64 Audio
Audio Adjustment
Activating sound optimization*
Only in vehicles with a premium sound
system*.
Press the softkey “ADJ” in any
audio menu.
Your current settings will be displayed
in the main audio adjust menu.
Select the parameter “SOUND” with
the softkeys or .
To select the desired sound settings,
press the softkeys , and
.Available sound optimizations

“STANDARD”- linear sound from the
center of the vehicle.

“SPEECH” - emphasis is placed on the
spoken word.

“DRIVER” - sound is optimized for the
front seats.

“AMBIENCE” - recreates the sound of
a room.Resetting audio adjustments
Return to the audio menu by pressing
the softkey “EXIT”.
Press and hold the audio menu softkey
“ADJ” for longer than 2 seconds.
All parameters are set to 0 and the
sound optimization is set to
“STANDARD”. The MCS automatically
returns to the audio mode.
i
You can only select one sound optimiza-
tion at a time.
i
Sound Optimization is not available for
service sources.
i
If your vehicle is equipped with the Bose
Audiopilot digital processor, digital
electronics will continually separate
program material from ambient noise
and modify the programming signal so
that you can enjoy the full musical
performance without making any
adjustments.
The normal operation of the Bose
Audiopilot could be interpreted as
volume fluctuations, however this is
normal operation.

72 Telephone
Telephone operation
Press .
The menu to enter the unlock code ap-
pears.
Entering the unlock code
Use the number keys through
to enter the unlock code.
Asterisks instead of digits will appear in
the input line.If the code entered is correct and the
phone is registered in a network, the
phone is ready for use.If the telephone is ready for operation,
“READY” appears. The graphic (left) de-
picts strong signal reception. If you are not
in a home network, the roaming indicator
“R” is shown.
Switch to an audio mode, navigation
mode*.
Allow the telephone to switch to sleep
mode.
or
Switch off the MCS system.
Switching telephone operation on
i
Timeport phones use a three-digit code.
V60 phones use a four-digit code. The
head unit unlocks the phone using the
first three digits of the four-digit V60
unlock code.
Your unlock code prevents unautho-
rized persons from using your tele-
phone. Be sure to memorize this code
carefully.
If you enter an incorrect code, the sys-
tem returns to the menu for entering
the unlock code.
You must always enter the unlock code
when you switch on the telephone in
locked mode.
Switching telephone operation off

111 Navigation
Route guidance
Function
1Maneuver screen
2Name of the street onto which
you should turn
3Distance to next maneuver
4Distance to the destination
5Direction to the destination
6Estimated remaining driving time
to the destination
or
Estimated arrival time at the des-
tination
Function
7Current road and city name
8Current time
9Detailed map display
10GPS signal strength icon
11Next maneuver icon
12Distance to next maneuver
13Name of street onto which you
should turn
14Compass icon indicates the di-
rection North
Function
15Distance to the destination
16Direction to the destination
17Estimated remaining driving
time to the destination
or
Estimated arrival time at the
destination
18Current road and city name
19Current time
20Zoom scale
