MERCEDES-BENZ E500 2003 W211 Owner's Manual

191 Controls in detail
Panorama sliding/pop-up roof*
Roller sunblind switch, rear 1Open
2Close
Make sure that the ignition is turned on
or press the KEYLESS-GO start/stop
button*.

Press the switch in the desired direc-
tion.
The sun roller sunblinds open.

Release the switch when the roller sun-
blinds have reached the desired posi-
tion.Opening the roller sunblinds automati-
cally

Press the switch past the resistance
point in direction1 and release it
again.
The roller sunblinds open completely.
Stopping the roller sunblinds

Press the switch again in any direction.Opening and closing the panorama slid-
ing/pop-up roof
1Push back to slide roof open
2Push forward to slide roof closed
3Push back to raise roof
4Push forward to lower roof

Make sure that the ignition is turned on
or press the KEYLESS-GO start/stop
button*.

Push the switch to the resistance point
in the required direction.
The panorama sliding/pop-up roof
opens.
Warning!
G
When closing the roller sunblinds, make
sure that no one is in danger of being injured
by the closing procedure.

192 Controls in detailPanorama sliding/pop-up roof*
Release the switch once the roof has
reached the desired position.
Opening and closing the panorama slid-
ing/pop-up roof automatically

Press the switch past the resistance
point in the desired direction.
The panorama sliding/pop-up roof
opens completely.
Stopping the panorama sliding/pop-up
roof

Press the switch again in any direction.Opening and closing windows and pan-
orama sliding/pop-up roof with the
SmartKey
The power windows will also be opened or
closed when the panorama sliding/pop-up
roof is operated with the key (
page 185).

Aim transmitter eye at the front door
handle.Opening (Summer opening feature)
If roller blinds are closed:

Press and hold buttonΠafter un-
locking the vehicle.
The windows and roller blinds begin to
open after approximately one second.

Press and hold buttonŒagain.
The panorama sliding/pop-up roof tilts
and opens.
If roller blinds are already open:

Press and hold buttonΠafter un-
locking the vehicle.
The windows move down and the pan-
orama sliding/pop-up roof tilts and
opens after approximately one second.

Release transmit button to interrupt
procedure.
!Do not transport any objects that pro-
trude out of the panorama slid-
ing/pop-up roof as the seals could be
damaged.
Warning!
G
Never operate the windows or slid-
ing/pop-up roof if there is the possibility of
anyone being harmed by the opening or
closing procedure.
In case the procedure causes potential dan-
ger, the procedure can be immediately halt-
ed by releasing the remote control button.
To reverse direction of movement
pressŒ for opening or ‹ for closing.

193 Controls in detail
Panorama sliding/pop-up roof*
Closing (Convenience feature)
Press and hold button‹ after lock-
ing the vehicle.
The windows and panorama slid-
ing/pop-up roof begin to close after
approximately one second.

Press and hold buttonΠagain.
The roller blinds close.

Release transmit button to interrupt
procedure.
Ensure that all side windows and the pan-
orama sliding/pop-up roof are properly
closed before leaving the vehicle.Synchronizing the panorama slid-
ing/pop-up roof
It is necessary to resynchronize the pan-
orama sliding/pop-up roof after:


voltage supply interruption due to a
disconnected or discharged battery


the roof has been closed manually


the roof has been opened with an
abrupt movement


a malfunction

Remove the fuse from the main fuse
box.

Replace the fuse in the main fuse box.

Turn the ignition on.

Press the switch in direction 3.

Wait until the panorama sliding/pop-up
roof is raised and then keep the switch
pressed for approximately 1 second.
Solar panel*
Combined with the panorama slid-
ing/pop-up roof a solar panel is available.
The solar cells convert natural light into
electrical energy. When the engine is
switched off, the energy generated auto-
matically switches on the ventilation fan.
The constant air flow creates a cooler tem-
perature for cars parked in the sunlight.
The air flow depends on the intensity of the
solar radiation. The ventilation starts 2
minutes after switching off the engine.

194 Controls in detailDriving systems
Driving systemsThe following driving systems are ex-
plained on the following pages:

Cruise control


Distronic*


AIRMATIC DC*


Park assist (Parktronic*)
The BAS, ABS, ESP and SBC driving sys-
tems are described in the "Safety and Se-
curity" section (
page 73).
Cruise control
Cruise control automatically maintains the
speed you set for your vehicle.
Use of cruise control is recommended for
driving at a constant speed for extended
periods of time. You can set any speed
over 20 mph (30 km/h).
The cruise control function is operated by
means of the cruise control lever.
The cruise control lever is the uppermost
lever found on the left-hand side of the
steering column (
page 20).
Warning!
G
Cruise control is a convenience system de-
signed to assist the driver during vehicle op-
eration. The driver must always remain
responsible for the vehicle speed and for
safe brake operation.
Only use cruise control if the traffic and
weather conditions make it advisable to
travel at a steady speed.

The use of cruise control can be danger-
ous on winding roads or in heavy traffic
because conditions do not allow safe
driving at a steady speed.


The use of cruise control can be danger-
ous on slippery roads. Rapid changes in
tire traction can result in wheel spin and
loss of control.


Deactivate cruise control when driving
in fog.
The "Resume" function should only be oper-
ated if the driver is fully aware of the previ-
ously set speed and wishes to resume this
particular preset speed.

195 Controls in detail
Driving systems
1Set current or higher speed
2Set current or lower speed
3Cancel cruise control
4Resume at previously set speed
Saving current speed
Accelerate or decelerate to the desired
speed.

Briefly lift1 or depress2 the cruise
control lever.
The current speed is set.

Remove your foot from the accelerator
pedal.
Cruise control is activated.Canceling cruise control
There are several ways to cancel cruise
control:

Step on the brake pedal.
or

Briefly push the cruise control lever to
position3.
Cruise control will be canceled. The
last speed set will be stored for later
use.iOn uphill or downhill grades, cruise
control may not be able to maintain the
set speed. Once the grade eases, the
set speed will be resumed.
!Vehicles with automatic transmission:
Moving gear selector lever to
positionN while driving also cancels
cruise control. However, the gear se-
lector lever should not be moved to
positionN while driving except to coast
when the vehicle is in danger of skid-
ding (e.g. on icy roads).iVehicles with manual transmission:
The set cruise controlled speed is
switched off when declutching exceeds
four seconds during downshifting a
gear.iThe last stored speed is canceled when
you turn off the engine.

196 Controls in detailDriving systemsSetting stored speed ("Resume"
function)
Briefly push the cruise control lever to
position4.
The cruise control will resume the last
previously set speed.

Remove your foot from the accelerator
pedal.Setting a higher speed

Lift the cruise control lever to
position1 and hold it up until the de-
sired speed is reached.

Release the cruise control lever.
The new speed is set.
Setting a lower speed

Depress the cruise control lever to
position2 and hold it down until the
desired speed is reached.

Release the cruise control lever.
The new speed is set.Fine adjustment in 0.6 mph (1 km/h)
increments
Faster

Briefly tip the cruise control lever in the
direction of arrow1.
Slower

Briefly tip the cruise control lever in the
direction of arrow2.
Warning!
G
The speed stored in memory should only be
set again if prevailing road conditions per-
mit. Possible acceleration or deceleration
differences arising from returning to preset
speed could endanger yourself and others.
iDepressing the accelerator pedal does
not deactivate cruise control. After
brief acceleration (e.g. for passing),
cruise control will resume the last
speed set.
iVehicles with automatic transmission:
When you use the cruise control lever
to decelerate, the transmission will au-
tomatically downshift if the engine’s
braking power does not brake the vehi-
cle sufficiently.

197 Controls in detail
Driving systems
Distronic*
When activated, the Distronic adaptive
cruise control system increases driving
convenience afforded by the cruise control
during travel on expressways and other
major roads.

If the Distronic distance sensor detects
a slower moving vehicle directly ahead,
your vehicle speed will be reduced so
that you follow that vehicle at a preset
distance.


If there is no vehicle directly ahead of
you, Distronic will function in the same
way as cruise control (
page 201).
Warning!
G
Distronic adaptive cruise control is no sub-
stitute for active driving involvement. It does
not react to stationary objects, nor recog-
nize or predict the curvature and lane layout
or the movement of vehicles ahead. Distron-
ic can only apply a maximum of 20% of the
vehicle’s braking power.
It is the driver’s responsibility at all times to
be attentive to traffic and road conditions
and to provide the steering, braking and oth-
er driving inputs necessary to retain control
of the vehicle.Warning!
G
Distronic is a convenience system. Its speed
adjustment reduction capability is intended
to make cruise control more effective and
usable when traffic speeds vary. However, it
is not intended to, nor does it, replace the
need for extreme care. The responsibility for
the vehicle speed and the distance to the ve-
hicle ahead, including most importantly
brake operation to assure safe stopping dis-
tance, always rests with the driver.
Distronic cannot take street and traffic con-
ditions into account.
Warning!
G
Distronic requires familiarity with its opera-
tional characteristics. We strongly recom-
mend that you review the following
information carefully before operating the
system.iFor operation in the USA only: This de-
vice complies with Part 15 of the
FCC Rules. Operation is subject to the
following two conditions:

This device may not cause harmful
interference, and


this device must accept any inter-
ference received, including interfer-
ence that may cause undesired
operation.
Any unauthorized modification to this
device could void the user’s authority
to operate the equipment.

198 Controls in detailDriving systemsWarning!
G
Distronic cannot take street and traffic con-
ditions into account. Only use Distronic if
the weather and traffic conditions make it
advisable to travel at a steady speed.Warning!
G
Use of Distronic can be dangerous on slip-
pery roads. Rapid changes in tire traction
can result in wheel spin and loss of control.
Distronic does not act upon adverse sight
distance conditions. Do not use Distronic
during conditions of fog and heavy rain,
snow or sleet.
Warning!
G
Close attention to road and traffic condi-
tions is imperative at all times, regardless of
whether or not Distronic is activated.
Use of Distronic can be dangerous on wind-
ing roads or in heavy traffic because condi-
tions do not allow safe driving at a steady
speed.
Distronic will not react to stationary objects
in the roadway (e.g. a stopped vehicle in a
traffic jam or a disabled vehicle). Distronic
will also not respond to oncoming vehicles.
Switch off Distronic:

when changing from the left to the right
lane if vehicles are moving more slowly
in the left lane


when entering a turn lane or highway off
ramp


in complex driving situations, such as in
highway construction zones
In these situations, Distronic will continue to
maintain the set speed unless deactivated.
Distronic is designed and intended only to
maintain a set speed and keep a set dis-
tance from moving objects in front of it.Warning!
G
The "Resume" function should only be oper-
ated if the driver is fully aware of the previ-
ously set speed and wishes to resume this
particular preset speed.

199 Controls in detail
Driving systems
Distronic displays in the speedometer
dial
1Set speed
If Distronic is activated, one or two seg-
ments light up around the set speed.1Segments
If Distronic detects a vehicle directly
ahead, the segments from the speed of the
vehicle ahead to the set speed light up.
If Distronic calculates that there is a dan-
ger of collision:


The DTR warning lampl in the in-
strument cluster lights up red.


An intermittent warning sounds.

Immediately brake the vehicle to avoid
a collision.Under no circumstances should the
driver await the intermittent warning
sound before braking. See warning
note on the next page.
The intermittent warning sound ceases
and the red DTR warning lampl
goes out when the necessary distance
to the vehicle ahead is again estab-
lished.
iThe vehicle speed displayed on the
speedometer can briefly vary from the
speed setting on the Distronic system.

200 Controls in detailDriving systems
Distronic menu in the control system
In the Distronic menu you can read the cur-
rent settings for Distronic. What appears in
the display depends on whether Distronic
and the distance warning function are
turned on or off.
Press buttonè orÿ repeatedly
until you see one of the following dis-
plays.
Warning!
G
An intermittent warning sounds and the
DTR warning lamp in the instrument cluster
is illuminated if the Distronic system calcu-
lates that the distance to the vehicle ahead
and your vehicle’s current speed indicate
that Distronic will not be capable of slowing
the vehicle sufficiently to maintain the pre-
set following distance, which creates a dan-
ger of a collision.
Immediately brake the vehicle to increase
the distance to the vehicle in front of you.
The warning sound is intended as a final cau-
tion that you have not interceded with your
own braking inputs to avoid a potentially
dangerous situation. Do not wait for the op-
eration of the warning signal to intercede
with your own braking, as that will result in
potentially dangerous emergency braking
which will not always result in an impact be-
ing avoided.
Tailgating increases the risk of an accident.
Warning!
G
Distronic brakes your vehicle with a maxi-
mum deceleration of 6.5 ft/s
2 (2 m/s
2).
This corresponds to about 20% of the maxi-
mum deceleration ability of your vehicle.
Distronic brakes the vehicle in an effort to
restore the preset distance or to maintain
the speed. The brake pedal is automatically
applied as this happens which results in the
brake pedal moving.
Keep driver’s foot area clear at all times, in-
cluding the area under the brake pedal. Ob-
jects stored in this area may impair pedal
movement which could interfere with the
braking ability of the Distronic system.
Do not place your foot under the brake pedal
– your foot could become caught.
