46 Audio
Radio operation
Automatic seek tuning
Press g or h.
or
Push the joystick to gor G.
or
Press j or k at the
multifunction steering wheel
The radio will tune in to the next
receivable station (FM, AM) or channel
(WB) with descending/ascending
frequency depending on the direction
of seek.
WB direct channel selection
Press a number key 1 through 7.Manual tuning (FM, AM)
Activate the desired wave band
(
page 44).
Press g or h longer than 2 se-
conds.
The function rapidly scans the
frequencies.
Press g or h repeatedly to
change the frequency step by step.
or
Push the joystick to H or h.
Each push of the joystick will change
the frequency by one step.
FM Band
The frequency displayed will change in in-
crements of 0.2 MHz.
AM Band
Tuning will take place in increments of
10 kHz.Station selection via direct frequency
entry (FM, AM)
E.g.: 102.7 MHz in the FM band
Activate the desired wave band
(
page 44).
Press *.
An input line will appear.
i
The selected channel is not shown in
the status line.

52 Audio
CD operation
Avoid touching the CD surface with
your fingers.
Clean the CD with a dry, lint-free cloth.
Wipe them from the inside to the outer
edge. Never wipe the CD in a circular
motion.
Do not use rubbing alcohol or solvents
to clean the CDs.
Do not expose the CDs to heat or direct
sunlight.
Do not write or put stickers on CD.Loading a CD into the CD drive
Tips on caring for your CDsLoading a CD
WarningG
In order to avoid distraction which could
lead to an accident, the driver should insert
CDs with the vehicle at a standstill and
operate the audio system only if permitted
by road, weather and traffic conditions.
Bear in mind that at a speed of just 30 mph
(approximately 50 km/h), your car covers a
distance of 44 feet (approximately 14 m)
every second.
i
There are two l buttons. One is on
the display unit. The other is located
left of the CD AUDIO slot behind the
display, see next page.
i
The CD drive can acommodate either
audio or MP3 CDs (
page 65).

54 Audio
CD operation
1Ejecting audio CD
2Opening/closing the display unit
3Warning message
Press EJECT to
close
With the COMAND switched on, press
l.
The display unit moves forward and
then tilts down. The CD AUDIO slot is
visible.
Press the l button left of the
CD AUDIO slot to eject a CD already
loaded.
Remove the CD from the slot.
Insert a CD into the slot. The CD should
be inserted with the label side up.
The COMAND pulls the CD in.
Press l on the display unit to return
the display unit to its closed position.
The display unit tilts up and then moves
to the rear.
Playback begins with track number
one.
The message
CD error will appear if
there is a media error.
Remove the CD or switch to
another operation.
WarningG
The display unit can cause injury if
contacted when open. Please close after
inserting an audio CD.
!
Do not place anything on the lowered
display panel (i.e. do not attempt to use
as a shelf). Placing objects on the
lowered display panel may result in
damage to the display or COMAND
unit which is not covered by the
Mercedes-Benz Limited Warranty.
i
Inserting a second CD with another CD
still loaded will cause damage to the
CD drive which is not covered by the
Mercedes-Benz Limited Warranty.
i
The message Press EJECT to close will
appear. If l on the display unit is
not pressed within 20 seconds, eight
successive series of two beep tones
will sound to remind you to return the
display to its closed position by
pressing l on the display unit. After
the beep tones COMAND returns the
display unit to its closed position.

57 Audio
CD operation

CD operation
Playback locations for audio CDs are:
the CD drive in the COMAND
the CD changer.
CD drive
CD changer
In the Audio menu (page 42), press
the
CD or theCD soft key.
CD changer main menu
1CD number or name of the CD currently
playing
2Track number or name of the track
currently playing
3CD - CD changer
CD - CD drive
Actual track number/max. track
number on CD and elapsed playback
time
4Symbol for inserted CD
Switching to CD operation
i
The CD drive is located behind the
display unit (
page 53).
i
The CD changer can accomodate up to
6 audio or MP3 CDs. The CD changer is
located in the rear cargo compartment.
If a CD changer is connected to the
COMAND, the
CD soft key is
available.
i
The Magaz. soft key is only assigned
when the CD changer is active.
If the CD changer has already read the
magazine, the Magazine menu will
appear (
page 60) when you press the
Magaz. soft key.
Otherwise the message
Magazine scan
Please wait
will appear first.

58 Audio
CD operation
CD drive
Activate the Audio menu (page 42).
Press the CD soft key.
The CD main menu is displayed.
If no audio CD has been inserted, the
message
No CD inserted will appear.
Load an audio CD into the CD drive
(
page 52).
CD main menu
CD changer
Activate the Audio menu (page 42).
Press the CD soft key.
The CD changer main menu will
appear. The CD last played is played
back.
CD changer main menu
If the last played CD is not available, the
next available audio CD or MP3 CD is
played back.
No CD in the magazine:
The message
Magazine empty will appear.
Load audio or MP3 CDs into the CD
changer (
page 55).
Switching oni
The name of the CD and the name of
the track played are displayed if the
information is available.
i
The CD soft key is available if a CD
changer is connected to the COMAND.
i
The name of the CD and the name of
the track played are displayed if the
information is available.

59 Audio
CD operation
You can select an audio or MP3 CD:
in the CD list (page 59)
with the number keypad (page 59)
in the magazine menu (page 60)
In the CD list
The CD list includes all loaded CDs. Only
one list entry is visible at a time.
The entry is displayed above the track
indication. It shows the number of the CD
currently playing.
Push the joystick to H or h to
select another CD from the list.
or
Press j or k at the
multifunction steering wheel.
Loading CD is displayed.
After the CD is loaded, playback
begins. With the number keypad
Press a number key, e.g. 2 to select
the corresponding CD.
Loading CD 2 is displayed.
The CD is changed. The selected CD is
played back.
The message
No CD will
appear if a selected slot is empty.
Selecting a CD
i
Selection is possible if the
CD changer has loaded the magazine
(COMAND knows the position of filled
and empty slots) and at least two audio
or MP3 CDs are loaded.
i
The number keys 1 - 6 can be used
for direct selection.
Keys
1 - 6 magazine slots 1 to 6
of the CD changer

60 Audio
CD operation
In the Magazine menu
Press the Magaz. soft key.
The Magazine menu is displayed. If the
magazine has not been read in, the
message
Magazine scan
Please wait
is displayed first.
Push the joystick to g or G to
select a CD.
Press E.
or
Press one of the number keys 1 to
6.
The CD is changed. The message
Loading CD will appear.
You can select a track:
with g or h (page 60)
with the joystick (page 60)
with the number keypad (page 61)
with CD track scan (page 61)
With g or h
Activate the main CD menu
(
page 57).Next track
Press h.
The next track is played.
Previous track or start of title (if more
than 10 seconds of playing time has
elapsed)
Press g.
Playback begins.
Select any desired track
Press g or h as many times as
necessary.
With the joystick
Push the joystick to g or G to play
the next or previous track.
With the multifunction steering wheel
Press j or k at the
multifunction steering wheel.
i
The name of the CD instead of e.g. CD1
is displayed if the information is
available.
Track select

61 Audio
CD operation
With the number keypad
Activate the CD main menu
(
page 58).
Press *.
An input line will appear in the CD main
menu.
1Number of tracks on CD corresponds
with the valid number range
2Input line
E.g.: Track 14.
Press 1 and 4 in short succession.
After entering the track number, wait
approximately 3 seconds.
The selected track is played. The CD
main menu is displayed.
CD track scan
The tracks on a CD can be scanned one
after the other for 8 seconds each. The
function will switch off automatically when
the starting track is reached. You can also
manually stop the scan function.Activating
Press the Scan soft key.
Scan will begin.
i
Entries higher than the number of
tracks available on the CD are not
possible.
During MP3 playback
CD drive:
You can select the tracks of the
current folder (
page 72).
CD changer:
You can select the first 99 tracks of
a MP3 CD.
i
When you start the scan function, the
playback mode
Normal sequence
(
page 63) is automatically activated.

62 Audio
CD operation
Ending the function
Scan search is running.
Press the Scan soft key.
or
Press E.
Playback will resume with the desired
track.
View track detail
At any time during playback an expanded
view of a track title can be displayed in the
CD main menu via a separate window.
Press the Detail soft key.
To cancel
Press the Detail soft key again.
or
The window will automatically disappear in
approx. 5 seconds.Fast forward
Press and hold h for more than
2 seconds.
Fast reverse
Press and hold g for more than
2 seconds.
Ending the function
Release h or g.
Playback will resume.
On
Press J during playback.
The CD operation is muted and theß
symbol is displayed in the status bar.
The soft keys on the left side are
greyed out in some submenus.Off
Press J again.
Playback will resume.
The ß disappears from the status bar.
The soft keys on the left side are
selectable again.
Fast forward/reverse
Muting
i
COMAND will also deactivate if you
Press A, B, g, h
Change the volume at COMAND or
the multifunction steering wheel
Operate the joystick
Press any keypad button except #
Press j or k at the
multifunction steering wheel if the
audio menu is selected
Press any soft key.

63 Audio
CD operation
The following options are available:
Normal sequence (page 63)
Track mix (page 63)
CD mix (page 63)
Repeat track (page 64)
Repeat CD (page 64)
Activating playback mode
E.g.:
Mode
Repeat track
Press the Setting soft key.
The setting menu will appear.
CD changer setting menu
Push the joystick to g or G to
select the playback mode
Repeat
track
.
Press E.
The mode is activated. The CD changer
main menu will then appear.
REPEAT
TRACK
will appear in the status bar.Explanation of the playback modes
Normal sequence
Tracks are played in ascending order
(e.g. 1, 2, 3 and so on). If just one CD is
inserted, the first track is played when
the last one is over.
If more than one CD is available, the
first track of the next CD is played
when the last track of the current CD is
over. The CDs are changed in normal
order.
Track mix
Tracks are played in random order. If
more than one CD is available, the next
available CD is played when the current
CD is over. The CDs are changed in
normal order.
CD mix (CD changer only)
At least 4 tracks of any CD are played
in random order. Then follows the next
available CD. The CDs are changed in
random order.

Playback mode
i
If the CD changer is connected, the
playback modes
Repeat CD and
CD mix are available additionally.
i
The playback mode Normal sequence is
not displayed in the status bar.
