Page 321 of 521

MERCEDES-BENZ E350 2006 W211 Owners Manual 320 OperationEngine compartment
Closing
Let the hood drop from a height of ap-
proximately 1 ft (30 cm).
The hood will lock audibly.

Check to make sure the hood is fully
closed.
If you can raise

Page 322 of 521

MERCEDES-BENZ E350 2006 W211 Owners Manual 321 Operation
Engine compartment
Checking engine oil level with the con-
trol system
(E 320 CDI, E 500, E 55 AMG)
When checking the oil level
the vehicle must be parked on level
ground

with the e

Page 323 of 521

MERCEDES-BENZ E350 2006 W211 Owners Manual 322 OperationEngine compartment
If engine is at operating temperature,
wait 5 minutes before repeating check
procedure.

If engine is not at operating tempera-
ture yet, wait 30 minutes before
re

Page 324 of 521

MERCEDES-BENZ E350 2006 W211 Owners Manual 323 Operation
Engine compartment
1Oil dipstick
2Upper (max) mark
3Lower (min) mark
To check the engine oil level with the oil
dipstick, do the following:
Open the hood (
page 319).

Pull out oil d

Page 325 of 521

MERCEDES-BENZ E350 2006 W211 Owners Manual 324 OperationEngine compartmentE350
E500E320CDI

Unscrew filler cap1 from filler neck.

Add engine oil as required. Be careful
not to overfill with oil.
Be careful not to spill any oil when adding.

Page 326 of 521

MERCEDES-BENZ E350 2006 W211 Owners Manual 325 Operation
Engine compartment
Coolant level
The engine coolant is a mixture of water
and anticorrosion/antifreeze. To check
the coolant level, the vehicle must be
parked on level ground and the

Page 327 of 521

MERCEDES-BENZ E350 2006 W211 Owners Manual 326 OperationEngine compartmentBatteries
Your vehicle is equipped with two
batteries:
Main battery (located in the trunk).

Auxiliary battery (located in the engine
compartment).
These batteries s

Page 328 of 521

MERCEDES-BENZ E350 2006 W211 Owners Manual 327 Operation
Engine compartment
Windshield washer system and headlamp cleaning system*
The windshield washer reservoir is located
in the engine compartment.
1Washer fluid reservoir
Fluid for the win

Page 329 of 521

MERCEDES-BENZ E350 2006 W211 Owners Manual 328 OperationTires and wheelsSee an authorized Mercedes-Benz Center
for information on tested and recommend-
ed rims and tires for summer and winter
operation. They can also offer advice con-
cernin

Page 330 of 521

MERCEDES-BENZ E350 2006 W211 Owners Manual 329 Operation
Tires and wheels
Tire care and maintenance
Regularly check your tire inflation pressure
at least once a month. For more informa-
tion on checking tire inflation pressure,
see “Recomm
