preglow MERCEDES-BENZ E320CDI 2005 W211 Owner's Manual
[x] Cancel search | Manufacturer: MERCEDES-BENZ, Model Year: 2005, Model line: E320CDI, Model: MERCEDES-BENZ E320CDI 2005 W211Pages: 506, PDF Size: 5.96 MB
Page 27 of 506
25 At a glance
Instrument cluster
Item
Page
1
LLeft turn signal indi-
cator lamp
2
vABS/ ESP warning
lamp
357
3
Speedometer
4
Multifunction display
145
5
lDistance warning
lamp
Vehicles without Distronic*:
Warning lamp without func-
tion. It illuminates with the
ignition on. It should go out
when the engine is running.
361
6
KRight turn signal indi-
cator lamp
7
Coolant temperature indi-
cator with:•Coolant temperature
warning lamp
361
Item
Page
8
Tachometer with:1Supplemental Re-
straint System
indicator lamp
364
-Antilock Brake Sys-
tem (ABS) indicator
lamp
356
BLow beam headlamp
indicator lamp
50
AHigh beam headlamp
indicator lamp
137
9
Main odometer with:
Selector lever position
46
Program mode
179
a
Clock with:
159
;Brake warning lamp,
USA only
358
3Brake warning lamp,
Canada only
358
Item
Page
?Engine malfunction
indicator lamp, USA
only
359
±Engine malfunction
indicator lamp, Cana-
da only
359
HTire inflation pres-
sure warning lamp*
363
qPreglow indicator
lamp, Diesel engine
only
47
b
Fuel display with:AFuel reserve warning
lamp
362
c
Reset button for:
Resetting trip odometer
143
Adjusting instrument
cluster illumination
142
Confirming new time set-
tings
159
Page 49 of 506
47 Getting started
Driving
Diesel engine:
M a k e s u r e t h e g e a r s e l e c t o r l e v e r i s s e t
to P.
Do not depress the accelerator.
Turn the SmartKey in the starter switch
to position2 (
page 34).
The preglow indicator lampq in the
instrument cluster comes on.
As soon as the preglow indicator
lampq goes out, turn the SmartKey
in the starter switch to position3
(page 34) and release it.
The engine starts automatically.
Depress the brake pedal.
The selector lever lock is released.Starting with KEYLESS-GO*
You can start your vehicle without the
SmartKey in the starter switch using the
KEYLESS-GO start/stop button on the
gear selector lever.
For information on turning off the engine
with KEYLESS-GO, see “Turning off with
KEYLESS-GO*” (
page 57).
The SmartKey with KEYLESS-GO must be
located in the vehicle.
KEYLESS-GO start/stop button1USA only
2Canada onlyGasoline engine:
Make sure the gear selector lever is set
toP.
Depress the brake pedal during the
starting procedure. Do not depress ac-
celerator.
The selector lever lock is released.
Press KEYLESS-GO start/stop
button1 once.
The engine starts automatically if the
SmartKey with KEYLESS-GO is in the
vehicle.
Diesel engine:
Make sure the gear selector lever is set
toP.
Depress the brake pedal during the
starting procedure. Do not depress ac-
celerator.
The selector lever lock is released.
Press KEYLESS-GO start/stop
button1 once.
iIf the engine is at operating tempera-
ture, the preglow indicator lampq
may not stay on and you can start the
engine without preglowing.
Page 50 of 506
48 Getting startedDriving
The engine begins to preglow and will
start automatically.
If the engine is at operating temperature,
the preglow indicator lampq may not
stay on and you can start the engine with-
out preglowing:
Press KEYLESS-GO start/stop
button1 until the engine is running.Starting difficulties
If the engine does not start as described,
carry out the following steps:
If you are starting the engine with the
SmartKey, turn SmartKey in starter
switch to position0 and repeat starting
procedure.
If you are starting the engine with
KEYLESS-GO: Close any doors that
may be open to allow for better detec-
tion of the SmartKey with
KEYLESS-GO.
Or:
Start the engine with the SmartKey as
radio signals from another source may
be interfering with the SmartKey with
KEYLESS-GO.
Repeat the starting procedure
(page 46). Remember that extended
starting attempts can drain the battery.
Get a jump start (
page 436).If the engine does not start after several
starting attempts, there could be a mal-
function in the engine electronics or in the
fuel supply system.
Notify an authorized Mercedes-Benz
Center.
Parking brake
1Parking brake pedal
2Parking brake release handle
