupts timing when you
stop the vehicleand turn the SmartKey to
position1in the ignition lock. If youturn the
SmartKey to position2or3and then press
to confirmStart,timing is continued.
Resetting the current lap
XStop the RACETIMER.
XPress the \nor button to select
ResetLap.
XPress to reset the laptime to "0".
Menus and submenus235
On-board computer and displays
Z
Page 238 of 382
Deleting all laps
If you switch offthe engine, the RACETIMER
is reset to "0" after 30 seconds. All laps are
deleted.
You cannot delete individualstored laps. If
you have stopped 16 laps, the current lap
does not have to be reset.
XReset the current lap.
XPress to confirmReset.
Reset Race Timer?appears in the
multifunction display.
XPress the button to selectYesand
press the button to confirm.
All laps are deleted.
Overall statistics
RACETIMER overall evaluation
Total time driven
$Average speed
!Distancecovered
Maximum speed
This function is shown if you have stored at
least one lap and stopped the RACETIMER.
XPress the \nor button on the
steering wheel to select theAMGmenu.
XPress the button repeatedly until the
overall evaluation is shown.
Lap statistics
Lap
Lap time
$Average lap speed
!Lap length
Top speed during lap
This function is only available if you have
stored at least two laps and have stopped the
RACETIMER.
XPress the \nor button on the
steering wheel to select theAMGmenu.
XPress the button repeatedly until the
lap evaluation is shown.
Each lap is shown inaseparate submenu.
The fastest lap is indicated by flashing
symbol .
XPress the or button to select a
different lap evaluation.
236Menus and submenus
On-board computer and displays
Page 239 of 382
Display messages
Introduction
General notes
Display messagesappear in themultifunction display.
Display messageswithgraphic displays may be shown in simplified forminthe Operator's
Manual and may differ from the messages shown in the multifunction display.
Please respond in accordance with the displaymessages and follow the additional notes in
this Operator's Manual.
Certain displaymessages are accompanied by an audible warning tone oracontinuous tone.
When the ignition is switched off, all displaymessages are deleted, apart from some high-
priority displaymessages. Once the causes of the high-priority displaymessages have been
rectified, the corresponding displaymessages are also deleted.
When you stop and park the vehicle, please observe the notes on:
RHOLD function (Ypage 186)
RParking (Ypage 167)
Hiding display messages
XPress the or button on the steering wheel to hide the displaymessage.
The displaymessage is cleared.
The multifunction displayshows high-priority displaymessages in red. Some high-priority
displaymessages cannot be hidden.
The multifunction displayshows these messages continuously until the causes for the
messages have been remedied.
Message memory
The on-board computer saves certain displaymessages in themessage memory.You can
call up the display messages:
XPress the \nor button on the steeringwheel to select theServ.menu.
If there are display messages, the multifunction display shows2Messages,for example.
XPress the or button to select the entry, e.g.2Messages.
XPress to confirm.
XPress the or button to scroll through the display messages.
Display messages237
On-board computer and displays
Z
Page 240 of 382
Safety systems
Display messagesPossible causes/consequences and Solutions
Currently
Unavailable See
Operator's Manual
ABS (Anti-lock Braking System), ESP®(Electronic Stability
Program), BAS (Brake Assist), PRE-SAFE®,the HOLD function and
hill start assist are temporarily unavailable.
BAS PLUS and PRE-SAFE®Brake may also have failed.
In addition, the , and warning lamps light up in
the instrumentcluster.
ATTENTIONASSIST is deactivated.
Possible causes are:
Rself-diagnosis is not yet complete.
Rthe on-board voltage may be insufficient.
GWARNING
The brake system continues to function normally, but without the
functions listed above. The wheels could therefore lock if you
brake hard, for example.
The steerability and braking characteristics may be severely
affected. The braking distance in an emergency braking situation
can increase.
If ESP®is not operational, ESP®is unable to stabilize the vehicle.
There is an increased risk of skidding and an accident.
XCarefully driveasuitable distance, making slight steering
movements, ataspeed above 12 mph (20 km/h).
If the displaymessage disappears, the functions mentioned
above are available again.
If the displaymessage continues to be displayed:
XDrive on carefully.
XVisitaqualified specialist workshop.
Inoperative See
Operator's Manual
ABS,ESP®,BAS,PRE-SAFE®,the HOLD function and hill start
assist are unavailable due toamalfunction.
The (USA only)/ (Canada only), , and
warning lamps in the instrumentcluster also light up.
ATTENTION ASSISTisdeactivated.
GWARNING
The brakesystem continues to function normally, but without the
functionslisted above. The wheels could therefore lock if you
brakehard, for example.
238Display messages
On-board computer and displays
