service indicator MERCEDES-BENZ METRIS 2016 MY16 Operator’s Manual

Customer Assistance Center
(CAC).................................................... .30
Customer Relation sDepartment .......3 0
D
Dashboar d
see Cockpit
Dashboar dlighting
see Instrumen tcluster lighting
Dat a
see Technica ldata
Dat e
Settin g(vehicle wit hsteerin g
whee lbuttons ).............................. .186
Setting (vehicle without steering
wheel buttons) ............................... 175
Daytime runningl amp mode
see Daytime running lamps
Daytime runningl amps
Changing bulbs .............................. 100
Display messages (vehicle with
steering wheel buttons) ................. 210
Display messages (vehicle with-
out steering wheel buttons) ........... 196
Switching on/off (switch) ................ 93
Dealership
see Qualified specialist workshop
Declarations of conformity ................. 29
Delaye dswitch-off
Exterior lighting (on-board com-
puter) ............................................. 186
Interior lighting .............................. 187
Diagnostic sconnection
Operating safety and vehicle
approval ...........................................2 9
Digital speedomete r
Displayin g(vehicle wit hsteerin g
whee lbuttons ).............................. .178
Displaying (vehicle without steer-
ing wheel buttons) ......................... 172
DIRECT SELEC Tlever
Automatic transmission ................. 126
Display
Function/notes (vehicle with
steering wheel buttons) ................. 176
Function/notes (vehicle without
steering wheel buttons) ................. 170 Permanent displa
y(vehicle with
steering wheel buttons) ................. 185
Permanent displa y(vehicle with-
out steering wheel buttons) ........... 174
see Warning and indicator lamps
Display messag e(vehicle with
steering wheel buttons)
Safety systems .............................. 203
Servi ce

intervald isplay.................. 247
Display messag e(vehicle without
steering wheel buttons)
Safety systems .............................. 189
Service intervald isplay.................. 247
Display messages (vehicle with
steering wheel buttons)
Calling up ....................................... 202
Driving systems .............................2 13
Engine ............................................ 211
Hiding ............................................ 201
Important safety notes .................. 201
Introduction ................................... 201
Key ................................................ 218
Lights ............................................. 208
Setting the language ......................1 85
Tire s............................................... 216
Vehicle ...........................................2 17
Display messages (vehicle without
steering wheel buttons)
Calling up ....................................... 188
Driving systems .............................1 98
Engine ............................................ 197
Hiding ............................................ 188
Important safety notes .................. 188
Introduction ................................... 188
Key ................................................ 201
Lamp s............................................ 194
Setting the language ......................1 73
Tire s............................................... 199
Vehicle ...........................................2 00
Distancer ecorder
Displaying (vehicle with steering
wheel buttons) ............................... 177
Displaying (vehicle without steer-
ing wheel buttons) ......................... 171
Setting the displa yunit (vehicle
without steering wheel buttons) .... 174
Distancew arning (warning lamp) .... 225
Distancew arning function ...............143
8Index

Memory card (audio)......................... 181
Mercedes-Ben zService24h .............. 262
Message memory
On-board computer (vehicle with
steering whee lbuttons) ................. 202
On-board computer (vehicle with-
out steering whee lbuttons) ...........1 88
Messages
see Warning and indicator lamps
Mirrors
Exterior mirrors ................................ 91
Important safety notes .................... 90
Rear-view mirror .............................. 91
see Vanity mirror
Mobile phone
Typeapproval/frequency .............. 294
Model designation
see Vehicle identification plate
Modifying the programming
(SmartKey) ...........................................6 8
Motor oil additives
see Additives
Mountin gwheels
Lowering the vehicl e...................... 289
Mounting anew whee l................... 288
Preparing the vehicl e.....................2 87
Raising the vehicle ......................... 287
Removing awheel .......................... 288
Removing and mounting the spare
wheel ............................................. 292
Securing the vehicle against roll-
ing away ........................................ 287
MP3
Operation ....................................... 181
N
NavigationMenu (on-board computer) ............ 179
Notes on breaking-i nanew vehi-
cle ....................................................... 119
O
Occupant Classification System
(OCS)
Conditions ....................................... 50
Faults ............................................... 54 Operation ......................................... 51
System self-test ............................... 52
Occupant safety
Automatic measure safter an acci-
dent ................................................. 56
Childre ninthe vehicle ..................... 56
Important safety notes .................... 43
Introduction to the restraint sys-
tem ..................................................4 3
Occupant Classification System
(OCS) ............................................... 50
PASSENGER AIR BAG indicator
lamps ............................................... 44
Pets in the vehicle ........................... 62
Restraint system warning lamp ........ 43
OCS
Conditions ....................................... 50
Faults ............................................... 54
Operation ......................................... 51
System self-test ...............................5 2
Odometer
Displaying (vehicle with steering
wheel buttons) .............................. .177
Displaying (vehicle without steer-
ing wheel buttons) ......................... 171
Setting the displa yunit (vehicle
with steering wheel but-
tons) .............................................. 185
Setting the displa yunit (vehicle
without steering wheel buttons) .... 174
Off-road driving
Checklist after driving off-road. ..... 140
Important safety notes .................. 138
Rules for driving off-road. ..............139
Oil
see Engine oil
On-board computer (vehicle with
steering wheel buttons)
Assistance menu ........................... 182
Audi omenu ................................... 180
Date menu ..................................... 186
Display messages .............. ............ 201
Fa ctory

settings .............................1 87
Important safety notes .................. 168
Instrument cluster menu ...............1 85
Lights menu ................................... 186
Menu overview .............................. 177
Message memory .......................... 202
14Index

GAWR(Gross Axle WeightR ating)
(definition) .................................... .284
GTW (Gross Trailer Weight) (defi-
nition) ............................................ 284
GVW (Gross Vehicle Weight) (def-
inition) ...........................................2 85
GVW R(Gross Vehicle Weight Rat-
ing) (definition) .............................. 285
Important safety notes .................. 267
Increase dvehicle weight due to
optional equipment (definition) ...... 284
Information on driving .................... 267
Kilopascal (kPa)( definition) ........... 285
Labeling (overview )........................ 281
Loadb earing index (definition) ...... 286
Loadi ndex ..................................... 283
Loadi ndex (definition) ................... 285
M+S tire s....................................... 269
Maximu mloadona tire (defini-
tion) ............................................... 285
Maximu mloaded vehicleweigh t
(definition) ..................................... 285
Maximu mpermissibl etire pres-
sure (definition) ............................. 285
Maximu mtire load ......................... 283
Maximu mtire load (definition) ....... 285
Optionale quipmentweight (defi-
nition) ............................................ 285
PSI (pounds pe rsquare inch )(de f-
inition) ........................................... 285
Replacing ....................................... 286
Service life ..................................... 268
Sidewal l(de finition) ....................... 285
Snow chains .................................. 270
Speed rating (definition) ................ 284
Storing ........................................... 286
Structure and characteristics
(definition) ..................................... 284
Summer tire s................................. 269
TIN (Tire Identification Number)
(definition) ..................................... 286
Tire bead (definition) ...................... 285
Tire pressure (definition) ................ 285
Tire pressures (recommended )...... 284
Tire size (data )............................... 290
Tire size desi
gnation, load-bearing
ca

pacity, speed rating .................... 281
Tire trea d....................................... 268 Tire trea
d(definition) ..................... 285
Tota lloa dlim it (definition) ............. 286
Tractio n(definition) ....................... 286
TWR (permissibl etraile rdrawbar
noseweight) (definition) ................. 286
Uniform Tire Quality Grading
Standard s(de finition) .................... 284
Wea rindicator (definition) ............. 286
Wheel and tire combination ........... 291
Wheel rim (definition) .................... 284
Top Tether ............................................ 59
Tow-starting
Emergency engine starting ............ 266
Important safety notes .................. 264
Towing
If the vehicl eisstuck ..................... 266
Installing/removing the towing
eye. ................................................ 265
Towin gatrailer
Active Parking Assist ..................... 154
Axle load ,permissibl e.................... 305
Cleaning the traile rtow hitch ......... 258
Coupling up atraile r...................... 165
Decoupling atraile r....................... 166
Driving tip s.................................... 162
Note sonr etrofitting ...................... 305
Power supply ................................. 167
Trailer load s................................... 305
Towin gaway
Important safety guideline s........... 264
With both axles on the ground ....... 266
With the rea raxler aised ................ 265
Towin geye......................................... 260
Trailer coupling
see Towing atrailer
Trailer loads and drawbar nose-
weights ............................................... 166
Trailer operation
Lights display messages (vehicle
with steering wheelb uttons) ......... 208
Lights display messages (vehicle
withou tsteering wheelb uttons) .... 194
Trailer towing
Blind Spot Assist ............................ 147
ESP
®................................................ 65
PARKTRONIC ................................. 153
Index21

stop automatically.The rear window wiper will
only resume wiping againw hen the tailgate and
rear door are closed and you pull awaya gain.
The rear window will no longer be wiped properly
if the wiper blade is worn. This may prevent you
from observing the traffic conditions. Informa-
tion on replacing the wiper blade can be found
under "Replacing wiper blades" (
Ypage 103).
Replacing the wiper blades
Important safety notes
GWARNING
If the windshieldw ipers begin to move while
you are changing the wiper blades, you could be trapped by the wiper arm. There is arisk of
injury.
Always switch off the windshieldw ipers and
ignition before changing the wiper blades.
!Never open the hood/tailgate or rear doors
if aw indshieldw iper arm has been folded
awayf rom the windshield/rear window.
Never fold awindshieldw iper arm without a
wiper blade back onto the windshield/rear
window.
Hold the windshieldw iper arm firmly when
you change the wiper blade.Ify ou release the
windshieldw iper arm without awiper blade
and it falls onto the windshield/rear window,
the windshield/rear window may be damaged
by the force of the impact.
Mercedes-Benz recommends that you have
the wiper bladesc hanged ataqualified spe-
cialist workshop.
!Only hold the wiper blade by the wiper arm.
You could otherwise damage the wiper rub-
ber.
Wiper bladesa re wear parts. The windshieldw ill
no longer be wiped properly if the wiper blades
are worn. This may prevent you from observing
the traffic conditions.
Please observe the service indicator after
changing the wiper bladesoft he windshield
wiper.
Service indicator
Replacement wiper bladesf or the windshield
wiper have aservice indicator on the tip of the
wiper blade.
Depending on the amount of use, the service
indicator will change color from black to yellow.
Change the wiper blade if:
Rthe wiper blade is damaged
Rthe service indicator has turned yellow
In order to activate the service indicator, you
have to remove the protective film
(
Ypage 103).
Windshield wiper
XFold out wiper arm awayf rom the windshield.
XHold the wiper arm and turn the wiper blade in
the direction of arrow:awayf rom the wiper
arm as far as it will go.
XSlide catch ;upwards in the direction of the
arrow until you can feel and hear it engage in
the changing position.
XRemove wiper blade =from wiper arm by
pulling it in the direction of the arrow.
Windshield wipers103
Lights and windshield wipers
Z

XInsert new wiper blade=into the wiper arm
in the direction of the arrow.
Please take the differing lengths of the two
wiper blades into account:
RDriver's side -long wiper blade
RFront-passenger side -short wiper blade
XSlide catch ;downwards in the direction of
the arrow until you can feel and hear it
engage.
XFold the wiper arm back onto the windshield.
XRemove protective film ?from the service
indicator on the tip of the wiper blades.
Rear window wiper
Tailgate
XFold wiper arm :awa yfrom the rear window
until you hear it engage.
XHold wiper arm :and pul lwiper blade ;in
the direction of the arrow awa yfrom the wiper
arm.
XPlace new wiper blade ;onto wiper arm :.
XHold wiper arm:and push wiper blade ;in
the opposite direction to the arrow until it
engages.
XMake sure that wiper blade ;is in the cor-
rect position.
XFold wiper arm :back onto the rear window.
Rear doors
Rea rwindow wipers (example: left rear door)
XFold wiper arm =awa yfrom the rear window.
XPress both retaining clips ;together in the
direction of the arrow and swing wiper
blade :awa yfrom wiper arm =.
XPullwiper blade :up and out of the retainer
on wiper arm =.
XSlide new wiper blade :into the retainer on
wiper arm =.
104Windshield wipers
Lights and windshield wipers

GWARNING
If you leave children unsupervised in the vehi-
cle, they coul dset it in motion by, for example:
Rrelease the parking brake.
Rshift the automatic transmission out of the
parking position P.
Rstart the engine.
In addition, they may operate vehiclee quip-
ment and become trapped. There is arisk of
an accident and injury.
When leaving the vehicle, alway stake the
SmartKey with you and lock the vehicle. Never
leave children unsupervised in the vehicle.
!Always secure the vehiclec orrectly against
rolling away. Otherwise, the vehicleori ts driv-
etrain coul dbedamaged.
!When the vehicleisp arked,alway sremove
the key to prevent the battery from becoming
discharged.
Always park you rvehicl esafel yand secure it
against rolling away. When parking, observe the
lega lrequirements of the country in which you
are currently driving.
To ensure that the vehicleisp roperly secured
against rolling awa yunintentionally:
Rthe parking brake must be firmly applied
Rthe transmission must be in position Pand the
key must be removed from the ignitio nlock
Ron steep uphill or downhill gradients, the front
wheels must be turned toward sthe curb
Parking brake
GWARNING
If you leave children unsupervised in the vehi-
cle, they coul dset it in motion by, for example:
Rrelease the parking brake.
Rshift the automatic transmission out of the
parking position P.
Rstart the engine.
In addition, they may operate vehiclee quip-
ment and become trapped. There is arisk of
an accident and injury.
When leaving the vehicle, alway stake the
SmartKey with you and lock the vehicle. Never
leave children unsupervised in the vehicle.
GWARNING
If you must brake the vehiclew ith the parking
brake, the braking distance is considerably
longer and the wheels coul dlock. There is an
increased dange rofskidding and accidents.
Only use the parking brake to brake the vehi-
cle when the service brake is faulty. Do not
apply the parking brake too firmly .Ifthe
wheels lock, release the parking brake until
the wheels begint urning again.
The brake lampsare not illuminated when you
brake the vehicleu sing the parking brake.
As arule ,you may only apply the parking brake
when the vehicleiss tationary.
XTo apply the parking brake: depress park-
ing brake pedal ;firmly.
The red F(only USA) or J(only Can-
ada )indicator lamp in the instrument cluster
lights up if the engine is running.
XTo release the parking brake: depress the
brake pedala nd keep it depressed.
XPullrelease handle :.
The parking brake is released abruptly.T he
red F (only USA) or J(only Canada)
indicator lamp in the instrument cluster goes
out.
Exceptionally,ift he service brake fails, the park-
ing brake can be used to brake the vehicleina n
emergency.
XEmergency braking: pullrelease handle :
and gradually depress parking brake
pedal ;.
Parking133
Driving and parking
Z

XPressato confirm.
The currents tatus is shown.
XTo activate/deactivate: pressaagain.
If the å warning lamp in the instrument
cluster lights up when the vehicle is ready to
drive, ESP
®is deactivated.
If the ÷ warning lamp lights up continuously,
ESP
®is not availabled ue toamalfunction.
Observe the information on warning lamps
(
Ypage 221) and display messages
(Ypage 207).
Activating/deactivating the distance
warning function
Using the steerin gwheel buttons
XPress =or; to select the Assist.menu.
XPress9or: to select DistanceWarning.
XPressato confirm.
The currents tatus is shown.
XTo activate/deactivate: press theabut-
ton again.
If the distanc ewarning function of COLLISION
PREVENTION ASSIST is activated, the display
shows the Äsymbol in the header.
At speeds up to approx 20 mph (30 km/h),
the display in vehicles with Active Parking
Assist first shows the ístatus indicator.
Only from aspeed of about 20 mph (30 km/ h)
does the display show the Äsymbol
instead of the ístatus indicator.
Further information can be found under "COL-
LISION PREVENTION ASSIST" (
Ypage 143).
Setting ATTENTION ASSIST
Using the steering wheel buttons
XPress =or; to select the Assist.menu.
XPress:or9 to select AttentionAssist.
XPressato confirm.
The currents etting is displayed.
XTo change the setting: pressaagain.
XPress :or9 to set Deactivated,
Standardor Sensitive.
XPress ato confirm the choice.
If ATTENTION ASSISTisa ctivated, theÀ
symbol is shown in the status area of the dis- play. The selection
Standard
orSensitivesets the sensitivity with which the system
determines the attention level.
Further information can be found under "ATTEN-
TION ASSIST" (
Ypage 149).
Activating/deactivating Blind Spot
Assist
Using the steering wheel buttons
XPress =or; to select the Assist.menu.
XPress:or9 to select Blind SpotAssist.
XPressato confirm.
The currents tatus is shown.
XTo activate/deactivate: press theabut-
ton again.
Further information can be found under "Blind
Spot Assist "(
Ypage 145).
Setting Lane Keeping Assist
Using the steering wheel buttons
XPress=or; to select the Assist.menu.
XPress:or9 to select LaneKeepingAssist.
XPressato confirm.
The currents electionStandardorAdaptiveis displayed.
XTo change the setting: pressaagain.
Further information can be found under "Lane
Keeping Assist "(
Ypage 147).
Service menu
184On-boardcomputer (vehicles with steering wheel buttons)
On-boardcomputer and displays

Display messagesPossible causes/consequences andMSolutions
ÒThe tailgateisopen.
XClos ethe tailgate.
ÑThe rear door is open .
XClosethe rear door(s).
ÓAn additional warning tone sounds. The hoo disopen.
GWARNIN G
The open hoo dmay then bloc kyour vie wwhen th evehicl eisinm otion.
There is ariskofana ccident.
XStop thevehicl eimmediately, payin gattention to roa dand traffic
conditions.
XSecur ethe vehicl etopreventitfromr ollin gaway (Ypage 132).
XClosethe hood.
CAn additional warning tone sounds while th evehicl eisinm otion.The
display shows th eopen door(s).
XClos eall doors.
Ð
Power Steering Mal ‐function See Oper.Manual
An additional warning tone sounds. The steering powe rassistanc e
could be malfunctioning .You may need to steer mor eforcefully.
XCarefully continu etoaqualified specialist workshop and hav ethe
steering checke dimmediately.
Â
Obtain aNew Key
The ke yneeds to be replaced.
XVisit aqualified specialist workshop .
Phone No ServiceYour vehicleisoutside th enetwork provider' stransmitter/receiver
range.
¥
Check Washer Fluid
The washer flui dlevel in th ewasher flui dreservoir has dropped belo w
th em inimum .
XAddw asher flui d(Ypage 246).
Indicatorand warning lamps in th einstrume nt cluster
Generaln otes
Whe nswitching on th eignition ,som esystems carry out aself-test .Som eindicator and warning
lamp smay temporarily tur nonorstart to flash. This is no tanindication of any problem .Onlyw hen
these indicator and warning lights tur nonorstart flashin gafter th eengineh as started or during th e
journey has amalfunction occurred .
218Indicator and warning lamps in th einstrument cluster
On-board computera nd displays

!Vehicles withagasolinee ngine:avoid
repeated and lengthy starting attempts. Oth-
erwise, the catalytic converter could be dam-
aged by non-combusted fuel.
If the indicator and warning lamps in the instru-
ment cluster do not light up at low tempera-
tures, the discharged battery may have frozen.
In this case you may neither charge the battery
nor jump-start the vehicle. The service life of a
thawed battery may be shorter. Start-up behav-
ior may deteriorate, in particular at low temper-
atures. Have the thawed battery checked at a
qualified specialist workshop.
Do not use arapid charging device to start the
vehicle. If your vehicle's battery is discharged,
the engine can be jump-started from another
vehicle or from adonor battery using jumper
cables. For this purpose, the vehicle has ajump-
starting connection point in the engine com-
partment.
When jump-starting, observe the following
points:
RThe battery is not accessible in all vehicles. If
the other vehicle's battery is not accessible,
jump-start the vehicle using adonor battery
or ajump-startingd evice.
RYou may only jump-start the vehicle when the
engine and exhaust system are cold.
RDo not start the engine if the battery is frozen.
Let the battery thaw first.
RJump-starting may only be performed from
batteries with anominal voltage of 12 V.
ROnly use jumper cables that have asufficient
cross-section and insulated terminal clamps.
RIf the battery is fully discharged, attach the
battery of another vehicle for afew minutes
before attempting to start. This charges the
empty battery alittle.
RMake sure that the two vehicles do not touch.
Make sure that:
Rthe jumper cables are not damaged.
Rbare parts of the terminal clamps do not come
into contact with other metal parts while the
jumper cables are connected to the battery.
Rthe jumper cables cannot come into contact
with parts such as the V-belt pulley or the fan.
These parts move when the engine is started
and while it is running.
Jumper cables and further information regarding
jump starting can be obtained at any qualified
specialist workshop.
Before connecting the jumper cables
XApply the parking brake.
XShift the transmission to position P.
XSwitch off all electrical consumers, e.g. audio
equipment, blower.
XTurn key to position 0in the ignition lock and
remove it.
XOpen the hood (Ypage 241).
Connecting the jumper cable
XPush contact protection cover :of the jump-
starting connection point backwards against
the spring force as far as it will go.
The jump-startingc onnection point is visible.
Terminal connecting plan
XRemove the cover from positive terminal =
of the donor vehicle's battery.
XConnect the positive terminal clamp of the
jumper cable to positive terminal =of the
donor vehicle's battery, and then to positive
terminal Aof the jump-startingc onnection
point.
XRun the donor vehicle's engine at idling
speed.
Jump-starting263
Breakdown assistance
Z

Regular wheel and tire checks
GWARNING
Damaged tire scan cause tire inflation pres-
sure loss. As aresult, yo ucould lose control of
your vehicle. There is ariskofa ccident.
Check the tire sregularl yfor signs of damage
and replace any damaged tire simmediately.
Check the wheel sand tire sofyourv ehicl efor
damag eregularly, i.e .atleast every two weeks,
as well as afte rdriving off-road or on rough
roads. Damaged wheel scan cause alos soft ire
pressure. Payp articula rattention to damage
such as:
Rcuts in the tires
Rpunctures
Rtears in the tires
Rbulges on tires
Rdeformation or severe corrosio nonwheels
Regularly check the tire trea ddepth and the
condition of the trea dacross the wholew idth of
the tire (
Ypage 268). If necessary, turn the
front wheel stofullloc kino rder to inspect the
inner sid eofthe tire surface.
All wheel smusth aveav alve cap to protect the
valve against dirt and moisture. Do not install
anything onto the valve othe rthan the standard
valve cap or othe rvalve cap sapproved for your
vehicl ebyd ealers listed on the inside of the
front cover. Do not install any othe rvalve caps
or systems ,e.g. tire pressure monitor systems.
Regularly check the pressure of al lthe tires,
particularly prior to long trips. Adjust the tire
pressure if neces sary (
Ypage 270).
The service life of tire sdepends on various fac-
tors, including the following:
Rdriving style
Rtire pressure
Rmileage
Tire tread
GWARNING
Insufficient tire trea dwillr educe tire traction.
The tire is no longer able to dissipate water.
Thi sm eans that on we troa ds urfaces, the risk
of hydroplaning increases, in particula rwhere
speed is not adapted to suit the driving con-
ditions .There is ariskofa ccident.
If the tire pressure is too hig hortoo low, tires
may exhibi tdifferent level sofwearatd iffer-
ent locations on the tire tread. Thus, you
shoul dregularl ycheck the trea ddepth and
the condition of the trea dacross the entire
width of al ltires.
Minimum tire trea ddepth for:
RSummer tires: âin (3 mm)
RM+S tires: ãin (4 mm)
For safety reasons,r eplace the tiresbefore
the legall yprescribed limit for the minimum
tire trea ddepth is reached.
Marker :shows the location where the bar
indicator (arrow )for trea dwearisi ntegrated
into the tire tread.
Tread wear indicators (TWIs) are required by
law. Six indicators are positioned ove rthe tire
tread. The yare visible once the trea ddepth is
approximately áin (1.6 mm). If this is the case,
the tire is so worn that it mus tbereplaced.
Selecting,m ounting and replacing
tires
ROnly mount tire sand wheel softhe same type
and make.
ROnly us ewheelsw itht ire size sapproved by
Mercedes-Benz.
ROnly mount tire softhe correct size onto the
wheels.
RBrea kinn ew tire satmoderate speeds for the
firs t65m iles (100 km).
268Operation
Wheel sand tires
