tow bar MERCEDES-BENZ ML320CDI 2007 W163 Comand Manual

519 Practical hints
Towing the vehicle
Warning!
G
If circumstances require towing the vehicle
with all wheels on the ground, always tow
with a tow bar if:

the engine will not run


there is a malfunction in the power
supply or in the vehicle’s electrical sys-
tem
Prior to towing the vehicle with all wheels on
the ground, make sure the starter switch is
in position2 (
page 40).
Warning!
G
With the engine not running, there is no
power assistance for the brake and steering
systems. In this case, it is important to keep
in mind that a considerably higher degree of
effort is necessary to brake and steer the
vehicle. Adapt your driving accordingly.
i
To signal turns while being towed with
hazard warning flasher in use, set the starter
switch to position2 and activate combination
switch for left or right turn signal in usual manner
– only the selected turn signal will operate.
Upon canceling the turn signal, the hazard
warning flasher will operate again.
i
If the battery is disconnected or discharged,
the automatic transmission will remain locked in
positionP and the SmartKey will not turn in the
starter switch. For more information, see “Bat-
tery” (page 507) and “Jump starting”
(
page 515).
!
When towing the vehicle with all wheels on
the ground, note the following:
With the automatic central locking activated and
the ignition in position2 (
page 40), the vehicle
doors lock if the left front wheel is turning at a
speed of approximately 9 mph (15 km/h) or
above.
To prevent the vehicle doors from locking,
deactivate the automatic central locking
(
page 126).
Towing of the vehicle should only be done using
the towing eye bolt. Never attach tow cable, tow
rope or tow rod to vehicle chassis, frame or sus-
pension parts.

554 IndexAutomatic climate control (3-zone)* 220
Air conditioning, Cooling 230, 231
Air distribution, Front 226
Air distribution, Rear 234
Air recirculation mode 228
Air vents, Front 226
Air volume 227
Control panel, Front 222
Control panel, Rear 232
Deactivating system 224
Defogging 227
Defrosting 227
Maximum cooling, MAX COOL 228
Rear passenger compartment 232
Rear window defroster 205
Residual engine heat (REST) 232
Using driver-side settings for
all temperature zones 231
Automatic headlamp mode 137
Automatic lighting control, Interior
lighting 143
Automatic locking when driving 126
Automatic shift program
(ML 63 AMG only) 196Automatic transmission 54
Accelerator position 191
Automatic shift program
(ML 63 AMG only) 196
Emergency operation
(Limp-Home Mode) 198
Gear ranges 193
Gear selector lever 54, 185
Gear shifting malfunctions 198
Hill start assist system 192
Kickdown 191
Kickdown, manual shift program
(ML 63 AMG only) 198
Manual shift progam
(ML 63 AMG only) 196
Program mode selector switch
(ML 63 AMG only) 195
Shift program (ML 63 AMG only) 195
Shifting procedure 188
Starting the engine 54
Steering wheel gearshift control 194
Towing a trailer 192
Transmission fluid level 362
Transmission positions 189
Automatic Transmission Fluid see ATFB
Backrest
Seat 44
Seat, Lumbar support 130
Seat, Multicontour* 130
Backup lamps
Messages in the
multifunction display 458
Replacing bulbs 490
Bar 395
BAS 97
Lamps in instrument cluster 414
Messages in the
multifunction display 430
Basic carrier bars* 281
Batteries, SmartKey
Check lamp 108, 112
Checking battery condition 111
Messages in the
multifunction display 446
Replacing 480
Battery, Vehicle 507
Charging 514
Disconnecting and connecting 509
Jump starting 515
Removing and installing 509
