MERCEDES-BENZ E320 BLUETEC 2007 W211 Owner's Manual

280 Controls in detailLoadingThe handling characteristics of a fully load-
ed vehicle depend greatly on the load dis-
tribution. It is therefore recommended to
load the vehicle according to the illustra-
tions shown, with the heaviest items being
placed towards the front of the vehicle.
Always place items being carried against
front or rear seat backrests, and fasten
them as securely as possible.
The heaviest portion of the cargo should al-
ways be kept as low as possible since it in-
fluences the handling characteristics of
the vehicle.
Cargo tie-down rings*
Four rings1 are located in the trunk.
Carefully secure cargo by applying
even load on all rings with rope of suffi-
cient strength to hold down the cargo.
Always follow loading instructions
(page 279).
Warning!
G
Always fasten items being carried as secure-
ly as possible using cargo tie-down rings and
fastening materials appropriate for the
weight and size of the load.
In an accident, during hard braking or sud-
den maneuvers, loose items will be thrown
around inside the vehicle and can cause in-
jury to vehicle occupants unless the items
are securely fastened in the vehicle.
To help avoid personal injury during a colli-
sion or sudden maneuver, exercise care
when transporting cargo. Put luggage or car-
go in the trunk if possible. Do not pile lug-
gage or cargo higher than the seat backs.
Do not place anything on the rear-window
shelf.
Never drive vehicle with trunk open. Deadly
carbon monoxide (CO) gases may enter ve-
hicle interior resulting in unconsciousness
and death.

281 Controls in detail
Loading
Rear seat
There is a cargo tie-down ring1 located
on each side of the footwell under the rear
seat.
Retaining hooks
Depending on vehicle production date one
or two hooks are located on the upper
edge of the trunk and can be used to
attach cargo items such as bags.
Pull tab 1 of retaining hook 2 down.
!
Do not use the retaining hooks to tie down
cargo.

282 Controls in detailUseful featuresStorage compartments Glove box
1Compartment for mobile phone/glass-
es
2Glove box lid release
Opening the glove box

Push glove box lid release2.
The glove box lid opens downward.
Closing the glove box

Push glove box lid up to close.Storage compartment in the rear cen-
ter console

Briefly press the top of the compart-
ment.
It extends automatically.
Warning!
G
To help avoid personal injury during a colli-
sion or sudden maneuver, exercise care
when storing objects in the vehicle. Put lug-
gage or cargo in the trunk if possible. Do not
pile luggage or cargo higher than the seat
backs. Do not place anything on the shelf
below the rear window.
Luggage nets cannot secure hard or heavy
objects.
Keep compartment lids closed. This will help
to prevent stored objects from being thrown
around and injuring vehicle occupants dur-
ing an accident.
i
Close the compartment for mobile
phone/glasses1 first before closing the glove
box.

283 Controls in detail
Useful features
Storage compartment in the rear arm-
rest
Press the handle upwards and fold the
rear armrest lid up.Ruffled storage bags
Ruffled storage bags are located on the
back of the front seats.
Warning!
G
USA only: Do not place objects with a com-
bined weight of more than 4.4 lb (2 kg) into
the ruffled storage bag. Otherwise, the
Occupant Classification System OCS
(page 75) may not be able to properly
approximate the occupant weight category.
The ruffled storage bag is intended for stor-
ing light-weight items only.
Heavy objects, objects with sharp edges or
fragile objects may not be transported in the
ruffled storage bag. In an accident, during
hard braking, or sudden maneuvers, they
could be thrown around inside the vehicle
and cause injury to vehicle occupants.
The ruffled storage bag cannot protect
transported goods in the event of an acci-
dent.

284 Controls in detailUseful featuresParcel net in front passenger footwell
A small convenience parcel net is located
in the front passenger footwell. It is for
small and light items, such as road maps,
mail, etc.
Cup holders
Warning!
G
The parcel net is intended for storing
light-weight items only.
Heavy objects, objects with sharp edges or
fragile objects may not be transported in the
parcel net. In an accident, during hard brak-
ing, or sudden maneuvers, they could be
thrown around inside the vehicle and cause
injury to vehicle occupants.
The parcel net cannot protect transported
goods in the event of an accident.
Warning!
G
In order to help prevent spilling liquids on
vehicle occupants and/or vehicle equip-
ment, only use containers that fit into the
cup holder. Use lids on open containers and
do not fill containers to a height where the
contents, especially hot liquids, could spill
during braking, vehicle maneuvers, or in an
accident. Liquids spilled on vehicle occu-
pants may cause serious personal injury.
Liquids spilled on vehicle equipment may
cause damage not covered by the
Mercedes-Benz Limited Warranty.
When not in use, keep the cup holder
closed. An open cup holder may cause injury
to you or others when contacted during
braking, vehicle maneuvers, or in an acci-
dent.

285 Controls in detail
Useful features
Storage compartment with cup holder
in the center armrest/telephone* com-
partment
The storage compartment in the center
armrest contains a removable dual cup
holder.
Opening storage compartment
1Cover
Slide cover1 in direction of arrow.2Dual cup holder
3Telephone* compartment
Closing storage compartment

Slide cover1 back.
Keep in mind that objects placed in the cup
holder may come loose during braking, vehi-
cle maneuvers, or in an accident and be
thrown around in the vehicle interior. Ob-
jects thrown around in the vehicle interior
may cause an accident and/or serious per-
sonal injury.
i
The Roadside Assistance button• and
the Information button¡ are located below
the cover1.
i
The dual cup holder can be removed to in-
crease storage space and for cleaning. Clean the
dual cup holder only with clear, lukewarm water.
Make sure to insert the dual cup holder in the
guides when reinstalling it (
page 286).

286 Controls in detailUseful featuresRemoving cup holder
1Dual cup holder
2Locking pins
Move both locking pins2 in direction
of arrows.

Take dual cup holder1 out upward.Reinstalling cup holder
3Locking pins

Insert cup holder.

Move both locking pins3 in direction
of arrows.Rear cup holder

Briefly press the front of the rear arm-
rest.
The cup holder extends automatically.
!
Make sure that the dual cup holder1 is
correctly positioned in the guides while you are
reinstalling it. Otherwise the cup holder can be
damaged.
!
Do not sit on or lean your body weight
against the armrest when it is folded down, as
you could otherwise damage it.

287 Controls in detail
Useful features
Ashtrays
Center console ashtray
1Cover
2Sliding button
Opening ashtray
Briefly press the marking on the bot-
tom of cover1.
The cover opens automatically.Removing ashtray insert

Secure vehicle from movement by set-
ting the parking brake. Move the gear
selector lever to positionN.
Now you have more room to take out
the insert.

Push sliding button2 to the right and
hold.

Grip and remove insert from ashtray
frame.Reinstalling ashtray insert

Install insert by pushing it back into
frame until it engages again.
Rear door ashtray
1Sliding button
2Insert slides out
3Ashtray
Opening rear door ashtray

Briefly press the top of the ashtray3.
The ashtray opens.
Warning!
G
Remove front ashtray only with vehicle
standing still. Set the parking brake to se-
cure vehicle from movement. Move gear se-
lector lever to positionN. With gear selector
lever in positionN, turn off the engine.

288 Controls in detailUseful featuresRemoving ashtray insert
Push sliding button1 (
page 287)
and remove insert2 (
page 287) up-
wards from ashtray frame.
Reinstalling ashtray insert

Install insert2 (
page 287) by push-
ing it back into ashtray frame until it en-
gages again.
Cigarette lighterThe cigarette lighter is located in the cen-
ter console compartment in front of the
center armrest (
page 30).
1Cigarette lighter

Switch on the ignition (
page 37).

Push in cigarette lighter1.
The lighter will pop out automatically
when hot.
Warning!
G
Never touch the heating element or sides of
the lighter; they are extremely hot. Hold the
knob only.
Make sure that any children traveling with
you do not injure themselves or start a fire
with the hot cigarette lighter.
When leaving the vehicle, always remove the
SmartKey or the SmartKey with
KEYLESS-GO* from the starter switch, take
it with you, and lock the vehicle. Do not
leave children unattended in the vehicle, or
with access to an unlocked vehicle. A child’s
unsupervised access to a vehicle could re-
sult in an accident and/or serious personal
injury.

289 Controls in detail
Useful features
Power outlet
The power outlet is located in the rear pas-
senger compartment.
Switch on the ignition (
page 37).

Flip up cover and insert electrical plug
(cigarette lighter type).
Heated steering wheel (Canada only)
The steering wheel heating warms up the
leather area of the steering wheel.
The stalk is on the lower left-hand side of
the steering wheel.
1Switching on
2Switching off
3Indicator lamp
!
The lighter socket can be used to accommo-
date 12 V DC electrical accessories (up to a
maximum of 85 W) designed for use with the
standard “cigarette lighter” plug type. Keep in
mind, however, that connecting accessories to
the lighter socket (for example extensive con-
necting and disconnecting, or using plugs that do
not fit properly) can damage the lighter socket.
With the socket damaged, the lighter may no
longer be able to be placed in the heating
(pushed-in) position, or the lighter may pop out
too early with the lighter not hot enough.
To help avoid damaging the cigarette lighter
socket, we recommend connecting 12 V DC
electrical accessories designed for use with a
standard “cigarette lighter” plug type to the 12 V
power outlets in your vehicle whenever possible.
i
The power outlet can be used to
accommodate 12 V DC electrical accessories
(e.g. air pump, auxiliary lamps) up to a maximum
of 180 W.
An additional power outlet is located on the left
side in the trunk.
