368 OperationTires and wheelsVehicle maximum load on the tire
Load on an individual tire that is
determined by distributing to each axle its
share of the maximum loaded vehicle
weight and dividing it by two.Rotating tires
Tire rotation can be performed on vehicles
with tires of the same dimension all
around. If your vehicle is equipped with
tires of the same dimension all around,
tires can be rotated, observing a a
front-to-rear rotation pattern that will
maintain the intended rotation (spinning)
direction of the tire (
page 338).In some cases, such as when your vehicle
is equipped with mixed-size tires (different
tire dimension front vs. rear), tire rotation
is not possible.
If applicable to your vehicle’s tire configu-
ration, tires can be rotated according to
the tire manufacturer’s recommended in-
tervals in the tire manufacturer’s warranty
pamphlet located in your vehicle literature
portfolio. If none is available, tires should
be rotated every 3 000 to 6 000 miles
(5 000 to 10 000 km), or sooner if neces-
sary, according to the degree of tire wear.
The same rotation (spinning) direction
must be maintained (
page 338).
Rotate tires before the characteristic tire
wear pattern becomes visible (shoulder
wear on front tires and tread center wear
on rear tires).
Thoroughly clean the mounting face of
wheels and brake disks, i.e. the inner side
of the wheels/tires, during each rotation.
Check for and ensure proper tire inflation
pressure.For information on wheel change, see the
“Practical hints” section (
page 430) and
(
page 456).
Warning!
G
Rotate front and rear wheels only if they are
of the same dimension.
If your vehicle is equipped with mixed-size
tires (different tire dimensions front vs.
rear), tire rotation is not possible.
Warning!
G
Have the tightening torque checked after
changing a wheel. Wheels could become
loose if not tightened with a torque of
110 lb-ft (150 Nm).
Only use genuine Mercedes-Benz wheel
bolts specified for your vehicle’s rims.

461 Practical hints
Flat tire
1-5Wheel bolts
Tighten the five wheel bolts evenly, fol-
lowing the diagonal sequence illustrat-
ed (1 to 5), until all bolts are tight.
Observe a tightening torque of
110 lb-ft (150 Nm).

Store all vehicle tools back in the cargo
compartment.

Store the damaged road wheel in the
cargo compartment.
Warning!
G
Have the tightening torque checked after
changing a wheel. The wheels could come
loose if they are not tightened to a torque of
110 lb-ft (150 Nm).
iThe damaged road wheel cannot be
stored in the wheel well under the car-
go compartment floor, but should be
transported in the cargo compartment
wrapped in a protective cover supplied
with the vehicle.

505 Technical terms
Production options weight
(
page 366)
PSI
(P
ounds per s
quare i
nch) (
page 366)
Recommended tire inflation pressure
(
page 366)
REST
(Residual engine heat utilization)
Feature that uses the engine heat
stored in the coolant to heat the vehi-
cle interior for a short time after the en-
gine has been turned off.
Restraint systems
Seat belts, belt tensioner, air bags and
child restraints, lower anchors and
tethers for children (LATCH). As inde-
pendent systems, their protective func-
tions complement one another.
Rim
(page 367)RON
(R
esearch O
ctane N
umber)
The Research Octane Number for gaso-
line as determined by a standardized
method. It is an indication of a gaso-
line’s ability to resist undesired detona-
tion (knocking). The average of both
the ->MON (Motor Octane Number)
and RON (Research Octane Number) is
posted at the pump, also known as
ANTI-KNOCK INDEX.
Sidewall
(
page 367)
SRS
(Supplemental R
estraint S
ystem)
Air bags, air bag control unit (with
crash sensor), emergency tensioning
device. Though independent systems,
they are closely interfaced to provide
effective occupant protection.Tele Aid* System
(T
elematic A
larm I
dentification on
D
emand)
The Tele Aid system consists of three
types of response: automatic and man-
ual emergency, Roadside Assistance
and information. Tele Aid is initially
activated by completing a subscriber
agreement and placing an acquain-
tance call.
The Tele Aid system is operational pro-
vided that the vehicle’s battery is
charged, properly connected, not dam-
aged and cellular and GPS coverage is
available.
Telematics*
A combination of the terms “telecom-
munications” and “informatics”.
Tightening torque
Force times lever arm (e.g. a lug
wrench) with which threaded fasteners
such as wheel bolts are tightened.

531 Index
Tar stains 375
Technical data 495
Brake fluid 495
Coolants 497
Electrical system 490
Engine 486
Engine oil 495
Engine oil additives 495
Fuel requirements 496
Gasoline additives 497
Main dimensions 491
Premium unleaded gasoline 496
Rims and tires 487
Weights 492
Windshield washer and
headlamp cleaning* system 500Tele Aid* 280
Call priority 287
Emergency calls 282
Information 286
Initiating an emergency call
manually 284
Messages in display 425, 426
Remote door unlock 288
Roadside assistance 284
Stolen vehicle recovery services 289
System self-check 282
Tele Aid* System 505
Telematics* 506
Telephone* 279
Answering a call 179
Dialing a number from
the phone book 180
Ending a call 180
Loading phone book* 180
Operating 178
Redialing 181Telephones and two-way radios 320
Telescoping rod 268
Temperature
Setting interior
temperature 207, 221
Tires 346
The coolant level is correct if
the level 333
Tie-down rings
(Cargo compartment) 260
Tightening torque 506
Tightening torque (Wheel bolts) 461
Tilt
Head restraint 41
Tilt/sliding sunroof*
Closing 235
Closing with KEYLESS-GO* 234
Opening 235
Synchronizing 237
