MERCEDES-BENZ E320CDI 2005 W211 Owner's Manual

119 Controls in detail
Locking and unlocking
For more information on towing the vehi-
cle, see the “Practical hints” section
(page 439).
You can deactivate the automatic locking
mode using the control system
(page 166).
Locking and unlocking from the inside
You can lock or unlock the doors and the
trunk from inside using the central locking
switch. This can be useful, for example, if
you want to lock the vehicle before starting
to drive.
The fuel filler flap cannot be locked or un-
locked with the central locking switch.The switch is located in the center console.
Central locking switch1Locking
2Unlocking
Locking
Press upper half1 of the central lock-
ing switch.
If all doors are closed, the vehicle
locks.
Warning!
G
When leaving the vehicle, always remove the
SmartKey or the SmartKey with
KEYLESS-GO* from the starter switch, take
it with you, and lock the vehicle. Do not
leave children unattended in the vehicle, or
with access to an unlocked vehicle. Unsu-
pervised use of vehicle equipment may
cause an accident and/or serious personal
injury.

120 Controls in detailLocking and unlockingUnlocking
Press lower half2 of the central lock-
ing switch.
The vehicle unlocks.iYou can open a locked door from the
inside. Open door only when conditions
are safe to do so.
If the vehicle was previously centrally
locked using the SmartKey, it will not
unlock using the central locking switch.
If the vehicle was previously locked
with the central locking switch

while in the selective remote con-
trol mode, only the front door
opened from the inside is unlocked.


while in the global remote control
mode, the vehicle is unlocked com-
pletely when a front door is opened
from the inside.

121 Controls in detailSeats
Seats
For more information on seat adjustment,
see the “Getting started” section
(page 38).
Easy-entry/exit feature
This feature allows for easier entry into and
exit from the vehicle.
The easy-entry/exit feature can be activat-
ed or deactivated in the
Convenience
sub-
menu of the control system (
page 167).When exiting the vehicle, with the
easy-entry/exit feature activated and de-
pending on your selection, the steering
wheel tilts upwards and/or the driver’s
seat moves a few inches to the rear when
you:


remove the SmartKey from the starter
switch,
or


open the driver’s door with the
SmartKey in starter switch position 0
or 1 or the KEYLESS-GO* start/stop
button (
page 35) in position 1.
Warning!
G
You must make sure no one can become
trapped or injured by the moving steering
wheel and driver’s seat when the easy-en-
try/exit feature is activated.
To cancel seat/steering wheel movement,
do one of the following:

Press seat adjustment switch
(page 30).


Move steering column stalk
(page 40).


Press one of the memory position but-
tons (
page 131).
Do not leave children unattended in the ve-
hicle, or with access to an unlocked vehicle.
Children could open the driver’s door and
unintentionally activate the easy-entry/exit
feature, which could result in an accident
and/or serious personal injury.

122 Controls in detailSeats
When entering the vehicle, with the
easy-entry/exit feature activated, the
steering wheel or, depending on your se-
lection, the steering wheel and driver’s
seat will return to their last set memory po-
sition or a factory-set maximum forward
position when you:

close the driver’s door with the ignition
switched on


insert the SmartKey in starter switch or
press the KEYLESS-GO* start/stop
button (
page 35) once with the driv-
er’s door closed.
iIf the current position for the steering
wheel is in the uppermost tilt position,
the steering wheel will no longer be
able to move upward when the
easy-entry/exit feature is activated.
If the current seat position falls into a
factory-set position range and the
sytem recognizes the current seat posi-
tion to be rearward enough for easy en-
try and exit, the driver’s seat will not
move to the rear when the
easy-entry/exit feature is activated.
iFor safety reasons, the driver’s seat will
not return to its last set position with
the easy-entry/exit feature activated if
the system recognizes the last set posi-
tion as an extreme forward position. In-
stead, the driver’s seat will remain at or
move to a factory-set maximum for-
ward position. To again fully return the
driver’s seat to your last set position or
to memory position, adjust the seat to
the desired position or press and hold
the respective memory position button
(page 131).

123 Controls in detailSeats
Removing and installing front seat head restraints
For more information on head restraint ad-
justment, see the “Getting started” section
(page 39).
Front seat head restraints
Removing front head restraints

Press switch1upwards and hold until
the head restraint is fully extended.

Pull out head restraint.Installing front head restraints:

Press switch1upwards and hold for
about five seconds.

Push the head restraint down until it
engages.

Adjust head restraint to desired posi-
tion (
page 39).
Warning!
G
For your protection, drive only with properly
positioned head restraints.
Adjust head restraint so that the center of
the head restraint supports the back of the
head at eye level. This will reduce the poten-
tial for injury to the head and neck in the
event of an accident or similar situation.
Do not drive the vehicle without the seat
head restraints. Head restraints are intend-
ed to help reduce injuries during an acci-
dent.
iTilt the backrest to the rear for easier
removal and installation of the head re-
straints.

124 Controls in detailSeatsRear seat head restraints
Folding head restraints back with
switch in the center console
The rear seat head restraints can be folded
backward for increased visibility.
1Head restraint release switch

Switch on the ignition (
page 33).

Press the symbol-side on rocker
switch1to release the head re-
straints.
The head restraints will fold backward.Placing head restraints upright

Pull the head restraint forward until it
locks into position.
!The rear seat head restraints cannot be
adjusted.
Warning!
G
For safety reasons, always drive with the
rear head restraints in the upright position
when the rear seats are occupied.
Keep the area around head restraints clear
of articles (e.g. clothing) to not obstruct the
folding operation of the head restraints.
!Make sure the head restraints engage
when placing them upright. Otherwise
their protective function cannot be as-
sured.

125 Controls in detailSeats
Removing and installing rear seat head
restraints
1Release catch
Removing rear seat head restraints

Fold the backrest forward
(page 257).

Fold back head restraint (
page 124).

Press head restraint release catch1
and pull the head restraints out of the
guides.

Fold the backrest back to its original
position.Installing rear seat head restraints
Warning!
G
For your protection, drive only with properly
positioned head restraints.
Adjust head restraint so that the head re-
straint supports the back of the head at eye
level. This will reduce the potential for injury
to the head and neck in the event of an ac-
cident or similar situation.
Do not drive the vehicle without the seat
head restraints. Head restraints are intend-
ed to help reduce injuries during an acci-
dent.
Do not interchange head restraints from
front and rear seat.
iWhen installing the head restraints,
make sure that:

you place the correct head restraint
on the middle seat. It is marked
with the letter “M” on the outside of
the metal bars.


the head restraints engage fully.

126 Controls in detailSeatsDrive - Dynamic seat* with multicon-tour features
The Drive - Dynamic seat automatically ad-
justs the lateral support provided by the
backrest to your driving style.
The Drive - Dynamic seat electronically
controls the air pressure in the air cham-
bers of the backrest side bolsters. This
function improves driving comfort and
pleasure.
Additional the Drive-Dynamic seat has a
movable seat cushion and inflatable air
cushions built into the backrest to provide
additional lumbar and side support.
The seat cushion movement, backrest
cushion height and curvature can be con-
tinuously varied with switches on the right
side of the seat after turning the SmartKey
in the starter switch to position2 or press-
ing the KEYLESS-GO* start/stop button
twice.1Backrest center
2Backrest bottom
3Seat cushion depth
4Activate drive dynamic function
5Backrest side bolsters
6Massage function

Switch on the ignition (
page 33).Multicontour features
Seat cushion depth

Adjust the seat cushion depth to the
length of your upper leg using
switch3.
Backrest contour

Adjust the contour of the backrest to
the desired position using æ or
ç.

Move the backrest support to the bot-
tom by using button2 or to the center
by using button1.
Backrest side bolders

Adjust the side bolsters so that they
provide good lateral support using
switch5.

127 Controls in detailSeats
Drive-dynamic features
Activating
Press button4 (
page 126).
The indicator lamp in the button comes
on for five seconds and the following
display appears in the multi-function
display for about five seconds.
Deactivating

Press button4 (
page 126) again.
The indicator lamp in the button goes
out.Massage function (PULSE)
The massage function can help prevent
muscle tension during long drives.

Press button6 (
page 126).
The indicator lamp in button2 comes
on. The air cushions in the lumbar area
pulsate.
Seat heating*
Both switches for the front seats are locat-
ed in the center console. The red indicator
lamps in the switch come on to show
which heating level you have selected.
iYou can adjust the characteristics of
the Drive - Dynamic seat using the con-
trol system (
page 169).
iWhen the engine is turned off, the last
cushion setting is retained in memory.
The cushion is automatically adjusted
to this setting when the engine is re-
started.iThe massage function turns off auto-
matically after approximately five min-
utes.
Leveloff
No indicator lamps on
1
One indicator lamp on
2
Two indicator lamps onThe seat heater automatically
switches to level 1 after approxi-
mately ten minutes.
3
Three indicator lamps onThe seat heater automatically
switches to level 2 after approxi-
mately five minutes.

128 Controls in detailSeats1Seat heating switch
Switch on the ignition (
page 33).
Switching seat heating on

Press button1 repeatedly until the
desired heating level is set.
One or more red indicator lamps on the
switch show the selected heater level.Switching seat heating off

Press button1 repeatedly until all in-
dicator lamps go out.
Seat ventilation*
The switch is located on the center con-
sole. Seat ventilation can be activated
manually with the ignition on, or by the
summer opening feature (
page 220).
The blue indicator lamps on the switch
show the ventilation level selected:
iThe seat heating will be automatically
switched off after approximately
20 minutes.!If one or more of the lamps on the seat
heater switch are flashing, there is in-
sufficient voltage available since too
many electrical consumers are turned
on. The seat heater switches off auto-
matically.
The seat heater will switch back on
again automatically as soon as suffi-
cient voltage is available.
Level3
Three indicator lamps on
2
Two indicator lamps on
1
One indicator lamp on
off
No indicator lamp on
