MERCEDES-BENZ GL550 2008 X164 Owner's Manual

350 Operation
Driving instructions
Parking brake
When driving on wet roads or dirt covered
surfaces, road salt and/or dirt can get into
the parking brake. To prevent corrosion
and a reduction in the braking power of the
parking brake, observe the following:
From time to time, lightly engage the
parking brake before driving off.
Drive a distance of approximately
110 yds (100 m) at a maximum speed
of 12 mph (20 km/h).
Driving off
Apply the brakes to test them briefly after
driving off. Perform this procedure only
when the road is clear of other traffic.
Warm up the engine smoothly. Do not
place full load on the engine until the oper-
ating temperature has been reached.Parking
Warning!G
While performing this procedure, please
assure that the vehicle is stopped before
applying the parking brake. Otherwise the
rear wheels could lock up. You could lose
control of the vehicle and cause an accident.
In addition, the vehicle’s brake lights do not
light up when the parking brake is engaged.
Make sure not to endanger any other road
users when you engage the parking brake.
!When driving off on a slippery surface, do
not allow a drive wheel to spin for an extended
period with the ESP
® switched off. Doing so may
cause serious damage to the drivetrain which is
not covered by the Mercedes-Benz Limited
Warranty.
!Simultaneously depressing the accelerator
pedal and applying the brake reduces engine
performance and causes premature brake and
drivetrain wear.
Warning!G
Do not park this vehicle in areas where com-
bustible materials such as grass, hay or
leaves can come into contact with the hot
exhaust system, as these materials could be
ignited and cause a vehicle fire.
To reduce the risk of personal injury or
damage to the vehicle drivetrain as a result
of vehicle movement, before turning off the
engine and leaving the vehicle always:

Keep right foot on brake pedal.

Firmly depress parking brake pedal.

Set the automatic transmission to
positionP.

Slowly release brake pedal.

When parked on an incline, turn front
wheel towards the road curb.
164.boo Seite 350 Freitag, 30. März 2007 12:54 12

351 Operation
Driving instructions
Tires
Treadwear indicators (TWI) are required by
law. These indicators are located in six
places on the tread circumference and
become visible at a tread depth of
approximately
1/16in (1.6 mm), at which
point the tire is considered worn and
should be replaced.The treadwear indicator appears as a solid
band across the tread.
Specified tire inflation pressures must be
maintained. This applies particularly if the
tires are subjected to high loads (e.g. high
speeds, heavy loads, high ambient temper-
atures).

Turn the SmartKey or the SmartKey with
KEYLESS-GO* to starter switch
position0 and remove, or press
KEYLESS-GO* start/stop button (vehi-
cles with KEYLESS-GO*).

Take the SmartKey or the SmartKey with
KEYLESS-GO* with you and lock vehicle
when leaving.
Warning!G
If you feel a sudden significant vibration or
ride disturbance, or you suspect that possi-
ble damage to your vehicle has occurred,
you should turn on the hazard warning flash-
ers, carefully slow down, and drive with cau-
tion to an area which is a safe distance from
the road.
Inspect the tires and the vehicle underbody
for possible damage. If the vehicle or tires
appear unsafe, have the vehicle towed to
the nearest Mercedes-Benz Light Truck
Center or tire dealer for repairs.
Warning!G
Although the applicable federal motor
vehicle safety laws consider a tire to be
worn when the treadwear indicators (TWI)
become visible at approximately
1/16in
(1.6 mm), we recommend that you do not
allow your tires to wear down to that level.
As tread depth approaches
1/8in (3 mm),
the adhesion properties on a wet road are
sharply reduced.
Depending upon the weather and/or road
surface (conditions), the tire traction varies
widely.
164.boo Seite 351 Freitag, 30. März 2007 12:54 12

352 Operation
Driving instructions
For more information, see “Tires and
wheels” (
page 384).
Hydroplaning
Depending on the depth of the water layer
on the road, hydroplaning may occur, even
at low speeds and with new tires. Reduce
vehicle speed, avoid track grooves in the
road and apply brakes cautiously in the
rain.
Tire traction
The safe speed on a wet, snow covered or
icy road is always lower than on a dry road.
You should pay particular attention to the
condition of the road whenever the outside
temperatures are close to the freezing
point.Mercedes-Benz recommends winter tires
(
page 420) with a minimum tread depth
of approximately 1/6in (4 mm) on all four
wheels for the winter season to make sure
normal balanced handling characteristics.
On packed snow, they can reduce your
stopping distance compared to summer
tires.
Stopping distance, however, is still consid-
erably greater than when the road is not
covered with snow or ice. Exercise appro-
priate caution.
Warning!G
Do not drive with a flat tire. A flat tire affects
the ability to steer or brake the vehicle. You
may lose control of the vehicle. Continued
driving with a flat tire or driving at high
speed with a flat tire will cause excessive
heat build-up and possibly a fire.
Warning!G
If ice has formed on the road, tire traction
will be substantially reduced. Under such
weather conditions, drive, steer and brake
with extreme caution.
!Avoid spinning of a drive wheel. This may
cause serious damage to the drivetrain which is
not covered by the Mercedes-Benz Limited
Warranty.
164.boo Seite 352 Freitag, 30. März 2007 12:54 12

353 Operation
Driving instructions
Tire speed rating
Regardless of the tire speed rating, local
speed limits should be obeyed. Use
prudent driving speeds appropriate to pre-
vailing conditions.
An electronic speed limiter prevents your
vehicle from exceeding a speed of
130 mph (210 km/h).The factory equipped tires on your vehicle
may have a tire speed rating above the
maximum speed permitted by the
electronic speed limiter.
Make sure your tires have the required tire
speed rating as specified for your vehicle in
the “Technical data” section (
page 555),
for example when purchasing new tires.
For information on how to identify the tire
speed rating on a tire’s sidewall, see “Tire
size designation, load and speed rating”
(
page 406).
If you are uncertain about the correct
reading of the information given on a tire’s
sidewall, any authorized Mercedes-Benz
Light Truck Center will be glad to assist
you.
Winter driving instructions
The most important rule for slippery or icy
roads is to drive sensibly and to avoid
abrupt acceleration, braking and steering
maneuvers. Do not use the cruise control
system under such conditions.
When the vehicle is in danger of skidding,
shift the automatic transmission to
positionN. Try to keep the vehicle under
control by corrective steering action.
Warning!G
Even when permitted by law, never operate
a vehicle at speeds greater than the maxi-
mum speed rating of the tires.
Exceeding the maximum speed for which
tires are rated can lead to sudden tire
failure, causing loss of vehicle control and
possibly resulting in an accident and/or
serious injury and possible death, for you
and for others.
iFor information on speed ratings for winter
tires, see “Winter tires” (
page 420).
For additional general information on tire speed
markings on the tire sidewall, see “Tire speed
rating” (
page 418).
iFor information on driving with snow chains,
see “Snow chains” (
page 421).
164.boo Seite 353 Freitag, 30. März 2007 12:54 12

354 Operation
Driving instructions
Road salts and chemicals can adversely af-
fect braking efficiency. Increased pedal
force may become necessary to produce
the normal brake effect.
Depressing the brake pedal periodically
when traveling at length on salt-strewn
roads can bring road-salt-impaired braking
efficiency back to normal.If the vehicle is parked after being driven
on salt-treated roads, the braking efficien-
cy should be tested as soon as possible af-
ter driving is resumed.
For more information, see “Winter driving”
(
page 420).
Warning!G
On slippery road surfaces, never downshift
in order to obtain braking action. This could
result in drive wheel slip and reduced vehi-
cle control. Your vehicle’s ABS will not pre-
vent this type of control loss.
Do not engage the transfer case in position
LOW when driving on ice or packed snow. At
speeds below 18 mph (30 km/h) vehicle
steering is adversely affected by the
Off-road – ABS (
page 102).
Warning!G
Make sure not to endanger any other road
users when carrying out these braking
maneuvers.
Warning!G
If the vehicle becomes stuck in snow, make
sure that snow is kept clear of the exhaust
pipe and from around the vehicle with the
engine running. Otherwise, deadly carbon
monoxide (CO) gases may enter vehicle in-
terior resulting in unconsciousness and
death.
To assure sufficient fresh air ventilation,
open a window slightly on the side of the ve-
hicle not facing the wind.
Warning!G
The outside temperature indicator is not de-
signed to serve as an ice-warning device and
is therefore unsuitable for that purpose. In-
dicated temperatures just above the freez-
ing point do not guarantee that the road
surface is free of ice.
164.boo Seite 354 Freitag, 30. März 2007 12:54 12

355 Operation
Driving instructions
Standing water
For more information, see “Driving through
water” (
page 360).
Off-road driving
!Do not drive through flooded areas or water
of unknown depth. Before driving through water,
determine its depth. Never accelerate before
driving into water. The bow wave could force wa-
ter into the engine and auxiliary equipment, thus
damaging them.
If you must drive through standing water, drive
slowly to prevent water from entering the pas-
senger compartment or the engine compart-
ment.
Water in these areas could cause

damage to electrical components

wiring of the engine or transmission
or could result

in water being ingested by the engine
through the air intake, causing severe inter-
nal engine damage.
Any such damage is not covered by the
Mercedes-Benz Limited Warranty.
iSelect the raised level (page 279) before
driving through standing water.
Warning!G
Do not load items on the crossbars*. It may
cause instability during some maneuvers
which could result in an accident.
Drive slowly in unknown terrain. This will
make it easier to recognize unexpected ob-
stacles and avoid damage to the vehicle.
To help avoid the vehicle rolling over, never
turn it around on steep inclines. If the vehi-
cle cannot complete the attempted climb,
back it down in reverse gear.
Do not drive along the side of a slope. The
vehicle might otherwise rollover. If in doing
so the vehicle begins to show a tendency to
roll, immediately steer into a line of gravity
(straight up or downhill).
Never let the vehicle roll backwards in idle.
You may lose control of the vehicle if you
use only the service brake. For information
on driving downhill, see “Driving downhill”
(
page 360).
Warning!G
Sand, dirt, mud and other material having
friction property can cause exceptional wear
and tear as well as brake failure.
Have the brakes checked for dirt build-up
and cleaned. There is otherwise a risk that
full braking power may not be available in an
emergency.
Warning!G
Please be aware that by raising the vehicle
level, the center of gravity also rises. There-
fore, always ensure that the vehicle level is
as low as possible. With higher ride height
the ESP
® may activate earlier in certain
situations.
164.boo Seite 355 Freitag, 30. März 2007 12:54 12

356 Operation
Driving instructions
Read this chapter carefully before you be-
gin off-road travel.
Familiarize yourself with the vehicle char-
acteristics and gear changing before you
attempt any difficult terrain off-road driv-
ing. We recommend that you start out with
easy off-road travel.Special driving features for off-road
driving
The following driving features are available
for specific kind of operation:

Off-road – ABS (page 102)

Off-road – ESP® (page 106)

Off-road – 4-ETS (page 108)

Hill start assist system (page 196)

LOW RANGE mode* (page 201)

Differential locks* (page 204)

Downhill Speed Regulation (DSR)
(
page 273)

Off-road driving program (Vehicles
without enhanced off-road package*)
(
page 277)

Air suspension (page 278)Off-road driving rules

Engage the off-road driving program
(
page 277) or LOW RANGE mode*
(
page 201) before driving under
off-road conditions.

If necessary, activate differential
locks* (
page 204).

Make sure you select a vehicle level
(
page 279) appropriate to the topo-
graphical conditions. Always make
sure the vehicle has enough ground
clearance.

Fasten items being carried as securely
as possible (
page 295).

Always navigate gradients with the en-
gine on and with the transmission en-
gaged in a gear. Switch on the DSR
(
page 274) to help maintain a preset
speed.
164.boo Seite 356 Freitag, 30. März 2007 12:54 12

357 Operation
Driving instructions
Checklist before off-road driving
Engine oil level

Check the engine oil level with the oil
dipstick (
page 380).
Only with a proper oil level can the
vehicle obtain a trouble-free oil supply,
even on steep gradients.
!Observe the following during off-road
driving:

Keep doors, tailgate, windows, and
tilt/sliding sunroof* closed whenever driving
off-road.

Adjust vehicle speed to condition of terrain.
The more uneven, rutty and steeper the ter-
rain, the lower the speed should be. Drive
through water slowly at an even speed,
avoiding a bow wave.

Be especially careful when driving in un-
known territory. It may be necessary to get
out of the vehicle and scout the path you in-
tend to take.

Watch out for obstacles, such as rocks,
holes, tree stumps and ruts.

Before driving through water, determine its
depth.

Do not stop vehicle while immersed in water,
and do not shut off the engine.

In sandy soil, drive at a steady speed as al-
lowed by conditions. This helps overcome
the vehicle rolling resistance and reduces
the likelihood of the vehicle sinking into the
ground.

Do not initiate jumps with the vehicle. It
interrupts the forward momentum of the
vehicle.

Always drive onto slopes with the engine
running and the vehicle in gear.

Do not shift automatic transmission to
positionN.
Warning!G
Do not reduce the tire inflation pressure
before driving through sand. However, if you
do so, remember to correct the tire inflation
pressure (
page 395) before continuing
your trip. Driving with reduced tire inflation
pressure increases the risk of losing control
of the vehicle and rolling over.
!If the engine oil level warning lamp
(
page 473) comes on while driving, stop the
vehicle in a safe location or as soon at is safe to
do so. Check the engine oil level (
page 380).
The engine oil level warnings should not be
ignored. Extended driving with the symbol
displayed could result in serious engine damage
that is not covered by the Mercedes-Benz
Limited Warranty.
164.boo Seite 357 Freitag, 30. März 2007 12:54 12

358 Operation
Driving instructions
Tires

Check the tread depth and maintain
specified tire inflation pressure
(a placard with the recommended tire
inflation pressures is located on the
driver’s door B-pillar (
page 388)).

Check tires for possible damage and
remove foreign objects.

Replace missing valve caps.
Rims

Dented or bent rims can cause tire in-
flation pressure loss and damage the
tire beads. For this reason, check and,
if necessary, change rims before driv-
ing off-road.
Vehicle tool kit

Check if the vehicle jack (page 492)
is functional.

In all cases take the vehicle tool kit, a
strong tow rope, a shovel and a small
plank (to put under the vehicle jack on
sandy soil) with you.Driving in steep terrain
Slope angle
1 Overhang angle, front
2Overhang angle, rear

Comply with the warnings
(
page 355) and rules for off-road
driving (
page 356).

Driving on embankments, slopes and
other steep inclines should only be
done straight up or downhill, i.e. in the
line of gravity. Maximum vehicle climb-
ing ability is a 100% grade which is
equivalent to a slope angle of
45 degrees. Keep in mind that the
climbing ability of the vehicle depends
on terrain conditions.
Vehicles with air sus-
pension program12
Raised level34°28°
Highway29°23°
Vehicles with
enhanced off-road
package*12
Off-road-level 336°30°
Off-road-level 234°28°
Off-road-level 131°25°
Highway29°23°
164.boo Seite 358 Freitag, 30. März 2007 12:54 12

359 Operation
Driving instructions

Shift automatic transmission to
position1 (
page 197).

Drive slowly.

Avoid excessive engine speeds – drive
with moderate engine speeds
(max. 3 000 rpm).

Utilize the engine’s braking power
when descending a slope, observe the
engine speed (do not overrev the en-
gine). Apply the service brake as need-
ed.

Check the brakes after a lengthy down-
grade drive.Traction in steep terrain
The maximum vehicle climbing ability is a
100% grade which is equivalent to a slope
angle of 45 degrees. Keep in mind that the
climbing ability of the vehicle depends on
terrain conditions.
Be easy on the accelerator and watch for
continuous wheel traction when driving in
steep terrain.Driving across a hilltop
Decelerate just ahead of a hilltop (do not
shift automatic transmission to
positionN), to prevent the vehicle from
speeding up too much after climbing a hill.
Use the momentum of the vehicle to drive
across the hilltop.
After climbing a hill, driving in this manner
prevents the vehicle from:
losing ground contact when cresting
hills

losing its forward momentum

speeding up too much after climbing
the hill
iFor maximum engine speed, see “Instru-
ment cluster” (
page 26) and see “Engine”
(
page 553).
Warning!G
Never turn the vehicle around on steep
inclines. The vehicle might roll over. If the
vehicle cannot complete the attempted
climb, back it down in reverse gear.
iThe hill start assist system supports you
when driving uphill.
For more information, see “Hill start assist sys-
tem” (
page 196).
iThe 4-ETS helps greatly when starting out on
a steep incline when the front wheels have then
the tendency to slip due to the weight shifting
towards the rear axle.
The 4-ETS recognizes the situation and limits the
torque for the front wheels by braking them.
Simultaneously the torque for the rear wheels is
increased.
iVehicles with enhanced off-road package*
are equipped with automatic locks for the center
and rear axle differential to improve vehicle
traction.
164.boo Seite 359 Freitag, 30. März 2007 12:54 12
