420 Practical hintsWhat to do if …Display symbol
Display messages
Possible cause/consequence
Possible solution
@
Vehicle rising
Your vehicle is adjusting to your level se-
lection.
Vehicle rising
Please wait briefly
The vehicle level is too low.

Do not drive off.
The Airmatic* has not yet adjusted the ve-
hicle level to the necessary height re-
quired for driving.

Wait until the message disappears from
the multifunction display.
You may then drive off.
Stop, car too low
The Airmatic* is malfunctioning.
Avoid excessive steering input. The fender or
tires could otherwise be damaged. Listen for
scraping noises. Do not drive faster than
50 mph (80 km/h).
Drive to the side of the road and select a
higher vehicle level. Depending on the
type of malfunction, this may raise the ve-
hicle’s level.
There is otherwise danger of an accident.

421 Practical hints
What to do if …
Display symbol
Display messages
Possible cause
Possible solution
@
Visit workshop
The system is functional only to a limited
extent.
The system display or the system is mal-
functioning.

Do not drive faster than 50 mph
(80 km/h).

Have the vehicle checked at an autho-
rized Mercedes-Benz Center.
Display malfunction
Visit workshop
The system display or the system is mal-
functioning.

Do not drive faster than 50 mph
(80 km / h).

Have the vehicle checked at an autho-
rized Mercedes-Benz Center.

422 Practical hintsWhere will I find ...?First aid kit
The first aid kit is in the storage compart-
ment at the front edge of the front passen-
ger seat.
1Tab
Pull tab1 upward.

Fold the covering forward.

Remove the first aid kit.
Spare wheel
The spare wheel is located under the trunk
floor.
Lift the trunk floor and engage the han-
dle in the upper edge of trunk.

Remove the luggage box (
page 423).
1Vehicle tool kit
Wheel bolt wrench and jack
2Spare wheel
3Luggage bowlRemoving the spare wheel

Turn luggage bowl3 counterclock-
wise.

Remove spare wheel2.
Storing the spare wheel

Place spare wheel2 in wheel well.

Turn luggage bowl3 clockwise to its
stop to secure the spare wheel.
iCheck expiration dates and contents
for completeness at least once a year
and replace missing/expired items.
!Always lower trunk floor before closing
trunk.

423 Practical hints
Where will I find ...?
In case of a flat tire, you may temporarily
use the spare wheel when observing the
following restrictions:

Do not exceed a vehicle speed of
50 mph (80 km / h).


Drive to the nearest tire repair facility
to have the flat tire repaired or re-
placed as appropriate.


Do not operate vehicle with more than
one spare wheel mounted.
For more information, see “Spare wheel”
(
page 480).
Luggage box
Remove luggage box
1Fastening clip
2Luggage box
Turn fastening clips1 to the left up-
wards from fastening bolts.

Lift luggage box in the area of the fas-
tening bolts and remove it from trunk.Install luggage box

Insert luggage box into trunk so that
fastening clips are in line with fastening
bolts.

Push front edge of luggage box in direc-
tion of arrow under cover of trunk sill.

Press fastening clips onto fastening
bolts until they lock into place.
Warning!
G
The dimension of the Minispare wheel is dif-
ferent from those of the road wheels. As a
result, the vehicle handling characteristics
change when driving with a spare wheel
mounted.
The spare wheel should only be used tempo-
rarily, and replaced with a regular road
wheel as quickly as possible.

424 Practical hintsWhere will I find ...?Vehicle tool kit
The vehicle tool kit is stored in the com-
partment underneath the trunk floor
(page 422).
The vehicle tool kit includes:


One pair of universal pliers


One towing eye bolt


One wheel wrench


One alignment bolt


One fuse extractor


Spare fuses


Collapsible wheel chock


A pair of gloves
Setting up the collapsible wheel chock
The collapsible wheel chock serves to
additionally secure the vehicle, e.g. while
changing the wheel.1Tilt the plates upward
2Fold the lower plate outward
3Insert the plate

Tilt both plates upward1.

Fold the lower plate outward2.

Guide the tabs of the lower plate all the
way into the openings of the base
plate3.
Vehicle jackWarning!
G
The jack is designed exclusively for jacking
up the vehicle at the jack take-up brackets
built into both sides of the vehicle. To help
avoid personal injury, use the jack only to lift
the vehicle during a wheel change. Never
get beneath the vehicle while it is supported
by the jack. Keep hands and feet away from
the area under the lifted vehicle. Always
firmly set parking brake and block wheels
before raising vehicle with jack.
Do not disengage parking brake while the
vehicle is raised. Be certain that the jack is
always vertical (plumb line) when in use,
especially on hills. Always try to use the jack
on level surface. Make sure the jack arm is
fully seated in the jack take-up bracket.
Always lower the vehicle onto sufficient
capacity jackstands before working under
the vehicle.

425 Practical hints
Where will I find ...?
The vehicle jack is located in the storage
compartment underneath the trunk floor
(page 422).
Storage position
Remove vehicle jack from its
compartment.

Turn crank handle in direction of arrow
as far as it will go.
Operational position
Turn crank handle clockwise.
Before storing the vehicle jack in its
compartment:


It should be fully collapsed.


The handle must be folded in (storage
position).

426 Practical hintsUnlocking/locking in an emergencyUnlocking the vehicle
If you cannot unlock the vehicle with the
SmartKey or SmartKey with
KEYLESS-GO*, open the driver’s door and
the trunk using the mechanical key. Removing the mechanical key
1Mechanical key locking tab
2Mechanical key

Move locking tab1 in direction of ar-
row.

Slide mechanical key2 out of the
housing.Unlocking the driver’s door
1Unlocking

Insert the mechanical key into the
driver’s door lock until it stops.

Turn the mechanical key counterclock-
wise to position1.
The driver’s door is unlocked.
iUnlocking your vehicle with the me-
chanical key will trigger the anti-theft
alarm system. To cancel the alarm, do
one of the following:

Press button Œ or ‹ on the
SmartKey.


Insert the SmartKey in the starter
switch.
Vehicles with KEYLESS-GO*


Pull the outside door handle.


Press the KEYLESS-GO* start/stop
button.

427 Practical hints
Unlocking/locking in an emergency
Unlocking the trunk
A minimum height clearance of 5.90 ft
(1.80 m) is required to open the trunk lid.
The handle is located above the rear li-
cense plate recess.
1Unlocking in an emergency
2Handle
Insert the mechanical key into the
trunk lid lock until it stops.

Turn the mechanical key counterclock-
wise to position1 and hold it in this
position.

Pull the handle2 and lift the trunk lid.
The trunk opens.

Turn the mechanical key back and re-
move it from the trunk lid lock.
Locking the vehicle
If you are unable to lock the vehicle with
the SmartKey or SmartKey with
KEYLESS-GO*, do the following:
Close the passenger door, the rear
doors and the trunk.

Press the central locking switch in the
center console (
page 130).

Check to see whether the locking
knobs on the doors have moved down.

If necessary, push them down
manually.

Remove the mechanical key out of the
SmartKey (
page 426).

Check whether the trunk is locked.

If necessary, lock the trunk with the
mechanical key (
page 128).
Except for the driver’s door, the vehicle
should now be locked.
1Locking

Insert the mechanical key into the
driver’s door lock until it stops.

Turn the mechanical key clockwise to
position1.
The driver’s door is locked.
!Always make sure there is sufficient
overhead clearance.

428 Practical hintsUnlocking/locking in an emergencyFuel filler flap emergency release
In case the central locking system does
not release the fuel filler flap, you can open
it manually.
1Release knob
Open the trunk.

Remove right-side tail trim.

Turn release knob1 clockwise (ar-
row).
The fuel filler flap can know be opened.Manually unlocking the gear selector
lever
In case of power failure, the gear selector
lever can be manually unlocked, e.g. to tow
the vehicle.
1Pin
Open the storage compartment in the
center armrest (
page 279).

Take out the cup holder (
page 279).

Insert a suitable object1 (e.g. a pin)
through the hole and press the pin
downward.

Remove pin1.
iThe gear selector lever is locked again
when moving it to positionP.

429 Practical hints
Opening/closing in an emergency
Opening/closing in an emergency
Power tilt/sliding sunroof* or panora-ma roof with power tilt/sliding panel*
You can open or close the tilt/sliding sun-
roof or tilt/sliding panel manually should
an electrical malfunction occur.
The tilt/sliding sunroof or tilt/sliding panel
drive is located behind cover1 of the in-
terior overhead light.
1Cover
Remove the SmartKey from the starter
switch.

Press on cover1 in direction of the ar-
row to release it.2Hole
3Crank

Take crank3 out of the glove box.

Insert crank3 through hole2.

Turn crank3 clockwise to:

slide roof panel/sunroof closed


raise roof panel/sunroof at the rear

Turn crank3 counterclockwise to:

slide roof panel/sunroof open


lower roof panel/sunroof at the
rear
iTurn crank3 slowly and smoothly.
The tilt/sliding sunroof or tilt/sliding
panel must be synchronized after being
operated manually (
page 238) or
(
page 242).
