MERCEDES-BENZ M-Class 2003 W163 Comand Manual

128 Navigation
Destination memory
A pop up menu appears and asks you if
you want to delete all. Select “Yes”, if
you want to delete all, or “No” to can-
cel.
Press .
or
Use the joystick to select the desired
destination and press .
The Select Address menu appears.
Press to delete the destination.
or
If you don’t want to delete the destina-
tion, press . You can save the current vehicle position
as a destination in the Previous Destina-
tion list.
Press .
Use the joystick to select “EDIT
ROUTE LISTS” and press .
The Edit Select menu appears.
Use the joystick to select “Save
Current Position in Previ-
ous Destinations” and press .
The vehicle position is saved as a desti-
nation in the Previous Destination list.
Saving the current vehicle position
P82.85-9566-31
P82.85-9662-31

129 Navigation
Destination memory
This feature allows you to delete destina-
tions from the previous destination list.
Press .
Use the joystick to select “EDIT
ROUTE LISTS” and press .
The Edit Select menu appears.
Use the joystick to select “Edit
Previous Destination” and
press .
The Previous Destination list menu is
displayed.
You can now delete individual destina-
tions or all destinations.
Delete individual destinations
Use the joystick to select the desired
destination and press .
A menu with the desired address ap-
pears.
Press to delete the destination.
The destination is deleted.
or
If you don’t want to delete the destina-
tion, press . Delete all destinations
Use the joystick to select “Delete
all” and press .
A pop up menu appears and asks you if
you want to delete all. Select “Yes”, if
you want to delete all, or “No” to can-
cel.
Press .
Editing the Previous Destination list
P82.85-9566-31

130 Navigation
Settings
Settings
The MCS allows you to change the fre-
quency of voice prompts used to guide you
to your destination.

Press .

Use the joystick to select “SYSTEM
SETUP” and press .
The Setup Select menu appears.

Use the joystick to select “Guidance
Setup” and press .
The Guidance Setup menu appears.
Use the joystick to select “Voice
prompt” and press .
The Voice Prompt menu appears.
Voice prompt frequency
P82.85-9566-31
P82.85-9576-31
i
The volume of the navigation voice
prompt can only be adjusted during active
route guidance. Turn the rotary push
button during an announcement, or press
Navi Voice to repeat the current/last
voice instruction and turn the rotary push
button during the announcement.
During an announcement, the volume
of the audio source is lowered automati-
cally.
P82.85-9593-31

131 Navigation
Settings
Use the joystick to select one of the fol-
lowing voice prompt frequency modes
and press .

“Min”: A beep tone will be heard
when approaching a maneuver.

“Normal”: Voice instructions are
announced shortly before
approaching a maneuver. In
addition, voice instructions are
announced 1/2 a mile before a
maneuver when travelling on local
or county roads and 1 mile before a
maneuver on freeways or express-
ways.

“Max”: Voice instructions accom-
panied by a beep tone are an-
nounced at all maneuver locations.
In addition, voice instructions are
announced 1/2 a mile before a ma-
neuver when travelling on local or
county roads and 1 mile before a
maneuver on freeways or express-
ways. Once a maneuver is com-
plete, the distance to the next
maneuver is announced.
To save the settings, use the joystick to
select “Return” and press .The MCS allows you to choose between
three distinct guidance displays.

Press .

Use the joystick to select “SYSTEM
SETUP” and press .
The Setup Select menu appears.
Selecting the guidance display
P82.85-9566-31

132 Navigation
Settings

Use the joystick to select “Guidance
Setup” and press .
The Guidance Setup menu appears. Use the joystick to select
“Guidance” and press .
The Guidance menu appears.
Use the joystick to select one of the fol-
lowing guidance modes and press .

“Hybrid”: The basic guidance
screen is displayed during a maneu-
ver. Once the maneuver is com-
plete, the MCS returns to the
detailed map display or the respec-
tive audio display.

“Arrow”: The Basic Guidance
screen is displayed at all times.

“Map”: The Detailed Map screen is
displayed at all times.
Use the joystick to save the settings,
select “Return” and press .
P82.85-9576-31P82.85-9593-31

133 Navigation
Settings
The MCS allows you to display either the
estimated arrival time at, or the remaining
time to your destination.

Press .

Use the joystick to select “SYSTEM
SETUP” and press .
The Setup Select menu appears.

Use the joystick to select “Guidance
Setup” and press .
The Guidance Setup menu appears.
Use the joystick to select
“Est.Time” and press .
The Est. Time setup menu appears.
Use the joystick to select one of the fol-
lowing estimated time modes and
press .

“Arrival”: The estimated arrival
time at your destination is dis-
played.

“Remaining”: The remaining
time to your destination is dis-
played.
To save the settings, select “Return”
and press .
Selecting the estimated time displayed
P82.85-9566-31
P82.85-9576-31
P82.85-9593-31

134 Navigation
Settings
The MCS allows you to display 3 different
Point of Interest icons when the detail map
display has been selected.

Press .

Use the joystick to select “SYSTEM
SETUP” and press .
The Setup Select menu appears.

Use the joystick to select “Display
Setup” and press .
The Display Setup menu appears. Use the joystick to select “POI Icon”
and press .
The POI Icon menu appears.
Selecting which Point of Interest icons
are displayed
P82.85-9566-31
P82.85-9576-31P82.85-9577-31

135 Navigation
Settings
Use the joystick to select one of the fol-
lowing POI modes and press .

“Show”: The selected POI icons are
shown when you select the detail
map display.

“Hide”: No POI icons are dis-
played.

“Edit”: Allows you to select which
POI icons are displayed.
To save the settings, use the joystick to
select “Return” and press .
When you move the Present Vehicle Posi-
tion icon to any of the visible POI icons and
press , the name, address, and phone
number respective of the POI icon will be
displayed.Editing POI icons
If you select “Edit” a list of 6 icons appears.
Use the joystick to select up to 3 of the
following icon types. After selecting each
icon, press .

“ATM”

“Bank”

“Gas Station”

“Hotel”

“Parking”

“Restaurant” and type of restau-
rantYou can set the map display so that north
is always referenced towards the top of the
display or the Present Vehicle Position icon
is always pointing towards the top of the
screen.
Press .
Use the joystick to select “SYSTEM
SETUP” and press .
The Setup Select menu appears.
Setting map and screen orientation
P82.85-9566-31


136 Navigation
Settings

Use the joystick to select “Display
Setup” and press .
The Display Setup menu appears. Use the joystick to select “Orienta-
tion” and press .
The Orientation menu appears.
Use the joystick to select one of the fol-
lowing orientation modes and press
.

“Heading Up”: The Map display
rotates such that the Present
Vehicle Position icon is always
pointing toward the top of the
screen.

“North Up”: The Map display
always shows the map with north
facing toward the top of the screen.
The Present Vehicle Position icon
rotates on the map.
To save the settings, use the joystick to
select “Return” and press .
P82.85-9576-31P82.85-9668-31

137
Info Services/System settings
InfoServices
Systemsettings
