MERCEDES-BENZ GL320CDI 2007 X164 Owner's Manual

320 Controls in detail
Useful features
Parcel nets Parcel net in front passenger footwell
A small convenience parcel net is located
in the front passenger footwell. It is intend-
ed for small and light items, such as road
maps, mail, etc.
1Parcel netParcel nets on front seat backrests
A small convenience parcel net is located
on each of the front seat backrests. It is in-
tended for small and light items, such as
road maps, mail, etc.
1Parcel net
Warning!G
Do not place objects with a combined
weight of more than 4.4 lb (2 kg) into the
parcel net on the back of the front passen-
ger seat. Otherwise, the Occupant Classifi-
cation System* OCS (
page 81) may not
be able to properly approximate the occu-
pant weight category.
Parcel nets are intended for storing
light-weight items only.
Heavy objects, objects with sharp edges or
fragile objects may not be transported in the
parcel nets. In an accident, during hard
braking, or sudden maneuvers, they could
be thrown around inside the vehicle and
cause injury to vehicle occupants.
Parcel nets cannot protect transported
goods in the event of an accident.

321 Controls in detail
Useful features
Cup holders
Cup holder in front of armrest
A cup holder and a card/ticket holder are
located in the front center console.
1Cup holderCup holder in rear armrest (second-row
seats)
1Cup holder
Pull the armrest down by its top.
Warning!G
In order to help prevent spilling liquids on
vehicle occupants and/or vehicle equip-
ment, only use containers that fit into the
cup holder. Use lids on open containers and
do not fill containers to a height where the
contents, especially hot liquids, could spill
during braking, vehicle maneuvers, or an
accident. Liquids spilled on vehicle occu-
pants may cause serious personal injury.
Liquids spilled on vehicle equipment may
cause damage not covered by the
Mercedes-Benz Limited Warranty.
When not in use, keep rear cup holder
closed. An open cup holder may cause injury
to you or others when contacted during
braking, vehicle maneuvers, or in an acci-
dent.
Keep in mind that objects placed in a cup
holder may come loose during braking,
vehicle maneuvers, or an accident and be
thrown around in the vehicle interior.
Objects thrown around in the vehicle interi-
or may cause an accident and/or serious
personal injury.
iThe front cup holder can be removed for
cleaning purposes (
page 322).
!Close the cup holder before folding the arm-
rest upwards.

322 Controls in detail
Useful features
Cup holders in third-row side trim
Cup holders are located in the side trims of
the third-row seats.
1Cup holderRemoving and reinstalling cup holder
The front cup holder can be removed for
cleaning purposes.
1Cup holder
2Bridge with card, ticket holder
Hold cup holder at its bridge2 and
pull out bridge in direction of arrow.
Pull cup holder1 out in direction of ar-
row.
First, insert the cup holder1 and then
insert bridge2.
Ashtrays*
Your vehicle is equipped with an ashtray
and a cigarette lighter (
page 324) locat-
ed in the front center console and an ash-
tray located in front of the second-row
seats (
page 323).
Ashtray in the center console
1Ashtray insert
2Cover plate
iIf your vehicle is not equipped with a smok-
ing package*, it has a storage compartment
(
page 318) with a power outlet (page 325)
instead.

323 Controls in detail
Useful features
Opening the ashtray
Briefly touch cover plate2.
The ashtray opens automatically.
Removing ashtray insert
Grip the ashtray insert1 on the sides
and pull it out upwards.
Reinstalling ashtray insert
Install ashtray insert1.
Close ashtray cover plate2.Rear center console ashtray
(second-row)
1Ashtray
2Ashtray coverOpening rear ashtray
Briefly press ashtray cover2.
The ashtray1 opens automatically.
Removing rear ashtray insert
Grip the insert on the sides and pull it
out upwards.
Reinstalling rear ashtray insert
Install ashtray insert.
Close the ashtray.
Cigarette lighter
Switch on the ignition (page 42).
Push in cigarette lighter.
The cigarette lighter will pop out auto-
matically when hot.
Warning!G
Remove ashtray only with vehicle standing
still. Set the parking brake to secure vehicle
from movement. Set automatic transmis-
sion toP. With the automatic transmission
set toP, turn off the engine.
!Close the ashtray when not in use and be-
fore folding the second-row seats

324 Controls in detail
Useful features
Cigarette lighter*
Switch on the ignition (page 42).1Cigarette lighter
Open the ashtray (page 323).
Push in cigarette lighter1.
The cigarette lighter will pop out auto-
matically when hot.
Warning!G
Never touch the heating element or sides of
the cigarette lighter; they are extremely hot.
Hold the knob only.
Make sure that any children traveling with
you do not injure themselves or start a fire
with the hot cigarette lighter.
When leaving the vehicle always remove the
SmartKey or SmartKey with KEYLESS-GO*
from the starter switch, take it with you, and
lock the vehicle. Do not leave children unat-
tended in the vehicle, or with access to an
unlocked vehicle. A child’s unsupervised
access to a vehicle could result in an
accident and/or serious personal injury.
!The lighter socket can accommodate
12V DC electrical accessories (up to a maximum
of 180 W) designed for use with the standard
“cigarette lighter” plug type. Keep in mind, how-
ever, that connecting accessories to the lighter
socket (for example extensive connecting and
disconnecting, or using plugs that do not fit prop-
erly) can damage the lighter socket. With the
socket damaged, the lighter may no longer be
able to be placed in the heating (pushed-in) posi-
tion, or the lighter may pop out too early with the
lighter not hot enough.
To help avoid damaging the cigarette lighter
socket, we recommend connecting 12V DC elec-
trical accessories designed for use with the stan-
dard “cigarette lighter” plug type to the 12V
power outlets (
page 325) in your vehicle
whenever possible.
iIf the engine is off, and the cigarette lighter
is being used extensively, the vehicle battery
may become discharged.

325 Controls in detail
Useful features
Power outletsPower outlets are located

in the front center console
(
page 325)

in the front passenger footwell
(
page 325)

in the second-row footwell
(
page 326)

on the left-hand side of the cargo com-
partment (
page 326)
Power outlet in front center console
1Power outlet cover
Switch on the ignition (page 42).
Open cover plate (page 318).
Pull out cover1 and insert electrical
plug (cigarette lighter type).
Power outlet in front passenger
footwell
Switch on the ignition (page 42).
Flip up cover and insert electrical plug
(cigarette lighter type).
!If you use all power outlets in the vehicle,
make sure that the maximum current drawn
does not exceed 55 A.
iThe power outlets can be used to
accommodate 12V DC electrical accessories
(e.g. auxiliary lamps) up to a maximum of 240 W.
If the engine is off, the battery may become dis-
charged if used for long periods of time.
iYou can use the power outlets, except for
the power outlet in the front center console,
even if the ignition is switched off.
An emergency shut-off feature ensures that the
vehicle’s electrical voltage does not fall below a
minimum level. If the voltage drops to this mini-
mum level, the power outlets are automatically
switched off. This ensures that enough power re-
mains to start the engine.
iIf your vehicle is equipped with a smoking
package*, the storage compartment contains an
ashtray with cigarette lighter (
page 324) in-
stead.

326 Controls in detail
Useful features
Power outlet in second-row footwell
Switch on the ignition (page 42).
Flip up cover and insert electrical plug
(cigarette lighter type).Power outlet in cargo compartment
Switch on the ignition (page 42).
Flip up cover and insert electrical plug
(cigarette lighter type).
Floormats*
Warning!G
Whenever you are using floormats, make
sure there is enough clearance and that the
floormats are securely fastened.
Floormats should always be securely fas-
tened using eyelets2 and retainer pins1
(
page 327).
Before driving off, check that the floormats
are securely in place and adjust them if nec-
essary. A loose floormat could slip and
hinder proper functioning of the pedals.
Do not place several floormats on top of
each other as this may impair pedal move-
ment.
iTo install or remove the floormat more easi-
ly, move the driver’s seat or front passenger seat
as far to the rear as possible (
page 46).

327 Controls in detail
Useful features
1Retainer pin
2Eyelet
Removing
Pull floormat off of retainer pins1.
Remove the floormat.
Installing
Lay down the floormat in the respective
footwell.
Press the floormat eyelets2 onto re-
tainer pins1.
Seat cover under third-row seats
If something falls under the third-row
seats, you can remove the seat cover in
order to reach under the seats.
Removing seat cover
Example passenger side
Fold the respective seat halfway in or
out (
page 307).
Reach into the recess in the seat cover.
Pull the seat cover in the direction of
the arrow.
Remove the seat cover to reach under
the seats.
Installing seat cover
Fold the seat halfway in or out
(
page 307).
Put the seat cover back into place
using the guide pins.
Press the seat cover down until it
engages.
Make sure that the seat cover is
engaged properly by folding the seat all
the way in and out.

328 Controls in detail
Useful features
Heated steering wheel*
The steering wheel heating warms up the
leather area of the steering wheel.
The stalk is on the lower left-hand side of
the steering wheel.
1Switching on
2Indicator lamp
3Switching offSwitching on
Switch on the ignition (page 42).
Turn switch at the tip of stalk in the
direction of arrow1.
The steering wheel is heated. Indicator
lamp2 comes on.Switching off
Turn switch at the tip of stalk in the
direction of arrow3.
The heated steering wheel is switched
off. Indicator lamp2 goes out.
For information on the steering wheel, see
“Multifunction steering wheel”
(
page 30).
iThe steering wheel heating is turned off tem-
porarily and the indicator lamp2 remains on
when

the temperature of the vehicle interior is
above 86°F (30°C)

the temperature of the steering wheel is
above 95°F (35°C)
When these conditions do not apply anymore,
steering wheel heating continues.
iIndicator lamp2 flashes or goes out

in case of power surge or undervoltage

in case of a steering wheel heating malfunc-
tion
iThe steering wheel heating switches off
automatically when you remove the SmartKey
from the starter switch or, on vehicles with
KEYLESS-GO*, when you switch off the ignition
(
page 41) and open the driver’s door.

329 Controls in detail
Useful features
Telephone*
Radio transmitters, such as a portable tele-
phone or a citizens band unit, should only
be used inside the vehicle if they are con-
nected to an antenna that is installed on
the outside of the vehicle.
The external antenna must be approved by
Mercedes-Benz. Please contact an autho-
rized Mercedes-Benz Light Truck Center
for information on the installation of an ap-
proved external antenna. Refer to the radio
transmitter operation instructions regard-
ing use of an external antenna.When the mobile phone is inserted in the
cradle, you can operate the telephone us-
ing the following devices:

mobile phone keypad

COMAND system (see separate operat-
ing instructions)

buttonss andt on the multi-
function steering wheel (
page 158)

Voice Control System* (see separate
operating instructions)
Please note that these functions are only
available with Mercedes-Benz approved
mobile phones.
Warning!G
Never operate radio transmitters equipped
with a built-in or attached antenna (i.e. with-
out being connected to an external antenna)
from inside the vehicle while the engine is
running. Doing so could lead to a malfunc-
tion of the vehicle’s electronic system, pos-
sibly resulting in an accident and/or serious
personal injury.
Warning!G
Please do not forget that your primary re-
sponsibility is to drive the vehicle. A driver’s
attention to the road must always be
his /her primary focus when driving. For
your safety and the safety of others, we rec-
ommend that you pull over to a safe location
and stop before placing or taking a tele-
phone call.
If you choose to use the telephone
1 while
driving, please use the hands-free device
and only use the telephone when road,
weather and traffic conditions permit. Some
jurisdictions prohibit the driver from using a
cellular telephone while driving a vehicle.
Only operate the COMAND system
1 if road,
weather and traffic conditions permit.
Bear in mind that at a speed of just 30 mph
(approximately 50 km/h), your vehicle is
covering a distance of 44 feet (approximate-
ly 14 m) every second.
1Observe all legal requirements
iVarious mobile phone cradles can be in-
stalled in the front center armrest, see separate
installation instructions for the mobile phone
cradle. These mobile phone cradles can be ob-
tained from an authorized Mercedes-Benz Light
Truck Center.
The functions and services available to you while
using the mobile phone depend on your service
provider and the type of mobile phone you are
using. See also separate operating manual for in-
structions on how to use your mobile phone.
