change language MERCEDES-BENZ ML-Class 2007 W166 Comand Manual

38 At a glance
Quick reference COMAND
If your vehicle is equipped with the
premium sound system*, the sound
functions* will be available for the
following operating modes:
Radio: FM-, AM- and
Weather (WB) bands
Single CD (CD) and CD changer*
(
CD)
MP3 CD operation
AUX
Satellite radio*The following sound functions* are
available:
Default Settings:
COMAND sets the default settings
(Bass, Treble, Bal/Fad) for the active
source mode.
Standard:
COMAND sets the sound linear for the
center of the vehicle.
Speech:
Playback optimized for language
comprehensibility.
LOGIC7 Surround:
Surround playback.
You can use different sound functions* for
the modes mentioned above.
E.g.:
For radio operation the function
Standard, for CD operation the function
LOGIC7 Surround.
Sound functions*i
LOGIC7 Surround sound offers a sound
quality superior to conventional stereo
sound.
If the radio reception is poor, the
system should be switched back to
standard stereo playback. Switching
back to standard stereo playback may
improve audio quality.

104 Rear Audio/Video*
Rear Seat Entertainment (RSE) operation*
Activating DVD menu
The DVD menu is the menu on the DVD.
The structure of the menu may vary
depending on the DVD and allows certain
settings or actions.
For example, multilingual DVDs allow the
DVD language to be selected in the menu.
Activating the DVD menu is possible by
selecting the
Menu soft key
while the soft keys are displayed
(
page 102) or
after stopping the DVD playback
(
page 103).
Turn the thumb wheel to highlight the
Menu soft key and press to confirm.
The highest level of the DVD menu is
displayed, if available.Selecting an item from the DVD menu
Use h, H, g or G to select a
menu item.
Press E.
The RSE CD/DVD player will perform
the action defined by the menu item se-
lected.Activating Setting menu
Turn the thumb wheel to highlight the
Setting soft key and press to select.
The Setting menu will appear.
Setting options:
4:3, 16:9 or Zoom soft key:
You can change the aspect ratio.
Lang. soft key:
You can change the DVD language.
i
A DVD menu may contain several sub-
menus or include an item for closing
the DVD menu. Submenus may include
a menu item to go up one level in the
menu.

105 Rear Audio/Video*
Rear Seat Entertainment (RSE) operation*
Subtitle soft key:
You can display and switch between
the subtitles.
Angle soft key:
You can change the camera view, if
possible.
Back soft key:
Switches back to the soft key display.
Changing the aspect ratio
You can manually change the aspect ratio
during playback of the DVD.
Turn the thumb wheel to highlight the
top left soft key. Press the thumb
wheel in succession to scroll to each
ratio.Possible aspect ratios are:
4:3, 16:9 and
Zoom.
The soft key indicates the aspect ratio to
which you will change when you press the
thumb wheel.Changing the DVD language
In the Setting menu (page 104), turn
the thumb wheel to highlight the
Lang. soft key and press to select.
The language list is displayed. The con-
tent of the list depends on which langu-
ages the DVD supports.
Use g or G to select a language.
Press E.
The selected language is set.
i
Zoom is useful to watch movies in cine-
matic aspect ratio. You can use this
function to reduce the width of the
black bars at the top and bottom.
i
You can only change the DVD language
if the DVD supports several languages.
Some DVDs allow the language to be
selected exclusively in the menu on the
DVD.

110 Rear Audio/Video*
Rear Seat Entertainment (RSE) operation*
You can use the following functions:
Bright. soft key:
Adjusts the display brightness.
Design soft key:
Sets the display dimming characteris-
tics.
Pic off soft key:
Switches the monitor off and on. This is
also possible by pressing on the
remote (
page 112).
Lang. soft key:
Selects the language for the menu text
displays.
Speaker soft key:
Selects the source of the speakers
(
page 111).Adjusting the display brightness
Turn the thumb wheel to highlight the
Bright. soft key and press to select.
Press H or h direction to adjust the
brightness.
Press E.
The setting is applied. The System
menu will appear.
Setting the display dimming characteri-
stics
Turn the thumb wheel to highlight the
Design soft key and press to select.
Press G or g to select an entry.
Day Mode
The display is continuously set to
daylight design.
Night Mode
The display is continuously set to night-
time design.
Automatic
The display changes depending on the
ambient light sensor in the vehicle.
Press E.
The setting is applied. The System
menu will appear.
Switching the monitor on and off
Turn the thumb wheel to highlight the
Pic off soft key and press to select.
The monitor is switched off.
Press the thumb wheel again.
The monitor is switched on again.

221 System settings
System settings
Push the joystick to g or G to
select the desired entry.
Daylight Savings Time:
Changes from summer to winter time.
Standard Time:
Changes from winter to summer time.
Press E.
The System settings menu will appear.
The setting is saved.The language affects the menu text
displays and the voice output during route
guidance.
In the System settings menu
(
page 220), press the Lang. soft
key.
The languages list will appear.
OptionSymbol
Time change selected_
Time change not
selected-
Selecting the language

236 Index
Repeat track . . . . . . . . . . . . . . . . . . . 68
switching to CD operation. . . . . . . . . 61
Track mix . . . . . . . . . . . . . . . . . . . . . 68
track select . . . . . . . . . . . . . . . . . . . . 64
CD changer*
accessing . . . . . . . . . . . . . . . . . . . . . 56
CD mix . . . . . . . . . . . . . . . . . . . . . . . 69
ejecting CDs . . . . . . . . . . . . . . . . . . . 59
loading CDs . . . . . . . . . . . . . . . . . . . . 56
playback options . . . . . . . . . . . . . . . . 67
Repeat CD . . . . . . . . . . . . . . . . . . . . . 69
retracting . . . . . . . . . . . . . . . . . . . . . 56
selecting a CD . . . . . . . . . . . . . . . . . . 63
CD/DVD
general information . . . . . . . . . . . . . . 87
Changing
aspect ratio . . . . . . . . . . . . . . . . . . . 105
camera view . . . . . . . . . . . . . . . . . . 106
DVD language . . . . . . . . . . . . . . . . . 105
map display . . . . . . . . . . . . . . . . . . . 177
CODE INCORRECT . . . . . . . . . . . . . . 134
COMAND
switching off . . . . . . . . . . . . . . . . . . . 34
switching on . . . . . . . . . . . . . . . . . . . 34Compass function . . . . . . . . . . . . . . 170
CONNECTING . . . . . . . . . . . . . 217, 218
Connecting
external video sources (rear seat
entertainment*) . . . . . . . . . . . . . . . . 95
headsets (rear audio operation*) . . . 84
headsets (rear seat entertainment*). 92
CONTINUE ROUTE GUIDANCE. . . . . 152
Current vehicle location . . . . . . . . . 175
D
Destination input . . . . . . . . . . . . . . . 156
Destination memory . . . . . . . . . . . . 198
Dialing
subsequent dialing . . . . . . . . . . . . . 138
Displaying
full screen . . . . . . . . . . . . . . . 103, 109
phone book . . . . . . . . . . . . . . . . . . . 144
route list . . . . . . . . . . . . . . . . . . . . . 185
soft keys during playback . . . 102, 108
the compass screen . . . . . . . . . . . . 170
Displaying and switching
between subtitles . . . . . . . . . . . . . . 106DRIVE EMPTY (rear seat
entertainment*) . . . . . . . . . . . . . . . . . 93
DVD
playback requirements (rear seat
entertainment*) . . . . . . . . . . . . . . . . 89
E
Ejecting
CD
at the CD changer* . . . . . . . . . . . . 59
at the COMAND . . . . . . . . . . . . . . . 53
at the RSE CD/DVD player . . . . . . 94
MP3 CD
at the CD changer* . . . . . . . . . . . . 59
at the COMAND . . . . . . . . . . . . . . . 74
navigation DVD
at the COMAND . . . . . . . . . . . . . . 149
Emergency call “911” . . . . . . . . . . . 131
Emergency call system . . . . . . . . . . 217
Ending
call. . . . . . . . . . . . . . . . . . . . . 136, 138
ENTER UNLOCK CODE . . . . . . . . . . . 128
