Page 41 of 522
40 Getting startedUnlockingIgnition (or position 2)
Press KEYLESS-GO start/stop button
twice.
This supplies power for all electrical
consumers. All lamps in the instrument
cluster (except low beam headlamp in-
dicator lamp, high beam headlamp indi-
cator lamp, and turn signal indicator
lamps unless activated) come on. If a
lamp in the instrument cluster fails to
come on when the ignition is switched
on, have it checked and replaced if nec-
essary. If a lamp in the instrument clus-
ter remains on after starting the engine
or comes on while driving, see “Lamps
in instrument cluster” (
page 380).For information on starting the engine us-
ing the KEYLESS-GO start/stop button,
see “Starting with KEYLESS-GO*”
(
page 53).
i
If you now press the KEYLESS-GO
start/stop button once, the power supply is
again switched off.
i
When you switch on the ignition, the indica-
tor and warning lamps (except low beam head-
lamp indicator lamp, high beam headlamp
indicator lamp, and turn signal indicator lamps
unless activated) in the instrument cluster come
on. The indicator and warning lamps (except low
beam headlamp indicator lamp, high beam head-
lamp indicator lamp, and turn signal indicator
lamps if activated) should go out when the en-
gine is running. This indicates that the respective
systems are operational.
Page 42 of 522
41 Getting started
Adjusting
Adjusting
Seats
Warning!
G
All seat, head restraint, steering wheel, and
rear view mirror adjustments, as well as fas-
tening of seat belts, must be done before
the vehicle is put into motion.
Warning!
G
Do not adjust the driver’s seat while driving.
Adjusting the seat while driving could cause
the driver to lose control of the vehicle.
Never ride in a moving vehicle with the seat
backrest in an excessively reclined position
as this can be dangerous. You could slide
under the seat belt in a collision. If you slide
under it, the seat belt would apply force at
the abdomen or neck. That could cause se-
rious or fatal injuries. The seat back and seat
belts provide the best restraint when the
wearer is in a nearly upright position and
seat belts are properly positioned on the
body.
Warning!
G
Your seat must be adjusted so that you can
correctly fasten your seat belt (
page 49).
Observe the following points:
Adjust the backrest until your arms are
slightly angled when holding the steer-
ing wheel.
Adjust the seat to a comfortable seating
position that still allows you to reach the
accelerator/brake pedal safely. The po-
sition should be as far to the rear as pos-
sible, consistent with ability to properly
operate controls.
Adjust the head restraint so that it is as
close to the head as possible and the
center of the head restraint supports
the back of the head at eye level.
Never place hands under the seat or
near any moving parts while a seat is be-
ing adjusted.
Failure to do so could result in an accident
and/or serious personal injury.
Page 43 of 522
42 Getting startedAdjustingWarning!
G
When leaving the vehicle, always remove the
SmartKey or the SmartKey with
KEYLESS-GO* from the starter switch, take
it with you, and lock the vehicle.
Even with the SmartKey or the SmartKey
with KEYLESS-GO* removed from the start-
er switch or the SmartKey with
KEYLESS-GO* removed from the vehicle,
the power seats can be operated when the
respective door is open. Therefore, do not
leave children unattended in the vehicle, or
with access to an unlocked vehicle. A child’s
unsupervised access to a vehicle could re-
sult in an accident and/or serious personal
injury.
Warning!
G
Canada only: Children 12 years old and un-
der must never ride in the front seat, except
in a Mercedes-Benz authorized
BabySmart
TM compatible child seat, which
operates with the BabySmart
TM system in-
stalled in the vehicle to deactivate the front
passenger front air bag when it is properly
installed. Otherwise they will be struck by
the air bag when it inflates in a crash. If this
happens, serious or fatal injury will result.
According to accident statistics, children
are safer when properly restrained in the
rear seating positions than in the front seat-
ing position. Thus, we strongly recommend
that children be placed in the rear seats
whenever possible. Regardless of seating
position, children 12 years old and under
must be seated and properly secured in an
appropriately sized infant restraint, toddler
restraint, or booster seat recommended for
the size and weight of the child. For addi-
tional information, see “Children in the vehi-
cle” (
page 88).
A child’s risk of serious or fatal injuries is
significantly increased if the child restraints
are not properly secured in the vehicle and
the child is not properly secured in the child
restraint.
Page 44 of 522
43 Getting started
Adjusting
Seat adjustment
The seat adjustment switches are located
on the front doors.
1Seat fore and aft adjustment
2Backrest tilt
3Seat height
4Seat cushion tilt
5Head restraint height
Switch on the ignition (
page 37).
or
Open the respective door.Seat fore and aft adjustment
Press the switch forward or backward
in direction of arrow1.
Backrest tilt
Press the switch forward or backward
in direction of arrow2.
Seat height
Press the switch up or down in direc-
tion of arrow3.Seat cushion tilt
Press the switch up or down in direc-
tion of arrow4 until your upper legs
are lightly supported.
Head restraint height
Press the switch up or down in direc-
tion of arrow5.
i
The memory function (
page 134) lets you
store the settings for the seat position together
with the settings for the steering wheel and the
exterior rear view mirrors.
!
When moving the seat, make sure there are
no items in the footwell or behind the seats. Oth-
erwise you could damage the seats.
i
Depending on the set height of the head re-
straint, the seat fore and aft position is
automatically pre-set.
i
Adjust the head restraint in such a way that
it is as close to the head as possible.Warning!
G
For your protection, drive only with properly
positioned head restraints.
Adjust head restraint so that the center of
the head restraint supports the back of the
head at eye level. This will reduce the poten-
tial for injury to the head and neck in the
event of an accident or similar situation.
Do not drive the vehicle without the seat
head restraints. Head restraints are intend-
ed to help reduce injuries during an acci-
dent.
Page 45 of 522
44 Getting startedAdjustingHead restraint adjusting
Manually adjust the head restraint.
Push or pull on the upper edge of the
head restraint cushion to the desired
position.Comfort head restraint* adjusting
1Head restraint side adjustment
2Head restraint fore and aft adjustment
To adjust the head restraint sides:
Pull or push sides1 into desired posi-
tion.To move the head restraint forward or
backward:
Pull or push head restraint in direction
of arrow2.
For more information on seats, see “Seats”
(
page 129).
i
Adjust the head restraint in such a way that
it is as close to the head as possible.
Warning!
G
When folding back the side cushions, never
reach between the side cushion and the
mounting post. You could otherwise be
trapped.
i
Adjust the head restraint in such a way that
it is as close to the head as possible.
Page 46 of 522
45 Getting started
Adjusting
Steering wheel Steering wheel adjustment
The steering wheel adjustment stalk is lo-
cated on the lower left of the steering col-
umn.
1Adjusting steering column, in or out
2Adjusting steering column, up or down
Switch on the ignition (
page 37).
or
Open the driver’s door.Adjusting steering column in or out
Move stalk in direction of arrows1
until a comfortable steering wheel posi-
tion is reached with your arms slightly
bent at the elbow.
Adjusting steering column up or down
Move stalk in direction of arrows2.
Make sure your legs can move freely
and all the displays (incl. malfunction
and indicator lamps) on the instrument
cluster are clearly visible.
Warning!
G
Do not adjust the steering wheel while driv-
ing. Adjusting the steering wheel while driv-
ing could cause the driver to lose control of
the vehicle.
When leaving the vehicle, always remove the
SmartKey or the SmartKey with
KEYLESS-GO* from the starter switch, take
it with you, and lock the vehicle.
Even with the SmartKey or the SmartKey
with KEYLESS-GO* removed from the start-
er switch or the SmartKey with
KEYLESS-GO* removed from the vehicle,
the steering wheel adjustment feature can
be operated when the driver’s door is open.
Therefore, do not leave children unattended
in the vehicle, or with access to an unlocked
vehicle. A child’s unsupervised access to a
vehicle could result in an accident and/or
serious personal injury.
i
The memory function (
page 134) lets you
store the settings for the steering wheel together
with the settings for the exterior rear view mir-
rors and the driver’s seat position.
Page 47 of 522
46 Getting startedAdjustingEasy-entry/exit feature
This feature allows for easier entry into and
exit from the vehicle. When entering and
exiting the vehicle, the steering wheel is in
its uppermost position.
The easy-entry/exit feature can be activat-
ed or deactivated in the
Convenience
sub-
menu of the control system (
page 178).With the easy-entry/exit feature activated,
the steering wheel will return to its last set
position when you:
close the driver’s door with the ignition
switched on
or
insert the SmartKey into the starter
switch or press the KEYLESS-GO*
start/stop button (
page 39) once
with the driver’s door closedWith the easy-entry/exit feature activated,
the steering wheel tilts upwards when you:
remove the SmartKey from the starter
switch
or
open the driver’s door with the
SmartKey in starter switch position 0
or 1 or the KEYLESS-GO* start/stop
button (
page 39) in position 1
Warning!
G
You must make sure no one can become
trapped or injured by the moving steering
wheel when the easy-entry/exit feature is
activated.
To stop steering wheel movement, do one of
the following:
Move steering wheel adjustment stalk
(page 45).
Press one of the memory buttons
(page 135).
Do not leave children unattended in the ve-
hicle, or with access to an unlocked vehicle.
Children could open the driver’s door and
unintentionally activate the easy-entry/exit
feature, which could result in an accident
and/or serious personal injury.i
The last set steering wheel position is stored
when
the ignition is switched off (
page 63)
the position is stored in memory
(page 135)
i
If the current position for the steering wheel
is in the uppermost tilt position, the steering
wheel will no longer be able to move upward
when the easy-entry/exit feature is activated.
The adjustment procedure is briefly interrupted
when the engine is started.
Page 48 of 522
47 Getting started
Adjusting
Mirrors
Adjust the interior and exterior rear view
mirrors before driving so that you have a
good view of the road and traffic condi-
tions.Interior rear view mirror
Manually adjust the interior rear view
mirror.
For more information, see “Rear view mir-
rors” (
page 198).
Exterior rear view mirrors
Warning!
G
Let the system complete the adjustment
procedure before setting the vehicle in mo-
tion. All steering wheel adjustment must be
completed before setting the vehicle in mo-
tion. Driving off with the steering wheel still
adjusting could cause the driver to lose con-
trol of the vehicle.
Warning!
G
In case of an accident, liquid electrolyte may
escape the mirror housing if the mirror glass
breaks.
Electrolyte has an irritating effect. Do not al-
low the liquid to come into contact with
eyes, skin, clothing, or respiratory system.
In case it does, immediately flush affected
area with water, and seek medical help if
necessary.!
Electrolyte drops coming into contact with
the vehicle paint finish can only be completely
removed while in their liquid state and by apply-
ing plenty of water.
Warning!
G
Exercise care when using the
passenger-side exterior rear view mirror.
The mirror surface is convex (outwardly
curved surface for a wider field of view). Ob-
jects in mirror are closer than they appear.
Check your interior rear view mirror or
glance over your shoulder before changing
lanes.
Page 49 of 522
48 Getting startedAdjustingThe buttons are located on the driver’s
door.
1Driver’s side exterior rear view mirror
button
2Adjustment button
3Passenger-side exterior rear view mir-
ror button
Switch on the ignition (
page 37).
Press button1 for the driver’s side ex-
terior rear view mirror or button3 for
the passenger-side exterior rear view
mirror.
Push adjustment button2 up, down,
left or right according to the desired
setting.For more information, see “Activating exte-
rior rear view mirror parking position”
(
page 200).
For more information, see “Rear view mir-
rors” (
page 198).
!
If an exterior rear view mirror was forcibly
pushed forward (hit from the rear) or forcibly
pushed rearward (hit from the front), reposition
it by applying firm pressure until it snaps into
place. The mirror housing is now properly posi-
tioned and you can adjust the mirror in the usual
manner.
i
At low ambient temperatures, the exterior
rear view mirrors will be heated automatically.
i
The memory function (
page 134) lets you
store the settings for the exterior rear view mir-
rors together with the settings for the steering
wheel and the driver’s seat position.
Page 50 of 522
49 Getting started
Driving
Driving
Fastening the seat beltsWarning!
G
Make sure that absolutely no objects are ob-
structing the pedals’ range of movement.
Keep the driver’s footwell clear of all obsta-
cles. If there are any floormats or carpets in
the footwell, make sure that the pedals still
have sufficient clearance.
During sudden driving or braking maneuvers
the objects could get caught between the
pedals. You could then no longer brake or
accelerate. This could lead to accidents and
injury.Warning!
G
Always fasten your seat belt before driving
off. Always make sure all of your passengers
are properly restrained, even those sitting in
the rear.
Failure to wear and properly fasten and
position your seat belt greatly increases
your risk of injuries and their likely severity
in an accident. You and your passengers
should always wear seat belts.
If you are ever in an accident, your injuries
can be considerably more severe without
your seat belt properly buckled. Without
your seat belt buckled, you are much more
likely to hit the interior of the vehicle or be
ejected from it. You can be seriously injured
or killed.
In the same crash, the possibility of injury or
death is lessened if you are wearing your
seat belt. The air bags can only provide the
protection they were designed to afford if
the occupants are using their seat belts
(page 82).
Warning!
G
Canada only: Children 12 years old and un-
der must never ride in the front seat, except
in a Mercedes-Benz authorized
BabySmart
TM compatible child seat, which
operates with the BabySmart
TM system in-
stalled in the vehicle to deactivate the front
passenger front air bag when it is properly
installed. Otherwise they will be struck by
the air bag when it inflates in a crash. If this
happens, serious or fatal injury will result.
According to accident statistics, children
are safer when properly restrained in the
rear seating positions than in the front seat-
ing position. Thus, we strongly recommend
that children be placed in the rear seats.
Regardless of seating position, children
12 years old and under must be seated and
properly secured in an appropriately sized
infant restraint, toddler restraint, or booster
seat recommended for the size and weight
of the child. For additional information, see
“Children in the vehicle” (
page 88).
