Page 7 of 420

ATTENTION ASSIST
Activating/deactivating .................237
Display message ............................ 261
Function/notes ............................. 210
Audio system
see separate operating instructions
Authorized Centers
see Qualified specialist workshop
Authorized Mercedes-Benz Center
see Qualified specialist workshop
Authorized workshops
see Qualified specialist workshop
AUTO lights
Display message ............................ 257
see Lights
Automatic engine start (ECO start/
stop function) .................................... 159
Automatic engine switch-off (ECO
start/stop function) .......................... 158
Automatic headlamp mode ..............121
Automatic transmission Automatic drive program ............... 166
Changing gear ............................... 164
DIRECT SELECT lever .....................162
Display message ............................ 271
Drive program display ....................162
Driving tips .................................... 164
Emergency running mode ..............169
Engaging drive position .................. 163
Engaging neutral ............................ 163
Engaging park position (AMG
vehicles) ........................................ 163
Engaging reverse gear ................... 163
Engaging the park position ............ 162
Kickdown ....................................... 165
Manual drive program ....................167
Overview ........................................ 161
Problem (malfunction) ...................169
Program selector button ................165
Pulling away ................................... 156
Selector lever ................................ 161
Shift ranges ................................... 166
Starting the engine ........................ 155
Steering wheel paddle shifters ...... 166
Transmission position display ........ 161
Transmission position display
(DIRECT SELECT lever) ................... 162
Transmission positions .................. 164Automatic transmission
emergency mode
...............................
169 B
Bag hook ............................................ 296
BAS (Brake Assist System) ................. 67
BAS PLUS (Brake Assist System
PLUS) .................................................... 68
Battery (SmartKey) Checking ..........................................
81
Important safety notes .................... 81
Replacing ......................................... 81
Battery (vehicle)
Charging ........................................ 350
Display message ............................ 259
Important safety notes .................. 348
Jump starting ................................. 352
Blind Spot Assist
Activating/deactivating ................. 237
Display message ............................ 264
Notes/function .............................. 214
see Active Blind Spot Assist
BlueTEC
Adding DEF .................................... 173
BlueTEC (DEF) .................................... 410
Bottle holder ...................................... 306
Box (trunk) ......................................... 299
Brake Assist see BAS (Brake Assist System)
Brake fluid
Display message ............................ 249
Notes ............................................. 412
Brake lamps
Display message ............................ 255
Brakes
ABS .................................................. 67
BAS .................................................. 67
BAS PLUS ........................................ 68
Brake fluid (notes) .........................412
Display message ............................ 247
Driving tips .................................... 180
High-performance brake system .... 181
Important safety notes .................. 180
Maintenance .................................. 181
Parking brake ................................ 176
Warning lamp ................................. 277 Index
5
Page 9 of 420

Overview of systems
......................138
Problems with cooling with air
dehumidification
............................ 143
Problem with the rear window
defroster ........................................ 147
Rear control panel .........................141
Setting the air distribution .............145
Setting the airflow ......................... 145
Setting the air vents ......................148
Setting the climate mode ............... 144
Setting the temperature ................ 144
Switching air-recirculation mode
on/off ............................................ 147
Switching on/off ........................... 142
Switching residual heat on/off ...... 147
Switching the rear window
defroster on/off ............................ 147
Switching the ZONE function on/
off .................................................. 145
Coat hooks ......................................... 298
Cockpit Overview .......................................... 30
see Instrument cluster
Collapsible spare wheel
Inflating ......................................... 400
see Emergency spare wheel
COMAND
see separate operating instructions
COMAND display
Cleaning ......................................... 338
Combination switch ..........................124
Combined cargo cover and net ........297
Compass Calibrating ..................................... 324
Calling up ....................................... 323
Setting ........................................... 324
Consumption statistics (on-board
computer) .......................................... 231
Convenience box ............................... 299
Convenience closing feature ..............94
Convenience opening feature ............94
Coolant (engine) Checking the level ......................... 331
Display message ............................ 258
Filling capacity ............................... 413
Important safety notes .................. 412
Temperature (on-board computer) . 242 Temperature gauge ........................ 227
Warning lamp .................................
283
Cooling
see Climate control
Cornering light function
Display message ............................ 254
Function/notes ............................. 126
Crash-responsive emergency
lighting ............................................... 129
Cruise control Activation conditions .....................184
Cruise control lever .......................184
Deactivating ................................... 185
Display message ............................ 267
Driving system ............................... 183
Function/notes ............................. 183
Important safety notes .................. 183
Setting a speed .............................. 185
Storing and maintaining current
speed ............................................. 184
Cup holder
Center console .............................. 305
Important safety notes .................. 305
Rear compartment ......................... 305
Customer Assistance Center (CAC) ...25
Customer Relations Department .......25 D
Dashboard see Instrument cluster
Dashboard lighting
see Instrument cluster lighting
Data
see Technical data
Daytime running lamps
Display message ............................ 256
Function/notes ............................. 121
Switching on/off (on-board
computer) ...................................... 239
Dealerships
see Qualified specialist workshop
DEF
Adding ........................................... 173
Display message ............................ 261
Filling capacity ............................... 410
Notes ............................................. 410 Index
7
Page 10 of 420

Delayed switch-off
Exterior lighting (on-board
computer) ...................................... 239
Interior lighting .............................. 240
Diagnostics connection ......................25
Diesel particle filter ..........................180
Digital speedometer .........................231
DIRECT SELECT lever see Automatic transmission
Display message
ASSYST PLUS ................................ 332
Display messages
Calling up (on-board computer) ..... 246
Driving systems ............................. 261
Engine ............................................ 258
General notes ................................ 246
Hiding (on-board computer) ........... 246
KEYLESS-GO .................................. 274
Lights ............................................. 254
Safety systems .............................. 247
SmartKey ....................................... 274
Tires ............................................... 268
Vehicle ........................................... 271
Distance display (on-board
computer) .......................................... 236
Distance recorder see Trip odometer
Distance warning (warning lamp) ....285
DISTRONIC PLUS Deactivating ................................... 194
Display message ............................ 265
Displays in the multifunction
display ........................................... 193
Function/notes ............................. 185
Important safety notes .................. 185
Setting the specified minimum
distance ......................................... 193
Warning lamp ................................. 285
Doors
Automatic locking (on-board
computer) ...................................... 240
Automatic locking (switch) ............... 86
Central locking/unlocking
(SmartKey) ....................................... 79
Control panel ................................... 37
Display message ............................ 273
Emergency locking ........................... 86
Emergency unlocking .......................86Important safety notes ....................
85
Opening (from inside) ......................85
Drinking and driving .........................178
Drinks holder see Cup holder
Drive program
Automatic ...................................... 166
Display ........................................... 161
Display (DIRECT SELECT lever) ...... 162
Manual ........................................... 167
SETUP (on-board computer) .......... 243
Drive program selector ..................... 165
Driver's door see Doors
Driving abroad
Mercedes-Benz Service .................333
Symmetrical low beam .................. 120
Driving on flooded roads ..................182
Driving safety systems ABS (Anti-lock Braking System) ....... 67
ADAPTIVE BRAKE ............................. 72
BAS (Brake Assist System) ..............67
BAS PLUS (Brake Assist System
PLUS) ............................................... 68
Electronic brake force distribution ... 72
ESP ®
(Electronic Stability
Program) .......................................... 69
ETS/4ETS (Electronic Traction
System) ........................................... 70
Important safety information ........... 67
Overview .......................................... 66
PRE-SAFE ®
Brake ............................. 72
Driving systems
Active Blind Spot Assist ................. 218
Active Driving Assistance
package ......................................... 218
Active Lane Keeping Assist ............ 221
AIRMATIC ...................................... 199
AMG adaptive sport suspension
system ........................................... 200
ATTENTION ASSIST ........................ 210
Blind Spot Assist ............................ 214
Cruise control ................................ 183
Display message ............................ 261
DISTRONIC PLUS ........................... 185
HOLD function ............................... 196
Lane Keeping Assist ...................... 2168
Index
Page 13 of 420

Quality (diesel)
............................... 408
Refueling ........................................ 169
Tank content/reserve fuel .............407
Fuel filler flap
Emergency release ........................ 171
Opening/closing ............................ 170
Fuel filter (display message) ............260
Fuel level Calling up the range (on-board
computer) ...................................... 231
Fuel tank
Capacity ........................................ 407
Problem (malfunction) ...................172
Fuse allocation chart (vehicle tool
kit) ...................................................... 342
Fuses Allocation chart ............................. 357
Before changing ............................. 357
Fuse box in the cargo
compartment ................................. 358
Fuse box in the engine
compartment ................................. 358
Fuse box in the trunk ..................... 358
Important safety notes .................. 357G
Garage door opener Clearing the memory
.....................323
Important safety notes .................. 320
Opening/closing the garage door ..323
Programming (button in the rear-
view mirror) ................................... 321
Gear indicator (on-board
computer) .......................................... 242
Genuine Mercedes-Benz parts ......... 404
Glove box ........................................... 289H
Handbrake see Parking brake
Hazard warning lamps ......................125
Head bags Display message ............................ 251
Headlamps
Adding fluid to cleaning system .....332
Cleaning system (capacity) ............ 413Cleaning system (function) ............
125
Cleaning system (notes) ................413
Fogging up ..................................... 128
see Automatic headlamp mode
Head restraints
Adjusting ....................................... 105
Adjusting (angle) ............................ 105
Adjusting (electrically) ...................105
Adjusting (rear) .............................. 105
Installing/removing (rear) .............. 106
Luxury ............................................ 105
Heating
see Climate control
High-beam headlamps
Changing bulbs .............................. 131
Display message ............................ 255
Switching Adaptive Highbeam
Assist on/off ................................. 127
Switching on/off ........................... 124
Hill start assist .................................. 156
HOLD function Display message ............................ 262
Function/notes ............................. 196
Hood
Closing ........................................... 329
Display message ............................ 272
Opening ......................................... 328
Hydroplaning ..................................... 182 I
Ignition lock see Key positions
Immobilizer .......................................... 74
Indicator lamps see Warning and indicator lamps
Infrared lamps (changing bulbs) ......132
Insect protection on the radiator .... 329
Instrument cluster Overview .................................. 31, 227
Settings ......................................... 238
Warning and indicator
lamps ....................................... 32, 275
Instrument cluster lighting .............. 227
Interior lighting ................................. 128
Automatic control .......................... 129
Delayed switch-off (on-board
computer) ...................................... 240 Index
11
Page 15 of 420

Locking verification signal (on-
board computer)
............................... 240
Low-beam headlamps Changing bulbs
.............................. 131
Display message ............................ 254
Setting for driving abroad
(symmetrical) ................................. 120
Switching on/off ........................... 122
Luggage holder (EASY-PACK load-
securing kit) ....................................... 301
Lumbar support Adjusting the 4-way lumbar
support .......................................... 108
Luxury head restraints .....................105M
M+S tires ............................................ 364
Malfunction message see Display messages
Massage function (PULSE) ...............107
Matte finish (cleaning
instructions) ...................................... 336
mbrace Call priority .................................... 315
Display message ............................ 249
Downloading destinations
(COMAND) ..................................... 316
Downloading routes .......................319
Emergency call .............................. 312
Geo fencing ................................... 319
Important safety notes .................. 311
Locating a stolen vehicle ............... 318
MB info call button ........................ 315
Remote vehicle locking .................. 317
Roadside Assistance button .......... 314
Search & Send ............................... 316
Self-test ......................................... 312
Speed alert .................................... 319
System .......................................... 312
Triggering the vehicle alarm ........... 320
Vehicle remote malfunction
diagnosis ....................................... 318
Vehicle remote unlocking .............. 317
Mechanical key
Function/notes ................................ 80
Locking vehicle ................................ 86
Unlocking the driver's door ..............86Memory card (audio) .........................
234
Memory function ............................... 116
Message memory (on-board
computer) .......................................... 246
Messages see Display messages
Mirrors
see Exterior mirrors
see Rear-view mirror
see Vanity mirror (in the sun visor)
Mobile phone
Menu (on-board computer) ............ 234
Modifying the programming
(SmartKey) ........................................... 80
MOExtended tires .............................. 344
Mounting wheels Lowering the vehicle ......................389
Mounting a new wheel ................... 388
Raising the vehicle ......................... 386
Removing a wheel ..........................388
Securing the vehicle against
rolling away ................................... 386
MP3
Operation ....................................... 234
see separate operating instructions
Multifunction display
Function/notes ............................. 230
Permanent display ......................... 238
Multifunction steering wheel
Operating the on-board computer . 228
Overview .......................................... 33 N
Navigation Menu (on-board computer) ............ 232
NECK-PRO head restraints
Operation ......................................... 53
Resetting after being triggered ........ 53
NECK-PRO luxury head restraints
Operation ......................................... 53
Resetting after being triggered ........ 54
Night View Assist Plus
Activating/deactivating
.................212
Cleaning ......................................... 338
Function/notes ............................. 211
Problem (malfunction) ...................214 Index
13
Page 19 of 420

Sliding sunroof
Important safety notes ....................96
Opening/closing .............................. 97
Problem (malfunction) ...................100
Resetting ......................................... 97
see Panorama roof with power
tilt/sliding panel
SmartKey
Changing the battery ....................... 81
Changing the programming ............. 80
Checking the battery ....................... 81
Convenience closing feature ............ 94
Convenience opening feature .......... 94
Display message ............................ 274
Door central locking/unlocking ....... 79
Important safety notes .................... 78
Loss ................................................. 83
Mechanical key ................................ 80
Positions (ignition lock) ................. 153
Problem (malfunction) .....................83
Starting the engine ........................ 155
Snow chains ...................................... 365
Sockets Center console .............................. 310
General notes ................................ 309
Luggage compartment ................... 310
Rear compartment ......................... 310
Spare wheel
Stowing .......................................... 400
Specialist workshop ............................ 25
Special seat belt retractor .................. 63
Speed, controlling see Cruise control
Speedometer
Digital ............................................ 231
In the Instrument cluster ......... 31, 227
Segments ...................................... 228
Selecting the unit of
measurement ................................ 238
see Instrument cluster
SPORT handling mode
Activating/deactivating (AMG
vehicles) .......................................... 70
Warning lamp ................................. 280
SRS (Supplemental Restraint
System)
Display message ............................ 250
Introduction ..................................... 41Warning lamp ................................. 281
Warning lamp (function) ...................
41
Standing lamps
Changing bulbs .............................. 132
Display message ............................ 256
Switching on/off ........................... 124
Starting (engine) ................................ 155
Steering (display message) ..............273
Steering wheel Adjusting (electrically) ...................112
Button overview ............................... 33
Buttons (on-board computer) ......... 228
Cleaning ......................................... 339
Important safety notes .................. 111
Paddle shifters ............................... 166
Steering wheel heating .................. 112
Storing settings (memory
function) ........................................ 116
Steering wheel heating
Problem (malfunction) ...................112
Switching on/off ........................... 112
Steering wheel paddle shifters ........166
Stopwatch (RACETIMER) ................... 243
Stowage areas ................................... 288
Stowage compartments Armrest (under) ............................. 290
Center console .............................. 289
Cup holders ................................... 305
Eyeglasses compartment ............... 289
Glove box ....................................... 289
Important safety information ......... 288
Rear ............................................... 290
Stowage net ................................... 291
Under driver's seat/front-
passenger seat .............................. 290
Stowage net ....................................... 291
Stowage well beneath the trunk
floor .................................................... 301
Summer tires ..................................... 364
Sun visor ............................................ 306
Supplement Restraint System see SRS (Supplemental Restraint
System)
Surround lighting (on-board
computer) .......................................... 239 Index
17
Page 37 of 420

Center console, lower section
Function Page
G
Stowage compartment 288
Ashtray 308
Cigarette lighter 309
Cup holders 305
H
e Sets the suspension
tuning
200
I
É Sets the vehicle level
199 Function Page
J
Stowage compartment 288
K
Ú Selects the drive
program
165
L
COMAND controller; see
the separate operating
instructions Center console
35At a glance
Page 42 of 420

Useful information
i This Operator's Manual describes all
models and all standard and optional
equipment of your vehicle available at the
time of publication of the Operator's
Manual. Country-specific differences are
possible.
Please note that your vehicle may
not be equipped with all features
described. This also applies to safety-
related systems and functions.
i Read the information on qualified
specialist workshops: ( Y page 25).Panic alarm
X
To activate: press ! button : for at
least one second.
An alarm sounds and the exterior lighting
flashes.
X To deactivate: press ! button :
again.
or
X Insert the SmartKey into the ignition lock.
or
X Press the KEYLESS-GO Start/Stop button.
The KEYLESS-GO key must be in the
vehicle.
i USA only:
This device complies with
Part 15 of the
FCC Rules. Operation is subject to the
following two conditions: 1. This device may not cause interference,
and
2.
this device must accept any interference
received, including interference that may
cause undesired operation.
Any unauthorized modification to this
device could void the user's authority to
operate the equipment.
The Product label with FCC ID and IC
certification number can be found in the
battery case of the SmartKey.
i Canada only:
This device complies with RSS-Gen of
Industry Canada. Operation is subject to
the following two conditions:
1. This device may not cause interference,
and
2. this device must accept any interference
received, including interference that may
cause undesired operation.
Any unauthorized modification to this
device could void the user's authority to
operate the equipment.
The Product label with FCC ID and IC
certification number can be found in the
battery case of the SmartKey. Occupant safety
Important safety notes
G
WARNING
Modifications to or work improperly
conducted on restraint system components
or their wiring, as well as tampering with
interconnected electronic systems, can lead
to
the restraint systems no longer functioning
as intended.
Air bags or Emergency Tensioning Devices
(ETDs), for example, could deploy
inadvertently or fail to deploy in accidents
although the deceleration threshold for air
bag deployment is exceeded. Therefore,
never modify the restraint systems. Do not 40
Occupant safety
Safety
Page 46 of 420

If you sell your vehicle, it is important that you
make the buyer aware of this safety
information. Be sure to give the buyer this
Operator's Manual.
G
WARNING
Accident research shows that the safest place
for children in an automobile is in a rear seat.
A side impact air bag related injury may occur
if occupants, especially children, are not
properly seated or restrained when next to a
side impact air bag which needs to deploy
rapidly in a side impact in order to do its job.
To help avoid the possibility of injury, please
follow these guidelines:
(1) Always sit as upright as possible and use the seat belts properly.
Make sure that children 12 years
old
and under use an appropriately
sized child restraint, infant
restraint, or booster seat
recommended for the size and
weight of the child.
(2) Always wear seat belts properly.
If the air bags are deployed, you will hear a
bang,
and a small amount of powder may also
be released. Only in rare cases will the bang
affect your hearing. The powder that is
released generally does not constitute a
health hazard. The 6 SRS warning lamp
lights up.
The air bags are deployed if the air bag control
unit detects the need for deployment. Only in
the event of such a situation will the air bags
provide their supplemental protection.
If the driver and front passenger do not wear
their seat belts, it is not possible for the air
bags to provide their supplemental
protection.
In the event of other types of impacts and
impacts below air bag deployment
thresholds, the air bags will not deploy. The
driver and passengers will then be protected
to the extent possible by a properly fastened
seat belt. A properly fastened seat belt is also needed to provide the best possible
protection in a rollover.
Air bags provide additional protection; they
are not, however, a substitute for seat belts.
All vehicle occupants must fasten their seat
belts regardless of whether your vehicle is
equipped with air bags or not.
It
is important for your safety and that of your
passengers to have deployed air bags
replaced and to have any malfunctioning air
bags repaired. This will help to make sure the
air bags continue to perform their protective
function for the vehicle occupants in the
event of a crash.
Front air bags Driver's air bag
: deploys in front of the
steering wheel; front-passenger front air
bag ;
deploys in front of and above the glove
box.
The front air bags increase protection for the
driver's and front-passenger's head and
chest.
They are deployed:
R in the event of certain frontal impacts
R if the system determines that air bag
deployment can offer additional protection
to that provided by the seat belt
R depending on whether the seat belt is being
used
R independently of other air bags in the
vehicle
If the vehicle overturns, the front air bags are
generally not deployed. If the system detects 44
Occupant safety
Safety
Page 47 of 420

high vehicle deceleration in a longitudinal
direction, the front air bags are deployed.
If a child restraint system is installed to the
front-passenger seat and the
4
PASSENGER AIRBAG OFF indicator lamp
does not light up on the center console:
R a child restraint system without
transponders for air bag deactivation
system is installed or
R a child restraint system with transponders
is not properly installed.
Your
vehicle has adaptive, two-stage front air
bags. In the event of a collision, the air bag
control unit evaluates the vehicle
deceleration. In the first deployment stage,
the front air bag is filled with enough
propellant gas to reduce the risk of injuries.
The front air bag is fully deployed if a second
deployment threshold is exceeded within a
few milliseconds.
The deployment of the front-passenger front
air bag is also influenced by the weight
category of the front passenger, which is
determined by the Occupant Classification
System (OCS) ( Y page 48).
The lighter the passenger side occupant, the
higher the vehicle deceleration rate required
(predicted at the start of the impact) for
second-stage inflation of the front-passenger
front air bag. In the second stage, the front
air bags are inflated with the maximum
amount of propellant gas available.
The front air bags are not deployed in
situations where a low impact severity is
predicted. You will then be protected by the
fastened seat belt.
Front-passenger front air bag will only deploy
if:
R the system, based on the OCS weight
sensor readings, has detected that the
front-passenger seat is occupied.
R the 45 indicator lamp on the center
console is not lit (Y page 48).
R the air bag control unit predicts a high
impact severity. Driver's knee bag
Driver's knee bag : deploys under the
steering
column. It is deployed together with
the front air bags. The driver's knee bag is
designed to operate together with the front
air bags in frontal impacts if certain
thresholds are exceeded. The driver's knee
bag operates best in conjunction with
correctly positioned and fastened seat belts.
The driver's knee bag increases protection of
the driver against:
R knee injuries
R thigh injuries
R lower leg injuries
Side impact air bags G
WARNING
Only use seat covers which have been tested
and approved by Mercedes-Benz for your
vehicle
model. Using seat covers or other seat
coverings can cause a malfunction of the side
impact air bags and/or the pelvis air bags.
Contact an authorized Mercedes-Benz Center
for availability. G
WARNING
The pressure sensors for side impact air bag
control are located in the doors. Do not
modify any components of the doors or door
trim panels including, for example, the
addition of door speakers.
Improper repair work on the doors or the
modification
or addition of components to the
doors create a risk of rendering the side Occupant safety
45
Safety
Z
