MERCEDES-BENZ GLA-Class 2015 X156 Owner's Guide

TELEAID
Call priority .................................... 281
Downloading destinations
(COMAND) ..................................... 281
Downloading routes ....................... 285
Emergency call .............................. 278
General notes ................................ 277
Geo fencing ................................... 285
Locating a stolen vehicle ............... 284
MB info call button ....................... .280
Remote vehicle locking .................. 283
Roadside Assistance button .......... 280
Search & Send ............................... 282
Self-test ......................................... 278
Speed alert ................................... .285
System .......................................... 278
Triggering the vehicle alarm ........... 285
Vehicle remote malfunction diag-
nosis .............................................. 284
Vehicle remote unlocking .............. 283
Telephone
Accepting a call ............................ .212
Display message ............................ 251
Menu (on-board computer) ............ 211
Number from the phone book ....... .212
Redialing ........................................ 212
Rejecting/ending a call ................. 212
Temperature
Coolant .......................................... 204
Coolant (on-board computer,
AMG vehicles) ................................ 218
Engine oil (on-board computer,
AMG vehicles) ................................ 218
Outside temperature ..................... .205
Setting (climate control) ................ 133
Through-loading ................................ 269
Time see separate operating instructions
Timing (RACETIMER) ......................... 219
Tiredness assistant see ATTENTION ASSIST
TIREFIT kit .......................................... 308
Tire pressure Calling up (on-board computer) ..... 332
Checking manually ........................ 331
Display message ............................ 245
Important safety notes .................. 332 Maximum ....................................... 330
Notes ............................................. 329
Not reached (TIREFIT) .................... 310
Reached (TIREFIT) .......................... 310
Recommended ............................... 328
see Tire pressure
Tire pressure loss warning sys-
tem
General notes ................................ 331
Important safety notes .................. 331
Restarting ...................................... 331
Tire pressure monitor
Checking the tire pressure elec-
tronically ........................................ 334
Function/notes ............................ .332
General notes ................................ 332
Restarting ...................................... 334
Warning lamp ................................. 263
Warning message .......................... 334
Tires
Aspect ratio (definition) ................. 346
Average weight of the vehicle
occupants (definition) .................... 345
Bar (definition) ............................... 345
Changing a wheel .......................... 347
Characteristics .............................. 345
Checking ........................................ 325
Curb weight (definition) ................. 346
Definition of terms ......................... 345
Direction of rotatio n...................... 348
Display message ............................ 245
Distribution of the vehicle occu-
pants (definition) ............................ 347
DOT, Tire Identification Number
(TIN) ............................................... 344
DOT (Department of Transporta-
tion) (definition) ............................. 345
GAWR (Gross Axle Weight Rating)
(definition) ..................................... 345
General notes ................................ 352
GVW (Gross Vehicle Weight) (def-
inition) ........................................... 346
GVWR (Gross Vehicle Weight Rat-
ing) (definition) .............................. 346
Important safety notes .................. 324
Increased vehicle weight due to
optional equipment (definition) ...... 345
Information on driving .................... 324 Index
19

Kilopascal (kPa) (definition) ........... 346
Labeling (overview) ........................ 341
Load bearing index (definition) ...... 347
Load index .....................................3
44
Load index (definition) ................... 346
M+S tires ....................................... 326
Maximum loaded vehicle weight
(definition) ..................................... 346
Maximum load on a tire (defini-
tion) ............................................... 346
Maximum permissible tire pres-
sure (definition) ............................ .346
Maximum tire load ......................... 339
Maximum tire load (definition) ....... 346
MOExtended tires .......................... 326
Optional equipment weight (defi-
nition) ............................................ 347
PSI (pounds per square inch) (def-
inition) .......................................... .346
Replacing ....................................... 348
Service life ..................................... 326
Sidewall (definition) ....................... 347
Snow chains .................................. 327
Speed rating (definition) ................ 346
Storing .......................................... .348
Structure and characteristics
(definition) ..................................... 345
Summer tires ................................. 167
Summer tires in winter .................. 326
Temperature .................................. 341
TIN (Tire Identification Number)
(definition) ..................................... 347
Tire bead (definition) ..................... .347
Tire pressure (definition) ................ 347
Tire pressures (recommended) ...... 345
Tire size (data) ............................... 352
Tire size designation, load-bearing capacity, speed rating .................... 342
Tire tread ....................................... 325
Tire tread (definition) ..................... 347
Total load limit (definition) ............. 347
Traction ......................................... 340
Traction (definition) ....................... 347
Tread wea r..................................... 340
Uniform Tire Quality Grading
Standards ...................................... 340
Uniform Tire Quality Grading
Standards (definition) .................... 345 Wear indicator (definition) ............. 347
Wheel and tire combination ........... 354
Wheel rim (definition) .................... 345
see Flat tire
Tool
see Vehicle tool kit
Top Tether ............................................ 61
Towing away Important safety guidelines ........... 317
Installing the towing eye ................ 318
Notes for 4MATIC vehicles ............ 320
Removing the towing eye ............... 319
Transporting the vehicle ................ 320
With both axles on the ground ....... 319
With front axle raised ..................... 319
Tow-starting
Emergency engine starting ............ 320
Important safety notes .................. 317
Installing the towing eye ................ 318
Removing the towing eye ............... 319
Traction system
see ETS/4ETS (Electronic Trac-
tion System)
Transmission
see Automatic transmission
Transmission position display ......... 149
Transporting the vehicle .................. 320
Traveling uphill Brow of hill ..................................... 171
Driving downhill ............................. 171
Maximum gradient-climbing capa-
bility ............................................... 171
Trim pieces (cleaning instruc-
tions) .................................................. 303
Trip computer (on-board com-
puter) .................................................. 207
Trip odometer Calling up ....................................... 207
Resetting (on-board computer) ...... 208
see Trip odometer
Trunk
see Cargo compartment
see Tailgate
Trunk load (maximum) ...................... 368
Turn signals Changing bulbs (front) ................... 119
Changing bulbs (rear) .................... 120 20
Index

Display message ............................ 235
Switching on/off ........................... 112
Type identification plate
see Vehicle identification plate U
Unlocking Emergency unlocking ....................... 83
From inside the vehicle (central
unlocking button) ............................. 82 V
Vanity mirror (in the sun visor) ........ 275
Vehicle Correct use ...................................... 28
Data acquisition ............................... 29
Equipment ....................................... 24
Individual settings .......................... 215
Limited Warranty ............................. 29
Loading .......................................... 335
Locking (in an emergency )............... 83
Locking (SmartKey ).......................... 76
Lowering ........................................ 351
Maintenance .................................... 25
Parking for a long period ................ 162
Pulling away ................................... 144
Raising ........................................... 349
Reporting problems ......................... 28
Securing from rolling away ............ 349
Towing away .................................. 317
Tow-starting ................................... 317
Transporting .................................. 320
Unlocking (in an emergency) ........... 83
Unlocking (SmartKey )...................... 76
Vehicle data ................................... 368
Vehicle battery
see Battery (vehicle)
Vehicle data
Roof load (maximum) ..................... 368
Vehicle data (off-road driving)
Approach/departure angle ............ 369
Maximum gradient climbing abil-
ity .................................................. 369
Maximum water depth ................... 369
Vehicle dimensions ........................... 368
Vehicle emergency locking ................ 83Vehicle identification number
see VIN
Vehicle identification plate .............. 360
Vehicle maintenance see ASSYST PLUS
Vehicle tool kit .................................. 306
Ventilation see Climate control
Video (DVD) ........................................ 211
VIN Seat ............................................... 361
Type plate ...................................... 360 W
Warning and indicator lamps ABS ................................................ 254
Brakes ........................................... 254
Check Engine ................................. 260
Coolant .......................................... 260
Distance warning ........................... 262
DISTRONIC PLUS ........................... 262
ESP ®
.............................................. 256
ESP ®
OFF ....................................... 257
Fuel tank ........................................ 260
Overview .......................................... 34
Reserve fue l................................... 260
Restraint system ............................ 259
Seat belt ........................................ 252
SPORT handling mod e................... 257
Tire pressure monitor .................... 263
Warranty .............................................. 24
Washer fluid Display message ............................ 251
Wheel and tire combination
see Tires
Wheel bolt tightening torque ........... 351
Wheel chock ...................................... 349
see Wheel chock
Wheels
Changing a whee l.......................... 347
Checking ........................................ 325
Cleaning ......................................... 300
Cleaning (warning) ......................... 348
General notes ................................ 352
Important safety notes .................. 324
Information on driving .................... 324 Index
21

Interchanging/changing ................ 348
Mounting a new wheel ................... 351
Mounting a wheel .......................... 348
Removing a wheel .......................... 351
Snow chains .................................. 327
Storing ........................................... 348
Tightening torque ........................... 351
Wheel size/tire size ....................... 352
Window curtain air bag
Display message ............................ 231
Operation ......................................... 50
Windows
see Side windows
Windshield
Defrosting ...................................... 135
see Windshield
Windshield washer system
Adding washer fluid ....................... 296
Important safety notes .................. 366
Windshield wipers
Display message ............................ 251
Problem (malfunction) ................... 124
Rear window wipe r........................ 122
Replacing the wiper blades ............ 122
Switching on/of f........................... 121
Winter driving
Slippery road surfaces ................... 167
Snow chains .................................. 327
Winter operation
General notes ................................ 326
Winter tires
M+S tire s....................................... 326
Wiper blades
Cleaning ......................................... 301
Important safety notes .................. 122
Replacing (rear window )................ 123
Replacing (windshield) ................... 122
Wooden trim (cleaning instruc-
tions) .................................................. 303
Workshop see Qualified specialist workshop Z
ZONE function Switching on/of f........................... 134 22
Index

Protection of the environment
General notes
H
Environmental note
Daimler's declared policy is one of compre-
hensive environmental protection.
The objectives are for the natural resources
that form the basis of our existence on this
planet to be used sparingly and in a manner
that takes the requirements of both nature
and humanity into account.
You too can help to protect the environment
by operating your vehicle in an environmen-
tally responsible manner.
Fuel consumption and the rate of engine,
transmission, brake and tire wear are affected by these factors:
R operating conditions of your vehicle
R your personal driving style
You can influence both factors. You should
bear the following in mind:
Operating conditions:
R avoid short trips as these increase fuel con-
sumption.
R always make sure that the tire pressures
are correct.
R do not carry any unnecessary weight.
R remove roof racks once you no longer need
them.
R a regularly serviced vehicle will contribute
to environmental protection. You should
therefore adhere to the service intervals.
R always have service work carried out at a
qualified specialist workshop.
Personal driving style:
R do not depress the accelerator pedal when
starting the engine.
R do not warm up the engine when the vehicle
is stationary.
R drive carefully and maintain a safe distance
from the vehicle in front.
R avoid frequent, sudden acceleration and
braking. R
change gear in good time and use each gear
only up to 00C3of its maximum engine speed.
R switch off the engine in stationary traffic.
R keep an eye on the vehicle's fuel consump-
tion. Environmental concerns and recom-
mendations
Wherever the operating instructions require
you to dispose of materials, first try to regen-
erate or re-use them. Observe the relevant
environmental rules and regulations when
disposing of materials. In this way you will
help to protect the environment. Genuine Mercedes-Benz parts
H
Environmental note
Daimler AG also supplies reconditioned major
assemblies and parts which are of the same
quality as new parts. They are covered by the same Limited Warranty entitlements as new
parts.
! Air bags and Emergency Tensioning Devi-
ces, as well as control units and sensors for these restraint systems, may be installed inthe following areas of your vehicle:
R doors
R door pillars
R door sills
R seats
R cockpit
R instrument cluster
R center console
Do not install accessories such as audio
systems in these areas. Do not carry out
repairs or welding. You could impair the
operating efficiency of the restraint sys-
tems.
Have aftermarket accessories installed at a qualified specialist workshop. Introduction
23 Z

You could jeopardize the operating safety of
your vehicle if you use parts, tires and wheels as well as accessories relevant to safety
which have not been approved by Mercedes.
This could lead to malfunctions in safety-rel-
evant systems, e.g. the brake system. Use
only genuine Mercedes-Benz parts or parts of
equal quality. Only use tires, wheels and
accessories that have been specifically
approved for your vehicle.
Genuine Mercedes-Benz parts are subject to
strict quality control. Every part has been spe- cifically developed, manufactured or selected
for and adapted to Mercedes-Benz vehicles.
Only genuine Mercedes-Benz parts should
therefore be used.
More than 300,000 different genuine
Mercedes-Benz parts are available for
Mercedes-Benz models.
All authorized Mercedes-Benz Centers main-
tain a supply of genuine Mercedes-Benz parts for necessary service and repair work. In addi-
tion, strategically located parts delivery cen-
ters provide quick and reliable parts service.
Always specify the vehicle identification num- ber (VIN) when ordering genuine Mercedes-
Benz parts (Y page 360). Operator's Manual
Vehicle equipment
This Operator's Manual describes all models
and all standard and optional equipment of
your vehicle available at the time of going to
print. Country-specific differences are possi-
ble. Bear in mind that your vehicle may not
feature all functions described here. This also applies to safety-relevant systems and func-
tions. The equipment in your vehicle may
therefore differ from that shown in the
descriptions and illustrations.
The original purchase agreement lists all sys- tems installed in your vehicle.
Should you have any questions concerning
equipment and operation, please consult an
authorized Mercedes-Benz Center. The Operator's Manual and Maintenance
Booklet are important documents and should
be kept in the vehicle. Service and vehicle operation
Warranty
The implied warranty for your vehicle applies in accordance with the warranty terms and
conditions in the Service and Warranty Infor-
mation booklet.
Your authorized Mercedes-Benz Center will
replace and repair all factory-installed parts in
accordance with the following warranty terms
and conditions:
R New Vehicle Limited Warranty
R Emission System Warranty
R Emission Performance Warranty
R California, Connecticut, Maine, Massachu-
setts, New York, Pennsylvania, Rhode
Island and Vermont Emission Control Sys-
tem Warranty
R State warranty enforcement laws (lemon
laws)
Replacement parts and accessories are cov-
ered by the Mercedes-Benz Parts and Acces- sories warranties. These are available at any
authorized Mercedes-Benz Center.
i Should you lose your Service and War-
ranty Information booklet, have an author-
ized Mercedes-Benz Center arrange for a
replacement. The new Service and War-
ranty Information booklet will be posted to you. 24
Introduction

Information for customers in Califor-
nia
Under California law you may be entitled to a replacement of your vehicle or a refund of thepurchase price or lease price, if after a rea-
sonable number of repair attempts
Mercedes-Benz USA, LLC and/or its author-
ized repair or service facilities fail to fix one or
more substantial defects or malfunctions in
the vehicle that are covered by its express
warranty. During the period of 18 months
from original delivery of the vehicle or the
accumulation of 18,000 miles (approximately 29,000 km) on the odometer of the vehicle,
whichever occurs first, a reasonable number
of repair attempts is presumed for a retail
buyer or lessee if one or more of the following occurs:
(1) the same substantial defect or malfunc- tion results in a condition that is likely to
cause death or serious bodily injury if the
vehicle is driven, that defect or malfunc-
tion has been subject to repair two or
more times, and you have directly noti-
fied Mercedes-Benz USA, LLC in writing
of the need for its repair,
(2) the same substantial defect or malfunc- tion of a less serious nature than cate-
gory (1) has been subject to repair four or
more times and you have directly notified us in writing of the need for its repair, or
(3) the vehicle is out of service by reason of repair of the same or different substantial
defects or malfunctions for a cumulative
total of more than 30 calendar days.
Please send your written notice to:
Mercedes-Benz USA, LLC
Customer Assistance Center
One Mercedes Drive
Montvale, NJ 07645-0350 Maintenance
The Service and Warranty Booklet describes
all the necessary maintenance work which
should be done at regular intervals.
Always have the Service and Warranty Book-
let with you when you bring the vehicle to an authorized Mercedes-Benz Center. The ser-
vice advisor will record every service for you
in the Service and Warranty Booklet. Roadside Assistance
The Mercedes-Benz Roadside Assistance
Program offers technical help in the event of a breakdown. Calls to the toll-free Roadside
Assistance Hotline are answered by our
agents 24 hours a day, 365 days a year.
1-800-FOR-MERCedes(1-800-367-6372)
(USA)
1-800-387-0100 (Canada)
For additional information, refer to the
Mercedes-Benz Roadside Assistance Pro-
gram brochure (USA) or the "Roadside Assis-
tance" section in the Service and Warranty
booklet (Canada). You will find both in your
vehicle literature portfolio. Change of address or change of own-
ership
In the event of a change of address, please
send us the "Notification of Address Change" in the Service and Guarantee booklet or sim-
ply call the Mercedes-Benz Customer Assis-
tance Center (USA) at the hotline number
1-800-FOR-MERCedes(1-800-367-6372 )or
Customer Service Center (Canada) at
1-800-387-0100. This will assist us in con-
tacting you in a timely manner should the
need arise.
If you sell your Mercedes, please leave the
entire literature in the vehicle so that it is
available to the next owner.
If you have purchased a used car, please send
us the "Notification of Used Car Purchase" in Introduction
25 Z

the Service and Guarantee booklet or simply
call the Mercedes-Benz Customer Assistance
Center (USA) at the hotline number
1-800-FOR-MERCede s(1-800-367-6372 )or
Customer Service (Canada) at
1-800-387-0100. Vehicle operation outside the USA
and Canada
If you plan to operate your vehicle in foreign
countries, please be aware that:
R service facilities or replacement parts may
not be readily available.
R unleaded fuel for vehicles with a catalytic
converter may not be available. Leaded fuel may cause damage to the catalytic con-
verter.
R the fuel may have a considerably lower
octane rating. Unsuitable fuel can cause
engine damage.
Some Mercedes-Benz models are available
for delivery in Europe through our European
Delivery Program. For details, consult an
authorized Mercedes-Benz Center or write to
one of the following addresses.
In the USA
Mercedes-Benz USA, LLC
European Delivery Department
One Mercedes Drive
Montvale, NJ 07645-0350
In Canada
Mercedes-Benz Canada, Inc.
European Delivery Department
98 Vanderhoof Avenue
Toronto, Ontario M4G 4C9 Sports Utility Vehicle
G
WARNING
Due to the high center of gravity, the vehicle
may start to skid and roll over in the event of
an abrupt steering maneuver and/or when the vehicle's speed is not adapted to the road
conditions. There is a risk of an accident.
Always adapt your speed and driving style to
the vehicle's driving characteristics and to theprevailing road and weather conditions.
Utility vehicles have a significantly higher roll-
over rate than other types of vehicles.
Failure to operate this vehicle safely may
result in an accident, rollover of the vehicle,
and severe or fatal injury.
In a rollover crash, an unbelted person is sig- nificantly more likely to die than a person
wearing a seat belt.
You and all vehicle occupants should always
wear your seat belts. Operating safety
Important safety notes
G
WARNING
If you do not have the prescribed service/
maintenance work or any required repairs
carried out, this can result in malfunctions or system failures. There is a risk of an accident.
Always have the prescribed service/mainte-
nance work as well as any required repairs
carried out at a qualified specialist workshop. G
WARNING
If you switch off the ignition while driving,
safety-relevant functions are only available
with limitations, or not at all. This could affect, for example, the power steering and the brake
boosting effect. You will require considerably
more effort to steer and brake. There is a risk of an accident.
Do not switch off the ignition while driving. G
WARNING
Flammable material such as leaves, grass or
twigs may ignite if they come into contact with hot parts of the exhaust system. There is a risk of fire. 26
Introduction

When driving off road or on unpaved roads,
check the vehicle's underside regularly. In
particular, remove parts of plants or other
flammable materials which have become
trapped. In the case of damage, contact a
qualified specialist workshop. G
WARNING
Modifications to electronic components, their software as well as wiring can impair their
function and/or the function of other net-
worked components. In particular, systems
relevant to safety could also be affected. As a
result, these may no longer function as inten-
ded and/or jeopardize the operating safety of
the vehicle. There is an increased risk of an
accident and injury.
Never tamper with the wiring as well as elec-
tronic components or their software. You
should have all work to electrical and elec-
tronic equipment carried out at a qualified
specialist workshop.
If you make any changes to the vehicle elec-
tronics, the general operating permit is ren-
dered invalid.
! There is a risk of damage to the vehicle if:
R the vehicle becomes stuck, e.g. on a high
curb or an unpaved road
R you drive too fast over an obstacle, e.g. a
curb or a hole in the road
R a heavy object strikes the undercarriage
or parts of the chassis
In situations like this, the body, the under-
carriage, chassis parts, wheels or tires
could be damaged without the damage
being visible. Components damaged in this way can unexpectedly fail or, in the case of
an accident, no longer withstand the strain
they are designed to.
If the underbody paneling is damaged,
combustible materials such as leaves,
grass or twigs can gather between the
underbody and the underbody paneling. If
these materials come in contact with hot parts of the exhaust system, they can catch
fire.
In such situations, have the vehicle
checked and repaired immediately at a
qualified specialist workshop. If on con-
tinuing your journey you notice that driving
safety is impaired, pull over and stop the
vehicle immediately, paying attention to
road and traffic conditions. In such cases,
visit a qualified specialist workshop. Declarations of conformity
Vehicle components which receive
and/or transmit radio waves USA:
"The wireless devices of this vehicle
comply with Part 15 of the FCC Rules. Oper-
ation is subject to the following two condi-
tions: 1) These devices may not cause harm-
ful interference, and 2) These devices must
accept any interference received, including
interference that may cause undesired oper-
ation. Changes or modifications not expressly
approved by the party responsible for com-
pliance could void the user’s authority to
operate the equipment."
Canada: "The wireless devices of this vehicle
comply with Industry Canada license-exempt
RSS standard(s). Operation is subject to the
following two conditions: (1) These devices
may not cause interference, and (2) These
devices must accept any interference, includ- ing interference that may cause undesired
operation of the device." Diagnostics connection
The diagnostics connection is only intended
for the connection of diagnostic equipment at a qualified specialist workshop. G
WARNING
If you connect equipment to the diagnostics
connection in the vehicle, it may affect the
operation of the vehicle systems. As a result, Introduction
27 Z

the operating safety of the vehicle could be
affected. There is a risk of an accident.
Do not connect any equipment to a diagnos-
tics connection in the vehicle. G
WARNING
Objects in the driver's footwell can restrict the pedal travel or obstruct a depressed pedal.
The operating and road safety of the vehicle is
jeopardized. There is a risk of an accident.
Make sure that all objects in the vehicle are
stowed correctly, and that they cannot enter
the driver's footwell. Install the floormats
securely and as specified in order to ensure
sufficient clearance for the pedals. Do not use loose floormats and do not place floormats on
top of one another.
! If the engine is switched off and equip-
ment on the diagnostics connection is
used, the starter battery may discharge.
Connecting equipment to the diagnostics
connection can lead to emissions monitoring information being reset, for example. This
may lead to the vehicle failing to meet the
requirements of the next emissions test dur-
ing the main inspection. Qualified specialist workshop
An authorized Mercedes-Benz Center is a
qualified specialist workshop. It has the nec-
essary specialist knowledge, tools and quali-
fications to correctly carry out the work
required on your vehicle. This is especially the case for work relevant to safety.
Observe the notes in the Maintenance Book-
let.
Always have the following work carried out at
an authorized Mercedes-Benz Center:
R work relevant to safety
R service and maintenance work
R repair work R
alterations, installation work and modifica-
tions
R work on electronic components Correct use
If you remove any warning stickers, you or
others could fail to recognize certain dangers.
Leave warning stickers in position.
Observe the following information when driv- ing your vehicle:
R the safety notes in this manual
R the Technical Data section in this manual
R traffic rules and regulations
R laws and safety standards pertaining to
motor vehicles Problems with your vehicle
If you should experience a problem with your
vehicle, particularly one that you believe may affect its safe operation, we urge you to con-
tact an authorized Mercedes-Benz Center
immediately to have the problem diagnosed
and rectified. If the problem is not resolved to
your satisfaction, please discuss the problem
again with a Mercedes-Benz Center or con-
tact us at one of the following addresses.
In the USA
Customer Assistance Center
Mercedes-Benz USA, LLC
One Mercedes Drive
Montvale, NJ 07645-0350
In Canada
Customer Relations Department
Mercedes-Benz Canada, Inc.
98 Vanderhoof Avenue
Toronto, Ontario M4G 4C9 Reporting safety defects
USA only: 28
Introduction
