MERCEDES-BENZ CLS 2021 Owners Manual

The
electr icpar king brak eis no taut omaticall y
applied ifth eengine isswitc hedoffby theEC O
st ar t/ stop funct ion.
Electr icpar king brak efunction (releasing
aut omat ically)
The electr icpar king brak eis released whenthe
fo llo wing condition sar efulf illed:
R The driver's door isclos ed.
R The engin eis running .
R The trans mis sion isin po sitio n005B or005E and
yo udepr esstheaccelera torpeda lor you
shif tfr om transmission position005Dto005B or
005E when onleve lgr ou nd withth edr iver's
door closed.
R Ifth etra nsmiss ionisin position 005E,the
tr unk lid mu stbe closed.
R The seat belttongu eis ins ertedint oth eseat
belt buckleofthedr iver's seat.
If th eseat belttongu eis no tins ertedint oth e
seat beltbuckleofthedr iver's seat, oneof
th efo llo wing condition smus tbe fulf illed:
- Youshif tfr om trans mis sion position005D. -
Youha ve prev iousl ydr iven atspeeds
gr ea terth an 2mp h(3 km/h).
When theelectr icpar king brak eis released, the
re d0049 (USA)or0024 (Canada) indicatorlam p
in theins trument clustergoes out.
Appl ying/rele asing theelectr icpa rking
br ak ema nuall y
Appl ying #
Push handle 1.
The red0049 (USA)or0024 (Canada) indica‐
to rlam plig hts upintheins trument cluster.
% The electr icpar king brak eis onl ysecur ely
applied ifth eindicat orlam pis lit con tinu‐
ously .
Re leasing #
Swit chon theignition . #
Pull handle 1.
The red0049 (USA)or0024 (Canada) indica‐
to rlam pin theins trument clustergoes out.
Emer gency braking #
Press and hold handle 1.
As long astheve hicle isdriving, thePlease
Release ParkingBrak emessag eis displa yed
and there d0024 indicat orlam pflashes .
When theve hicle hasbeen brak ed toa
st ands till,th eelectr icpar king brak eis
applied. Thered0049 (USA)or0024 (Can‐
ada) indicat orlam plights upintheins tru‐
ment cluster. Dr
iving and parking 15
9

Inf
orma tion oncollision detection ona
pa rked vehicl e If
acolli sion isde tected whe nth eto w- aw ay
alar misarmed onaloc kedve hicle, youwill
re cei veano tificat ion inthemultimedia system
when youswit chon theignition .
Yo uwill recei veinformatio nabout thefo llo wing
point s:
R The area oftheve hicle that ma yha ve been
damag ed.
R The forc eof theim pact.
The follo wing situat ionscanlead toinadv ertent
acti vatio n:
R The parked vehicle ismo ved, e.g. inatw o-
st or yga rage .
% Dea ctivateth eto w- aw ay alar minorder to
pr eve ntina dvertent acti vatio n.Ifyo udeac ti‐
va te theto w- aw ay alar m,collision detection
wi llal so be dea ctivated.
% Ifth ebatt eryis se verely disc ha rged ,th e
function forde tecting acoll ision on apa rked ve
hicle isaut omaticall ydeactiv ated tofacil i‐
ta te thene xt engine star t.
Sy stem limit s
De tection maybe restrict ed inthefo llo wing sit‐
uation s:
R The vehicle isdamag edwithout impact, e.g.
if an outside mirroris torn offor thepaint is
damag edbyaSm artK ey
R Animpa ct occu rsat low spee d
R The electric par kingbr ak eis no tapplied No
teson par king theve hicl efo ran extended
per iod If
yo ulea vetheve hicle parkedfo rlong erthan six
we eks,itma ysuf ferdama gethro ugh disus e.
The 12Vbatt eryma yalso beimpair edordam‐
ag ed byhea vydisc harging.
% Further information canbeobt ained ata
qu alif ied spec ialistwo rkshop. St
andb ymode (ext ens ion ofthe star terbat‐
te ry 's per iod out ofuse) St
andb ymode function
% This function isno tav ailable forall model s.
If standb ymode isact ivat ed, energyloss willbe
min imis eddur ing ex tende dpe riods ofnon- oper‐
ation.
St andb ymode isch aract erised bythefo llo wing:
R The star terbatt eryis preser ved.
R The maximum non-opera tionaltime appear s
in themedia display.
R The conn ection toonline services isint erru p‐
te d.
R The ATA(anti-t heftal ar m system) isno tav ail‐
able.
R The interior motionsen sor and tow- aw ay
alar mfun ction sar eno tav ailable.
R The function forde tecting collisions ona
pa rked vehicle isno tav ailable. 16
0
Driving and parking

If
th efo llo wing condition sar efulf illed, standb y
mode canbeact ivat ed ordeac tivated usin gth e
multime diasystem:
R The engine isswitc hedoff.
R The ignition isswitc hedon.
Ex ceeding theve hicle's displayednon -oper a‐
tion altime maycause inconvenie nce, i.e.it can‐
no tbe guarant eedth at thest ar terbatt erywil l
re liably star tth eengine.
The star terbatt erymus tbe charge dfirs tin the
fo llo wing situat ions:
R The vehicle's non-oper ational timemustbe
ex tende d.
R The Batte ryCh arg eInsu fficie ntfor Stand by
Mod emes sage appear sin themedia display.
% Standb ymode isaut omat icallydeac tivated
when theignition isswitc hedon.
Ac tiv atin g/deac tivatin gst andb ymode (park‐
ing theve hicl efo ran extended period)
Re quirement s:
R The engin eis switc hedoff. Multime
diasystem:
4 © 5
Set ting s5
Vehicle #
Activateor deacti vate Stand byMod e. #
Select Yes. Dr
ivi ng and drivi ng safetysy stems Dr
iving systems andyour responsibility Yo
ur vehicle iseq uipped withdr iving systems
whic hassis tyo uin drivin g,par kingand man eu‐
ve ring theve hicle. Thedriving systems areonl y
aids. Theyar eno ta subs titutefo ryo ur att entio n
to thesur round ingsand donotre lie ve youof
yo ur responsibili typer tainin gto road traf fic law.
The driver isalw aysre sponsible formaint aining
a saf edis tance totheve hicle infront, forve hicle
speed, forbr aking ingood timeandforst ay ing
in lane. Payatt ention tothetra ffic con dition sat
all tim esand interve ne when nece ssary.Be
aw areof thelimit ations rega rding thesaf euse of
th ese systems.
Dr iving systems canneither reduce therisk of
accident ifyo ufa ilto adap tyo ur drivin gst yle nor
ove rride thelaws ofphysics. Theycan notalw ays ta
ke intoacc ount road, weather ortraf fic condi ‐
tions . In
fo rm ation onvehicl esen sorsand camer as Some
driving anddriving safetysy stems use
camer asas wellas radar orultr asonic sensors
to monit orthear ea infront of,behind ornext to
th eve hicle. Dr
iving andparking 16
1

%
The radar sensor sar eint egratedbehind the
bum persand/or behindtheMer cedes star.
1 Cameras intheoutside mirrors
2 Multifunction camera
3 Front camer a
4 Ultrasonic sensors
5 Rear vie wcam era &
WARNIN GRisk ofacci dent dueto
re strict ed detection perform anc eof vehi‐
cle sensor sand camer as
If th ear ea around vehicle sensor sor cam‐
er as isco vered, damag edordir ty,cer tain
dr ivin gand safetysy stems cann otfunction
cor rectly .The reisarisk ofan accident. #
Keep thear ea around vehicle sensor s
or camer asclear ofanyobs tructions
and clean. #
Have damag eto thebum per,ra diat or
gr ille orstone chipping inthear ea of
th efront and rear wind owsrepair edat
a qu alif ied spec ialistwo rkshop. Pa
rticular ly,ke ep thear eas around thesensor s
and camer asfree ofdir t,ice orslush
(/ page27 2). The sensor sand camer asma y
no tbe coveredand thede tection rang es arou nd
th em mus tbe kept free. Donotatt achadd itiona l
lice nse platebrac kets, advertisemen ts,sticke rs,
fo ils orfoils toprotect agains tst one chipping sin
th ede tection rang eof thesensor sand camer as.
Mak esur eth at ther ear eno ove rhang ingloads
pr otru ding intoth ede tection rang e.
If th er eis damag eto abum perorthera diat or
gr ille, orafte ran impact, have thefunc tion of
th esensor sch eckedat aqu alif ied spec ialist
wo rkshop. Have damag eor stone chipping inthe
ar ea ofthecamer ason thewindshield andrear
wind owrepair edataqu alif ied spec ialistwo rk‐
shop. Ov
ervie wof driving systems anddriving
saf etysy stems R
ABS(Ant i-lockBra king System)
(/ page16 3)
R BAS(Bra keAssis tSys tem) (/ page16 3) R
ESP ®
(Electr onicStability Program)
(/ page16 3)
R ESP ®
Cr oss wind Assi st(/ pag e16 5)
R EBD (El ectr onicBra keforc eDis tribution)
(/ page16 5)
R STEER CONTR OL(/ page 165)
R HOLD functio n(/ page 166)
R HillSt artAs sis t(/ page16 7)
R ATTENTION ASSIST(/ page16 7)
R Cruis econtr ol(/ page 169)
R Traf fic Sign Assist(/ pag e18 7)
R DYNA MIC BODY CONTR OL(/ page19 6)
R AIR BODY CONTR OL(/ page19 6)
Dr ivi ng Ass istan cepac kage
The follo wing functionsar epar tof theDr iving
Assis tance Packag e. Cer tain func tionsar eonl y
av ailable insom ecoun tries. Som efun ction sar e
also available without theDr iving Assistance
Pa ckag e, albeit withre strict ed functi onality.
R ActiveDis tance AssistDIS TRONI C
(/ page 171) 16
2
Driving and parking

R
ActiveSpe edLimi tAssi st(coun try- depend‐
ent )(/ page17 5)
R Route-based speedadap tatio n(co untr y-
dependen t)(/ page17 6)
R ActiveBr ak eAssi st(/ pag e18 2)
R ActiveSt eer ing Assis t(count ry-de pende nt)
(/ page 178)
R ActiveEmerg encyStop Assis t(countr y-
dependen t)(/ page18 0)
R ActiveLa ne Chang eAssi st(coun try- depend‐
ent )(/ page18 1)
R ActiveSt op-and-Go Assist(countr y-depend‐
ent )(/ page17 7)
R Blind SpotAssis tand ActiveBli nd Spo tAssi st
wit hex itwa rning (/ page19 1)
R ActiveLa ne Keeping Assist(/ page19 4)
Pa rking Packag e
R Parking AssistPA RK TRONI C(/ page20 3)
R Rear vie wcam era(/ page19 8)
R Surround viewcam era(/ page20 1)
R ActivePa rking Assist(coun try- dependen t)
(/ page208 ) Fu
nction ofABS The
Anti-loc kBr ak eSy stem (ABS )re gulat esthe
br ak epr essur ein critical driving situation s:
R Dur ing braking, e.g.atfull brak eapplication
or insuf ficie nttiretracti on, thewheels are
pr eve nted from lock ing.
R Vehicle steer ability whilebraking isensur ed.
If ABS interve nes when braki ng, youwill feel a
pulsing inthebr ak epedal. Thepulsating brak e
pedal canbeanindicat ionofhazar dous road
con dition sand canserveas are minder totake
ex tra car ewh ile dr ivi ng. Fu
nction ofBA S The
Brak eAssis tSy stem (BAS )suppor tsyour
eme rgency braking situation withadditional
br ak efo rc e.
If yo udepr essthebr ak epedal quickl y, BA Sis
acti vated:
R BASau tomatical lyboos tsthebr ak epr es‐
sur e.
R BAScan shorten thebr aking distance. R
ABS preve nts thewheels from locking .
The brak es will func tion asusual onceyo u
re lease thebr ak epedal. BASis dea ctivated. Fu
nction ofESP ®
(Electr onicStabil ityPro‐
gr am) &
WARNIN GRisk ofskid ding ifESP ®
is
dea ctivated
If yo udeac tivateES P®
,ES P®
can notcar ry
out vehicle stabiliz ation. #
ESP®
shoul don lybe deactiv ated inthe
fo llo wing situat ions. *
NO
TEMercede s-AMG vehicles #
Obser vetheno tesin theSupplement .
Yo uco uld other wise failto recogni ze
da ngers. Dr
iving and parking 16
3

ESP
®
can moni torand improve driving stabilit y
and tract ion inthefo llo wing situat ions,wit hin
ph ysical limit s:
R When pulling away on awe tor slip pe ry road.
R When brakin g.
If th eve hicle deviat esfrom thedir ect ion desir ed
by thedr iver ,ES P®
can stabiliz eth eve hicle by
int erve ning inthefo llo wing ways:
R One ormor ewheels arebr ak ed.
R The engine outputisadap tedaccor dingto
th esituation .
When ESP®
is deactiv ated, the00BB warning
lam plight sup con tinuousl y:
R Drivin gst abilit ywill nolongerbe improve d.
R The drive wheels couldspin.
R ETS/4 ETStra ction control isstill act ive.
% When ESP®
is deact ivat ed, youar est ill assis‐
te dby ESP ®
wh en braki ng. Wh
enthe00E5 warning lam pflashes ,on eor
se veralwheels hasreac hed itsgrip limit :
R Adaptyo ur drivin gst yle to suit thecur rent
ro ad and weather condition s.
R Donotdeac tivateES P®
.
R Onlyde pres sth eacceler ator pedal asfaras
is necessar ywhen pulling away.
Dea ctivateESP ®
in thefo llo wing situat ionsto
im prove tracti on:
R Whenusing snowch ains .
R Indeep snow .
R Onsand orgrav el.
% Spinn ingthewheels results inacutting
action, whichenhances traction.
If th e00E5 ESP®
wa rning lam plight sup con tinu‐
ousl y,ESP ®
is no tav ailable duetoamalf unction.
Obse rveth efo llo wing informatio n:
R Warning and indic ator lam ps(/ page38 7)
R Disp lay mess ages (/ page340) ET
S/4ET S(Electr onicTractio nSy stem)
ET S/ 4ETS tracti oncontr olispa rtof ESP ®
and
mak esitpossible topull away and accelerat eon
a slippe ryroad.
ET S/ 4ETS can improve theve hicle's traction by
int erve ning inthefo llo wing ways:
R The drive wheels arebr ak ed individually if
th ey spin.
R Mor edr ive to rq ue istrans ferred tothewheel
or wheels withtra ction.
Inf luence ofdrive pr og rams onESP®
The drive pr og rams enabl eESP ®
to adap tto dif‐
fe re nt we ather and road con dition sas wellas
th edr iver's prefer reddr iving style. Depen dingon
th eselect eddrive pr ogr am, theappr opriate
ES P®
mode willbeactiv ated. Youcan selectthe
dr ive pr ogr ams using theDY NA MIC SELE CT
switc h(/ page14 6). 16
4
Driving and parking

Fu
nction ofESP ®
Cr osswind Assist ES
P®
Cr osswind Assistde tects sudde ngu stsof
side wind andhelps thedr iver tokeep theve hi‐
cle inthelane:
R ESP®
Cr osswind Assistis activ eat vehicle
speeds between appr ox.47 mp h(7 5 km/h)
and 125mp h(200 km/h) whendriving
st ra ight ahead orcor ner ing slight ly.
R The vehicle isstabiliz edbymeans ofindivi d‐
ua lbr ak eapp lication onone side. Ac
tiv atin g/deac tivatin gES P®
(E lectr onicSta‐
bil ity Prog ram) Mu
ltimed iasystem:
4 © 5
Set ting s5
Quick Access
% ESP®
can onlybe activ ated/deact ivat ed
using quick acc ess when atleas tone other
funct ionisavailable inqu ick acc ess. ESP®
can other wise befound intheAssist ance
menu. *
NO
TEMer cedes-AMG vehicles #
Obser vetheno tesin theSupplement .
Yo uco uld other wise failto recogni ze
da ngers. #
Sele ctESP . #
Sele ctOn or00BB Off.
ESP ®
is dea ctivated ifth e00BB ESP®
OFF warn‐
ing lam plight sup con tinuousl yin theins trument
clus ter.
Obser vetheinf ormation onwarning lam psand
displa ymess ages whic hma ybe sho wninthe
ins trumen tclus ter. Fu
nction ofEBD Elect
ronic Brea kfor ce Dis trib uti on (EBD) isch ar‐
act erize dby thefo llo wing:
R Mon itor ing and regulating thebr ak epr essur e
on there ar wheels .
R Improve ddr iving stabilit ywhen brakin g,
espe ciallyon ben ds. Fu
nction ofSTEER CONT ROL ST
EER CONTR OLhelpsyo uby trans mitting a
no tice ablesteer ing forc eto thesteer ing wheel in
th edir ect ion requ ired forve hicle stabiliz ation.
This steer ing recomme ndation isgiv en inthefo l‐
lo wing situat ions:
R Both right wheels orboth leftwheels areon
a we tor slip pe ry road sur face whe nyo u
br ak e
R The vehicle star ts to skid
Sy stem limit s
ST EER CONTR OLmaybe impai redor ma yno t
func tion inthefo llo wing situat ions:
R ESP®
is deact ivat ed.
R ESP®
is malfun ctionin g.
R The steer ing ismalfunct ioning.
If ES P®
is malfunct ioning,youwill beassis ted
fur ther by theelectr icpo we rst eer ing. Dr
iving andparking 16
5

HOLD
functio n HOLD
functio n
The HOLD function holdsth eve hicle atast and‐
st ill wit hout requ iring youto depr essthebr ak e
pedal, e.g.while waitin gin traf fic.
The HOLD functionisonly anaid. The responsi‐
bility forth eve hicle safely standi ngstill remains
wit hth edr iver .
Sy stem limit s
The HOL Dfun ction isonl yint end edtoprov ide
assis tance when drivi ng and isno ta su fficien t
mean sof saf eguar dingtheve hicle agains tro lling
aw ay when statio nary.
R The incline mustno tbe great erthan 30%. Ac
tiv atin g/deac tivatin gthe HOL Dfunc tion &
WARNIN GRisk ofan acci dent dueto the
HOLD functio nbei ng activ ewhe nyo u
lea vetheve hicle
If th eve hicle isonl ybr ak ed withth eHOLD
func tion itcould, inthefo llo wing situat ions,
ro llaw ay:
R Ifth er eis amalfunct ioninthesy stem or
in thepo we rsupp ly.
R Ifth eHOLD function isdeactiv ated by
depr essing theaccelera torpeda lor brak e
peda l,e.g. byave hicle occupant. #
Alw ayssecur eth eve hicle agains tro ll‐
ing away bef oreyo ulea veit. Re
quirement s:
R The vehicle isstatio nary.
R The driver's door isclosed ortheseat belton
th edr iver's side isfastened.
R The engine isrunning orhasbe en automati‐
cally switc hedoffby theEC Ostar t/ stop
funct ion. R
The electr icpar king brak eis released.
R ActiveDis tance AssistDIS TRONI Cis de acti ‐
va ted.
R The transmis sionisin position 005B,005Eor005C.
Ac tiv atin gthe HOL Dfun ction #
Dep ress thebr ak epedal, andafte ra shor t
time quickl ydepr essfurther until the00D9
displa yappear sin themultifunc tiondispla y. #
Release thebr ak epedal.
Deactiv atingtheHOLD function #
Depr esstheacceler ator pedal topull away.
or #
Depr essthebr ak epedal untilthe00D9 dis‐
pla ydisappear sfrom themultifunc tiondis‐
pla y.
The HOLD functionisdeactiv ated inthefo llo w‐
ing situat ions:
R ActiveDis tance AssistDIS TRONI Cis acti va‐
te d.
R The transmission isshif tedto position 005D. 16
6
Driving and parking

R
The vehicle issecur edwithth eelectr icpar k‐
ing brak e.
In thefo llo wing situat ions,th eve hicle isheld by
tr ans missi on positio n005D and /or bytheelectr ic
par king brak e:
R The seat beltisunf astened andthedr iver's
door isopened.
R The vehicle isswitc hedoff.
R Ther eis amalfunction inthesy stem orthe
po we rsupp lyis insuf ficie nt. Fu
nction ofHill StartAss ist Hill
StartAs sis tholds theve hicle fora shor t
time when pulling away on ahill under thefo l‐
lo wing condition s:
R The transmissio nis in posit ion005Bor005E.
R The elect ric pa rking brak eis released.
This gives youen ough timeto mo veyour foot
fr om thebr ak epedal totheacceler ator pedal
and depr essitbef oreth eve hicle begins toroll
aw ay. &
WARNIN GRisk ofacci dent andinjury
due totheve hicle rolling away
Af tera shor ttime, HillStartAs sis tno longer
holds theve hicle. #
Swif tly mo veyour foot from thebr ak e
pedal totheaccelera torpeda l.Do not
lea vetheve hicle when itis being held
by HillSt artAs sis t. AT
TENTI ONASSIST Fu
nction ofATTENTI ONASSIST
AT TENTION ASSISTassis tsyouon long,mon oto‐
nous journeys,e.g. onhighw aysand trunk roads.
If AT TENTION ASSISTde tects indicatorsof fati‐
gu eor incr easing laps es inconce ntration onthe
par tof thedr iver ,it sugg ests taking abr ea k.
AT TENTION ASSISTis onl yan aid. Itcann ot
alw aysde tect fatig ue orlaps es inconce ntration
in tim e.The system isno ta subs titutefo ra we ll-
re sted and attent ive dr iver .On long journeys,
ta ke regular break sin good timethat allo wfor
adeq uatere cup erati on. Yo
ucan choose between twose ttings:
R Standar d:nor mal system sensit ivity.
R Sensitiv e:higher system sensit ivity.The
dr iver iswa rned ear lier and theatt ent ion
le ve lde tected byATTENTION ASSISTis adap‐
te daccor dingly.
If dr ow siness orincr easing lapsesinconcen tra‐
tion arede tected, theATTE NTION ASSIS T:Take
a Break !wa rning appear sin theIns trument Dis‐
pla y.Yo ucan ackn ow ledg eth emessag eand
tak eabr eak wher eneces sary.Ifyo udo notta ke
a br eak and ATTENTION ASSISTcont inues to
de tect incr easing lapse sin concentr ation, you
will bewarned again afte ra minimu mof
15 minut es. Dr
iving andparking 16
7

Yo
ucan have thefo llo wing status informat ionfor
AT TENTION ASSISTdispla yedin theassis tance
menu oftheon- boar dcom puter:
R The lengt hof thejour neysince thelas t
br eak .
R The attent ion leve lde term ined byATTENTION
ASS IST:
- The fuller thecir cle, thehigher theatt en‐
tion alleve lde term ined
- Asyour att entio nwa nes, thecir cle inthe
cent erofthedispla ybecomes smaller If
AT TENTION ASSISTis unable tocal cul ateth e
att ent ion leve land cannotissue awa rning, the
Sys tem Suspend edmes sage appear s.
If awa rning isgiv en intheIns trument Display,
th emultimedia system offers to sear chfora re st
ar ea. Youcan selectare st area and star tna vig a‐
tio nto this rest area. This function can beact iva‐
te dand deactiv ated inthemultimedia system.
If AT TENTION ASSISTis deactiv ated, theÛ
symbol appearsin theassis tance grap hicin the
Ins trument Displaywhen theengine isrunning .
AT TENTION ASSISTis activ ated aut omaticall y
when theengine isre-sta rted. The lastselect ed
sensit ivityleve lre mains stor ed.
Sy stem limit s
AT TENTION ASSISTis activ ein the37 mph
(60 km/ h)to 124mp h(2 00 km/h) speedra ng e.
Pa rticular lyin thefo llo wing situat ions,AT TEN‐
TION ASSISTonl yfunct ionsinare strict ed man‐
ner and warnings maybe dela yedor notocc ur:
R Ifyo uha ve been driving forless than appr ox‐
imat ely30 min utes. R
Ifth ero ad con dition ispoor (unevenro ad
sur face orpotholes).
R Ifth er eis ast ro ng side wind.
R Ifyo uadop ta spor tydrivin gst yle (high cor‐
ner ing speeds orhigh ratesof acceler ation).
R Ifth eSt eer ing Assis tfunc tion ofActiveDis ‐
ta nce AssistDIS TRONI Cis acti ve.
R Ifth etime hasbeen setincor rectly .
R Ifyo uch ang elane sand vary your spee dfre‐
qu ent lyIn activ edr iving situation s.
The ATTENTION ASSISTdr ows ines sor aler tness
assess mentis rese tand restar tedwhen continu‐
ing thejour neyin thefo llo wing situat ions:
R Ifyo uswit choffth eengine.
R Ifyo uunf astenyo ur seat beltandopen the
dr iver's door (e.g.tochang edr iver sor take a
br eak). 16
8
Driving and parking
