230 Controls in detail4-zone automatic climate control*Adjusting air distribution
Push the slide for the left center
vent1 or right center vent2 to the
left, right, up, or down.
The air flow is directed in the
corresponding direction.
Adjusting air volume

Turn thumbwheel3 or 7
(page 229) up or down.
The air volume is increased or
decreased.Adjusting the rear settings with the
front control panel
You can adjust the temperature for the
rear climate control from the front climate
control panel.

Press button™ or 5
(page 216) or (
page 217).
The display switches over.
1Rear climate control display

Set the desired temperature for the
rear passenger compartment using
temperature rocker switches4
and6 (
page 229).
After approximately 5 seconds after
the last adjustment, the display switch-
es back to its standard display.
iThe rear climate control will not cool
the air when the air conditioning is
switched off (
page 227).
iFor draft-free ventilation, push
slides1 and 2 (
page 229) upward.
iYou can also press button™ or
5 (
page 216) or (
page 217)
once more to switch back to the stan-
dard display.


231 Controls in detail
Power windows
Power windows
Opening and closing the windows
The side windows are opened and closed
electrically. The switches for all of the side
windows are on the driver’s door. The
switches for the respective windows are
on the front passenger door and the rear
doors.
1Rear window override switch
(
page 89)
2Right front window
3Right rear window
4Left rear window
5Left front window
Warning!
G
When closing the windows, make sure that
there is no danger of anyone being harmed
by the closing procedure.
The closing of the door windows can be im-
mediately halted by releasing the switch or,
if switch was pulled past the resistance
point and released, by either pressing or
pulling the respective switch.
The door windows are equipped with the ex-
press-close and automatic reversal func-
tion. If the window encounters an
obstruction that blocks its path in a circum-
stance where you pulled the switch past the
resistance point and released it to close the
window, the automatic reversal function will
stop the window and open it slightly.
If the window encounters an obstruction
that blocks its path in a circumstance where
you are closing the window by pulling and
holding the switch, by pressing and holding
button ‹ on the SmartKey, by pressing
and holding the lock button (vehicles with
KEYLESS-GO*) on an outside door handle,
or by pressing and holding button, on
the climate control panel, the automatic re-
versal function will not operate.
When leaving the vehicle, always remove the
SmartKey or SmartKey with KEYLESS-GO*
from the starter switch, take it with you, and
lock the vehicle. Do not leave children unat-
tended in the vehicle, or with access to an
unlocked vehicle. Unsupervised use of vehi-
cle equipment can cause an accident
and/or serious personal injury.

232 Controls in detailPower windows

Switch on the ignition (
page 36).
Opening the windows

Press switch2 to 5 to the resistance
point.
The corresponding window will move
downwards until you release the
switch.Closing the windows

Pull switch2 to 5 to the resistance
point.
The corresponding window will move
upwards until you release the switch.
Fully opening the windows
(Express-open)

Press switch2 to 5 past the resis-
tance point and release.
The corresponding window opens com-
pletely.
iYou can also open or close the win-
dows using the SmartKey, see “Sum-
mer opening feature” (
page 234) and
“Convenience closing feature”
(
page 235).
Depending on current position, the win-
dows may also open or close when the
air recirculation button, in the
control panel of the climate control
(page 204), (
page 216) and
(
page 217) is pressed and held.
iOperating the windows from the rear is
not possible if you activate the override
switch (
page 89).
iWith the SmartKey in starter switch po-
sition 0 or removed from the starter
switch, the power windows can be op-
erated:

until you open the driver’s or front
passenger’s door


for at least 5 minutes.
Warning!
G
If you pull and hold the switch up when clos-
ing the window, and upward movement of
the window is blocked by some obstruction
including but not limited to arms, hands, fin-
gers, etc., the automatic reversal will not op-
erate.

233 Controls in detail
Power windows
Fully closing the windows
(Express-close)
Pull switch2 to 5 past the resis-
tance point and release.
The corresponding window closes com-
pletely.
Stopping windows during Express-op-
eration

Press or pull the respective power win-
dow switch again.
Synchronizing power windows
The power windows must be synchronized

after the battery has been disconnect-
ed


if the power windows cannot be fully
opened (Express-open) or closed
(Express-close)
Synchronizing

Close all doors.

Switch on the ignition (
page 36).

Pull switch2 to 5 until the side win-
dows are completely closed.

Hold on to switches2 to 5 for ap-
proximately 1 second.
The power windows are synchronized.
Warning!
G
Driver’s door only:
If within 5 seconds switch is again pulled
past the resistance point and released, the
automatic reversal will not operate.
!If the upward movement of the window
is blocked during the closing proce-
dure, the window will stop and open
slightly.
Remove the obstruction, pull the re-
spective power window switch again
past the resistance point and release.
If the window still does not close when
there is no obstruction, pull and hold
the respective power window switch.
The side window will then close without
the obstruction sensor function.

234 Controls in detailPower windowsSummer opening feature
If the weather is warm, you can ventilate
the vehicle before driving off by simulta-
neously:

opening the side windows


opening the tilt/sliding sunroof* or
tilt/sliding panel*


turning on the seat ventilation* for the
driver’s seat

Aim transmitter eye of the SmartKey or
SmartKey with KEYLESS-GO* at the
driver’s outside door handle. The
SmartKey or SmartKey with
KEYLESS-GO* must be in close proxim-
ity to the driver’s outside door handle.
Vehicles without panorama roof*

Press and hold button
Œ
until the
windows and the tilt/sliding sunroof*
have reached the desired position.

Release button
Œ
to interrupt proce-
dure.Vehicles with panorama roof*
If roller sunblinds are closed:

Press and hold button
Œ
. The win-
dows and roller blinds begin to open af-
ter approximately 1 second.

With the windows and roller blinds fully
opened, press and hold button
Œ

again. The tilt/sliding panel of the pan-
orama roof* tilts and opens.
If roller sunblinds are open:

Press and hold button
Œ
. The win-
dows move down and the tilt/sliding
panel tilts and opens after approxi-
mately 1 second.

Release button
Œ
to interrupt proce-
dure.
iThe seat ventilation* for the driver’s
seat is automatically set to the highest
level if activated via summer opening
feature.

235 Controls in detail
Power windows
Convenience closing feature
When you lock the vehicle, you can close
the windows, tilt/sliding sunroof* or
tilt/sliding panel* simultaneously.
Aim transmitter eye of the SmartKey or
SmartKey with KEYLESS-GO* at the
driver’s outside door handle
(page 234). The SmartKey or
SmartKey with KEYLESS-GO* must be
in close proximity to the driver’s out-
side door handle.

Press and hold button ‹ until the
windows, the tilt/sliding sunroof* or
tilt/sliding panel* are completely
closed.
Vehicles with panorama roof*:

Press and hold button ‹ again. The
roller sunblinds close.

Release button ‹ to interrupt pro-
cedure.Vehicles with KEYLESS-GO*:

Press and hold the lock button on an
outside door handle (
page 64) until
the windows, the tilt/sliding sunroof*
or tilt/sliding panel* are completely
closed.

Release the lock button on the outside
door handle to interrupt procedure.
Warning!
G
When closing the side windows and the
tilt/sliding sunroof* or tilt/sliding panel*,
ma ke s ur e th at th er e is no dan ge r o f an y o ne
being harmed by the closing procedure.
If potential danger exists, proceed as fol-
lows:

Release button ‹ to stop the closing
procedure. To open, press and hold
buttonŒ. To continue the closing
procedure after making sure that there
is no danger of anyone being harmed by
the closing procedure, press and hold
button‹.
Vehicles with KEYLESS-GO*:


Release the lock button (
page 64) on
the outside door handle to stop the clos-
ing procedure.


Pull on the outside door handle and hold
firmly. The side windows and the
tilt/sliding sunroof* or tilt/sliding pan-
el* will open for as long as the door han-
dle is held but the door not opened.

236 Controls in detailPower tilt/sliding sunroof*Opening and closing the power tilt/sliding sunroof
The tilt/sliding sunroof is opened and
closed electrically. The switch for the
tilt/sliding sunroof is on the overhead con-
trol panel.Sunroof switch1Push back to slide sunroof open
2Push forward to slide sunroof closed
3Push up to raise sunroof at rear
4Pull down to lower sunroof at rearWith the sunroof closed or tilted open, a
screen can be slid into the sunroof opening
to guard against sun rays. When sliding the
sunroof open, the screen will also retract.
Warning!
G
When closing the tilt/sliding sunroof, make
sure there is no danger of anyone being
harmed by the closing procedure.
The opening/closing procedure of the
tilt/sliding sunroof can be immediately halt-
ed by releasing the switch or, if the switch
was moved past the resistance point and re-
leased, by moving the switch in any direc-
tion.
The tilt/sliding sunroof is made out of glass.
In the event of an accident, the glass may
shatter. This may result in an opening in the
roof.
In a vehicle rollover, occupants not wearing
their seat belts or not wearing them properly
may be thrown out of the opening. Such an
opening also presents a potential for injury
for occupants wearing their seat belts prop-
erly as entire body parts or portions of them
may protrude from the passenger compart-
ment.

237 Controls in detail
Power tilt/sliding sunroof*

Switch on the ignition (
page 36).Opening and closing the power
tilt/sliding sunroof

To open, close, raise or lower the
tilt/sliding sunroof, move the sunroof
switch to resistance point in the re-
quired direction of arrows1to4.
Release the sunroof switch when the
tilt/sliding sunroof has reached the de-
sired position.
Fully opening (Express-open) and clos-
ing (Express-close) the power tilt/slid-
ing sunroof

To open or close the tilt/sliding sun-
roof, move the sunroof switch past the
resistance point in direction of
arrow1to2 and release.
The tilt/sliding sunroof opens or closes
completely.
When leaving the vehicle, always remove the
SmartKey or the SmartKey with
KEYLESS-GO* from the starter switch, take
it with you, and lock the vehicle. Do not
leave children unattended in the vehicle, or
with access to an unlocked vehicle. Unsu-
pervised use of vehicle equipment can
cause an accident and/or serious personal
injury.!To avoid damaging the seals, do not
transport any objects with sharp edges
which can stick out of the tilt/sliding
sunroof.
Do not open the tilt/sliding sunroof if
there is snow or ice on the roof, as this
could result in malfunctions.
The tilt/sliding sunroof can be opened
or closed manually should an electrical
malfunction occur (
page 429).
iYou can also open or close the tilt/slid-
ing sunroof using the SmartKey, see
“Summer opening feature”
(page 234) or see “Convenience
closing feature” (
page 235).
Depending on current position, the
tilt/sliding sunroof may also open or
close when the air recirculation
button, in the control panel of the
climate control (
page 204),
(
page 216) or (
page 217) is
pressed and held.

238 Controls in detailPower tilt/sliding sunroof*Stopping the power tilt/sliding sunroof
during Express-operation
Move the sunroof switch in any direc-
tion.Synchronizing the power tilt/sliding
sunroof
The tilt/sliding sunroof must be synchro-
nized

after the battery has been
disconnected or discharged


after the tilt/sliding sunroof has been
closed manually (
page 429)


after a malfunction


if the tilt/sliding sunroof does not open
smoothly

Remove the respective fuse from the
main fuse box (
page 461).

Reinsert the fuse in the main fuse box.

Switch on the ignition (
page 36).

Move and hold the sunroof switch in di-
rection of arrow3 until the tilt/sliding
sunroof is fully raised at the rear.
Keep holding the sunroof switch in di-
rection of arrow3 for approximately
1 second.

Check the Express-open feature
(page 237).
If the tilt/sliding sunroof opens com-
pletely, the roof is synchronized. Other-
wise repeat the above steps.
iIf the movement of the tilt/sliding sun-
roof is blocked during the
Express-close procedure, the tilt/slid-
ing sunroof will stop and reopen
slightly.

239 Controls in detail
Panorama roof with power tilt/sliding panel*
Panorama roof with power tilt/sliding panel*
Opening and closing the roller
sunblinds for the panorama roof with power tilt/sliding panel
The tilt/sliding panel and the front and
rear roller sunblinds are opened and
closed electrically. The switch for the
tilt/sliding panel and the roller sunblinds is
on the overhead control panel. An addi-
tional switch for the roller sunblinds is in
the rear passenger compartment.
The roller sunblinds only operate with the
tilt/sliding panel closed. The front and rear
roller sunblind cannot be operated individ-
ually.
Roof panel switch1Open roller sunblinds
2Close roller sunblinds
Roller sunblinds switch, rear 1Open roller sunblinds
2Close roller sunblinds
Switch on the ignition (
page 36).
Opening and closing the roller sun-
blinds

To open or close the roller sunblinds,
move the roof panel/roller sunblinds
switch to the resistance point in the re-
quired direction of arrow1 or2.
Release the roof panel/roller sunblinds
switch when the roller sunblinds have
reached the desired position.
