470 Technical dataFuels, coolants, lubricants etc.Windshield and headlamp washer system
Both the windshield and headlamp washer
systems are supplied from the windshield
washer fluid reservoir.
The washer fluid reservoir has a capacity of
approximately 7.4 US qt. (7.0 l).

Refill the reservoir with MB Windshield
Washer Concentrate and water (or con-
centrate and commercially available
premixed windshield washer sol-
vent/antifreeze, depending on ambient
temperatures).Windshield and headlamp washer fluid
mixing ratio
For temperatures above “freezing point”,
use MB Windshield Washer Concentrate
“S” and water:


1 part “S” to 100 parts water
(1.34 floz [40 ml] “S” to 1 gallon [4.0 l] wa-
ter).
For temperatures below “freezing point”
use MB Windshield Washer Concentrate
“S” and commercially available premixed
windshield washer solvent/antifreeze:


1 part “S” to 100 parts solvent
(1.34 floz [40 ml “S” to 1 gallon [4.0 l] sol-
vent).
Warning!
G
Washer solvent/antifreeze is highly flamma-
ble. Do not spill washer solvent/antifreeze
on hot engine parts, because it may ignite
and burn. You can be seriously burned.

471 Technical terms
ABS
(A
ntilock B
rake S
ystem)
Prevents the wheels from locking up
during braking so that the vehicle can
continue to be steered.
Accessory weight
(
page 332)
ADS
(Adaptive D
amping S
ystem)
Automatically adapts the optimum sus-
pension damping to prevailing driving
conditions.
Air pressure
(
page 332)Airmatic DC
(A
irmatic D
ual C
ontrol)
Automatically selects the optimum
suspension tuning and ride height for
your vehicle. Airmatic consists of two
components:


Adaptive Damping System


Vehicle level control
Alignment bolt
Metal pin with thread. The centering
pin is an aid used when changing a tire
to align the wheel with the wheel hub.
Aspect ratio
(
page 332)BabySmart
TM air bag deactivation
system
This system detects if a special system
compatible child restraint seat is in-
stalled on the front passenger seat. The
system will automatically deactivate
the passenger front air bag when such
a seat is properly installed (the
57indicator lamp in the
center console comes on and remains
illuminated).
BabySmartTM compatible child seats
Special restraint system for children.
The sensor system for the passenger
seat prevents deployment of the pas-
senger front air bag if a BabySmart
TM
compatible child seat is installed. See
an authorized Mercedes-Benz Center
for availability.

472 Technical termsBar
(
page 332)
BAS
(Brake A
ssist S
ystem)
System for potentially reducing braking
distances in emergency braking situa-
tions. The system is activated when it
senses an emergency based on how
fast the brake is applied.
Bead
(
page 332)
Bi-Xenon headlamps*
Headlamps which use an electric arc as
a light source and produce a more in-
tense light than filament headlamps.
Bi-Xenon headlamps produce low
beam and high beam.CAC
(C
ustomer A
ssistance C
enter)
Mercedes-Benz customer service
center which can help you with any
questions about your vehicle and pro-
vide assistance in the event of a break-
down.
CAN system
(C
ontroller A
rea N
etwork)
Data bus network serving to control
vehicle functions such as door locking
or windshield wiping.
Cockpit
All instruments, switches, buttons and
indicator/warning lamps in the passen-
ger compartment needed for vehicle
operation and monitoring.Cold tire inflation pressure
(
page 332)
Collapsible tire
An especially compact spare tire that
must be inflated with a provided air
pump before using. It should only be
used to bring the vehicle to the nearest
service station.
COMAND
(Cockpit M
anagement and D
ata
System)
Information and operating center for
vehicle sound and communications
systems, including the radio and navi-
gation system, as well as other optional
equipment (CD changer, telephone,
etc.).

473 Technical terms
Control system
The control system is used to call up
vehicle information and to change
component settings. Information and
messages appear in the multifunction
display. The driver uses the buttons on
the multifunction steering wheel to
navigate through the system and to
adjust settings.
Cruise control
Driving convenience system for auto-
matically maintaining the vehicle speed
set by the driver.
Distronic*
A driving convenience cruise control
system which helps the driver maintain
a pre-selected speed:


If there is no vehicle directly ahead,
the system operates in the same
way as conventional ->cruise con-
trol.


If a slower moving vehicle is ahead,
Distronic will reduce your vehicle
speed to the extent permitted by
reduced throttle and up to 20%
braking power to maintain the pre-
set minimum following distance.
DOT
(Department o
f Transportation)
(
page 332)
DTR
(->Distronic*)
Engine number
The number set by the manufacturer
and placed on the cylinder block to
uniquely identify each engine pro-
duced.Engine oil viscosity
Measurement for the inner friction
(viscosity) of the oil at different temper-
atures. The higher the temperature an
oil can tolerate without becoming thin,
or the lower the temperature it can tol-
erate without becoming viscous, the
better the viscosity.
ESP
®(Electronic S
tability Pr
ogram)
Improves vehicle handling and direc-
tional stability.
ETD
(E
mergency T
ensioning D
evice)
Device which deploys in certain frontal
and rear collisions exceeding the sys-
tem’s threshold to tighten the seat
belts.
->SRS

474 Technical termsFSS PLUS (Canada vehicles)
(F
lexible S
ervice S
ystem PLUS)
Maintenance service indicator in the
multifunction display that informs the
driver when the next vehicle mainte-
nance service is due. FSS evaluates
engine temperature, oil level, vehicle
speed, engine speed, distance driven
and the time elapsed since your last
service, calculates other maintenance
service work required, and calls for the
next maintenance service accordingly.
GAWR
(G
ross A
xle W
eight R
ating)
(
page 332)
Gear range
Number of gears which are available to
the automatic transmission for shifting.
The automatic gear shifting process
can be adapted to specific operating
conditions using the selector lever.GPS
(G
lobal P
ositioning S
ystem)
Satellite-based system for relaying
geographic location information to and
from vehicles equipped with special
receivers. Employs DVD digital maps
for navigation.
GVW
(G
ross V
ehicle W
eight)
(
page 332)
GVWR
(Gross V
ehicle W
eight R
ating)
(
page 333)
Instrument cluster
The displays and indicator/warning
lamps in the driver’s field of vision, in-
cluding the tachometer, speedometer
and fuel gauge.KEYLESS-GO*
System for entering and operating the
vehicle without the use of a SmartKey.
Kickdown
Depressing the accelerator past the
point of resistance shifts the transmis-
sion down to the lowest possible gear.
This very quickly accelerates the vehi-
cle and should not be used for normal
acceleration needs.
Kilopascal (kPa)
(
page 333)
Locking knob
Knob on the door which indicates
whether the door is locked or un-
locked. Pushing the locking knob down
on an individual door from inside will
lock that door.

475 Technical terms
Maintenance System (U.S. vehicles)
Maintenance service indicator in the
multifunction display that informs the
driver when the next vehicle mainte-
nance service is due. The Vehicle Main-
tenance System in your vehicle tracks
distance driven and the time elapsed
since your last maintenance service,
calculates other maintenance service
work required, and calls for the next
maintenance service accordingly.
Maximum loaded vehicle weight
(
page 333)
Maximum load rating
(page 333)
Maximum tire inflation pressure
(page 333)Memory function*
Used to store three individual seat,
steering wheel and exterior mirror posi-
tions.
MON
(M
otor O
ctane N
umber)
The Motor Octane Number for gasoline
as determined by a standardized meth-
od. It is an indication of a gasoline’s
ability to resist undesired detonation
(knocking). The average of both the
MON (Motor Octane Number) and
->RON (Research Octane Number) is
posted at the pump, also known as
ANTI-KNOCK INDEX.
Multifunction display
The display field in the instrument clus-
ter used to present information provid-
ed by the control system.Multifunction steering wheel
Steering wheel with buttons for operat-
ing the control system.
Normal occupant weight
(
page 333)
Overspeed range
Engine speeds within the red marking
on the tachometer dial. Avoid this
engine speed range, as it may result in
serious engine damage that is not cov-
ered by the Mercedes-Benz Limited
Warranty.
Parktronic (Parking assist)*
System which uses visual and acoustic
signals to assist the driver during park-
ing maneuvers.
Poly-V-belt drive
Drives engine-components (alternator,
AC compressor, etc.) from the engine.

476 Technical termsPower train
Collective term designating all compo-
nents used to generate and transmit
motive power to the drive axles, includ-
ing:


Engine


Clutch/torque converter


Transmission


Transfer case*


Drive shaft


Axle shafts/axles
Production options weight
(
page 333)Program mode selector switch
Used to switch the automatic transmis-
sion between standard operationS and
operationC.
CLS 55 AMG with steering wheel gear-
shift control and manual shift program:
in addition to S and C (for sporty S or
comfortable C operation), you can use
M for manual shift program.
PSI
(P
ounds per s
quare i
nch)
(
page 333)
Recommended tire inflation pressure
(page 333)
Restraint systems
Seat belts, belt tensioners, air bags and
child restraint systems. As indepen-
dent systems, their protective func-
tions complement one another.Rim
(
page 333)
RON
(Research O
ctane N
umber)
The Research Octane Number for gaso-
line as determined by a standardized
method. It is an indication of a gaso-
line's ability to resist undesired detona-
tion (knocking). The average of both
the ->MON (Motor Octane Number)
and RON (Research Octane Number) is
posted at the pump, also known as
ANTI-KNOCK INDEX.
Electro-hydraulic brake system
Electronically controlled hydraulic
braking system for increased braking
safety and comfort.
Sidewall
(
page 333)

477 Technical terms
Shift lock
When the vehicle is parked, this lock
prevents the transmission selector le-
ver from being moved out of positionP
without the ignition or engine on and
brake pedal depressed.
SRS
(S
upplemental R
estraint S
ystem)
Seat belts, emergency tensioning de-
vice and air bags. Though independent
systems, they are closely interfaced to
provide effective occupant protection.Tele Aid System
(T
elematic A
larm I
dentification on D
e-
mand)
The Tele Aid system consists of three
types of response: automatic and man-
ual emergency, roadside assistance
and information. Tele Aid is initially
activated by completing a subscriber
agreement and placing an acquain-
tance call.
The Tele Aid system is operational
provided that the vehicle’s battery is
charged, properly connected, not dam-
aged and cellular and GPS coverage is
available.
Telematics*
A combination of the terms “telecom-
munications” and “informatics”.Tightening torque
Force times lever arm (e.g. a lug
wrench) with which threaded fasteners
such as wheel bolts are tightened.
TIN
(T
ire I
dentification N
umber)
(
page 334)
Tire load rating
(page 334)
Tire ply composition and material used
(page 334)
Tire speed rating
(page 334)
Traction
(page 334)
Tread
(page 334)

478 Technical termsTreadwear indicators
(
page 334)
Uniform Tire Quality Grading Standards
(page 334)
Vehicle capacity weight
(page 334)
Vehicle level control
The ground clearance of the vehicle is
automatically controlled according to a
selected setting and speed.The driver
can set the ground clearance manually
for example on very rough roads.Vehicle maximum load on the tire
(
page 334)
VIN
(Vehicle I
dentification N
umber)
The number set by the manufacturer
and placed on the body to uniquely
identify each vehicle produced.
Voice control system*
Voice control system for car phones,
portable cell phones and audio sys-
tems (radio, CD, etc.).

479 Index
A
ABS 84
Indicator lamp 352
Messages in display 365
Accelerator position 180
Accessory weight 332
Accident 57
Active head restraint 74, 124
Adjusting 39
Air bags 65
BabySmart
TM air bag deactivation
system 471
Children 78
Children in the vehicle 66
Front, Driver 69
Front, Passenger 69
Safety guidelines 68
Side impact 70
Window curtain 70
Air conditioning, Cooling 209
Air distribution 204
Air pressure 332Air pressure see Tire inflation pressure
Air pump, electric 428
Air recirculation mode 206
Air vents 197
Rear passenger compartment 210
Air volume 205
Airmatic DC
Message in display 396, 397
Airmatic DC (Dual Control) 238
Alarm
Audible 83
Canceling 95
Visual 93
Alarm system see Anti-theft systems
Alignment bolt (vehicle tool kit) 399, 425
Anticorrosion/antifreeze 468
Antilock brake system see ABS
Anti-theft systems 93
Anti-theft alarm system 93
Immobilizer 93
Tow-away alarm 95
Aquaplaning see HydroplaningAshtrays 257
Aspect ratio 332
At the gas station 290
AUDIO menu 153
Audio system
CD mode 154
Auto-dimming, Rear view mirrors 191
Automatic central locking, control
system 168
Automatic climate control
4-zone automatic climate
control 196
Automatic climate control (4-zone) 196
Air recirculation mode 206
Deactivating 201
Maximum cooling MAX COOL 206
Rear air conditioning 210
Rear window defroster 195
Setting the temperature 203
Automatic headlamp mode 135
Automatic lighting control, Interior
lighting 141
