MERCEDES-BENZ E500 2003 W211 Owner's Manual

221 Controls in detail
Loading
Returning seat backrest to original po-
sition
1Seat cushion
2Seat backrest
Swing seat backrest2 to the rear until
it engages.

Swing seat cushion1 to the rear and
press the center front of the cushion
until it audibly engages.

Swing the head restraint forward by
hand until it engages.
Warning!
G
Always lock backrest in its upright position
when rear seat bench is occupied, or the ex-
tended trunk compartment is not in use.
Check for secure locking by pushing and
pulling on the backrest.
In an accident, during hard braking or sud-
den maneuvers, loose items will be thrown
around inside the vehicle, and cause injury
to vehicle occupants unless the items are
securely fastened in the vehicle.
To help avoid personal injury during a colli-
sion or sudden maneuver, exercise care
when transporting cargo.

222 Controls in detailLoadingFolding front passenger seat*
Folding front passenger seat forward
1Release handle
Press the right-hand side of release
handle1.
The handle folds out.

Pull the left-hand side of the release
handle.
The front passenger seat backrest is
released and can be folded forward.

Fold the backrest all the way forward.

Press the backrest lightly downward
until it is resting on the seat cushion.Folding front passenger seat back
1Release handle

Using release handle1, pull the back-
rest to its original position. Pull the
handle until the backrest has reached
an angle of approximatley 45°.
Warning!
G
Make sure that the backrest engages and
locks when folding it back into place.

223 Controls in detail
Loading
Expanding the cargo area*
Removing the rear seat cushions will pro-
vide you with a larger, flat cargo area.
Fold the seat cushions and the back-
rests forward.

Remove the head restraints.
(Raise the seat backrest and fold the
head restraints forward.)
1Release catch

Press head restraint release catch1
and pull the head restraints out of the
guides.

Fold the backrest into the vertical posi-
tion.
1Release lever

Pull seat cushion release lever1 and
remove the seat cushion by pulling it
upward.
!Leave the seat cushion hinge in this po-
sition. The upholstery could be dam-
aged if you fold the hinge back.

224 Controls in detailLoadingLoading instructions
The total load weight including vehicle oc-
cupants and luggage/cargo should not ex-
ceed the vehicle capacity weight indicated
on the certification tag which can be found
on the left door pillar.The handling characteristics of a fully load-
ed vehicle depend greatly on the load dis-
tribution. It is therefore recommended to
load the vehicle according to the illustra-
tions shown, with the heaviest items being
placed towards the front of the vehicle.
Always place items being carried against
front or rear seat backrests, and fasten
them as securely as possible.
The heaviest portion of the cargo should al-
ways be kept as low as possible since it in-
fluences the handling characteristics of
the vehicle.
Warning!
G
Always fasten items being carried as secure-
ly as possible.
In an accident, during hard braking or sud-
den maneuvers, loose items will be thrown
around inside the vehicle and can cause in-
jury to vehicle occupants unless the items
are securely fastened in the vehicle.
To help avoid personal injury during a colli-
sion or sudden maneuver, exercise care
when transporting cargo. Put luggage or car-
go in the trunk if possible. Do not pile lug-
gage or cargo higher than the seat backs.
Do not place anything on the shelf below the
rear windows.
Never drive vehicle with trunk open. Deadly
carbon monoxide (CO) gases may enter ve-
hicle interior resulting in unconsciousness
and death.

225 Controls in detail
Loading
Cargo tie-down rings*
Four rings1 are located in the cargo com-
partment.
Carefully secure cargo by applying
even load on all rings with rope of suffi-
cient strength to hold down the cargo.
Always follow loading instructions
(page 224).Rear seat
There is a cargo tie-down ring located on
each side of the footwell under the rear
seat.

226 Controls in detailUseful features
Useful featuresInterior storage spaces Parcel net in front passenger footwell
A small convenience parcel net is located
in the front passenger footwell. It is for
small and light items, such as road maps,
mail, etc.Glove box
1Glove box lid release
2Compartment for mobile phone/glass-
es
Opening the glove box

Push lid release1.
The glove box lid opens downward.
Closing the glove box

Push lid up to close.
Warning!
G
To help avoid personal injury during a colli-
sion or sudden maneuver, exercise care
when stowing objects in the vehicle. Put lug-
gage or cargo in the trunk if possible. Do not
pile luggage or cargo higher than the seat
backs. Do not place anything on the shelf
below the rear window.
Luggage nets cannot secure hard or heavy
objects.
Keep compartment lids closed. This will help
to prevent stored objects from being thrown
about and injuring vehicle occupants during
an accident.
Warning!
G
The parcel net is intended for storing
light-weight items only.
Heavy objects, objects with sharp edges or
fragile objects may not be transported in the
parcel net.
The parcel net cannot protect transported
goods in the event of an accident.

227 Controls in detail
Useful features
Storage compartment in the center
console
1Opening/closing button
Press button1 to open.The control panel swings out upward
and the storage compartment extends
out.

Press button1 to close.
Storage compartment in front of the
armrestOpening

Briefly press the marking in the back of
the cover.
The cover opens.
Cup holder in the center console

Briefly press marking on the cup hold-
er.
The cup holder extends automatically.
iPrior to closing the glove box, close the
compartment for glasses first.iThe storage compartment in the center
console cannot be opened if the cas-
sette tray is open.
iNever place any medications in the
storage compartment. If there is a pow-
er failure, the storage compartment
cannot be opened.

228 Controls in detailUseful features1Left cup holder
2Right cup holderStorage space under armrest
1Storage compartment
2Storage tray
Opening storage tray

Pull handle2.
Opening storage compartment

Pull handle1.
iThe cup holder can be removed for
cleaning. Clean the cup holder only
with clear, lukewarm water.
Make sure to insert the cup holder in
the guides when reinstalling it.
Warning!
G
When not in use, keep the cup holder closed
while traveling. Place only containers that fit
into the cup holder to prevent spills. Use lids
on open containers and do not fill containers
to a height where the contents, especially
hot liquids, could spill during vehicle maneu-
vers.

229 Controls in detail
Useful features
Front center console storage compart-
ment ventilation
The front center console storage compart-
ment under the armrest has its own air out-
let. The air temperature is about the same
as that of the dashboard air outlets.
The lever is located in the front center out-
let.
1Lever
To open air outlet slide the lever up.

To close air outlet slide the lever down.Storage compartment in the rear cen-
ter console

Briefly press the top of the compart-
ment.
It extends automatically.
iThe compartment can get very warm
due to its confined space. When storing
heat sensitive objects (e.g. groceries)
in the compartment, close the air outlet
while heating the passenger compart-
ment

230 Controls in detailUseful featuresRuffled storage bags
Ruffled storage bags are located on the
back of the front seats.Storage compartment in the rear arm-
rest

Press the handle upward and fold the
armrest up.Rear cup holder

Briefly press the front of the center
armrest.
The cup holder extends automatically.
Warning!
G
Do not transport hard objects in the storage
bags.
Warning!
G
When not in use, keep the cup holder closed
while traveling. Place only containers that fit
into the cup holder to prevent spills. Use lids
on open containers and do not fill containers
to a height where the contents, especially
hot liquids, could spill during vehicle maneu-
vers.
